Cembre B540ND User manual

1
BATTERY OPERATED HYDRAULIC
CRIMPING TOOL
ENGLISH OPERATION AND MAINTENANCE MANUAL
18 M 153 U
B540ND B540NDA B540NDK

2
FIG. 1b
B540NDK
Makita battery
FIG. 2
FIG. 1a
B540NDA
Metabo battery
8
8
"W" style crimping dies
FIG. 3
6
red lines
13
13

3
FIG. 4 FIG. 5
FIG. 6
14
Tool components in configuration B540NDA
Cable connector

4
1
2
3
4
5
6
7 x4
9
10
11
1
2
3
4
6
7 x4
9
8
12
8
FIG. 7
1
JAWS SUPPORT
2
RUBBER GRIP
3
OPERATING BUTTON
4
HANDLE
5
BATTERY
6
JAW LOCKING PIN
7
LED WORKLIGHT (x4)
8
BATTERY RELEASE
9
WRIST STRAP
10
DISPLAY
11
TOUCH BUTTON FOR MENU SELECTION
12
PRESSURE RELEASE BUTTON
B540NDK
B540ND
B540NDA
5

5
Use and Care of rechargeable batteries
Recharge the supplied battery using the specific manufacturer’s charger only.
A charger intended for a specific type of battery may become a fire hazard if used with other types
of battery.
Use the tool with the specific intended battery pack only. The use of any other type of battery may
lead to a risk of injury or fire.
When the battery is not in use, store it away from other metal objects, such as paperclips, coins,
keys, nails, screws or other small metal objects that can create a connection between two terminals.
Keep batteries out of reach of children.
Short-circuiting the battery terminals can cause burns or fire.
If in very poor condition, a battery can leak liquid. Avoid contact with the eyes.
In the case of accidental contact, rinse immediately under running water.
If the liquid comes into contact with the eyes, seek medical assistance immediately. Battery liquid
can cause irritation or burns.
Keep batteries dry!
Keep batteries away from fire!
Never throw batteries into fire or water.
Always recycle batteries after use.
Never dispose batteries with household waste. They must be deposited at the dedicated
collection points for disposal.
Transporting Li-Ion batteries
Lithium ion rechargeable batteries are subject to the legal requirements on hazardous goods.
In the event of road transport by the user, no further precautions are necessary.
In the event of third-party transport (e.g. transported by airplane or courier), transportation must
comply with the special requirements concerning packaging and labelling. We recommend that
you consult an expert.
Rechargeable batteries can only be transported if undamaged.
The packaging must prevent the batteries from moving around and exposed contacts must be
covered with adhesive tape.
Beforeusing thetool,care-
fully read the instructions
contained in this manual.
SAVE THESE INSTRUC-
TIONS: this manual con-
tainsimportant safetyand
operating instructions for
the tool.
When operating
thetool,keephan-
ds away from the
danger zone.
WARNING SYMBOLS
User information
(Directives 2011/65/
UE and 2012/19/
UE),see page 16.
Always wear safety
gloves when ope-
rating the tool.

6
WARNINGS
Before starting work on electrical equipment, please ensure that either there are no live parts
in the immediate working area or that precautions are taken for working near live parts in
accordance with EN50110-1.
Do not use this tool on, or near, live conductors without proper personal
protective equipment.
Electrical Shock Hazard: The tool is not insulated and the jaws will conduct
electricity. This product should be used only by persons knowledgeable in
the safe use of jaws and crimpers. Failure to observe this warning could result
in injury or death.
Do not use the tool for purposes other than those intended by Cembre.
The operator should concentrate on the work being performed and be careful to maintain
a balanced working position.
Avoid dirty surfaces as dust and sand are a danger to any electro-hydraulic equipment.
Protect the tool and accessories from rain and moisture. Water will damage the tool and
battery. Electro-hydraulic tools should not be operated in pouring rain.
Work in a clean, uncluttered area and keep persons away from immediate work area.
Before each use, verify the integrity of the tool. Replace any worn, possibly damaged or missing
parts with original Cembre spares.
Inspect the blades before each use of the cutting jaw.
Do not use damaged blades.
Damaged blades can break and cause injury or damage to the tool.
Wear eye protection as metal chips can fly from blades when cutting.
Pay attention when cutting short, free pieces of steel rod or rope as they may fly off danger-
ously, causing injury to the operator or persons nearby.
Do not cut live cables or conductors.
The tool is unsuitable for continuous use and should be allowed to cool down following un-
interrupted, successive operations. For example, having exhausted a fully charged battery in
one session, delay battery replacement for a few minutes.

