CHAPTER
40-1
Cisco CallManager System Guide
OL-7135-01
40
Cisco IP Phones
Cisco IP Phones as full-featured telephones can plug directly into your IP
network. H.323 clients, CTI ports, and Cisco IP Communicator comprise
software-based devices that you configure similarly to the Cisco IP Phones.
Cisco CallManager Administration allows you to configure phone features such
as call forwarding and call waiting for your phone devices. You can also create
phone button templates to assign a common button configuration to a large
number of phones.
After you have added the phones, you can associate users with them. By
associating a user with a phone, you give that user control over that device.
This section covers the following topics:
•Supported Cisco IP Phones, page 40-2
•H.323 Clients and CTI Ports, page 40-10
•Cisco IP Communicator, page 40-11
•Phone Button Templates, page 40-11
•Softkey Templates, page 40-19
•Softkey Template Operation, page 40-23
•Methods for Adding Phones, page 40-24
•Directory Numbers, page 40-25
•Phone Features, page 40-33
•Phone Association, page 40-40
•Phone Administration Tips, page 40-40

Chapter 40 Cisco IP Phones
Supported Cisco IP Phones
40-2
Cisco CallManager System Guide OL-7135-01
•Phone Failover and Fallback, page 40-47
•Phone Configuration Checklist, page 40-48
•Where to Find More Information, page 40-49
Supported Cisco IP Phones
Table 40-1 provides an overview of the features that are available on the following
Cisco IP Phones that Cisco CallManager supports:
•Cisco IP Phone 7900 family
•Cisco IP Phone 7914 expansion module
•Cisco IP Conference Station 7935 and 7936
•Cisco IP Phone model 30 VIP
•Cisco IP Phone model 12 series
Not all Cisco IP Phone models support all features and services. For the latest
information on features and services that support these phone models, refer to the
following documentation:
•Phone administration or user documentation that supports the phone model
and this version of Cisco CallManager
•Firmware release notes for your phone model
•Cisco CallManager release notes

40-3
Cisco CallManager System Guide
OL-7135-01
Chapter 40 Cisco IP Phones Supported Cisco IP Phones
Table 40-1 Supported Cisco IP Phones and Features
Cisco IP Phone Model Description
Cisco IP Phone 7970 The Cisco IP Phone model 7970, a full-featured,
eight-line business set, supports the following
features:
•A backlit, color touchscreen display for easy
access to call details and features.
•Four fixed feature buttons:
– Messages—accessing voice-messaging
messages
– Settings—adjusting phone settings
– Services—accessing services
– Directories—accessing call logs and
directories
•A Help (?) button for immediate assistance with
calling features
•Eight programmable buttons to use as Line
buttons, speed dial buttons, or for other phone
services
•Five softkeys for accessing additional call details
and functionality (softkeys change depending on
the call state for a total of 16 softkeys)
•An internal, two-way, full-duplex speakerphone
and microphone mute
The 7970G-GE is the gigabit ethernet version of the
7970. Phones 7970G, 7960G and 7940G are the
non-gigabit version.

Chapter 40 Cisco IP Phones
Supported Cisco IP Phones
40-4
Cisco CallManager System Guide OL-7135-01
Cisco IP Phone 7960 The Cisco IP Phone model 7960, a full-featured,
six-line business set, supports the following features:
•A help (?) button
•Six programmable line, speed-dial, or feature
buttons
•Four fixed buttons for accessing voice-messaging
messages, adjusting phone settings, accessing
services, and accessing directories
•Four softkeys for accessing additional call details
and functionality (softkeys change depending on
the call state for a total of 16 softkeys)
•A large LCD display that shows call details and
softkey functions
•An internal, two-way, full-duplex speakerphone
and microphone mute
Cisco IP Phone 7940 The Cisco IP Phone model 7940, a two-line business
set with features similar to the Cisco IP Phone model
7960, includes the following features:
•A help (?) button
•Two programmable line, speed-dial, or feature
buttons
•Four fixed buttons for accessing voice-messaging
messages, services, and directories, and adjusting
phone settings
•Four softkeys for accessing additional call details
and functionality (softkeys change depending
upon the call state for a total of 16 softkeys)
•A large LCD display that shows call details and
softkey functions
•An internal, two-way, full-duplex speakerphone
and microphone mute
Table 40-1 Supported Cisco IP Phones and Features (continued)
Cisco IP Phone Model Description

