Intrusion Alarm Systems | B930 ATM Style Alphanumeric Keypad (SDI2)
B930 ATM Style Alphanumeric Keypad
(SDI2)
www.boschsecurity.com
u5-line ATM style LCD display with up to 32 character
point, user, and area names
uSimple menu-style user interface with dedicated
function buttons for common commands
uProgrammable keypad shortcuts and situation
sensitive on-screen help makes system operation
simple and easy
uHighly visible on (arm)/alarm, ready to turn on
(arm), power and gas alarm indicators
uSimple installation with self-locking base and
chassis design, plus built-in bubble level
The B930 ATM Style Alphanumeric Keypad (SDI2) is a
SDI2 bus compatible device. Each keypad has user
adjustable options such as volume and display
brightness. The B930 shows five-line system messages
for all areas.
System overview
• For commercial use, install the keypad in building
entrances and areas with unrestricted access.
Mounting a keypad near exterior doors in hotel or
business lobbies allows people to identify the type
and location of the emergency.
• For residential use, install the keypad near the front
and rear entrances to the home. Install additional
keypads in a kitchen or in a bedroom.
• Use multiple keypads in a large building with many
separate areas of security. Program multiple keypads
to control multiple areas.
• Audible tones from the keypad sounder alert
personnel to fire events and assist fire fighters in
locating the keypad.
Functions
LCD Display
The keypad uses words, numbers, and symbols to
show the status of the security system. When several
events occur, the keypad shows each event in order of
priority. The display shows five lines, 21 characters
per line.
Keys
Each keypad has 10 numeric keys, 5 navigation keys,
and eight softkeys. When pressed, keys enable keypad
backlighting and emit a muted beep. Use the eight
softkeys to select a menu and associated functions.
Audible tones
The keypad has a built-in speaker that produces
several distinct warning tones. The tones are
differentiated so that the user can recognize an event
simply by hearing its associated tone. The keypad
backlight illuminates when it emits an audible tone.
Users can use a passcode to silence the tone.

Status indicators
The status indicators on the keypad provide a quick
visual reference for system status.
The indicator lights when the system is ready to turn on (arm).
The indicator lights when the system is on (armed).
The indicator lights when there is a trouble condition.
The indicator lights when dangerous gases are present including
carbon monoxide (NFPA 720).
The indicator lights when the system has power.
Audible tones
The keypad has a built-in speaker that produces
several distinct warning tones. The keypad backlight
illuminates when it emits an audible tone. You can use
a passcode to silence the tone.
The tones include:
• Fire signal. When an area is in fire alarm, the keypad
emits a pulsed, high-pitched bell tone.
• Gas signal. When a gas point activates, the keypad
emits a unique high pitched tone.
• User alarm. When a user alarm (such as panic and
medical alarms) occurs, the tone sounds for the
programmed amount of time.
• Burglary signal. When an area is in alarm, the keypad
emits a steady, high pitched bell tone.
• Entrance warning. The keypad emits an intermittent
beep tone during entry delay periods to remind the
user to disarm the area.
• Exit warning. The keypad emits an intermittent beep
tone during exit delay.
• Invalid button buzz. When an invalid button, or
sequence of buttons, is pressed, the keypad emits a
flat buzz tone.
• Keypad encoding tone. The keypad emits a muted
beep tone as each button is pressed to indicate that
the entry was accepted.
• Trouble buzzer. When a trouble event occurs, such as
a service alert, the keypad emits a two-tone warble
until you enter a programmed passcode with the
appropriate authority.
• Watch tone. A single clean tweedle tone alerts the
user anytime a watch point is faulted.
Certifications and approvals
Region Certification
USA UL 365 - Police Station Connected Burglar Alarm Units
and Systems
UL 609 - Local Burglar Alarm Units and Systems
UL 636 - Holdup Alarm Units and Systems
UL 985 - Household Fire Warning System Units
UL 1023 - Household Burglar Alarm System Units
UL 1076 - Proprietary Burglar Alarm Units and Systems
UL 1610 - Central Station Burglar Alarm Units
CSFM - California Office of The State Fire Marshall
FCC Part 15 Class B
Canada CAN/ULC S303 - Local Burglar Alarm Units and Systems
CAN/ULC S304 - Signal Receiving Centre and Premise
CAN/ULC S545 - Residential Fire Warning System Control
ICES-003 - Information Technology Equipment (ITE)
ULC-ORD C1023 - Household Burglar Alarm System Units
ULC-ORD C1076 - Proprietary Burglar Alarm Units and
System
Region Certification
USA UL NBSX.S1871, NBSX7.S1871,
UTOU.S1871, UTOU7.S1871,
AMCX.S1871, AMCX7.S1871,
AMTB.S1871, ANET.S1871,
AOTX.S1871, AOTX7.S1871,
APAW.S1871, APAW7.S1871,
APOU.S1871, APOU7.S1871 [UL &
cUL]
CSFM see our website
Installation/configuration notes
Mounting considerations
Mount in indoor dry locations.
Power supply
A compatible control panel supplies the power and
data requirements to the keypad through a four-wire
connection.
Enclosure and wiring
The sliding self-locking enclosure has an integrated
bubble level and custom gap‑free, lift‑gate style
terminal blocks to make installation easier.
Parts included
Quant. Component
1Keypad
1 Hardware pack
1 Installation Guide
1 User Quick Reference Guide
Technical specifications
Properties
Dimensions 6.2 in x 5.5 in x 1 in
(158 mm x 140 mm x 26 mm)
Weight 14.1 oz (0.40 kg)
Material Acrylonitrile butadiene styrene (ABS)
Poly(methyl methacrylate) (PMMA)
2 | B930 ATM Style Alphanumeric Keypad (SDI2)

Display window 5 line display
21 characters per line
Indicators Illuminated keys
Status indicators
Warning and indicating tones
Environmental considerations
Relative humidity 5% to 93% at +32°C (+90°F) non-
condensing
Temperature (operating) 0°C to +50°C (+32°F to +122°F)
Power requirements
Current 35 mA in standby mode
80 mA in alarm mode
Voltage (input) 12 VDC nominal
Wiring
Terminal wires 12 AWG to 22 AWG (2 mm to 0.65
mm) wire
Compatibility
Control panels B9512G/B9512G-E
B8512G/B8512G-E
B5512/B5512E
B4512/B4512E
B3512/B3512E
D9412GV4/D7412GV4 v2.00 and
higher
Trademarks
All hardware and software product names used in this
document are likely to be registered trademarks and
must be treated accordingly.
Ordering information
B930 ATM Style Alphanumeric Keypad (SDI2)
Five-line ATM style alphanumeric keypad
Order number B930
Accessories
B56 Keypad Surface Mount Box
Surface mount box for mounting a keypad to concrete
or block.
Order number B56
B96 Keypad Trim Bezel
Cover the wall footprint of previous keypads when
replacing them with the new, slim design of B Series
keypads. The white trim bezel is 8.6 in x 6.3 in x 0.12
in (22 mm x 16 mm x 3 mm).
Order number B96
