CDN TCTW572 User manual

Model: TCTW572
WATERPROOF
FOLDING THERMOCOUPLE THERMOMETER
-58 to +572°F/-50 to +300°C
FOR THIN CUTS OF MEAT AND
GENERAL PURPOSE COOKING
•NSF®Certied
•4-way rotating display
•2-3 second response
•1.5 mm thin tip
•4.33"/11.0 cm probe
•Waterproof (IPX7: protected from water up to
3 feet/1 meter for 30 minutes)
•Extra big digit
•Backlit display
•Field calibration
•Automatic on/off
•Food-safe ABS plastic with BioCote®
•304 stainless steel probe
•Temperature guide on thermometer
•Mounting: loop
•Two AAA 1.5V IEC LR03 alkaline batteries (included)
Note: Remove label from display before initial use.
Clean the thermometer probe before each use.
Simply ip down the rapid response thermocouple
probe and insert it into food as thin as 1/8-inch.
Note: In the following instructions, names of the control
buttons are shown in CAPS. Function information that
appears on the display is shown in BOLD CAPS.
BATTERY INSTALLATION
Replace battery when LCD becomes dim.
The display ashes fast when the batteries need
to be replaced.
1. Power off the unit before installing the batteries.
A malfunction may occur if the power is on
when the battery is installed. If a malfunction
occurs, press the RESET button in the battery
compartment or restart the device.
2. Using a small Phillips screwdriver, remove the
screws on the back by turning them counter
clockwise.
Note: Be careful to use a properly-sized screwdriver as a
screwdriver too large will strip the screwtops.
3. Remove the cover completely.
4. Install two 1.5V AAA batteries observing polarity
shown in compartment.
5. Replace the battery cover.
Important: THE WATER RESISTANT FEATURE REQUIRES
MAINTAINING THE RUBBER GASKET EVENLY WITHIN THE
GROOVE.
6. Fasten the screws on the back by turning them
clockwise, being careful not to over-turn.
OPERATING INSTRUCTIONS
A. On/Off
1. Flip down the probe to turn the thermometer on.
2. The TCTW572 will automatically turn off after
10 minutes of inactivity.
3. Flip the probe back into the case to turn the
thermometer off and conserve battery life.
CAUTION: Probe may be HOT after use. Always wear a heat
resistant glove to touch the stainless steel probe during or
just after cooking. Do not touch with bare hands.
B. Temperature Scale
To select temperature reading in Fahrenheit or
Celsius:
1. Using a small Phillips screwdriver, remove the
screws on the back by turning them counter
clockwise.
Note: Be careful to use a properly-sized screwdriver as a
screwdriver too large will strip the screwtops.
2. Remove the cover completely.
PO Box 10947 Portland, OR 97296-0947 Tel [phone] Fax [phone] Web CDNkitchen.com

3. Press the °F/°C button inside the battery
compartment to change the scale.
4. The °F or °C symbol changes on the display.
5. Replace the battery cover.
Important: THE WATER RESISTANT FEATURE REQUIRES
MAINTAINING THE RUBBER GASKET EVENLY WITHIN THE
GROOVE.
6. Fasten the screws on the back by turning them
clockwise, being careful not to over-turn.
C. LCD Backlight
The backlight will turn on automatically for
3 seconds when the TCTW572 is on.
D. Temperature Measurement
Important: THE PROBE MAY BE DAMAGED IF MEASUREMENT
TEMPERATURE IS LOWER THAN -58°F/-50°C OR HIGHER
THAN +572°F/+300°C.
Note: The TCTW572 is intended for food service use — do not
use for safety related applications.
1. Flip down the probe until fully extended.
2. Insert the probe at least 0.25"/6.3 mm into the
food.
3. The current cooking temperature appears on the
display.
4. Wearing a heat resistant glove, ip the probe
back into the case when nished.
Important: DO NOT TWIST THE PROBE OR ROTATE IT IN
WRONG DIRECTION. EXCEPTIONAL STRESS ON PROBE
MAY CAUSE IT TO BREAK.
CAUTION: Probe may be HOT after use. Always wear a heat
resistant glove to touch the stainless steel probe during or
just after cooking. Do not touch with bare hands.
E. Display Rotation
The orientation of LCD display follows that of the
TCTW572.
F. Field Calibration
1. Fill a 1 cup measuring container with a slurry
of ice water using 3 parts crushed ice to
1 part water.
Note: It is very difcult to get a 32°F/0°C ice water
temperature. It will probably be closer to 34°F/1°C.
2. Allow to stand for 3-5 minutes.
3. Using a small Phillips screwdriver, remove the
screws on the back by turning them counter
clockwise.
Note: Be careful to use a properly-sized screwdriver as a
screwdriver too large will strip the screwtops.
4. Remove the cover completely.
5. Immerse the probe into the middle of the ice
slurry to a depth of at least 2 inches. Do not let
the stem touch the bottom of container.
6. Press the CAL button inside the battery
compartment. C0 appears on the display for
3 seconds and then shows current temperature.
7. Press the CAL button again to calibrate to
32.0°F/0°C.
8. CAL appears on the display for 5 seconds and
then returns to the current temperature.
Note: To avoid accidental recalibration, this function only
works when the water temperature is 30 to 34°F/-1 to +1°C.
Err will appear for 2 seconds if the water is not within this
range and then return to the temperature display mode.
9. Replace the battery cover.
Important: THE WATER RESISTANT FEATURE REQUIRES
MAINTAINING THE RUBBER GASKET EVENLY WITHIN THE
GROOVE.
10. Fasten the screws on the back by turning them
clockwise, being careful not to over-turn.
G. Battery Status
1. The display ashes when the voltage on the
batteries is low.
2. “--” ashes on the display when the batteries
need to be replaced.
H. Reset
Press the RESET button in the battery
compartment to reset the thermometer to factory
defaults.
Important: DO NOT LEAVE THERMOMETER CASE IN
HOT OVEN. CASE IS NOT HEAT RESISTANT. HAND
WASH AND DRY.
Note: Remove label from display before initial use.
Clean the thermometer probe before each use.
Note for Induction Cooktops: Sometimes, the induction
cooktop magnetic eld may interfere with digital
thermometers. If there is interference, briey turn off the
induction cooktop to get a digital thermometer reading or
use a dial thermometer.
Tip: Meat should be allowed to “rest” for 10 to 15 minutes
after it is removed from oven. This allows time for the
meat’s internal temperature to stabilize and the juices to
redistribute. This will result in a roast that is both juicier and
easier to carve.