40-5
Cisco CallManager System Guide
OL-7135-01
Chapter 40 Cisco IP Phones Supported Cisco IP Phones
Cisco IP Phone 7920 The Cisco Wireless IP Phone 7920, which is an
easy-to-use IEEE 802.11b wireless IP phone, provides
comprehensive voice communication in conjunction
with Cisco CallManager and Cisco Aironet (r) 1200,
1100, 350, and 340 series of Wi-Fi (IEEE 802.11b)
access points. Features include:
•A pixel-based display for intuitive access to
calling features.
•Two soft keys that dynamically present calling
options to the user.
•A four-way rocker switch allowing easy
movement through the displayed information.
•Volume control for easy decibel-level adjustments
of the handset and ringer when in use.
Cisco IP Phone 7912G The Cisco IP Phone 7912G, which is a single-line
phone that supports a maximum of two calls at the
same time, provides basic-feature functionality for
individuals who conduct low to medium telephone
traffic.
This model, which supports inline power, provides an
integrated 10/100 Ethernet switch for connectivity to a
collocated PC.
This model offers four dynamic softkeys.
Table 40-1 Supported Cisco IP Phones and Features (continued)
Cisco IP Phone Model Description

Chapter 40 Cisco IP Phones
Supported Cisco IP Phones
40-6
Cisco CallManager System Guide OL-7135-01
Cisco IP Phone 7914
Expansion Module Cisco IP Phone 7914 Expansion Module extends the functionality of the Cisco IP Phone 7960 by providing
14 additional buttons. To configure these buttons as
lines or speed dials, use Phone Button Template
Configuration.
The Cisco IP Phone 7914 Expansion Module includes
an LCD to identify the function of the button and the
line status.
You can daisy chain two Cisco IP Phone 7914
Expansion Modules to provide 28 additional lines or
speed-dial and feature buttons.
Cisco IP Phone 7910 The Cisco IP Phone 7910, a single-line, basic-feature
phone that is designed primarily for common-use areas
with medium telephone traffic such as lobbies or
breakrooms, includes the following features:
•Four dedicated feature buttons for Line, Hold,
Transfer, and Settings
•Six programmable feature buttons that you can
configure through phone button templates in
Cisco CallManager
Available features include Call Park, Redial,
Speed Dial, Call Pickup, Conference, Forward
All, Message Waiting, and Meet-Me Conference.
•A two-line LCD display (24 characters per line)
that indicates the directory number, call status,
date, and time
•An internal speaker that is designed for hands-free
dialing.
Table 40-1 Supported Cisco IP Phones and Features (continued)
Cisco IP Phone Model Description

40-7
Cisco CallManager System Guide
OL-7135-01
Chapter 40 Cisco IP Phones Supported Cisco IP Phones
Cisco IP Phone 7905G The Cisco IP Phone 7905G, a low-cost, single-line,
basic-feature phone that is designed primarily for
common-use areas such as cafeterias, break rooms,
lobbies, and manufacturing floors, includes the
following features:
•LCD that displays features such as time, date,
phone number, caller ID, call status, and softkey
tabs
•Four softkeys that engage any of the functions that
display on the corresponding LCD screen tabs.
Softkey functions change depending on the status
of the phone
•Three dedicated buttons for Hold, Menu, and
Navigation
•An internal speaker that is designed for hands-free
dialing
Cisco IP Phone model
7902G The Cisco IP Phone 7902G provides a cost-effective, entry-level IP phone for a lobby, laboratory,
manufacturing floor, or another area where only basic
calling capability is required. The single-line Cisco IP
Phone 7902G includes the following features:
•Fixed feature keys that provide one-touch access
to the redial, transfer, conference, and voice-mail
access features
•Three dedicated buttons for hold, menu, and
volume control
•Inline power which allows the phone to receive
power over the LAN
Table 40-1 Supported Cisco IP Phones and Features (continued)
Cisco IP Phone Model Description

