BWT TFPKIT User manual

Specifications
Pressure Range: 30–125 psi (2.1–8.62 bar)
Temperature Range: 40–100°F (4.4–37.7°C)
Rated Service Flow: 1.9 Lpm
Filter Capacity: 1893 L
Parts Included:
•Filter head with built-in mounting bracket, and
compression fittings
•1000R filter cartridge
•Screws for mounting bracket
•Saddle tapping valve with tube attached
•Drinking water tap with tube attached
•6.35 mm (1/4") plastic tubing
Customer Help Line: 01376 334 200
Monday to Friday 08.30 – 17.00 UK Only.
Precautions
WARNING: Do not use with water that is microbiologically
unsafe or of unknown quality without adequate
disinfection before or after the system. Systems
certified for cyst reduction may be used on
disinfected waters that may contain filterable cysts.
CAUTION: This filter must be protected from freezing, which
can cause cracking of the filter and water leakage.
CAUTION: Because of the product’s limited service life and to
prevent costly repairs or possible water damage,
we strongly recommend that the head of the filter
be replaced every ten years. If the head of your filter
has been in use for longer than this period, it should
be replaced immediately. Date the top of any
new head to indicate the next recommended
replacement date.
CAUTION: Turn off water supply to head without cartridge if it must
be left unattended for an extended period of time.
Tools Required
•Phillips Screwdriver •File or Sandpaper
•Towel P •encil
•Drill •3.2 mm (1/8") Drill Bit
•Tape Measure •Adjustable Wrench
Optional Materials
•6.3 & 12.7 mm (1/4" & 1/2") Drill Bit
•Cone-shaped grinding wheel
Installation
•For standard installation on 15mm copper, steel, brass or PVC
cold water pipe.
•Please read all instructions and precautions before installing
and using your under-sink drinking water system.
•Numbered diagrams correspond with numbered steps.
1. Selecting the Tap Location
NOTE: The drinking water tap should be positioned with function,
convenience, and appearance in mind. An adequate flat area
is required to allow tap base to rest securely. The tap fits through
a 12mm hole.
CAUTION: Do not attempt to drill through an all-porcelain sink. If
you have an all-porcelain sink,drill through countertop next to
sink. The following instructions apply to porcelain-coated cast iron
and stainless steel sinks only. Consult a professional plumber
about installation on an all-porcelain sink.
(continued overleaf)
•For cold water use only.
•Make certain that installation complies
with all local bylaws and regulations.
•The contaminants or other substances
removed or reduced by the selected
cartridge are not necessarily in your water.
Ask your local water supplier for a copy of
their water analysis.
•After prolonged periods of non-use (such as during a
holiday) it is recommended that the system be flushed
thoroughly. Let water run for 2-3 minutes before using.
•The filter cartridge used with this system has a limited service
life. Changes in taste, odour, colour; and/or flow of the water
being filtered indicate that the cartridge should be replaced.
Taste Fresh Protection Drinking Water Filter System
Installation and Operating Instructions
Model: TFPKIT
4
1000R Cartridge
U.S. EPA Avg. Influent Avg.(Max) Effluent Avg.(Min)
MCL* Concentration Concentration Reduction
Standard 42
Chlorine–Class I –** 2.1 ppm 0.02 ppm 99%
Particulates –** 7,108,826 #/ml 15,896 #/ml 99.8%
(0.5 to<5 µm)
–Class I
Standard 53
Cysts
†99.95 % 130,750 #/ml 0 #/ml 99.99%
Reduction (0 #/ml ) (99.99%)
Turbidity 0.5 NTU* 37.4 NTU 0.08 NTU 99.96%
(0.08 NTU) (99.95%)
Lead 0.010 ppb‡ 0.15 mg/L 0.001 mg/L 99.3%
(6.5 pH) (0.001 mg/L) (99.3%)
Lead 0.010 ppb‡ 0.15 mg/L 0.002 mg/L 98.6%
(8.5 pH) (0.003 mg/L) (98%)
Atrazine 0.003 mg/L 0.0088 mg/L 0.0002 mg/L 97.7%
(0.0002 mg/L) (97.7%)
Lindane 0.0002 mg/L 0.002 mg/L 0.00005 mg/L (97.5%)
(0.00005 mg/L) (97.5%)
Flow Rate = 1.89 Lpm Capacity = 1892L or 6 Months
* US EPA Maximum Contaminant Level
** No maximum contaminant level
† NSF test requirement of at least 50,000 3–4 micron particles per milliliter.
