CREE LIGHTING XSP Series Installation instructions

XSP Series
Street Lights
Includes: XSP 1 Module, XSP 2 Modules
DISASSEMBLY INSTRUCTIONS
Tools:
Disassembly Instructions
Light Source (LS)
For End User (EU)
LS-EU
1.LED bars are not replaceable by the end user by construction; only a technical operator at the production site can re-
place these bars. In order not to compromise the functionality and performance of the luminaire, the light sources used
in it can be handled only in environments protected from possible contamination of dust and / or external chemical
agents and with safety measures to prevent possible electrostatic discharge caused by the handling of the same.The con-
nection of the light sources to the body of the luminaire is also made by means of double-sided thermo-conductive
which, if not properly installed, could cause incorrect thermal management of the light sources.
For Control Authority (CA) LS-CA
1.Follow points A - B - C of paragraph PS-CA
2.Unscrew the screws 2 of the optics 3
3.Remove the gaskets 4
4.Unscrew the screws 5 that fix LED bars 6 on housing 1
5.Remove LED bars 6 without damaging the thermal pad 7 and taking the
utmost care not to bend or damage the LED bars
N° DOC: DI069RLER0 Rev: 01 Latest Release Date: 18/11/2021
Models :
XSP 1 module
XSP 2 modules
Light Sources
codes
Power Supply
codes
XSP#
LEA# PH#
Warning: Before opening the appliance, remove voltage from the mains line
1
2
3
45
6
7

Disassembly instructions
Power Supply (PS)
For End User (EU)
PS-EU
a.Access the wiring compartment by unscrewing the two screws 8
on the appliance door
b.Disconnect the cables connected to the driver on its terminal
block 9
c.Unscrew the ground screw 10 paying attention to the notched
washers
d.Unscrew the screws 11 that fix metal plate 12 on door 13 (or
on housing 1 in the case of Nema or Zhaga option)
e.Replace the old wiring plate with a new one
f.Screw the screws 11 back on plate 12 and door 13 via a torque
of 2.5 Nm
g.Screw the screw 10 back on plate 12 and door 13 by reapplying
the notched washers, applying a torque of 2.5 Nm
h.Reconnect the cables on driver terminal block 9 (see attached
wiring diagrams)
i. Close the door by tightening the screws 8 applying a torque of
2.5 Nm
For Control Authority (CA) PS-CA
A.Follow points “a-b” in the paragraph PS-EU
B.Unscrew the screw 14 that fix the driver on the plate 12 il dri-
ver alla piastra 12
C.Extract the driver
N° DOC: DI069RLER0 Rev: 01 Latest Release Date: 18/11/2021
8
9
13
12
11
10
14

© 2021 Cree Lighng, A company of IDEAL INDUSTRIES. All rights reserved. For informaonal purposes only. Content is subject to change.
See www.creelighng.com/warranty for warranty and specicaons. Cree® and the Cree logo are registered trademarks of Cree, Inc.
www.creelighng-europe.com
Disassembly Instructions
End of Life (EL)
Light Source (LS) Follow points: 1 - 2 - 3 - 4 - 5 of instructions in the paragraph LS
-CA
Power Supply (PS) Follow instructions in the paragraph PS-CA
DIRECTIVE 2012/19/EU (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT – WEEE): Information for users.
This product complies with EU Directive 2012/19/EU. The crossed-out wastebasket symbol on the appliance means that at the end of its useful lifespan, the product must be dispo-
sed of separately from ordinary household wastes. The user is responsible for delivering the appliance to an appropriate collection facility at the end of its useful lifespan. Appropria-
te separate collection to permit recycling, treatment and environmentally compatible disposal helps prevent negative impact on the environment and human health and promotes
recycling of the materials making up the product. For more information on available collection facilities, contact your local waste collection service or the shop where you bought this
appliance.