7
B540ND B540NDA B540NDK
Application range suitable for installing electrical compression
connectors for conductors up to 150 mm2(300 MCM)
and for cutting Copper, Aluminium, ACSR and Steel
conductors, ropes and rods
Type of acceptable jaws:
(Ref. to table page 17)
Crimping
Cutting
CDD6N - CDD6-6N - CDD6-8N
CMB4N - CMB5N - CMB6N
Crimping force
kN (US sh. ton)
54 (6.1)
Operating pressure
bar (psi) 600 (8702)
Dimensions
(Ref. to FIG. 8 page 18) mm (inches) 403 x 104 x 87
(15.9 x 4.1 x 3.4)
413 x 108 x 87
(16.3 x 4.2 x 3.4)
Weight with battery only
(no jaws) kg (lbs) 2,9 (6.4) 3,1 (6.8)
Motor V DC 18
Operating temperature °C (°F) -15 to +50 (+5 to +122)
Recommended oil TOTAL DIEKAN 1640 or equivalents
Safety maximum pressure valve
Rechargeable battery type METABO
CB1820L
MAKITA
BL1850B
V / Ah (Wh) 18 / 2.0 (36) 18 / 5.0 (90)
Weight kg (lbs) 0,4 (0.9) 0,6 (1.3)
Acoustic noise (1) dB LpA 67,7 (A) LpCPeak 89,2 (C) LWA 74,2 (A)
Vibrations (2) m/s2ahv 0,724
Battery charger
Input
type
V / Hz
METABO ASC30-36
37334000
METABO ASC30-36
37401000
MAKITA DC18RC
220 - 240 / 50 - 60 115 / 60 120 / 50 - 60
(1) Directive 2006/42/EC, annexe 1, point 1.7.4.2 letter u
LpA = weighted continuous acoustic pressure level equivalent.
LpCPeak = maximum value of the weighted acoustic displacement pressure at the work place.
LWA = acoustic power level emitted by the machine.
(2) Directive 2006/42/EC, annexe 1, point 2.2.1.1
Weighted root mean square in frequency of the acceleration the upper limbs are exposed to for each biodynamic
referenceaxis.Tests carriedoutincompliancewiththeindicationscontainedinENISO5349-1/2 Standard andunder
operating conditions much more severe than those normally found.
1. GENERAL CHARACTERISTICS