The 3–4 micron size particle is a surrogate particle for Cryptosporidium
and Giardia cysts.
‡ US EPA Action Level for lead
NOTE: Substances reduced are not necessarily in your water.
Filter must be maintained according to manufacturer’s
instructions, including replacement of filter cartridges.
T roubleshooting
Leaks:
...Between head and cartridge
(1) Tu rn off the water supply to the filter and dispense water from
drinking water tap until water and airflow stops.
(2) Remove cartridge and inspect o-rings to make sure they are
in place and clean.
(3) Install cartridge and turn on water supply. If it still leaks, con-
tact Technical Support.
...From pushfits
Tu rn off saddle valve and turn on drinking water tap. Remove
tubing from the pushfit inserts on the filter head and ensure
the tube is cut squarely. If so insert the tube back into the
p ushfits ensuring the tube is pushed fully home. Open the
water supply valve, then close tap and check for leaks.
If the leaks persist, or if there are other leaks on the unit, turn
off the water supply then call Technical Support.
...On saddle valve connection
Call Technical Support.
...On tap/tubing connection
Call Technical Support.
NOTE: If leaks persist, or if there are other leaks on system, turn off
water supply. Call our technical support department.
P erformance Data
Model: Taste Fresh Protection
Important Notice: Read this performance data and compare
the capabilities of this system with your actual water treatment
needs.
Test Conditions:
Flow Rate = 0.5 gpm
Inlet Pressure = 60 psi (4.1 bar)
pH = 7.5 ± 1
Temperature = 68º F ± 5º F (20º C ± 2.5º C)
Operating Requirements:
Pressure = 30-125 psi (2.1-8.62 bar)
Temperature = 40º-100º F (4.4º-37.7º C)
Turbidity = 5 NTU Max
Do not use with water that is microbiologically unsafe or
unknown quality without adequate disinfection before or after
the system. Systems certified for cyst reduction may be used on
disinfected waters that may contain filterable cysts.
Guarantee
This product is guaranteed for the period of one year from the date of
purchase against any manufacturing fault. The guarantee is only valid if
the product has been installed and used in accordance with the
manufacturers instructions and has not been dismantled or interfered
with in any way. Damage caused to the product or by the product as a
result of failure to use the product in accordance with the
manufacturers instructions is not covered by this guarantee. Under this
guarantee we undertake at our discretion to repair or replace free of
charge the product or any part thereof that is found to be faulty. Costs
associated with the fitting of a replacement product or part or the
removal of the product are not covered by this guarantee. Loss or
damage caused by the product (including consequential loss) is not
covered by this guarantee. This guarantee does not affect your
statutory rights.
Customer Help Line:
01376 334 200
Monday to Friday 08.30 – 17.00 UK Only.
All trademarks are protected under European law and must not be reproduced by
third parties without express permission of BWT UK Limited in writing.
As part of BWT's policy of constant product development, BWT reser ves the
right to alter product specifications without prior notice.
BWT UK Limited,
BWT House,
Coronation Road,
High Wycombe,
Buckinghamshire,
HP12 3SU
Tel: [phone]
Fax: [phone]
Email: [email protected]

A
1. Selecting the Tap Location (cont)
(A) Line bottom of sink with newspaper to prevent metal shavings, parts, or
tools from falling down drain and damaging sink disposal unit if fitted.
(B) If sink is porcelain-coated, place masking tape over area to be drilled to
prevent excess chipping of enamel.Use a cone-shaped grinding wheel
to grind away a 3/4–inch diameter circle of porcelain before drilling.