Chapter 40 Cisco IP Phones
Supported Cisco IP Phones
40-8
Cisco CallManager System Guide OL-7135-01
Cisco IP Conference
Station 7936 The Cisco IP Conference Station 7936, a full-featured, IP-based, hands-free conference station for use on
desktops and offices and in small-to medium-sized
conference rooms, includes the following features:
•Three softkeys and menu navigation keys that
guide a user through call features and functions
Available features include Call Park, Call Pick Up,
Group Call Pick Up, Transfer, and Conference
(Ad Hoc and Meet-Me).
•An LCD display that indicates the date and time,
calling party name, calling party number, digits
dialed, feature, and line status
•A digitally tuned speaker and three microphones
that allow conference participants to move around
while speaking
•Microphone mute
•Ability to add external microphones to support
larger rooms
Table 40-1 Supported Cisco IP Phones and Features (continued)
Cisco IP Phone Model Description

40-9
Cisco CallManager System Guide
OL-7135-01
Chapter 40 Cisco IP Phones Supported Cisco IP Phones
Cisco IP Conference
Station 7935 The Cisco IP Conference Station 7935, a full-featured, IP-based, hands-free conference station for use on
desktops and offices and in small-to medium-sized
conference rooms, includes the following features:
•Three softkeys and menu navigation keys that
guide a user through call features and functions
Available features include Call Park, Call Pick Up,
Group Call Pick Up, Transfer, and Conference
(Ad Hoc and Meet-Me).
•An LCD display that indicates the date and time,
calling party name, calling party number, digits
dialed, feature, and line status
•A digitally tuned speaker and three microphones
that allow conference participants to move around
while speaking
•Microphone mute
Cisco IP Phone 12 SP+ The Cisco IP Phone model 12 SP+ offers many of the
same features as PBX or POTS telephones. This IP
phone includes the following features:
•12 programmable line and feature buttons
•An LED that is associated with each of the 12
feature and line buttons to indicatefeature and line
status
•A two-line LCD display (20 characters per line)
for call status and identification
•An internal, two-way speakerphone and
microphone mute
Table 40-1 Supported Cisco IP Phones and Features (continued)
Cisco IP Phone Model Description

Chapter 40 Cisco IP Phones
H.323 Clients and CTI Ports
40-10
Cisco CallManager System Guide OL-7135-01
H.323 Clients and CTI Ports
Cisco CallManager Administration enables you to configure software-based
devices such as H.323 clients and CTI ports. Software-based Cisco CallManager
applications such as Cisco SoftPhone, Cisco AutoAttendant, and Cisco IP
Interactive Voice Response (IVR) use CTI ports that are virtual devices.
H.323 clients include Microsoft NetMeeting devices.
You configure H.323 clients and CTI ports through the Phone Configuration
window in Cisco CallManager Administration like you do phones, but they often
require fewer configuration settings.
Note Cisco recommends that you do not configure CTI ports or devices that use TAPI
applications in a line group.
For information on H.323 clients and shared line appearances, see the “Shared
Line Appearance” section on page 40-26.
Cisco IP Phone 30 VIP The Cisco IP Phone model 30 VIP offers many of the
same features as PBX or POTS telephones. This IP
phone includes the following features:
•26 programmable line and feature buttons
•An LED that is associated with each of the 26
feature and line buttons to indicatefeature and line
status
•A two-line LCD for displaying date and time,
calling party name, calling party number, and
digits dialed
•An internal, two-way speakerphone with
microphone mute
•Dedicated feature buttons for Transfer, Hold, and
Redial
Table 40-1 Supported Cisco IP Phones and Features (continued)
Cisco IP Phone Model Description