8
2. INSTRUCTIONS FOR USE
The part reference includes the following:
– Hydraulic basic tool.
– 2 pcs Metabo or Makita battery (model depends on the tool version).
– Battery charger (model depends on the tool version).
– Canvas bag.
– Plastic case (only for B540ND).
– Shoulder strap.
– USB cable (Ref. to section 6, page 16).
The tool can be easily carried using either the main handle (4) or the shoulder strap attached
to the two eyelets of the wrist strap (9) (see FIG. 7).
The tool can be held in one hand while positioning the conductor with the other.
Before starting any work, check the battery charge and recharge it if necessary following
the instructions in the battery charger user manual.
To replace the battery, grip the tool as illustrated in the Fig. 1a or 1b.
Press the release button (8) and slide the battery out unlocking it.
2.1) Setting
On the display the operator can view and change some of the tool’s settings using the touch
button (Ref. to section 4).
The display shows the operating mode and oil release settings of the tool at each start-up (starting
with the display off) or upon insertion of the battery.
Examples:
IMPORTANT: Prior to using the tool, always check the operating mode set is the correct
one for the type of job to be carried out, choosing between:
CRIMPING – CUTTING (Ref. to section 4.2).
Default settings are:
– operating mode: CRIMPING (Ref. to section 4.2 to choose cutting mode).
– oil release type: SMART, automatic return of the jaw once the crimping
operation is complete (Ref. to section 4.3 to choose manual release).
2.2) Crimping mode
With the tool in the rest position (the ram fully retracted), proceed as follows:
Select the appropriate crimping jaws or die set for the connector to be crimped (see table page 17).
Insert the crimping jaws into the tool (see section 3.1).
If necessary, select the appropriate die set for the connector to be crimped and insert the dies
into the jaws (see section 3.2).
Insert the conductor into the connector and position the connector between the groove or
die set (see FIG. 3). Ensure the correct location of the crimp.

9
Position the connector in the die groove and ensure the correct location of the crimp.
NOTE: when more compression
is required, proceed according
to the sequence and direction
indicated in the figure, uniformly
spacing the compressions.
Press operating button (3) to activate the motor-pump and advance the ram.
To halt the advancement, release the operating button and the motor will cut out.
Make sure the dies are exactly positioned on the desired crimp point otherwise re-open
dies by pressing the release button (12) and reposition the connector.
By keeping operating button (3) pressed, the motor continues to operate and the ram will
gradually move forward until the two dies touch.
The motor will stop automatically when the set pressure has been reached.
To perform proper compression, press and hold the operating button (3) until the motor
stops automatically.
NOTE: To display the momentary force or pressure
during the work cycle, select the appropriate display
from the menu (Ref. to section 4).When the operating
buttonisreleasedbeforethemotorstopsautomatically,
the display will show the peak force (Fp) or the peak
pressure (Pp) reached at that instant.
To complete the work, press the operating button again until the motor stops automatically. The
display will show the maximum force or pressure reached followed by ‘OK’ to confirm correct
operation.
The display ‘ERROR’, combined with a beep and the LEDs flashing,
indicates an incorrect crimping procedure caused by the work cycle
being interrupted before the control parameters (force/pressure) of
the tool are reached. This error appears when the pressure release button has been operated and
the tool has already reached a pressure > 100 bar. In this case, repeat the compression by pressing
and holding the operat ing button until the motor stops automatically.
By releasing the operating button (3), the ram will automatically retract (SMART RELEASE) and
open the jaw.
terminal
connector
123
12
1
3
2
3
conductor
conductor
Pn= 602 bar
OK
Fm = 54.3 kN
OK
Fm= 54.3 kN
Fp= 42.3 kN
Pm= 602 bar
Pp = 465 bar
ERROR
Ï
Ð

10
2.3) Cutting mode
With the tool in the rest position (the ram fully retracted), proceed as
follows:
Select the appropriate cutting jaws for the conductor to be cut (see
table page 17).
Insert the cutting jaws into the tool (see section 3.1).
Insert the conductor between the blades (14), up to the desired
cutting point (see FIG. 5).
To cut short pieces of steel or ACSR ropes, it is suggested to tie
or wrap rope with adhesive or duct tape around the area to
be cut and at its end, so to limit the projection of steel frag-
ments which could cause damage or injure the operator.
Press the operating button (3) to activate the motor-pump, the ram
will gradually move forward until the blades (14) touch the conduc-
tor.
Make sure the blades are exactly positioned on the desired cutting
pointotherwisere-openbypressingthereleasebutton(12)andreposi-
tion.
To halt the advancement, release the operating button (3) and the motor will
cut out.
Firmly hold the tool and press the operating button (3) to gradually move
the blades (14), until the cutting operation is complete. At the end of the
cycle the display will show the maximum pressure reached (Pp).
By operating the pressure release button (12), the ram will retract and open the blades.
2.4) LED Worklights
Whilst the tool is in operation, the working area is illuminated by four high luminosity LED Work-
lights that switch off automatically at the end of the cycle.
The LED Worklights can be disabled by following the procedure described in section 4.4.
2.5) Head rotation
For ease of operation, the tool head can rotate through 180°, allowing the operator to work in the
most comfortable position.
Do not attempt to rotate the head when the hydraulic circuit is pressurised.
Pp = 325 bar
P = 0 bar
3
12

