Crow Runner Series Operator's manual

!
ELECTRONIC ENGINEERING LTD.
Runner Series
WIRELESS AND WIRED CONTROL PANEL
Installation and
Configuration Guide
!
by CROW Electronic Engineering Ltd.
Version 9.08.2
!

IMPORTANT NOTICE
All information and data contained in this document is proprietary and confidential.
CROW Electronic Engineering Ltd. shall not be liable, in any event, for any claims for damages or
any other remedy in any jurisdiction whatsoever, whether in an action in contract, tort (including
negligence and strict liability) or any other theory of liability, whether in law or equity including,
without limitation, claims for damages or any other remedy in whatever jurisdiction, and shall not
assume responsibility for patent infringements or other rights to third parties, arising out of or in
connection with this document. Further, CROW Electronic Engineering Ltd. reserves the right to
revise this publication and to make changes to its content, at any time, without obligation to notify
any person or entity of such revision changes. These materials are copyrighted and any
unauthorized use of these materials may violate copyright, trademark, and other laws. Therefore,
no part of this publication may be reproduced, photocopied, stored on a retrieval system, or
transmitted without the express written consent of CROW Electronic Engineering Ltd. Any new
issue of this document invalidates previous issues.
!
"#$%&!'()*+,-./*!'.0/.)),/.0!1+23!!45567!45583!9((!,/0:+;!,);),<)23!
Information in this document is subject to change without notice. No part of this document
may be reproduced or transmitted in any form or by any means, electronic or mechanical,
without express written permission of CROW Electronic Engineering Ltd..
Document Version 1.00.015
Runner Series
P/N 7103585 Rev. C. Y.A/Y.S January 2008

i
CONTENTS
OVERVIEW ........................................................................................................................... 6
CONNECTION DIAGRAMS......................................................................................................... 6
RUNNER IN MINI BOX SPECIFICATION :............................................................................ 7
RUNNER COMPACT /FDX SPECIFICATION :........................................................................ 9
INPUT OPTIONS ................................................................................................................ 11
DIFFERENT INPUT CONFIGURATIONS ........................................................................................ 11
ZONE WIRING EXAMPLES ...................................................................................................... 12
OTHER INPUTS .................................................................................................................. 14
OUTPUTS............................................................................................................................ 16
DESCRIPTION OF OUTPUTS.................................................................................................... 16
KEYPAD PORT.................................................................................................................... 16
EXPANSION PORT ............................................................................................................... 17
ACCESSORIES .................................................................................................................... 18
RADIO RECEIVER................................................................................................................ 18
VOICE BOARD.................................................................................................................... 18
NIGHT MONITOR KEYPAD ..................................................................................................... 25
KEYPAD INDICATORS........................................................................................................ 27
LED KEYPAD..................................................................................................................... 27
LCD KEYPAD................................................................................................................... 32
KEYPAD ADDRESS ASSIGNMENT & INSTALLATION.......................................................... 34
LED KEYPAD..................................................................................................................... 34
LCD KEYPAD................................................................................................................... 35
ADJUSTING BACKLIGHTING AND BUZZER TONE............................................................................ 36
LCD KEYPAD “LOCAL EDIT” MODE .................................................................................... 37
LCD KEYPAD..................................................................................................................... 37
PROGRAM MODE ACCESS .................................................................................................. 44
ACCESSING PROGRAM MODE.................................................................................................. 44
EXITING PROGRAM MODE ..................................................................................................... 45
SPECIAL KEYPAD FUNCTIONS........................................................................................... 55
ARMING OR DISARMING TWO AREAS AT A KEYPAD ....................................................................... 55
LCD QUICK VIEW MODE ...................................................................................................... 55