40-11
Cisco CallManager System Guide
OL-7135-01
Chapter 40 Cisco IP Phones Cisco IP Communicator
For instructions on how to configure H.323 clients and CTI ports, refer to
“Cisco IP Phone Configuration” in the Cisco CallManager Administration Guide.
Cisco IP Communicator
Cisco IP Communicator is a software-based application that allows users to place
and receive phone calls using their personal computers. Cisco IP Communicator
depends upon the Cisco CallManager call processing system to provide telephony
features and Voice-over-IP capabilities.
This interaction with Cisco CallManager means that Cisco IP Communicator
provides the same functionality as a full-featured Cisco IP Phone, while providing
the portability of a desktop application. Additionally, it means that you administer
Cisco IP Communicator as a phone device by using the Cisco CallManager
Administration Phone Configuration window.
Phone Button Templates
Cisco CallManagerincludes severaldefaultphone button templates.When adding
phones, you can assign one of these templates to the phones or create a new
template.
Creating and using templates provides a fast way to assign a common button
configuration to a large number of phones. For example, if users in your company
do not use the conference feature, you can create a template that reassigns this
button to a different feature, such as speed dial.
To create a template, you must make a copy of an existing template and assign the
template a unique name. You can make changes to the custom templates that you
created, and you can change the labels of the default phone button templates. You
cannot change the function of the buttons in the default templates. You can rename
existing templates and modify them to create new ones, update custom templates
to add or remove features, lines, or speed dials, and delete custom templates that
are no longer being used. When you update a template, the change affects all
phones that use the template.
Renaming a template does not affect the phones that use that template. All
Cisco IP Phones that use this template continue to use this template after it is
renamed.

Chapter 40 Cisco IP Phones
Phone Button Templates
40-12
Cisco CallManager System Guide OL-7135-01
Make sure that all phones have at least one line that is assigned to each phone.
Normally, this assignment specifies button 1. Phones can have additional lines
that are assigned, depending on the Cisco IP Phone model. Phones also generally
have several features, such as speed dial, that are assigned to the remaining
buttons.
You can delete phone templates that are not currently assigned to any phone in
your system if they are not the only template for a given phone model. You cannot
delete a template that is assigned to one or more devices or the default template
for a model (specified in the Device Defaults Configuration window). You must
reassign all Cisco IP Phones that are using the template that you want to delete to
a different phone button template before you can delete the template.
Note The standard phone button template for the Cisco IP Phone Model 7960, which
supports the Cisco IP Phone Model 7914 Expansion Module, includes buttons for
both devices (up to 34 buttons).
Use the Dependency Records link on the Phone Button Template Configuration
window to view the devices that are using a particular template.
Cisco CallManager does not directly control all features on Cisco IP Phones
through phone button templates. Refer to the Cisco IP Phone Administration
Guide for Cisco CallManager and other phone documentation for detailed
information about individual Cisco IP Phone 7900 family models.
Default Phone Button Templates
Although all Cisco IP Phones support similar features, you implement these
features differently on various models. For example, some models configure
features such as Hold or Transfer by using phone button templates; other models
have fixed buttons or onscreen program keys for these features that are not
configurable. Also, the maximum number of lines or speed dials that are
supported differs for some phone models. These differences require different
phone button templates for specific models.
Each Cisco IP Phone model comes with a default phone button template. You can
use the default templates as is to quickly configure phones. You can also copy and
modify the templates to create custom templates.