11
2.6) Capacitive touch button for menu selection
This button is located under the display and allows selection of various
screens (Ref. to section 4) and only works when the display is on.
Wearing gloves or using other objects may inhibit the operation of the
button, therefore use a bare finger and apply only a light touch.
Do not apply pressure to, or stab at the touch button as a light touch using a bare finger
is sufficient. The command pulse is sent when the finger is released from the button.
2.7) Battery status
Withthebatteryinserted into the tool,theremainingbat-
tery life can also be checked on the display via touch but-
ton selection (Ref. to section 4).
The screen shown adjacent indicates that the battery voltage has
dropped below a minimum safety threshold. Under these conditions
the tool will not start, and it is necessary to recharge or replace the
battery.
Batteries are equipped with LED indicators that indicate the remaining battery life at any time
by pressing the adjacent button.
2.8) Using the battery charger
Carefully follow the instructions in the battery charger user manual.
3. DIE AND JAW ASSEMBLY
The interchangeable crimping jaws have plastic covers on the outside edges.
Whenintroducingorchangingjawsordies,thebatterymustfirstberemovedfromthetool.
3.1) Jaw assembly
Pressthe lockingpin (6)and turn itto the rightto release itintothe fullyopen position (seeFIG. 2).
Insert the jaws into the support head until the hole is aligned with the locking pin.
Push the pin (6) right in and turn it to the left to lock it (see FIG. 2) until the red lines are aligned.
3.2) Crimping die assembly
Use of ”W”style crimping dies into the CDD6N, CDD6-6N, CDD6-8N jaws
Press pins (13) and insert “W” dies into their seats (see FIG. 3).
To disassemble, simply press the pins (13) and slip them from the jaws.
It is recommended to use the tool only with product to be crimped inserted.
BATTERY Ï
Ð
max.
BATTERY BATTERY
Ï
Ð
min.
BEEP
2

12
B540ND
NR 18AW125
10
-29990
3
BATTERY
RESET
SW:S1J96900
Pn= 600 bar
P= 0 bar
Pn= 8702 psi
LED
ON LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
Fm= 54.0 kN
Fp = 0.0 kN
Fm= 6.07 ton
Fp = 0.00 ton
4. NAVIGATION MENU
The navigation menu is shown on the display (10). By touching the but-
ton (11) it is possible to browse the menu via the various screens.
4.1) Structure of the "main menu"
Fm: Operating/minimum set force, expressed in kN.
Fp: Peak force reached, expressed in kN.
Fm: Operating/minimum set force, expressed in USA sh. tons.
Fp: Peak force reached, expressed in USA sh. tons.
Pn: Operating/minimum set pressure, expressed in bar.
P: Peak pressure reached, expressed in bar.
Pn: Operating/minimum set pressure, expressed in psi.
P: Peak pressure reached, expressed in psi.
Battery charge level
No. of cycles performed.
No. of cycles before scheduled recommended maintenance.
Cembre logo, tool model.
Tool serial number
Operating mode set
(Ref. to section 4.2 for further details).
Release mode set
(Ref. to section 4.3 for further details).
Enabling/disabling the LED Worklights.
(Ref. to section 4.4 for further details).
Return to original factory settings.
Firmware version (Ref. to section 4.5 for further details).
11
10

