Custom Dynamics® Dynamic LED Fork Reflectors
Installation Instructions
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
04-2020
We thank you for purchasing the Custom Dynamics® Dynamic LED
Fork Reflectors. Our products utilize the latest technology and high
quality components to ensure you the most reliable service. We offer
one of the best warranty programs in the industry and we back our
products with excellent customer support, if you have questions be-
fore or during installation of this product please call Custom Dynam-
ics® at 1(800) 382-1388.
Package Contents:
- LED Fork Reflector (pair)
- BCM Adapter Harness (2)
- Wire Tie Wrap (10)
- Isopropyl Alcohol Wipe (1)
Part Numbers:
CD-FORK-BCM-AB CD-FORK-BCM-AC
CD-FORK-BCM-SB CD-FORK-BCM-SC
Warning: Disconnect negative battery cable from battery; refer to owner’s
manual. Failure to do so may result in electrical shock, injury, or fire. Secure
negative battery cable away from positive side of battery and all other posi-
tive voltage sources on vehicle.
Safety First: Always wear appropriate safety gear including safety glasses
when performing any electrical work. It is highly recommended that safety
glasses be worn throughout this installation process. Be sure vehicle is on
level surface, secure and cool.
Important: This product is designed and intended for use as auxiliary light-
ing only. It is NOT intended to replace any original equipment lighting in-
stalled on the vehicle and should not be used for that purpose. This product
must be wired so that it does not interfere with any original equipment light-
ing.
ATTENTION
Please read all Information below before Installation
Batwing Fitment: 2014-2020 Harley-Davidson® Electra
Glide Ultra Classic (FLHTCU), Electra Glide Ultra Classic
Low (FLHTCUL), Ultra Limited (FLHTK), Ultra Limited Low
(FLHTKL), Limited CVO™ (FLHTKSE), Street Glide (FLHX),
Street Glide Special (FLHXS), Street Glide CVO™
(FLHXSE), and 2019-2020 Electra Glide Standard (FLHT).
2014-2020 Harley-Davidson® TriGlide® Models.
Instructions Page 1
Road Glide Fitment: 2015-2020 Road Glide (FLTRX),
Road Glide Special (FLTRXS), Road Glide Limited (FLTRK),
Road Glide Ultra (FLTRU), Road Glide CVO (FLTRXSE),
Road Glide Ultra CVO (FLTRUSE)
Instructions Page 4
Batwing Installation:
1. Remove the 1/2” nuts that secure the turn signal as-
sembly to the fork shown in Picture 1. Pull assembly
away from the fork to reveal the black wiring connect-
or as shown in Picture 2.
2. Unplug the connector by pushing in on the tab located
on the male side of the connection as shown in Pic-
ture 3. Push the tab and pull apart both sides at the
same time. Remove the turn signal assembly from the
bike completely.
1

Installation Instructions - Page 2
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 8:30AM-5:30PM EST
04-2020
3
2
4
3. Repeat steps 1 and 2 on the opposing side turn signal assembly.
4. Remove the 3 top T27 Torx Bolts from the outer fairing as shown in Pic-
ture 4. Remove the windshield and store it in a safe place for reinstalla-
tion later.
5. Reinstall the center T27 Torx Bolt only that was removed in Step 4.
Lightly tighten the center bolt to secure the fairing while you remove the
remaining 4 inner fairing bolts.
6. Remove the 2 T27 Torx bolts from the left and the right side of the inner
fairing as shown in Picture 5. Save the bolts for reinstallation.
7. While standing in front of the bike and holding the fairing, remove the
center outer fairing T27 Torx bolt and pull the fairing slightly away from
the bike.
8. With the fairing slightly pulled away from the bike, disconnect the con-
nector from the headlamp. Lay the fairing on a protected flat surface to
prevent damage.
9. Using one of the BCM Adapter harnesses, plug the black male connect-
or of the pass-through into the female connector of the turn signal wiring
harness.
10. Push the female 4 pin JAE connector of the pass-through harness into
the hole in the fork. Plug the 4 pin JAE connector from the turn signal
into the Pass-through harness, then reinstall the turn signal onto the fork
frame and secure with the original nuts. Repeat for the other side.
11. On the left side BCM Adapter Harness, plug the 2 pin female connector
into the male 2 pin connector of the right side BCM Adapter Harness.
12. Locate the 2 pin fairing connector to the lower left (looking at the fairing)
of the fairing vent. See Photo 6.
13. Remove the connector plug from the 2 pin fairing connector on the mo-
torcycle by pushing the center tab in and pulling the plug out. Save the
plug for reinstallation later. Refer to Photo 7.
14. Plug the BCM Adapter Harnesses into the fairing 2 pin fairing connector,
ensure that it snaps in. Make sure to reinstall the plug removed in the
previous step into the right side BCM Adapter Harness pass-through
connector.
15. Using the provided wire ties, secure the BCM Adapter Harnesses to pre-
vent the wires from being damaged during fairing installation.
16. Remove the OEM fork reflector from the lower fork leg. Clean the reflec-
tor area removing any debris or tape from the OEM Reflector.
17. Wipe the reflector area down with the provided Isopropyl Alcohol Wipe
and let dry.
18. Remove the protective red film from the back of the LED Fork Reflec-
tors. Align the LED Fork Reflectors in the reflector area and press into
place. The LED Fork Reflector should be mounted in the same location
as the OEM reflector with the wire exiting the top, rear side of the light.
5

Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
01/2020
Installation Instructions - Page 3.
2 Pin Connector
Fairing Vent
6
Plug Tab:
Push In
2 Pin Connector Plug
7
7
Installation:
19. Route the wiring harness from each LED Fork Reflectors to the
associated side BCM Adapter Harnesses in the fairing and con-
nect to the Female JAE Connector.
20. Using the provided wire ties, secure the LED Fork Reflectors wir-
ing harnesses to prevent the wires from being damaged.
21. Reinstall the fairing and windshield in the reverse order that it
was removed. NOTE: THE 4 INNER FAIRING BOLTS ARE
TWO DIFFERENT LENGTHS! The 2 longer bolts go in the top
holes and the 2 shorter bolts go in the bottom holes of the inner
fairing.
22. Reconnect the negative battery cable to the battery and reinstall
the seat.
23. Perform a BCM sync by turning the ignition on, turn the 4 way
hazards on, turn the ignition off. Allow the 4 way hazards to run
for 3-4 minutes. Turn the ignition on. Turn the 4 way hazards off.
Turn the ignition off.
24. Test operation of all lighting in all modes before riding.

Road Glide® Installation:
1. Remove the 4 windshield fasteners, Picture 10. Lift the
windshield up to remove. Store the windshield in a safe
place to prevent damage.
2. Once the windshield fasteners and windshield are re-
moved, you will need to remove the vent. The vent is
secured to the fairing by clips. Position yourself in the
front of the motorcycle and lift straight up on the vent to
release. Refer to Photo 11.
3. Locate both the left and right 3 pin turn signal connect-
ors. Press down on the releasing tab of the JAE connect-
or to disconnect. Refer to Photo 12.
10
11
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
04-2020
Installation Instructions - Page 4.
12
4. Remove the 3/16” socket Allen head bolts from
the outside of each turn signal housing. Refer to
Photo 13.
5. Remove both left and right speaker grilles on the
inner fairing.
6. Once the speaker grilles are removed, Locate
and remove the T-27 torx bolts in each corner of
the speaker housing. Refer to Photo 14.
13
14

Installation Instructions - Page 5
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
04/2020
7. Locate and remove the lower T-25 screw on each
side of the inner fairing. Refer to Photo 15.
8. Remove the outer fairing and set to side.
9. Using one of the BCM Adapter harnesses, plug the
black male connector of the pass-through into the
female connector of the turn signal wiring harness.
10. Leave the female 4 pin JAE connector of the pass-
through harness disconnected until the fairing is
reinstalled. Repeat for the other side.
11. On the left side BCM Adapter Harness, plug the 2
pin female connector into the male 2 pin connector
of the right side BCM Adapter Harness.
12. Locate the 2 pin fairing connector in the upper left
of the fairing. See Photo 16.
15
3. Remove the connector plug from the 2 pin
fairing connector on the motorcycle by push-
ing the center tab in and pulling the plug out.
Save the plug for reinstallation later. Refer to
Photo 7.
13. Plug the BCM Adapter Harnesses into the
fairing 2 pin fairing connector, ensure that it
snaps in. Make sure to reinstall the plug re-
moved in the previous step into the right side
BCM Adapter Harness pass-through connect-
or.
14. Using the provided wire ties, secure the BCM
Adapter Harnesses to prevent the wires from
being damaged during fairing installation.
15. Remove the OEM fork reflector from the low-
er fork leg. Clean the reflector area removing
any debris or tape from the OEM Reflector.
16. Wipe the reflector area down with the provid-
ed Isopropyl Alcohol Wipe and let dry.
17. Remove the protective red film from the back
of the LED Fork Reflectors. Align the LED
Fork Reflectors in the reflector area and press
into place. The LED Fork Reflector should be
mounted in the same location as the OEM
reflector with the wire exiting the top, rear
side of the light.
18. Route the wiring harness from each LED Fork
Reflectors to the associated side BCM Adapt-
er Harnesses in the fairing and connect to the
Female JAE Connector.
19. Using the provided wire ties, secure the LED
Fork Reflectors wiring harnesses to prevent
the wires from being damaged.
20. Reinstall the fairing and windshield in the re-
verse order that it was removed
21. Reconnect the negative battery cable to the
battery and reinstall the seat.
22. Perform a BCM sync by turning the ignition
on, turn the 4 way hazards on, turn the igni-
tion off. Allow the 4 way hazards to run for 3-4
minutes. Turn the ignition on. Turn the 4 way
hazards off. Turn the ignition off.
23. Test operation of all lighting in all modes be-
fore riding.
16
