BLK BOX 21-0174 User manual

OWNERS MANUAL & QUICK START GUIDE
MED BALL STORAGE
NOTE : PLEASE READ ALL THE INSTRUCTIONS
CAREFULLY BEFORE ASSEMBLING THIS PRODUCT.
BLK BOX
PRODUCT SPECIFICATION
PRODUCT WEIGHT
DIMENSIONS
-12kg
1380mm x 356mm x 200mm
-
21-0174
#MADEINBELFAST

WARNING
xx
Nm
SPIRIT LEVEL 10MM MASONRY
DRILL BIT
TOOLS REQUIRED
13MM SPANNER
HAMMER
HAMMER DRILL VACUUM
PARTS & ATTACHMENTS
SERIOUS OR FATAL INJURIES MAY OCCUR FROM INCORRECTLY ASSEMBLED EQUIPMENT. ALWAYS ENSURE
BOLTS ARE TIGHTENED CORRECTLY AND ALL PARTS ARE LEVEL AND PLUMB. TO FURTHER REDUCE RISK OF
INJURIES OR DEATH PLEASE USE OUR SUGGESTED TOOLS AND PERSONAL PROTECTIVE EQUIPMENT (PPE).
WE SUGGEST THAT A MINIMUM OF THREE PEOPLE ARE INVOLVED IN THE ASSEMBLY OF THIS PRODUCT.
EACH PERSON SHOULD BE EQUIPPED WITH SAFETY GLASSES, STEEL TOE CAP BOOTS AND EAR PLUGS.
THIS SYMBOL IS AN INDICATION OF THE RECOMMENDED TORQUE EACH
BOLT SHOULD BE TIGHTENED TO. THIS VALUE WILL BE DEPENDENT ON
THE BOLT TYPE. PLEASE HAND TIGHTEN ALL BOLTS UNTIL YOU SEE THIS SYMBOL.
#MADEINBELFAST
No. Name SKU QTY
1 MED BALL STORAGE 21-0237 1
2 M10X80 SLEEVE ANCHOR 10-0031 4
3 M10 FLAT WASHER 10-0019 4
1
2
3

#MADEINBELFAST
INSTALLATION
1
MEASURE, MARK AND DRILL HOLES USING GUIDES PROVIDED.
-DRILL 10MM HOLE INTO THE WALL, 90MM DEEP
-VACUUM OUT THE DUST.
DRILL HOLE VACUUM
90MM
SLEEVE ANCHOR BOLT FITTING
1050mm
CENTER LINE
1268mm

#MADEINBELFAST#MADEINBELFAST
2
30
Nm
x4
ATTACH MED BALL STORAGE (21-0237) TO THE WALL USING SLEEVE ANCHORS (10-0031) AS
SHOWN.
TIGHTEN ALL BOLTS TO SPECIFIED TORQUE.
-HAMMER SLEEVE ANCHOR
INTO THE HOLE.
-TIGHTEN SLEEVE ANCHOR
TO SPECIFIED TORQUE
USING 13MM SPANNER.
30
Nm
HAMMER IN
BOLT TIGHTEN
SLEEVE ANCHOR BOLT FITTING

1:1 SCALE FASTENERS
FOR TERMS AND CONDITIONS VISIT OUR WEBSITE AT
www.blkboxfitness.com/pages/terms-conditions
GET IN TOUCH
TEL: [phone]
EMAIL: [e-mail]
DISCOVER MORE AT:
www.blkboxfitness.com
M10x80 SLEEVE ANCHOR
10-0031
M10 FLAT WASHER
10-0019
