Crux SWRHN-62L User manual

- Retains factory features in select Honda vehicles while functioning with an aftermarket radio.
- Pre-programmed to retain factory Steering Wheel Controls.
- Retains Factory Auxiliary Input.
- EIA color coded wiring for easy installation.
1. Does not support amplified systems.
2. Does not retain Rear Seat Entertainment system (RSE).
3. Does not retain factory navigation system.
SWRHN-62L MODULE
SWRHN-62L HARNESS
Rev.090117
17
1 / 2

SETTING THE HONDA SWC
SETTING THE AFTERMARKET RADIO BRAND
With the key in the off position, set the DIP switches to the corresponding radio listed below.
3.5MM SWC CABLE
Use the proper 3.5MM to 4-Pin SWC cable for the aftermarket radio you are using.
OPTION A is used for ALPINE, CLARION, (JVC and KENWOOD units will use the Blue/Yellow wire).
OPTION B is used for BOSS, DUAL, FAHRENHEIT, JENSEN, POWER ACOUSTIK, PIONEER, SONY and
SOUNDSTREAM units.
NOTE: Cap or insulate the 3.5mm plug or Blue/Yellow wire if not being used.
BOSS Radio SWC Wiring Connection
HONDA
2008 –2012 Accord DX/EX/LX*
2011 –2013 CRZ
2009 –2013 Fit
2008 –2011 Odyssey
2009 –2013 Pilot*
2009 –2013 Ridgeline
*Does NOT retain factory radio display.
rev.090117
2 / 2
