BWT Haier HBP-V40 User manual

产品说明书
前置过滤器
HB Filter V40
海尔牌HBP-V40型前置过滤器
Haier HBP-V40 POE Filter
请妥善保存安装和操作说明书，避免进行错误操作。在对设备进行任何操作之前，请仔细阅读安装和操作说
明并遵循其指导。内容仅供参考，不具有法律效力。除此之外，我们的一般贸易条款和条件也适用此声明。
内容可能有变动！恕不另行通知。

2
2
2
2
2
3
3
3
3
4
5
6
7
目 录
部件组成
应用
功能
安装条件
安装
开始使用
操作
维护
保修期
规格参数
故障解决
产品保养及维修记录
产品保修卡

1

HBP-V40 由以下部件组成:
1.顶部铜件
2.密封连接配件
3.透明滤杯
该过滤器用于过滤饮用水和生活用水。它能保护
管道及其相连的设施，防止因铁锈颗粒、碎片、沙
子、纤维等杂质造成的故障和污染。过滤器不能用于
经化学处理的循环水、工艺水和连续用于冷却系统的
冷却水。
该过滤器不适用于油、油脂、溶剂、肥皂水和其
他润滑介质，也不适用于分离水溶性物质。
部件组成
应用
功能
2
遵守所有当地安装规则、一般指南和技术规范。
必须连接至污水系统（排水），最小管径
DN40。
注意：安装现场必须防冻，必须保证过滤器免
受溶剂蒸汽、燃油、垃圾、各种化学品、紫外线辐
射和40℃以上热源的影响。
注意：避免在塑料零件表面使用油、油脂、溶
剂和酸性或碱性清洁剂。在猛烈碰撞或撞击后，例
如，使用不合适的工具，或落在坚硬地面上等（以
防突然爆裂），即使没有可见的损坏，塑料零件也
必须更换，避免极端的压力冲击。
4.冲洗水连接软管
5.反冲洗旋钮
安装条件
根据过滤器的标称宽度，在相同尺寸的冷水管
道中安装过滤器，并安装在需要保护的设备之前。
在过滤器前后安装截止阀。
将连接件（2）与管道相连，并在水平冷水管
道中沿流向（见流向箭头）安装过滤器（见安装草
图）。
使用软管将冲洗水接头连接至污水管道或提供
一个废水桶(容量约10升)。
请注意：根据德国工业标准EN 1717，冲洗水
管必须安装在距离最高废水水位以下至少20毫米
（以便顺利排水）。
安装
未经处理的水通过原水进水口流入过滤器，然后
从内部通过过滤元件后流到净水出口。大于90微米
的杂质被截留在滤芯内部。滤芯需要通过定期反冲
洗进行清洁。进行反冲洗时，废水口可以通过旋钮
打开，同时反冲洗元件也被打开。滤芯内部的杂质
通过抽吸被清除，并冲洗到废水口排走。

应用
3
检查过滤器和冲洗水管是否安装正确。
截止阀还不能打开。检查透明滤杯(3)是否正确安
装，然后顺时针转动旋钮(5)。
缓慢打开过滤器前后的截止阀，并对（过滤器
后部）最靠近过滤器的排气管进行排气。
如果冲洗水管没有连接到排水口，在反冲洗前提供
一个废水桶。
逆时针打开旋钮，直到听到水流出来，然后再
次关闭。检查过滤器是否密封良好。
如果在保修期内出现故障，请联系我们的客户
服务部门，并说明过滤器的型号和生产编号（参见
参数表或铭牌）。
任何保修工作只能由我公司专业的客户服务部
门执行。
不符合安装条件或未经授权的操作人员进行维
修/保养，将使保修失效。
开始使用
操作
保修期
建议每月进行一次反冲洗，以防止污垢颗粒沉
积在滤芯上。（如果水质较差反冲洗频率也应该相
应增加）
在开始反冲洗之前，如果冲洗水管没有连接到
排水口，则需要提供一个废水桶收集废水。
反冲洗
逆时针打开反冲洗旋钮(5)，直到听到水流出
来，然后再次关闭。检查过滤器是否密封良好。
塑料零件只能用浸湿的软布清洗。请勿使用任
何溶剂或清洁剂或酸性清洁剂。
所有技术设备都需要定期维护。根据德国工业
标准1988，维护必须由专业技术人员进行，专业
人员也会定期更换易磨损的零件。因此，我们建议
签订维护合同。
非技术设备部分必须每年维护一次或两次。维
护应由安装方或制造商来执行。
维护

