BLK BOX GOLIATH 21-0816 User manual

OWNERS MANUAL & QUICK START GUIDE
GOLIATH WALL MOUNTED FUNCTIONAL RIG
4 BAY
NOTE : PLEASE READ ALL THE INSTRUCTIONS
CAREFULLY BEFORE ASSEMBLING THIS PRODUCT.
BLK BOX
PRODUCT SPECIFICATION
21-0816
#MADEINBELFAST
PRODUCT WEIGHT
MAX USER WEIGHT
MAX USER
MAX TRAINING WEIGHT
DIMENSIONS
-
260kg
125kg
300kg
10130mm x 2220mm x 3600mm
-
-
-
4
-

WARNING
SPIRIT LEVEL
10MM MASONRY
DRILL BIT
TOOLS REQUIRED
17MM SPANNER X2
13MM SPANNER
HAMMER
HAMMER DRILL VACUUM STEP LADDER
PARTS & ATTACHMENTS
No. Name SKU QTY
1 2.4 UPRIGHT DNA60 WITH FEET 21-0036 4
2 3.6 UPRIGHT DNA60 WITH FEET 21-0036 4
3 1.2 SINGLE BAR WM DNA60 21-0126 4
4 1.2 SINGLE BAR CM DNA60 21-0015 4
5 1.8 SINGLE BAR CM DNA60 21-0028 3
6 1.2 BOX WM DNA60 21-0434 4
7 1.2 GOLIATH ARM 21-0235 4
8 M10X80 SLEEVE ANCHOR 10-0031 48
9 M10X90 BOLT 10-0008 51
10 M10 NYLOCK NUT 10-0024 51
11 M10 FLAT WASHER 10-0019 150
12 J-HOOKS PAIR 16-0001 4
SERIOUS OR FATAL INJURIES MAY OCCUR FROM INCORRECTLY ASSEMBLED EQUIPMENT. ALWAYS ENSURE
BOLTS ARE TIGHTENED CORRECTLY AND ALL PARTS ARE LEVEL AND PLUMB. TO FURTHER REDUCE RISK OF
INJURIES OR DEATH PLEASE USE OUR SUGGESTED TOOLS AND PERSONAL PROTECTIVE EQUIPMENT (PPE).
WE SUGGEST THAT A MINIMUM OF THREE PEOPLE ARE INVOLVED IN THE ASSEMBLY OF THIS PRODUCT.
EACH PERSON SHOULD BE EQUIPPED WITH SAFETY GLASSES, STEEL TOE CAP BOOTS AND EAR PLUGS.
PLEASE BE AWARE OF THIS SYMBOL AS AN INDICATION TO CHECK THAT A PART IS LEVEL
OR PLUMB.
THIS SYMBOL IS AN INDICATION OF THE RECOMMENDED TORQUE EACH
BOLT SHOULD BE TIGHTENED TO. THIS VALUE WILL BE DEPENDENT ON
THE BOLT TYPE. PLEASE HAND TIGHTEN ALL BOLTS UNTIL YOU SEE THIS SYMBOL.
#MADEINBELFAST
1
3
4
5
8
9
10
11
12
xx
Nm
2
6
7

ASSEMBLY
1
BOLT 1QTY 1.2 SINGLE BAR CM (21.0015) BETWEEN 1QTY 2.4 UPRIGHT (21-0036), AND 1QTY
3.6 UPRIGHT (21-0038) AND BOLT 1QTY 1.2 SINGLE BAR WM (21-0126) WITH BOLTS AS-
SEMBLY AS SHOWN. ENSUE LOGO ON UPRIGHTS ARE FACING OUTWARD AND ALL BOLTS
FACING INWARDS. BOLT 1QTY 1.2 BOX WM (21-0434) AND 1 QTY GOLIATH ARM (21-0235)
TO 1QTY 3.6 UPRIGHT (21-0038). REPEAT FOR EACH BAY.
#MADEINBELFAST
x
1
0
10.0008
10.0019 x2
10.0024

#MADEINBELFAST
POSITION 1 BAY 1740MM FROM NEXT BAY. BOLT 1QTY 1.8 SINGLE BAR (21-0028) TO THE SIDE OF THE
3.6 UPRIGHT (21-0038) AND 2.4 UPRIGHT (21-0036)REUSING BOLT ASSEMBLY AS SHOWN. ENSURE
THAT BOLTS ARE FACING INWARD.
2
x
6
10.0008
10.0019 x2
10.0024

30
Nm
DRILL HOLE VACUUM
90MM
3
TIGHTEN ALL BOLT ASSEMBLIES WITHIN THE ELLIPSES TO THE 30Nm TORQUE . ENSURE UPRIGHTS
ARE PLUMB. DRILL AND SECURE UPRIGHTS, 1.2 BOX WM (21-0434) AND 1.2 `SINGLE BAR WM (21-
0126) AS SHOWN IN GUIDE.
HAMMER IN
BOLT
TIGHTEN
-DRILL 10MM HOLE, 90MM DEEP
USING PLATE AS A GUIDE.
-VACUUM OUT THE DUST.
-HAMMER SLEEVE ANCHOR INTO
THE HOLE.
-TIGHTEN SLEEVE ANCHOR TO
SPECIFIED TORQUE
USING 13MM SPANNER.
SLEEVE ANCHOR BOLT FITTING
#MADEINBELFAST
x
1
2
x
1
6
30
Nm
x
1
2
x
1
6
10.0031
10.0019
10.0031
10.0019

#MADEINBELFAST
1:1 SCALE FASTENERS
FOR TERMS AND CONDITIONS VISIT OUR WEBSITE AT
www.blkboxfitness.com/pages/terms-conditions
GET IN TOUCH
TEL: [phone]
EMAIL: [e-mail]
DISCOVER MORE AT:
www.blkboxfitness.com
NYLOCK NUT
10-0024
M10 FLAT WASHER
10-0019
M10x80 SLEEVE ANCHOR
10-0031
M10x90 BOLT
10-0008
4
REPEAT FIRST THREE STEPS FOR ADDITIONAL BAYS.