WARNING: Wear safety glasses to prevent eye injury.
(C) Mark hole with center punch. Use a 6mm drill bit for a pilot hole, then
using a 12mm diameter bit, drill a hole completely through the sink or
work top. Smooth rough edges with a file.
2. Mounting the Tap
3. Installing the Saddle Valve
NOTE: Saddle valve must be installed on a 50 mm (2”) long, straight-walled
section of 10 mm (3/8”) to 23 mm (7/8”) steel, brass, copper, or PVC pipe.
(A) Select a straight section of the water supply line.
(B) Clamp around water line using two clamping screws (A). Tighten evenly.
Note: Use saddles (B) & (C) for 10 mm (3/8") O.D. pipe, only saddle (C) for
13 mm (1/2") O.D. pipe, or no saddles for 16 mm (5/8") pipe.
(C) Connect the end of the tubing to the filter system water input.
(D) Tu rn adjustment knob (D) clockwise as far as it will go to pierce the
water line.
(E) Back out knob counter clockwise as far as it will go for full flow. Adjust
down for desired flow.
4. Mounting the Filter System
(A) Select location under sink where filter is to be mounted.
NOTE: Allow 50mm clearance below housing or 280mm below filter head
to enable filter cartridge changes.
CAUTION: Filter head should be mounted on stud or firm surface. The
mounting bracket will support the weight of the filter and help prevent
strain on the cold water line.
(B) Filter head should be mounted in vertical position, use mounting
bracket as a template to mark screw locations. Mount filter head in
marked location using screws.
3
B
A
D
C
B
C
A
D
2
2
1
A
C
280260240220
4
(A) The tap should be positioned on a work surface adjacent to a sink
where the spout can properly discharge water into the basin.
(B) Using a pencil, mark the work surface to indicate the centre of the
tap.
(C) Drill a ½”hole where marked on the work surface.
(D) Insert the black rubber washer into the base of the tap.
(E) Insert the threaded section of the tap body into the ½”hole.
(F) Assemble the washers and lock nut on the threaded section as over.
(G) Tighten the lock nut to prevent the tap moving. Do not over
tighten.
5. Connecting the Saddle Valve Tube
to the Filter Inlet
6. Installing the Cartridge
Hold cartridge from the bottom when installing or changing the cartridge.
Use caution not to scrape knuckles on bracket when locking the cartridge
into place. Line up the arrow on the cartridge with unlocked padlock on
head. Insert cartridge and turn arrow to locked padlock. (See Diagram R4)
7. Putting the Filter into Operation
(A) Tu rn on water supply and saddle tapping valve by turning counter-
clockwise until it comes to a stop to allow filter to fill with water.
Check for leaks. If it leaks, see Troubleshooting.
(B) Allow water to run for 5 minutes to flush air and carbon fines (very fine
black powder) through the system.
(C) Check for leaks before leaving installation. If it leaks, see Troubleshooting.
R. Filter Cartridge Replacement
NOTE: It is recommended that the filter be replaced every six months,
or when you notice a change in taste, odour, or flow of the water
being filtered.
(1) Turn off water supply to the filter and dispense water from drinking
water tap until water flow stops to relieve pressure.
(2) Place towel under the system to catch any water drips.
(3) (a) Turn arrow from locked to unlocked position.
(b) Remove cartridge.
(4) (a) Line up arrow with unlocked position on head and insert cartridge.
(b) Tu rn to locked position.
(5) Tu rn on water and check for leaks. If it leaks, see Troubleshooting.
(6) Flush water through drinking water tap for 5 minutes to remove carbon
fines. Check for leaks before leaving installation. If it leaks, see
Troubleshooting.
A
3
Inlet
Outlet To
Tap
5
B
R4
B
A
To Detach Cartridge
To Attach Cartridge
Attatch saddle valve inlet and tap outlet tubing
to the inlet and outlet port on the cartridge housing
using the push-fit fittings. Ensure each tube is pushed
fully home to achieve secure fitting.
R3
B
A