40-13
Cisco CallManager System Guide
OL-7135-01
Chapter 40 Cisco IP Phones Phone Button Templates
Custom templates enable you to make features available on some or all phones,
restrict the use of certain features to certain phones, configure a different number
of lines or speed dials for some or all phones, and so on, depending on how the
phone will be used. For example, you may want to create a custom template that
can be applied to phones that will be used in conference rooms. Table 40-2
provides descriptions of the default phone button template for each
Cisco IP Phone model.
Table 40-2 Default Phone Button Templates Listed by Model
Cisco IP Phone Model Default Phone Button Template Description
Cisco IP Phone 7970 The default Cisco IP Phone 7970 template uses
buttons 1 and 2 for lines and assigns buttons 3 through
8 as speed dials. Access other phone features, such as
call park, call forward, redial, hold, resume, voice
messaging system, conferencing, and so on using
softkeys on the Cisco IP Phone 7970.
Cisco IP Phone 7960 The default Cisco IP Phone 7960 template uses
buttons 1 and 2 for lines and assigns buttons 3 through
34 as speed dials or lines or for the features privacy and
service URL. Access other phone features, such as
abbreviated dial, call park, call forward, redial, hold,
resume, call back, conferencing, and so on, by using
softkeys on the Cisco IP Phone 7960.
Cisco IP Phone 7940 The Cisco IP Phone 7940 comes with a preconfigured
one-line phone button template (button 1 for line 1 and
button 2 for speed dial). Access phone features, such
as abbreviated dial, call park, call forward, redial,
hold, resume, call back, conferencing, and so on, by
using softkeys on the Cisco IP Phone 7940.
Cisco IP Phone 7920 The default phone button template for the Cisco IP
Phone 7920 uses buttons 1 and 2 for lines and assigns
buttons 3 through 6 for speed dials.
Cisco IP Phone 7912 The default phone button template for the
Cisco IP Phone 7912 uses button 1 for line 1, buttons
2 through 5 for speed dial, button 6 for Hold, and
button 7 for Settings.

Chapter 40 Cisco IP Phones
Phone Button Templates
40-14
Cisco CallManager System Guide OL-7135-01
Cisco IP Phone 7910 The default phone button template for the
Cisco IP Phone 7910 uses button 1 for message
waiting, button 2 for conference, button 3 for
forwarding, buttons 4 and 5 for speed dial, and button
6 for redial.
The Cisco IP Phone 7910 includes fixed buttons for
Line, Hold, Transfer, and Settings.
Cisco IP Phone 7905 The default phone button template for the
Cisco IP Phone 7905 uses button 1 for line 1, buttons
2 through 5 for speed dial, button 6 for Hold, and
button 7 for Settings.
Cisco IP Phone 7902 The default phone button template for the
Cisco IP Phone 7902 uses button 1 for line 1, buttons
2 through 5 for speed dial, button 6 for Hold, and
button 7 for Settings.
Cisco IP Conference
Station 7936 The default phone button template, which is not configurable,for theCisco IP Conference Station7936
uses button 1 for line 1.
Cisco IP Conference
Station 7935 The default phone button template, which is not configurable,for theCisco IP Conference Station7935
uses button 1 for line 1.
Cisco IP Phone 30 SP+ The default Cisco IP Phone model 30 SP+ template
uses buttons 1 through 4 for lines, and button 5 for call
park; button 6 through 8 and 17 through 21 remain
undefined, and button 9 through 13 and 22 through 25
apply for speed dial; button 14 applies for message
waiting indicator, button 15 for forward, and button 16
for conference.
Note For only the Cisco IP Phone model 30 SP+,
assign button 26 for automatic echo
cancellation (AEC).
Table 40-2 Default Phone Button Templates Listed by Model (continued)
Cisco IP Phone Model Default Phone Button Template Description