13
(*) Screens 1-2-3-4-5-6-7 can be set as the “main screen” which is
shown on the display at every use of the tool. To do this, when the
pre-selected screen is displayed, hold the finger on the button (11)
until a confirmation “beep” is heard.
4.2) Choosing the "operating mode"
The“operating mode”allows the user to set the tool depending on the type of jaw mounted. This
enables the optimisation of the job cycle and charging of the battery.
It is possible to choose between two different operating modes:
Operating
mode
Associated
pictogram Function
CRIMPING
factory setting
Specificallyforusing the tool with crimpingjaws(CDD6N,CDD6-
6N, CDD6-8N) for crimping of electrical connectors.
CUTTING Specificallyfor using the toolwithcuttingjaws(CMB4N,CMB5N,
CMB6N) for cutting electrical conductors and steel ropes.
To change the desired“operating mode”, proceed as follows:
- Select screen 8 from the “main menu” (Ref. to section 4.1).
- Hold the finger on the button (11) until a confirmation“beep”is heard, the choice made is shown
by filling of the related pictogram.
4.3) Choosing the "release mode"
The phase of discharging the oil into the tool’s tank can be carried out in two different ways,
depending on the mode set in the menu:
Release
mode
Associated
pictogram Function
SMART
factory setting
By releasing the operating button (3) the oil is returned in full to
the tool reservoir only following automatic shut-off of the motor.
During the return phase, pressing the buttons enables the ram
stroketobeinterruptedat anypointsoastobeabletorestart from
this position in the next work phase, thus saving time and energy.
MANUAL
To return the oil to the tool reservoir it is necessary to press and
hold the release button (12).
During the return phase, by releasing the button it is possible for
head ram stroke to be interrupted at any point so as to be able
to restart from this position in the next work phase, thus saving
time and energy.
BEEP
2
BEEP
2

14
To change the "release mode", proceed as follows:
- Select screen 9 from the “main menu”(Ref. to section 4.1).
- Hold the finger on the button (11) until a confirmation“beep”is heard.The choice made is shown
by positioning of the cursor under the pictogram.
4.4) Enabling/disabling the LED Worklights (factory setting is LED ON)
Select screen 10 from the “main menu”
(Ref. to section 4.1). To deactivate or re-
activate operation of the LED Worklights,
hold the finger on the button (11) until a
confirmation “beep” is heard.
4.5) Return to original factory settings / firmware version
Select screen 11 from the“main menu”(Ref. to section 4.1). To return the tool to its factory settings,
hold the finger on the button (11) until a confirmation“beep” is heard.
The RESET screen also shows the firmware version of the control board.
4.6) Alarms/Warnings
These appear on the display during operation and inform the operator on the state of the tool.
Message Meaning Description
BATTERY
LOW
Replace or recharge the battery.
NOTE: when the battery voltage falls below a minimum safety
threshold, the tool will not start, although it is still possible to
end the work cycle in progress.
BATTERY
TEMPERATURE
HIGH
Remove the battery and wait until it cools down.
In order to cool quicker, it is possible to insert it into the supplied
battery charger supplied, thus making use of the specific “AIR
COOLED” function.
REQUEST
MAINTENANCE
No. of cycles to recommended maintenance is reached.The tool
continues to work however, it is recommended that it is sent to
Cembre for a complete overhaul (Ref. to section 7).
NOTE: this message, will reappear when the tool has been idle
for 30 s.
BATTERY Ï
Ð
BATTERY
Ï  Ð
30001
3
Ð
LED
OFF
LED
ON
LED
OFF LED
ON
BEEP
2
RESET
SW:S1J96900