RUNNER - Installation & Config. Guide CONTENTS
ii
TOGGLE CHIME MODE ON/OFF .............................................................................................. 56
SEND MANUAL TEST CALL ..................................................................................................... 56
MANUALLY ANSWER AN INCOMING CALL.................................................................................... 56
PROGRAMMING USERS ..................................................................................................... 57
USER CODES ..................................................................................................................... 57
USER CODE TYPE ............................................................................................................... 58
USER AREAS ..................................................................................................................... 58
USER ACCESS OPTIONS ........................................................................................................ 59
USER CODE PRIVILEGES -USER PROGRAM OPTIONS ..................................................................... 60
RADIO USER TYPE -PENDANT TYPE ......................................................................................... 60
RADIO USER PRIVILEGES –PENDANT OPTIONS ............................................................................ 61
USER TIME ZONE ASSIGNMENTS ............................................................................................. 61
USER TO KEYPAD ASSIGNMENT –USER DEVICES .......................................................................... 62
RADIO PENDANT PANIC BEEPS TO KEYPAD................................................................................. 62
USER TO OUTPUT MASK ....................................................................................................... 62
USER CAN TURN AN OUTPUT ON AND OFF ............................................................................... 63
RADIO PENDANT PANIC ALARM TO OUTPUT ............................................................................... 64
LEARN FIND AND DELETE RADIO KEY CODES AND TAGS ................................................................ 64
MISCELLANEOUS PANEL & CLOCK SETTINGS ................................................................... 67
INSTALLER CODE ................................................................................................................ 67
DURESS DIGIT................................................................................................................... 67
DIAL REPORTING DELAY ....................................................................................................... 67
RADIO ZONE SUPERVISED TIMER ............................................................................................ 67
TWO TRIGGER TIMER .......................................................................................................... 68
MAINS FAIL REPORTING DELAY .............................................................................................. 68
RECEIVER FAIL DELAY/TIMER ................................................................................................ 68
UPLOAD/DOWNLOAD SITE CODE NUMBER ................................................................................. 68
TEMPORARY OUTPUT DISABLE................................................................................................ 68
MISCELLANEOUS INSTALLER AND PANEL OPTIONS ........................................................................ 69
HIDE USER CODES -USER OPTIONS..................................................................................... 70
SETTING TIME,DATE AND DAYLIGHT SAVING ............................................................................ 73
DAYLIGHT SAVING (DLS) SETTINGS ........................................................................................ 73
OUTPUTS............................................................................................................................ 74
OUTPUT OPTIONS .......................................................................................................... 74
OUTPUT ON DELAY,PULSE,RESET AND CHIME TIMES .................................................................. 77
OUTPUT VOICE BOARD REMOTE CONTROL START MESSAGES .......................................................... 78
UN-MAP AN OUTPUT ........................................................................................................... 78

RUNNER - Installation & Config. Guide CONTENTS
iii
ASSIGNING A TIME-ZONE TO AN OUTPUT .................................................................................. 78
AREAS ................................................................................................................................ 79
AREA ARM AND SPECIAL FUNCTION OPTIONS ............................................................................. 79
AREA ARM/STAY PULSE &CHIRPS TO OUTPUTS .......................................................................... 81
MONITORING ACCOUNT CODE NUMBER .................................................................................... 85
REMOTE ARM/DISARM DTMF CODE &START VOICE MESSAGE ....................................................... 85
AREA DELINQUENCY DELAY ................................................................................................... 86
AUTOMATIC ARM/DISARM TIME ZONE ...................................................................................... 86
KEYPADS............................................................................................................................ 87
KEYPAD AREA ASSIGNMENT ................................................................................................... 87
KEYPAD BUTTON OPERATIONS,MISC.BEEPS AND LED CONTROL .................................................... 87
KEYPAD ARM,STAY,AAND BBUTTON OPTIONS ......................................................................... 89
KEYPAD TO OUTPUT MASK .................................................................................................... 93
<CONTROL>BUTTON TO OUTPUT MASK .................................................................................. 93
KEYBOARD PANIC,FIRE AND MEDICAL ALARMS TO OUTPUTS AND KP BUZZER ..................................... 95
KEYPAD CHIME TIMER.......................................................................................................... 97
PROXIMITY READER OPTIONS ................................................................................................ 97
KEY-SWITCHES.................................................................................................................. 99
KEY-SWITCH AREA ASSIGNMENT............................................................................................. 99
KEY-SWITCH ARM/DISARM OPTIONS ....................................................................................... 99
ZONES.............................................................................................................................. 101
ZONE AREA ASSIGNMENT.................................................................................................... 101
ZONE ALARM TYPE OPTIONS................................................................................................ 101
ZONE EOL (END-OF-LINE)OPTIONS AND VIBRATION SETTINGS ................................................... 104
RADIO ZONE DETECTOR TYPE .............................................................................................. 106
ZONE ALARMS TO OUTPUT AND KEYBOARD BUZZER MAPPING ....................................................... 107
ZONE CID REPORT CODES.................................................................................................. 111
ARMED AND STAY MODE ENTRY DELAY TIMES .......................................................................... 112
ZONE WATCH DOG TIMER .................................................................................................. 112
LEARN/FIND AND DELETE RADIO ZONE CODES ......................................................................... 113
TIME ZONES..................................................................................................................... 115
HOLIDAYS ...................................................................................................................... 115
TIME ZONE DAYS ............................................................................................................. 115
TIME ZONE START AND STOP TIMES ...................................................................................... 116
=>911'$ ........................................................................................................................... 117
DIALLER OPTIONS ............................................................................................................ 117