40-15
Cisco CallManager System Guide
OL-7135-01
Chapter 40 Cisco IP Phones Phone Button Templates
Cisco IP Phone 30 VIP The default Cisco IP Phone model 30 VIP template
uses buttons 1 through 4 for lines, button 5 for call
park, button 6 through 13 and 22 through 26 for speed
dial, button 14 for message waiting indicator,
button 15 for call forward, and button 16 for
conference.
Cisco IP Phone
12 Series, including
the 12 S, 12 SP, and
12 SP+
The default Cisco IP Phone 12 Series template uses
buttons 1 and 2 for lines, button 3 for redial, buttons 4
through 6 for speed dial, button 7 for hold, button 8 for
transfer, button 9 for forwarding, button 10 for call
park, button 11 for message waiting, and button 12 for
conference.
Cisco VGC Virtual
Phone The default phone button template for the Cisco VGC Virtual Phone uses button 1 for a line and buttons 2
through 10 for speed dials.
Cisco ATA 186 (and
188) The default phone button template for the Cisco ATA 186 and Cisco ATA 188 uses button 1 for
a line and buttons 2 through 10 for speed dials.
Cisco IPMA Assistant
7960 The default phone button template for the Cisco IPMA Assistant uses button 1 and buttons 7 through 12 for
lines, buttons 2 through 6 and buttons 17 through 34
for speed dials.
ISDN BRI Phone The default phone button template for the ISDN BRI
phone uses button 1 for line 1.
Cisco IP
Communicator The default Cisco IP Communicator template uses buttons 1 and 2 for lines and assigns buttons 3 through
8 as speed dials. Access other phone features, such as
call park, call forward, redial, hold, resume, voice
messaging system, conferencing, and so on using
softkeys (by configuring the softkey template to the
phone).
Table 40-2 Default Phone Button Templates Listed by Model (continued)
Cisco IP Phone Model Default Phone Button Template Description

Chapter 40 Cisco IP Phones
Phone Button Templates
40-16
Cisco CallManager System Guide OL-7135-01
Guidelines for Customizing Phone Button Templates
Use the following guidelines when you are creating custom phone button
templates:
•Make sure that phone users receive a quick reference card or getting started
guide that describes the most basic features of the custom template. If you
create a custom template for employees in your company to use, make sure
that it includes the following features and that you describe them on the quick
reference card that you create for your users.
– Cisco IP Phone 7970, 7960, 7940—Line (one or more)
– Cisco IP Phone 7912—Line, speed dial, hold, and settings
– Cisco IP Phone 7910—Forward all
– Cisco IP Phone 7905 and 7902—Line, speed dial, hold, and settings
– Cisco IP Phone model 12 SP+—Line (one or more), hold, call park, and
forward all
– Cisco IP Phone model 30 VIP—Line (one or more), call park, and
forward all
– Cisco VGC Virtual Phone and Cisco ATA 186 (and 188)—Line and
speed dials
•Consider the nature of each feature to determine how to configure your phone
button template. You might want to assign multiple buttons to speed dial and
line; however, you usually require only one of the other phone button features
that are described in Table 40-3.

40-17
Cisco CallManager System Guide
OL-7135-01
Chapter 40 Cisco IP Phones Phone Button Templates
Table 40-3 Phone Button Feature Description
Feature Description
AEC If you are configuring a template for the
Cisco IP Phone model 30 VIP, you must include one
occurrence of this feature and assign it to button 26.
Auto echo cancellation (AEC) reduces the amount of
feedback that the called party receives when the calling
party is using a speakerphone. Users should press the
AEC button on a Cisco IP Phone model 30 SP+ when
they are using speakerphone. Users do not need to press
this button when speakerphone is not in use. This
feature requires no configuration for it to work.
Answer/release In conjunction with a headset apparatus, the user can
press a button on the headset apparatus to answer and
release (disconnect) calls.
Auto answer If this feature is programmed on the template, activating
this button causes the speakerphone to go off hook
automatically when an incoming call is received.
Note You configure this feature for some phones
models through the Phone Button Template
window. You configure this feature for some
phone models in the Phone Configuration
window.
Call park In conjunction with a call park number or range, when
the user presses this button, call park places the call at a
directory number for later retrieval. You must have a call
park number or range that is configured in the system for
this button to work, and you should provide that number
or range to your users, so they can dial in to the
number(s) to retrieve calls.