15
4.7) Errors/Malfunctions
These appear on the display during operation, combined with a beep to notify the operator of
procedural or operational errors.
Message Error description Solution
In crimping mode: the pressure re-
leasebutton(12)waspressedbefore
thecontrolparameterswerereached
(Force/Pressure).
Repeat the work cycle and wait for the motor
to stop automatically.
Interruption of the signal from
the NTC temperature probe of the
battery.
Replace the battery.
Iftheproblempersists,pleasecontactCembre.
Interruption of the signal from
the NTC temperature probe of the
battery.
Replace the battery.
Iftheproblempersists,pleasecontactCembre.
Abnormal power consumption of
the motor.
The tool stops.
Waitforthedisplay toturnoff(60sec.)orremove
and re-insert the battery, then re-start the tool.
If the error occurs frequently,contact Cembre.
Outputvoltageof the pressuretrans-
mitterisoutofthepre-setrange.The
tool stops.
Repeat the work cycle.
If the error occurs frequently,contact Cembre.
Failure to reach the set pressure
within 30 sec. of continuous opera-
tion of the tool. The tool stops.
Repeat the work cycle.
Iftheerroroccursfrequently,contact Cembre.
Overcharging of the battery with
protection tripping.
The tool stops.
Waitforthedisplay toturnoff(60sec.)orremove
and re-insert the battery, then re-start the tool.
If the error occurs frequently,contact Cembre.
Errors 00.. are displayed for about 30 seconds before being reset, but will display re peat-
edly in the event of permanent anomalies.
5. MAINTENANCE
The tool is robust, completely sealed, and requires very little daily maintenance. Compliance with
the following points, should help to maintain its optimum performance:
5.1) Thorough cleaning
Dust, sand and dirt are a danger for any hydraulic device.
Every day, after use, the tool must be wiped with a clean cloth taking care to remove any residue,
especially close to pivots and moveable parts.
Do not use hydrocarbons to clean the rubber parts.
5.2) Storage case
When not in use, to protect the tool from accidental damage and dust, it should be stored with
its accessories in the special canvas bag or plastic case supplied and sealed well.
B540NDA and B540NDK provided with CVB-033 canvas bag, size 740x215x200 mm (29.1x8.5x7.9
inches), weight 1,7 kg (3.7 lbs) .
B540ND provided with VAL-P60 plastic case, size 620x360x138 mm (24.4x14.2x5.4 inches), weight
2,4 kg (5.3 lbs).
ERROR
Ï
Ð
001
Ï
Ð
002
Ï
Ð
003
Ï
Ð
004
Ï
Ð
NTC
FAULT
NTC
FAULT

16
6. CONNECTION TO COMPUTER (Smartool technology)
Thememorycardintegratedinthetoolrecordsoperatingdata
from 200.000 cycles for transfer via the USB cable supplied.
To view and manage this data, go to www.cembre.com
and register in the dedicated area, then download the free
Cembre software CEM_SWBT01.
Keeping the Firmware of the tool updated, via free of charge
download from here, will optimise the tool's performance.
7. RETURN TO Cembre FOR OVERHAUL
In the case of a breakdown contact our Area Agent who will advise you on the problem and give
you the necessary instructions on how to dispatch the tool to our nearest service centre. If pos-
sible, attach a copy of theTest Certificate supplied by Cembretogether with the tool or fill in and
attach the form available in the“ASSISTANCE” section of the Cembre website.
_________________________________________________________________________________________
Following information applies in member states of the European Union:
USER INFORMATION in accordance with Directives 2011/65/EU and 2012/19/EU.
The ‘Not in the bin’ symbol above when shown on equipment or packaging means that the equipment
must, at the end of its life, be disposed of separately from other waste.
The separate waste collection of such equipment is organised and managed by the manufacturer.
Users wishing to dispose of such equipment must contact the manufacturer and follow the prescribed
guidelines for its separate collection. Appropriate waste separation, collection, environmentally compat-
ible treatment and disposal is intended to reduce harmful environmental effects and promote the reuse
and recycling of materials contained in the equipment. Unlawful disposal of such equipment will be
subject to the application of administrative sanctions provided by current legislation.
B540NDKB540ND / B540NDA
USB port
USB port