RUNNER - Installation & Config. Guide CONTENTS
iv
AUTO ANSWER RING COUNT ................................................................................................ 119
TEST CALL OPTIONS .......................................................................................................... 119
KEYPAD LISTEN-IN AND OUTPUT OPTIONS .............................................................................. 119
DIALLING PRE-FIX NUMBER................................................................................................. 120
KEYPAD PANIC,FIRE AND MEDICAL ALARMS CID REPORT CODE.................................................... 120
OUTPUT,MICROPHONE &VOICE KISS OFF DTMF REMOTE CODES ................................................ 121
MISCELLANEOUS VOICE REPORTING MESSAGE NUMBERS ............................................................. 123
TELEPHONE NUMBERS .................................................................................................... 124
PROGRAMMING TELEPHONE NUMBERS .................................................................................... 124
REPORTING FORMATS ........................................................................................................ 124
TELEPHONE NUMBER REPORT OPTIONS......................................................................... 126
MAXIMUM DIAL RE-TRIES PER TELEPHONE NUMBER ................................................................... 127
DIAL PROGRESS OPTIONS ................................................................................................... 127
CALL DIVERT NUMBERS &OPTIONS....................................................................................... 129
CALL DIVERT NUMBERS &OPTIONS....................................................................................... 130
4+2 PROGRAM OPTIONS ................................................................................................ 132
USING THE 4+2 CODES ..................................................................................................... 132
MAINS/BATTERY/TAMPER/DURESS &ARMING 4+2 CODES .......................................................... 133
SIA ALARM REPORT CODES................................................................................................. 134
DIAGNOSTIC & DEFAULT OPTIONS................................................................................. 136
DISPLAY SOFTWARE VERSION,KEYPAD NUMBER AND KEYPAD AREAS .............................................. 136
DISPLAY ACTIVE TIME ZONES &BATTERY VOLTAGE ................................................................... 136
START WALK TEST MODE ................................................................................................... 136
READ OR WRITE TO THE DTU.............................................................................................. 137
RESTORE DEFAULTS .......................................................................................................... 137
CLEAR MEMORY BUFFER ..................................................................................................... 137
START A CALL-BACK CALL ................................................................................................... 137
USER PRIVILEGES CHART ............................................................................................... 139
TELECOM INTERFACE ......................................................................................................... 140
CONTACT ID CODE SUMMARY......................................................................................... 142
SIA REPORTING CODE SUMMARY................................................................................... 144
SOFTWARE CHANGE UPDATE NOTICE............................................................................. 146
RUNNER 8/16 QUICK START GUIDE ............................................................................... 150
RUNNER 8/16 CONFIGURATION SUMMARY GUIDE ....................................................... 152
USERS ........................................................................................................................... 153

RUNNER - Installation & Config. Guide CONTENTS
v
MISCELLANEOUS PANEL &CLOCK SETTINGS............................................................................. 158
OUTPUTS ....................................................................................................................... 161
AREAS ........................................................................................................................... 163
KEYPADS ........................................................................................................................ 166
KEY-SWITCHES ................................................................................................................ 172
ZONES........................................................................................................................... 172
TIME ZONES ................................................................................................................... 180
DIALLER......................................................................................................................... 181
TELEPHONE NUMBERS........................................................................................................ 183
MISCELLANEOUS 4+2 PROGRAM OPTIONS............................................................................... 187
PANEL DIAGNOSTIC &DEFAULT OPTIONS................................................................................ 188
CROW ELECTRONIC ENGINEERING LTD. (CROW)WARRANTY POLICY CERTIFICATE ............ 189
HOW TO CONTACT US...................................................................................................... 190