Chapter 40 Cisco IP Phones
Phone Button Templates
40-18
Cisco CallManager System Guide OL-7135-01
Conference Users can initiate an ad hoc conference and add
participants by pressing the Conference button. (Users
can also use the Join softkey to initiate an ad hoc
conference.)
Only the person who initiates an ad hoc conference
needs a conference button. You must make sure that an
ad hoc conference bridge device is configured in
Cisco CallManager Administration for this button to
work. See Conference Bridges for more information.
Forward all Users press this button to forward all calls to the
designated directory number. Users can designate
forward all in the Cisco IP Phone Configuration
windows, or you can designate a forward all number for
each user in Cisco CallManager Administration.
Hold Users press this button to place an active call on hold. To
retrieve a call on hold, users press the flashing line
button or lift the handset and press the flashing line
button for the call on hold. The caller on hold receives a
tone every 10 seconds to indicate the hold status or
music (if the Music On Hold feature is configured). The
hold tone feature requires no configuration to work.
Line Users press this button to dial a number or to answer an
incoming call. You must have added directory numbers
on the user phone for this button to work.
Meet-Me conference When users press this button, they initiate a meet-me
conference, and they expect other invited users to dial in
to the conference. Only the person who initiates a
meet-me conference needs a meet-me button. You must
make sure that a meet-me conference device is
configured in Cisco CallManager Administration for
this button to work.
Message waiting Users press this button to connect to the
voice-messaging system.
None Use None to leave a button unassigned.
Table 40-3 Phone Button Feature Description (continued)
Feature Description

40-19
Cisco CallManager System Guide
OL-7135-01
Chapter 40 Cisco IP Phones Softkey Templates
Softkey Templates
Use softkey templates to manage softkeys that are associated with applications
such as Cisco IPMA or call-processing features such as Cisco Call Back on the
Cisco IP Phones. The administrator uses the Softkey Template Configuration
windows in Cisco CallManager Administration to create and update softkey
templates.
Cisco CallManager supports two types of softkey templates: standard and
nonstandard. Standard softkey templates in the Cisco CallManager database
contain the recommended selection and positioning of the softkeys for an
application. Cisco CallManager provides the following standard softkey
templates:
•Standard User
•Standard Feature
•Standard IPMA Assistant
Redial Users press this button to redial the last number that was
dialed on the Cisco IP Phone. This feature requires no
configuration to work.
Privacy Users press this button to activate/deactivate privacy.
Service URL Users press this button to access a Cisco IP Phone
Service such as personal fast dials, stock quotes, or
weather.
Speed-dial Users press this button to speed dial a specified number.
System administrators can designate speed-dial
numbers in Cisco CallManager Administration. Users
can designate speed-dial numbers in the Cisco IP Phone
User Options Menu.
Transfer Users press this button to transfer an active call to
another directory number. This feature requires no
configuration to work.
Table 40-3 Phone Button Feature Description (continued)
Feature Description

Chapter 40 Cisco IP Phones
Softkey Templates
40-20
Cisco CallManager System Guide OL-7135-01
•Standard IPMA Manager
•Standard IPMA Shared Mode Manager
Note The default process does not assign a softkey template to the Cisco IP Phone. The
administrator must assign standard or nonstandard softkey templates to the
Cisco IP Phone by assigning the templates individually to each phone or by
assigning the device pool to each phone.
The administrator creates a nonstandard softkey template by using the Softkey
Template Configuration windows in Cisco CallManager Administration. To
create a nonstandard softkey template, the administrator copies a standard softkey
template and makes changes. The administrator can add and remove applications
that are associated with any nonstandard softkey template. Additionally, the
administrator can configure softkey sets for each call state for a nonstandard
softkey template.
The Softkey Template Configuration window lists the standard and nonstandard
softkey templates and uses different icons to differentiate between standard and
nonstandard templates.
The administrator assigns softkey templates in the following Cisco CallManager
Administration configuration windows:
•Device Pool Configuration
•Phone Configuration (Cisco IP Phones 7905, 7912, 7920, 7940, 7960, 7970)
•User Device Profile Configuration
Add Application
The administrator can add a standard softkey template that is associated with a
Cisco application to a nonstandard softkey template. When the administrator
clicks the Add Application button from the Softkey Template Configuration
window, a separate window displays and allows the administrator to choose the
standard softkey template that is to be added to the end of the nonstandard softkey
template. Duplicate softkeys get deleted from the end of the set that is moving to
the front of the set.