17
INTERCHANGEABLE CRIMPING JAWS
CAT. No CRIMPING DIE COMPATIBILITY
CDD6N With "D3" groove to
accept all "W" style
crimping dies + "BG"
fixed groove.
FCI Burndy
Greenlee
Ilsco
Huskie
Panduit
W, X Series
KD6 Series
ND Series
HT-58 Series
CD-2001 Series
CDD6-6N With "D3" groove to
accept all "W" style
crimping dies.
FCI Burndy
Greenlee
Ilsco
Huskie
Panduit
W, X Series
KD6 Series
ND Series
HT-58 Series
CD-2001 Series
CDD6-8N With "D3" groove to
accept all "W" style
crimping dies + "O"
fixed groove.
FCI Burndy
Greenlee
Ilsco
Huskie
Panduit
W, X Series
KD6 Series
ND Series
HT-58 Series
CD-2001 Series
INTERCHANGEABLE CUTTING JAWS
CAT. No CUTTING COMPATIBILITY
CMB4N Cutting jaws for underground:
Aluminum & Copper stranded cables.
Max opening 1-1/4.
CMB5N Cutting jaws for OHL:
ACSR up to 556 and tree wire.
CMB6N Cutting jaws for guy wires:
Up to 7/16 EHS guy wire.
JAWS TABLES
CAUTION
• Inspect the jaws before each use. Do not use damaged jaws.
• Damaged jaws can break and cause injury or damage to the tool.
• Work in a clean, uncluttered area.
• Keep persons away from immediate work area.
• Use these jaws for the manufacturer’s intended purpose only.
Wear eye protection. Metal chips can fly from blades when cutting.
Do not cut short, free pieces of steel rods or ropes, they may dangerously fly off; injury to the
operator and persons nearby may result.

18
87 (3.4) 104 (4.1)
403 (15.9)
87 (3.4) 108 (4.2)
413 (16.3)
B540ND
B540NDA
B540NDK
Dimensions mm (inch)
FIG. 8

19

20
cod. 6261442
20
cod
.
626
14
4
42
www.cembre.com
Cembre Ltd.
Dunton Park
Kingsbury Road, Curdworth - Sutton Coldfield
West Midlands B76 9EB (UK)
Tel.: [phone] - Fax: [phone]
E-mail: [email protected]
www.cembre.co.uk
Cembre S.a.r.l.
22 Avenue Ferdinand de Lesseps
91420 Morangis (France)
Tél.: [phone] - Fax: [phone]
CS 92014 - 91423 Morangis Cédex
E-mail: [email protected]
www.cembre.fr
Cembre España S.L.U.
Calle Verano 6 y 8
28850 Torrejón de Ardoz - Madrid (España)
Teléfono: 91 4852580
Telefax: 91 4852581
E-mail: [email protected]
www.cembre.es
Cembre GmbH
Heidemannstraße 166
80939 München (Deutschland)
Telefon: [phone]
Telefax: 089 35806777
E-mail: [email protected]
www.cembre.de
Cembre Inc.
Raritan Center Business Park
181 Fieldcrest Avenue
Edison, New Jersey 08837 (USA)
Tel.: [phone] - Fax: [phone]
E-mail: [email protected]
www.cembreinc.com
Cembre S.p.A.
Via Serenissima, 9
25135 Brescia (Italia)
Telefono: 030 36921
Telefax: 030 3365766
E-mail: [email protected]
www.cembre.com
IKUMA GmbH & Co. KG
Boschstraße 7
71384 Weinstadt (Deutschland)
Telefon: [phone] - 60
Telefax: 07151 20536 - 80
E-mail: [email protected]
www.ikuma.de
This manual is the property of Cembre: any reproduction is forbidden without written permission.