6
Overview
Connection Diagrams
Runner 8
The Runner 8 board is installed in three different enclosures:
!PW-housing
!COMPACT housing - has a 20VA transformer
!MINI-housing – has a 25VA transformer
Battery Spec.: Sealed Lead-Acid Rechargeable Battery 12V/1.3Ah up to 12V /7Ah in the
Mini and PW-housings.
Battery Cutoff Level: (When AC mains fails) : 10 ± 0.3V

RUNNER - Installation & Config. Guide
7
Runner In Mini Box Specification :
Operating Voltage : 230V AC ,50Hz.
Transformer: 25VA
Fuse: TD 100mA /250V AC (SIBA Type 179120).
Back Up Battery: Lead Acid Battery 12V /1.3A up to 12V /7Ah
Battery Dynamic Test : Every 6 seconds.
Current Consumption:
Standby:
C.P = 40mA
Keypad =60-130mA Depend on Keys and Display backlight intensity.
Maximum Current Drain allowed from the C.P:
Standby: 400mA
Alarm: 900mA.
Inputs:
x!8 wired Zones 1-8 (Full Programmable).
x!Programmable Wired Tamper Input.
Outputs:
Output#1&2: Open Collector Type , 0.75A @12V DC..
Output#3&4: Open Collector Type , 0.5A @12V DC.
Output#4: Relay Change Over Contacts Capability: 2A @12V DC.
Protections:
12V Out : Each output power protected by reset able Fuse 0.75A.
Battery Out: Protected by reset able Fuse 2.5A.
POS : Protected by reset able Fuse 0.75A.
Physical:
Size:
Weight:
Operating Temperature: -10-50ºC.
Storage Temperature: -20 - 60ºC.
Humidity: 85% relative humidity @ 30ºC

RUNNER - Installation & Config. Guide
8
$?..),!#-@AB*+CD=E!
The Runner FDX board is installed inside the Compact Box and together with a 20VA
transformer.

RUNNER - Installation & Config. Guide
9
Runner Compact /FDX Specification :
Operating Voltage : 230V AC ,50Hz.
Transformer : 20VA
Fuse: TD 100mA /250V AC (SIBA Type 179120).
Back Up Battery: Lead Acid Battery 12V /1.3A up to 12V /7Ah
Battery Dynamic Test : Every 6 seconds.
Current Consumption:
Standby: C.P = 40mA ,
Keypad =60-130mA,
Voice Board FDX=50-150mA
Alarm : 260mA.
Maximum Current Drain allowed from the C.P:
Standby: 300mA
Alarm: 800mA.
Inputs:
x!8 wired Zones 1-8 (Full Programmable).
x!Programmable Wired Tamper Input.
Outputs:
Output#1: Internal Piezo with Driver connected
Output#2: Open Collector Type , 0.75A @12V DC..
Output#3&4: Open Collector Type , 0.5A @12V DC.
Output#4: Relay Change Over Contacts Capability: 2A @12V DC.
Protections:
12V Out : Each output power protected by reset able Fuse 0.75A.
Battery Out: Protected by reset able Fuse 2.5A.
POS : Protected by reset able Fuse 0.75A.
Physical:
Size:
Weight:
Operating Temperature: 0-50ºC.
Storage Temperature: -10 - 55ºC.
Humidity: 85% relative humidity @ 30ºC