注：为尽可能满足用户需求，本公司产品会不断优化和改进，本说明书的内容及产品参数
如有改动，恕不另行通知。
规格参数
4
毛重 奥地利
海尔牌HBP-V40型前置过滤器
适用水源
适用水压
适用水温
适用环境温度
净重
毛重
HBP-V40 5-30℃
5-40℃
市政自来水
0.2-1.0MPa
200m3
4.0m /h
3
产品名称
产品型号
额定净水流量
额定总净水量
产品尺寸(mm)
包装尺寸(mm)
原产地
连接管径
执行标准
卫生批准文号
出水水质
实际生产企业
实际生产企业地址
在华责任单位
软管连接尺寸 E
旋转螺母螺纹 G
管道中心距离墙面最小距离
未装配总长度 A 100mm
未装配总长度 B
总高度 C
管道中心距离地面最小距离 D
184mm
278mm
400mm
14mm
G 1 1/4"
50mm
在华责任单位地址
QB/T4695-2014
鲁卫水进字【2019】第B009号
DN25
倍世海尔饮水科技有限公司
符合《生活饮用水卫生标准》（GB5749）的要求
山东省青岛市黄岛区太白山路172号青岛中德生态园双创中心216室
BWT Aktiengesellschaft
Walter-Simmer-Strasse 4, A-5310 Mondsee
184x60x278
365x180x80 1.53kg
1.85kg
C

5
故障解决
故障排除原因故障
滤芯元件污堵 进行反冲洗
完全打开和关闭旋钮，
重复几次反冲洗
供水系统中的水压大幅下降，水
龙头打开时水压大幅下降（降幅
超过静止压力的35%）
由于沉淀物颗粒较大，反冲洗元
件被卡住，无法旋拧到位
冲洗水管出口不关闭
如果使用这些方法无法解决机器的故障，请拨打我们的客服电话。

产品保养及维修记录
6
备注：请妥善保存此卡，并于保养维修时出示。
为了保证产品正常工作并滤出优质的净水，请仔细阅读说明书中的产品使用部分，按时进行反冲洗。
产品保养记录
产品维修记录
产品型号： 购买日期：
保养日期 服务人员签字
维修内容
保养内容
服务人员签字维修日期

7
产品保修卡
回执单（服务商联）
回执单（公司联）
产品类别：
产品型号：
购买日期：
购买地点：
销售人员：
用户姓名：
用户电话：
联系地址：
邮政编码：
电子邮件：
购买日期：
产品型号：
服务商名称：
安装人员：
安装时间：
客户签字：
承蒙购买海尔倍世产品，谨致谢意！
消费者通过合法渠道购买的产品，如果出现非人为损坏的
故障，自安装之日起即可享受为期2年的免费保修服务。
如需安装，请在周一至周五，9：00-17：00（法定假日
除外），请拨打服务热线：400-699-9999
一.请消费者仔细阅读以下保修条款
1.请核对产品包装及本卡序号一致有效,并请与安装人员
一起完整、正确和真实地填写回执单。
2.请妥善保管保修卡和购买产品发票。
3.维修时请出示保修卡或发票原件(保修卡和发票不得涂
改，否则无效)。
二、凡在产品保修期内出现以下问题，均可享受免费服务。
1.产品出现罐体漏水，外箱自然破损等质量问题，公司均
负责保修;但因碰撞及有害气体液体而损坏不属保修范围。
2.在符合产品要求的电源电压和供水水压的情况下使用出
现故障。
三、符合下列情况之一，均不在保修范围，公司或其授权
服务中心将实行合理的收费修理。
1.不能出示保修卡或发票;
2.产品保修卡内容与实际保修商品不符或有涂改;
3.因使用不当或人为造成的损坏或其他损失:
5.因使用电源电压，供水水压，使用环境温度等不符合技
术规范要求造成的损坏及其他损失;
裁去区域
用户姓名：
用户电话：
联系地址：
邮政编码：
电子邮件：
购买日期：
产品型号：
服务商名称：
安装人员：
安装时间：
客户签字：

Contents
Scope of Supply
Application
Function
Installation Conditions
Installation
Startup
Operation
Maintenance
Warranty
Technical Specifications
Troubleshooting
Record of Product Maintenance & Repair
Product Warranty Card
2
2
2
2
2
3
3
3
3
4
5
6
7

1

2
HBP-V40 consisting of:
1 Top section in brass
2 Connection fitting with seals
3 Transparent cylinder with filter element
4 Hose connection for flushing water supply
5 Turning knob for the backwashing element
Observe the local installation regulations, general
guidelines, general hygiene regulations and the
technical specifications.
A connection to the sewage system (discharge) of
min. DN 40 should be available.
Attention: The installation site must be protected
against frost and must ensure the protection of the
filter against e.g. solvent vapours, fuel oil, lees,
chemicals of any kind, UV radiation and heat
sources above 40 °C.
Attention: keep the plastic parts free from grease,
solvents and acidic as well as basic detergents.
The plastic parts must be replaced even if there is
no visible damage after severe concussions and
shocks e.g. due to the use of unsuitable tools or if
dropped on stone floors etc (danger of bursting).
Avoid extreme pressure impact.
This filter is intended for the filtration of drinking
and service water. It protects the water pipes and
the connected water system parts from malfunc-
tions and corrosion damage due to impurities such
as rust particles, chippings, sand, hemp, etc. The
filter cannot be used in applications with chemi-
cally treated circulating water, process water and
cooling water for continuous cooling systems.
In applications with water containing coarse im-
purities, a coarse dirt separator must be used. The
filter is not suitable for oils, greases, solvents,
soaps and other lubricating media nor for the
separation of watersoluble substances.
The untreated water flows through the untreated
water inlet into the filter and from there from the
inside to the outside through the filter element into
the clean water outlet. Any impurities >90 μm are
trapped on the inside of the filter cloth. The filter
element needs to be cleaned by backwashing at
regular intervals. For the backwashing process,
the waste water connection is opened by turning
the turning knob and the backwashing element is
also turned. The particles on the filter cloth are re-
moved by suction and then washed out.
Scope of Supply
Application
Function
Install filter according to its nominal width in cold
water pipes of the same dimensions and before
the equipment to be protected. Install stop valves
before and after the filter.
Assemble the connection fittings (2) in the pipe
and install filter in flow direction (see flow direc-
tion arrow) in the horizontal cold water pipe (see
installation sketch).
Route the flushing water connection with hose to
the sewage channel or provide a collection basin
(capacity approx. 10 l).
Please note: According to DIN EN 1717, the
flushing water hose must be installed at a mini-
mum distance of 20mm to the highest possible
waste water level (free discharge).
Installation
Installation Conditions

