San Luis pergola 10' x 10' B101055 (2020)
Assembly Instructions
CORRI EAU
MEUBLES DE JARDIN
OUTDOOR FURNITURE

2
IMPORTANT:
Please read and follow all safety statements, warnings, assembly instructions, use & care
directions before attempting to assemble. Each of the recommendations must be followed
to ensure the utmost solidity.
Security Rules
Warning:
Keep flame and heat sources away from the gazebo fabric. The fabric may burn if it is
exposed to prolonged contact with a source of heat. The application of any foreign
substance to the gazebo fabric may render the flame-resistant properties ineffective.
Regulation
It is the responsibility of the consumer being in accordance with city regulation, construction
code, zoning or any limitations and obtaining permit prior assembling gazebo.
Recommendation
●When assembling and using this product, basic safety precautions should always be
followed to reduce the risk of personal injury and damage to parts.
●Do not use the gazebo during extreme weather conditions.
●Before beginning assembly of product, make sure all parts are present. Compare parts
with package contents list. If any part is missing or damaged, do not attempt to assemble
the product.
●Some parts may contain sharp edges. Use of protective gloves is always recommended.
●When installing and assembling your gazebo, it is recommended that 2 or more adults
are involved.
●Considering at least three hours to complete installation, even well anchored, a gazebo
unit that is not finished assembly can get or create damages to nearby environment.
●Verify that all nuts and bolts are tightly secured before and during use.
●Use proper tools and equipment for a safe and compliant installation. Never climb, sit or
stand on structure while assembling.

3
●Even if this gazebo is built for all year round, the snow must be removed from the roof at
all time.
●Mosquito net and curtains (optional) must be removed from the unit in freezing period.
●Anchoring bolts or other anchoring devices are not supplied.
●Keep away from any electric installation or transportation device.
●Always recommended to keep assembly manual for further reference.
Care
Avoid using a pressure washer. The use of a mild soap with warm water is the best solution
for the frame only. A clear water rinse is necessary then. Never use soap on fabric, this will
reduce their durability, consequently their lifespan and general look. The use of a soft brush
and warm water are an excellent solution for cleaning the fabric.
Warranty
Covered
We warrant the frame and fabric to be free of manufacturing defects to the original
purchaser for one year.
Not covered
This warranty does not cover commercial use, improper care, neglected storage,
vandalism, chemical, acts of nature, fire, oxidation, stains, freeze damage, improper
packaging for return and unreasonable or abusive use. Normal discoloration and build-up
snow are not covered either.
Customer service:
Consumer
For each part request, please contact your retailer with a description of the problem,
pictures and consumer invoice copy, to ensure the proper information to be proceed.
Seller
In addition to all the information already provided by the consumer, any parts requested
must mention the person responsible for the client’s file, the retailer name, address, branch
if applicable, e-mail address, fax and phone number.

A
A
B
B
C
C
F
E
E
F
F
F
E
E
G
G
H
H
H
H
H
I
J
J
J
J
D
D
4

No. Description Drawing QTY
A
B
C
D
E
F
G
H
I
J
2
2
2
2
4
4
2
5
1
4
5
Post
Post
Crossbar
Crossbar
Long brace
Short brace
Middle crossbar
Canopy slidebar
Roof cover
Base flange

AA
No. Description Drawing QTY
BB
CC
DD
10
4
Bolt M6 x 15mm 16
16
6
Bolt M6 x 40mm
Bolt M6 x 35mm
1
Allen key
EE
Bolt M6 x 70mm

7
Ax2
1
1
Bx2
A/B
J
A/B
J
Jx4
AA
AA
Step 1:
Secure base flanges ( J ) on the bottom of posts ( A & B ) by using bolts ( AA ) as fig. 1
shown. Bolts can be tight completely.

B
C
D
D
C
A
B
B
A
C
D
G
D
8
Cx2 Dx2
Gx2
G
G
BB
DD
23
1
1
2
2
33
33
2
2
1
1
1
A
D
BB
Step 2:
1. Secure crossbars ( D ) on two posts ( A & B ) using bolts ( BB ) as shown in fig. 1.
2. Secure crossbars ( C ) on two posts ( A & B ) using bolts ( BB ) as shown in fig. 2.
3. Secure middle crossbars ( G ) on crossbars ( D ) using bolts ( DD ) as shown in fig. 3.
Note: Please check above fig. carefully and make sure all the parts are in right position.
For your security, you may need 4 people for this step.

AA AA
BB
BB
EF
E
F
F
E
FE
CD
EF
9
1
Ex4 Fx4
2
FE
C
D
1
1
1
1
2
2
2
2
Step 3:
Secure short and long braces ( F & E ) to posts ( A & B ) by using bolts ( AA ) as fig 1
shown. Do not tight bolts yet. Then secure other end of braces ( E & F ) to crossbars
assembly ( CD ) by using bolts ( BB ) as fig. 2 shown.

H
I
H
I
Hx5 Ix1
1
10
1
1
1
1
1
Step 4:
Insert canopy slide bars ( H ) through roof cover sleeves ( I ) as fig. 1 shown.

I
C
IH
CC
1
11
1
1
1
1
1
1
1
1
Step 5 :
1.Insert bolts ( CC ) through the sliding hook of crossbars ( C ), and secure with canopy
slide bars ( H ) as shown. Tight bolts.
2.Fix pergola through base flanges ( J ) into the ground. Take note anchoring devices may
vary with ground status. Anchoring devices are not supplied.
11

1
1
1
Step 6:
1. The handgrip of roof cover ( I ) can help you open and close the roof cover.
2.The Velcro of roof cover can be tied to the crossbars and posts, increasing shade area.
3.At windy conditions, roof cover must be closed and Velcro tied to crossbars.