RUNNER - Installation & Config. Guide
10

RUNNER - Installation & Config. Guide
11
Input Options
Different Input Configurations
The Runner 8 has nine separate programmable monitored analogue inputs.
These are:
!Eight programmable multi-state detection inputs
!One programmable tamper input (with optional Key-switch functions)
The input connector block is located on the board.
NOTE
Each input must be terminated with the appropriate value or combination of
End-Of-Line resistors, even if the input is unused.
Zone Inputs
Each of the Eight programmable zone inputs can be assigned one of the following End of Line
(EOL) configuration options,
Zone EOL Type (P125E) Input Resistor Comments
0 (Short circuit) Loop EOL
1 1k (Brown, Black, Red) Single EOL
2 1k5 (Brown, Green, Red) Single EOL
3 2k2 (Red, Red, Red) Single EOL
4 3k3 (Orange, Orange, Red) Single EOL
5 3k9 (Orange, White, Red) Single EOL
6 4k7 (Yellow, Violet, Red) Single EOL
7 5k6 (Green, Blue, Red) Single EOL
8 6k8 (Blue, Grey, Red) Single EOL
9 10k (Brown, Black, Orange) Single EOL
10 12k (Brown, Red, Orange) Single EOL
11 22k (Red, Red, Orange) Single EOL
12 2k2 Tamper, 4k7 Zone Zone & Tamper
13 3k3 Tamper, 6k8 Zone Zone & Tamper
14 2k2 Tamper, 4k7 Low Zone,
8k2 High Zone Zone Doubling with Tamper
15 4k7 Low Zone, 8k2 High Zone Zone Doubling without tamper

RUNNER - Installation & Config. Guide
12
Zone Wiring Examples
Type 0 (Short/Loop Circuit)
!
Type 1-11 (Single EOL no Tamper)
"#$!%&'(')*+
,-.
,-#
/01&!2322 45(678&!"#$!,-#!/9:1&+;!
!
Type 12-13 (Single Zone with Tamper)
!
Type 14 (Zone Doubling with Tamper)
!

RUNNER - Installation & Config. Guide
13
Short circuit loop, No EOL
!
2k2 EOL, No Tamper
!
Type 12 Configuration
Alarm & Tamper monitoring (contacts can be N/C or N/O).
!
Type 15 Configuration
Zone Doubling, NO Tamper (contacts can be N/C or N/O).
!

RUNNER - Installation & Config. Guide
14
Wiring a PIR Detector (N/C) for Alarm & Tamper
Monitoring
!
Other Inputs
Tamper
A 24Hr tamper circuit is available for monitoring system tampers. This Tamper circuit is
programmable as either normally closed loop or 2k2 EOL supervision (the default is normally
closed loop). Any Tamper alarms on this input are mapped to alarm outputs in the same
manner as for detection zones 1-16. Using Dual-End-of-Line resistors (Refer to Zone Type 15
on Page 13) the Tamper input can also provide two key-switches. The Low key-switch (4k7
resistor) is Key-switch 1 while the High key-switch (8k2 resistor) is Key-switch 2.
In addition to the Zone & Tamper inputs, you will find the following additional inputs on the
control PCB;
AC
Connect the two low voltage wires (no polarity) from the transformer to the terminals
marked AC on the PCB. The panel includes a mains transformer rated at 15.5VAC.
Earth - not used
In case of using metal box connect the mains earth to the appropriate terminal on the mains
terminal block in the control box cabinet. Also connect a lead from this earth point to the
terminal marked with the Earth symbol (next to AC terminals) on the panel PCB.
Battery
Connect a sealed lead acid rechargeable 12VDC battery to the terminals labelled red and
black on the control panel being careful to observe the correct polarity. The maximum
recommended battery capacity is 7 amp hours. Battery charge current at these terminals is
limited to 260mA maximum. The battery connection is protected against short circuits by a
thermal fuse (F1).
Line In
These terminals are used to connect the panel to the incoming telephone line. The dialler
uses this line for reporting alarm events. An ADSL filter will be required before the Line in
terminal, in case there is ADSL in the building.

RUNNER - Installation & Config. Guide
15
Line Out
These terminals are used to connect telephones and other communication equipment to the
incoming phone line via the panel dialler circuit. The telephone line is passed through the
controller to ensure that the line is available to the controller when it is required.