© 04 -2020 CDN Made in China CD9999390en - 4/20 L-DESIGN 614.525.1472
CE Note: This device could be sensitive to electrostatic
discharge. If electrostatic discharge or malfunctioning
occurs, please re-install the battery to reset this unit.
Antimicrobial properties are
built-in to inhibit the growth of
bacteria that may affect this
product. According to EPA
guidelines we cannot claim that
the antimicrobial properties in this
product protect users or others
against bacteria, viruses, germs,
or other disease organisms.
This product does not protect
users or others against food-borne bacteria. Always clean and
wash this product thoroughly before and after each use.
USDA SAFE FOOD TEMPERATURES
* Beef, Veal, Lamb – well ......160°F ..71°C
* Beef, Veal, Lamb – medium...145°F ..63°C
* Beef, Veal, Lamb – rare ......140°F ..60°C
Poultry ...................165°F ..74°C
* Pork/Ham – pre-cooked .....145°F ..63°C
Ground Meat ..............160°F ..71°C
* 3 minutes rest time
The information in this document has been reviewed and is believed to
be accurate. However, neither the manufacturer nor its afliates assume
any responsibility for inaccuracies, errors or omissions that may be
contained herein. In no event will the manufacturer or its afliates be
liable for direct, indirect, special, incidental or consequential damages
arisen by using this product or resulting from any defect/omission in
this document, even if advised of the possibility of such damages.
The manufacturer and its afliates reserve the right to make
improvements or changes to this document and the products and
services described at any time, without notice or obligation.
5-Year Limited Warranty: Any instrument that proves to be
defective in material or workmanship (excluding batteries)
within ve years of original purchase will be repaired or
replaced without charge upon receipt of the unit prepaid
at: CDN, PO Box 10947, Portland, OR 97296-0947 USA.
This warranty does not cover damage in shipment or
failure caused by failure to adhere to the accompanying
instructions, inadequate maintenance, normal wear
and tear, tampering, accident, misuse, unauthorized
modication, obvious carelessness or abuse. CDN shall
not be liable for any consequential or incidental damages
whatsoever.
For more detailed information on our
products, please visit CDNkitchen.com
or call 800-338-5594.
CARE OF YOUR PRODUCT
• Wipe clean with a damp cloth.
• Store the thermometer at room temperature
between -4 to +149°F/ -20 to +65°C.
PRECAUTIONS
• Always wear a heat resistant glove to touch the
stainless steel probe during or just after cooking.
Do not touch with bare hands.
• Dispose of used batteries promptly and keep the
batteries and thermometer away from children.
• Avoid subjecting the probe or thermometer to an
open ame on the BBQ.
• Avoid subjecting the probe and/or thermometer to
temperatures over 572°F/300°C.
• Clean the probe and thermometer with warm soapy
water and dry thoroughly after use.
• Avoid cleaning the unit with an abrasive or corrosive
compound, which may scratch the plastic parts and
corrode the electronic circuits.
• Avoid subjecting the thermometer to excessive
force, shock, dust, temperature, direct sunlight
or humidity. This may result in thermometer
malfunction, shorter electronic life span, battery
damage and/or distort parts.
• Avoid tampering with the thermometer’s internal
components, which may cause battery damage and
distort parts.
• Do not use the thermometer in microwave oven.
• Always read the user manual thoroughly before
operating.
SPECIFICATIONS
Measurement Range -58 to +572°F/-50 to +300°C
Unit of Measure °F/°C
Resolution 0.1°F/0.1°C
Operating Range 32 to 104°F/0 to 40°C/≤90% RH
Water Resilience IPX7 – protected from water up to
3 feet/1 meter for 30 minutes
Accuracy -40 to +392°F/-40 to +200°C:
±0.7°F/±0.4°C; above 392°F/200°C:
±1.8°F/±1°C (@ ambient temperature
73°F: ±3.6°F/23°C: ±2°C)
Power Supply Two AAA 1.5V IEC LR03 alkaline
batteries, included
Product Dimensions 6.31 W x 1.97 H x 0.81 D (in)/
16.03 W x 5.0 H x 2.06 D (cm)
Weight 3.6 oz / 90 g (including battery)