Check the filter and the flushing water pipe for
proper installation. The stop valves must not be
opened yet. Check the transparent cylinder (3) for
proper fit and then close the turning knob (5) by
turning it clockwise.
Slowly open the stop valves before and after the
filter and deaerate the pipework at the air bleed
closest to the filter (after the filter).
Before backwashing provide a collecting basin, if
the flushing water pipe is not connected to the
waste water system.
Open the turning knob counter-clockwise until
you can hear water running out and then close it
again. Check whether the filter is correctly sealed.
Backwashing
Open the turning knob (5) counter-clockwise
until you can hear water running out and then
close it again. Check whether the filter is cor-
rectly sealed.
The plastic parts may only be cleaned with a
soft, damp cloth. Do not use any solvents or
detergents nor acid cleaners.
A backwash must be carried out once a month to
prevent dirt particles from settling on the filter cloth
(or more frequently with higher amounts of dirt).
Before starting the backwash procedure,
provide a collecting basin, if the flushing water pipe
is not connected to the waste water system.
All technical equipment requires regular mainte-
nance. According to DIN 1988, maintenance must
be carried out by expert technical staff who also
replaces the parts subject to wear and tear. We
therefore recommend closing a maintenance
contract.
Maintenance must be carried out once a year, or
twice a year for communal installations. It is to be
carried out by the installer or manufacturer.
Operation
Maintenance
In the event of malfunction during the warranty
period please contact our Customer Service and
state the filter type and the production number
(see Specifications or rating plate).
Any warranty work may only be carried out by our
Customer Service.
Non-compliance with the installation conditions
and maintenance/repair carried out by unautho-
rized operator voids the warranty.
Warranty
Startup
3

4
Technical Specifications
5-30℃
5-40℃
Austria
HB HBP-V40 POE Filter
HBP-V40
0.2-1.0MPa
200m
4.0m /h
3
3
QB/T4695-2014
鲁卫水进字【2019】第B009号
BWT Aktiengesellschaft
Walter-Simmer-Strasse 4, A-5310 Mondsee
Tap Water
184x60x278
365x180x80 1.53kg
1.85kg
Product Name
Product Type
Flow Rate
Product Size(mm)
Packaging Size(mm)
Nominal Capacity
Net Weight
Gross WeightCountry of Origin
Pipe Diameter DN25
Water
Temperature
Ambient
Temperature
Water Supply
Water Pressure
Water Quality
Implementation
Standard
MOH No.
Actual Manufacturer
Address of Actual
Manufacturer
Responsible
Company in China
Address of Responsible
Company in China
Sanitary Standard for Hygienic Safety of Drinking Water(GB5749)
BWT Haier Drinking Water Technology Co., Ltd
Qingdao Sino-German Eco Park, Beta Space, Room 216,172 Taibaishan Rd.,
Huangdao District, Qingdao, Shandong, China
Hose connection, diameter E
Threads of the coupling ring G
Minimum distance: tube centre to wall
Installation length without screw joint A 100mm
Installation length with screw joint B
Total height C
Minimum distance: tube centre to floor D
184mm
278mm
400mm
14mm
G 1 1/4"
50mm
C
Note: in order to meet the needs of customers as far as possible,our products will
be constantly optimized and improved. The contents of this manual and product
parameters are subject to change without prior notice.

Operation
SolutionCauseFault
Dirty filter element Carry out backwash
Fully open and close turning knob;
repeat backwash several times
Water pressure in system has
dropped considerably; Water
pressure drops considerably
when water is bled (by more
than 35% of the static pressure)
Backwash element does not
reach the end position due to
large particles of dirt
Flushing water outlet does not close
If the fault cannot be rectified using these notes, please contact our Customer Service.
Troubleshooting
5

6
Note: Please keep this card properly and show it during maintenance and repair.
In order to ensure the product can be operated properly and filter out high-quality purified water, please carefully
read the instruction manual and carry out backwash on time.
Record of Product Maintenance
Record of Product Repair
Product type: Purchase date:
Maintenance Service Person Signature
Repair Content
Maintenance Content
Service Person Signature
Record of Product Maintenance & Repair
Repair Date