16
Outputs!
Description of Outputs
12 Volt Outputs
There are three 12VDC outputs on the panel PCB. These 12 volt outputs are regulated and
Thermal fuse protected against short circuits. The accessory outputs are marked 12V and
0V, while the keypad buss 12V supply is labelled “POS” & “NEG”. The 12V outputs are
supplied by thermal fuses F2 & F3. The maximum total load that allowed to be drawn from
all of the 12V outputs during an alarm is 0.9A.
Outputs 1 & 2
These fully programmable, high current, open drain (high-going-low) type FET outputs
capable of switching up to 1.5A @ 12VDC. These 2 outputs are normally set as switched
outputs, providing power for 12V sirens or piezos. If required, these outputs can be
programmed to be siren outputs designed to drive an 8 ohm 10 watt horn speaker on each
output (see P37E option 1). Also if a horn speaker is connected to Output #1 you may
select (Refer to P175E 7E program address) the listen-in feature to this output as well so
that the dialling sequence can be heard at the speaker.
Output 3 & 4
This is a low current, open drain (high-going-low) type FET outputs capable of switching up
to 500mA. Like Outputs 1 & 2 it is fully programmable. You cannot use with option 1 at
P37E on outputs 3 & 4.
NOTE
Connecting devices which draw current in excess of 500mA to output 3/4 can
damage the output.
Relay Out
This is a relay is related to Output 4 with single pole changeover contacts. If required, the
Common (C) contact of the relay is connected by default to GND via JUMPER, the jumper can
be selected to 12V or removed.
Keypad Port
The terminals marked POS, NEG, CLOCK, & DATA make up the communications port which
the keypads and other intelligent field devices use to talk to the controller. The terminals are
connected to corresponding terminals on the remote devices. The "line" terminal is only
used by the keypads and utilises a fifth wire to provide a communicator “listen-in” facility.
This feature is particularly useful when servicing monitoring faults. The keypad 12V supply
(POS,NEG) is protected by fuse F3.

RUNNER - Installation & Config. Guide
17
Expansion Port
The expansion port allows connection of the RS232 serial board, 90 second Voice Board,
DTMF Board or EEPROM data transfer board (DTU). The serial board allows direct connection
of a PC running the Upload/Download software. The 90 second voice board allows voice
messages to be programmed for monitoring purposes. The Voice & DTMF boards allow
Touchtone Code remote control via a telephone. The DTU allows for program “Cloning” from
one panel to another.

18
Accessories
Radio Receiver
The panel can have wireless capability via the FW-RCVR receiver module. The receiver will
add wireless capability to your system in the form or wireless PIR detectors, Wireless Radio-
key transmitters and wireless reed switch transmitters.
The FW-RCVR connects to the same communications port as the keypads. The FW-RCVR is
available in 3 frequencies, 916MHz,433MHz,868MHz. Multiple FW-RCVR can be connected to
the panel to increase the coverage range if desired.
The red LED fitted to the FW-RCVR receiver will flash at 1 second intervals when in "Learn"
mode (see P18E & P164E). The LED will also turn on when it is receiving an actual radio
transmission (On Steady).
Voice Board
The panel can also be fitted with a 90 second Voice Board module. The Voice board stores
either alarm event messages for Voice dial monitoring and /or status messages for use with
Command Control. The panel Voice Board are installed directly onto the motherboard via the
SERIAL socket.
Installation procedure for the Voice Board module is as follows.
1. Power-down the panel fully before starting the installation procedure.
2. Carefully plug the Voice Board into the SERIAL socket (it will only fit in one direction).
3. Power-up the panel.
Speech message programming
Once you have installed the Voice Board you can record your personalised speech messages
into the module with the speech programmer (the programmer plugs onto the 10 way strip
connector on the voice board).
Before programming your voice messages you should work out a list of the messages you
would like to be sent for each alarm type and write them down in order, giving them a
message number. These messages should then be recorded in the same order they are
written down so you know what the message number is letter when programming alarms to
messages.
To record your messages once the programmer is installed, first press the reset button on
the side of the Voice Board, then hold the programmer about 10 cm away from the mouth
and speak clearly at normal level into the microphone while holding down the "REC" button.
When you reach the end of your message release the REC button. (NOTE: Each individual
message must be longer that 2 seconds duration). When recording your voice alarm
message, you must ensure that you clearly identify the origin of the call. You can play the
message back through the programmer by first pressing the reset button then by pressing
the "PLAY" button momentarily. Because the panel can address many individual voice
messages you must store individual messages at what is known as recording slots within the
Voice Board. These recording slots are recorded sequentially, one message starting where
the other finishes. Every time you press and release the REC button on the programmer,
you create an end of message marker. These markers are used to define the recording slots
within the Voice Board and can be of varying length according to each message duration.
