BLK BOX HARLAND SQUAT STAND User manual

OWNERS MANUAL & QUICK START GUIDE
HARLAND SQUAT STAND
NOTE : PLEASE READ ALL THE INSTRUCTIONS
CAREFULLY BEFORE ASSEMBLING THIS PRODUCT.
BLK BOX
21-0704-0A
#MADEINBELFAST
1700mm x 650mm x 1820mm
2700mm x 1850mm x 2684mm
65kg
PRODUCT SPECIFICATION
PRODUCT WEIGHT
MAX USER WEIGHT
MAX USER
MAX TRAINING WEIGHT
DIMENSIONS
SAFE WORKING ZONE
-n/a
350kg
-
-
-
-
1
-

WARNING
TOOLS REQUIRED
2x 17MM SPANNER
#MADEINBELFAST
SERIOUS OR FATAL INJURIES MAY OCCUR FROM INCORRECTLY ASSEMBLED EQUIPMENT. ALWAYS ENSURE
BOLTS ARE TIGHTENED CORRECTLY AND ALL PARTS ARE LEVEL AND PLUMB. TO FURTHER REDUCE RISK OF
INJURIES OR DEATH PLEASE USE OUR SUGGESTED TOOLS AND PERSONAL PROTECTIVE EQUIPMENT (PPE).
WE SUGGEST THAT A MINIMUM OF THREE PEOPLE ARE INVOLVED IN THE ASSEMBLY OF THIS PRODUCT.
EACH PERSON SHOULD BE EQUIPPED WITH SAFETY GLASSES, STEEL TOE CAP BOOTS AND EAR PLUGS.
PLEASE BE AWARE OF THIS SYMBOL AS AN INDICATION TO CHECK THAT A PART IS LEVEL
OR PLUMB.
THIS SYMBOL IS AN INDICATION OF THE RECOMMENDED TORQUE EACH
BOLT SHOULD BE TIGHTENED TO. THIS VALUE WILL BE DEPENDENT ON
THE BOLT TYPE. PLEASE HAND TIGHTEN ALL BOLTS UNTIL YOU SEE THIS SYMBOL. xx
Nm

PARTS & ATTACHMENTS
#MADEINBELFAST
1
2
3
4
5
6
7

ASSEMBLY
1
PLACE 1QTY OF THE HARLAD SQUAT STAND UPRIGHT (21-0703-0A) INTO 1QTY OF THE
HARLAND SQUAT STAND BASE (21-0703-0A) -ENSURING THE TABS OF THE UPRIGHT
ALIGN WITH THE HOLES IN THE BASE. PLEASE ALSO ENSURE THE BLK BOX LOGO IF FAC-
ING OUTWARDS FROM THE RACK.
#MADEINBELFAST

#MADEINBELFAST
FASTEN THE UPRIGHT IN PLACE BY PLACING 2QTY GOLIATH SIDE PLATES (20-0472-0A) EITHER SIDE OF THE PLATE,
AND FASTENING USING 4QTY M10X90 HEX HEAD BOLT (10-0008), 8QTY M10 WASHER (10-0019) AND 4QTY M10
NYLOC NUT (10-0024).
10-0008 x 4
10-0019 x 4
10-0019 x 4
10-0024 x 4 30
Nm

#MADEINBELFAST

#MADEINBELFAST
2
ONCE COMPLETED. REPEAT STEP USING OTHER UPRIGHT AND BASE. ONCE AGAIN ENSURE
TABS ALIGN WITH SLOTS, AND THE BLK BOX LOGO FACES OUTWARDS FROM THE RACK.
10-0008 x 4
10-0019 x 4
10-0019 x 4
10-0024 x 4
30
Nm

#MADEINBELFAST

#MADEINBELFAST
3
THE HARLAND SQUAT STAND HAS NOW BEEN ASSEMBLED

#MADEINBELFAST
FOR TERMS AND CONDITIONS VISIT OUR WEBSITE AT
www.blkboxfitness.com/pages/terms-conditions
GET IN TOUCH
TEL: [phone]
EMAIL: [e-mail]
DISCOVER MORE AT:
www.blkboxfitness.com
1:1 SCALE FASTENERS
M10 x 90 HEX HEAD BOLT
10-0008
M10 WASHER
10-0019
M10 NYLOC NUT
10-0024
