We thank you for purchasing the Custom Dynamics® ProBEAM® Scout Rear Turn Signals! Our LEDs oer maintenance free
service and higher visibility. Our ProBEAM® product line ulizes the latest technology and automove grade components to
ensure the highest level of reliable service. Custom Dynamics® oers one of the best warranty programs and customer sup-
port in the industry. If you have any quesons during the installaon of this product please call us at 1(800) 382-1388.
Custom Dynamics® ProBEAM®
Scout Rear Turn Signal
Installaon Instrucons
Package Contents:
- ProBEAM® Scout Rear Turn Signals (Pair)
- Instrucons
Fitment: 2015-2022 Indian® Scout & Scout Sixty (Does
NOT t Scout Bobber models).
Custom Dynamics® ProBEAM® Scout Turn Signals can ONLY be used with
ProBEAM® Bullet Style Turn Signal Lenses. Bullet Bezel Turn Signal
Adapters are not compable with ProBEAM® Scout Turn Signals.
Part Number: PB-SCOUT-RR-BR PB-SCOUT-RR-BS
PB-SCOUT-RR-CR PB-SCOUT-RR-CS
US Patents: D830,597 D830,596
Chinese Patents: ZL201830045649.4, ZL201830409102.8
Warning: Disconnect negave baery cable from baery; refer to owner’s manual.
Failure to do so may result in electrical shock, injury, or re. Secure negave
baery cable away from posive side of baery and all other posive voltage
sources on vehicle.
Safety First: Always wear appropriate safety gear including safety glasses when
performing any electrical work. It is highly recommended that safety glasses be
worn throughout this installaon process. Be sure vehicle is on level surface, se-
cure and cool.
NOTE: If installed with a GEN-SMART-TPU-SCOUT module, the turn signal run
funcon will need to be turn o on the GEN-SMART-TPU-SCOUT module. Refer to
the GEN-SMART-TPU-SCOUT module programming secon of the GEN-SMART-TPU
-SCOUT module instrucons.
NOTE: Turn Signals funcon as run and turn only.
ATTENTION
Please read all Informaon below before Installaon
12-2021
Installaon:
1. Remove motorcycle seat and disconnect the negave baery ca-
ble from the baery. Consult your owners manual if unsure of this
process.
2. Locate the rear lighng harnesses and connectors behind the rear
fender as shown in Photo 1. Cut the wire es to free the rear
lighng wiring harnesses .
1

Quesons? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
Installaon Connued:
3. Disconnect the Le and Right rear turn signal har-
nesses.
4. Remove the le and Right rear turn signal mounng
bolt and remove the turn signal housings from the
bike. Refer to Photo 2.
5. Install the new ProBEAM turn signals using the OEM
bolt removed in Step 4.
6. Connect the 2 pin connecter from each turn signal
housing to bike’s associated le or right rear turn
signal connecter.
7. Locate the black 2 pin license plate light connector.
See photo 3.
8. Connect the black 2 pin connecters from each rear
turn signal in line with the license plate connector.
See Photo 4.
Installation Instructions - Page 2
04-2020
2
9. Using the provided wire es, secure the wiring harnesses to
prevent them from becoming frayed or damaged by the rear
re under the fender. Refer to Photo 1.
10. Reconnect the negave baery cable to the baery and install
the seat.
11. Test all lighng for proper operaons before riding
4
3
Le
Running
Light
Right
Running
Light
License Plate
Light Female
Connector
License Plate
Light Male
Connector
