Custom Dynamics® Smart Triple Play®
Installation Instructions
We thank you for purchasing the Custom Dynamics® Smart Triple
Play®. Our products utilize the latest technology and high quality
components to ensure you the most reliable service. We offer one of
the best warranty programs in the industry and we back our prod-
ucts with excellent customer support, if you have questions before
or during installation of this product please call Custom Dynamics®
at 1(800) 382-1388.
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
04/2019
Package Contents:
- Smart Triple Play® Module (1)
- Instructions
Part Number: GEN-SMART-TPU - IND
US Patent 8,588,997
Fits: 2014-2019 Indian® Chief®, Springfield™ and Roadmaster® Models, 2014-
2019 Chieftain® Classic & Chieftain® Elite 2014-2018 Chieftain®, Chieftain® Dark
Horse, & Chieftain® Limited (DOES NOT fit Scout®)
Important: For this system, you must use RED rear turn signal lens or lamps.
Important: Unit draws no current when the ignion is in the o posion.
Important: This system is designed to work with single intensity rear turn sig-
nals, if you do not have single intensity rear turn signals do not install this mod-
ule. Contact Technical Support.
Important: Remove any exisng Run-Brake-Turn or similar modules prior to
installing this unit.
Cauon: Never install a load equalizer with the use of this unit. Your model has a
CanBus electrical system and is not needed.
Cauon: Never install a trailer adapter, trailer harness or trailer controller on
the output side of this unit, a trailer adapter, harness or controller must be in-
stalled on the input side of this unit.
Cauon: This unit is designed for a maximum load of 27 was per channel. Do
no exceed 27 was per le turn signal output, 27 was per right turn signal
output, and 27 was per brake signal output. Overloading unit could cause
damage to the unit and cause the unit to malfuncon.
Important: Dial and switches should be maneuvered by hand only. Do not use
any tool such as a screwdriver that could damage waterproof covers.
Important: Module must be secured aer installaon. Find safe area away from
any moving parts and out of the way of normal operaon of the bike. Use Tie-
wraps, tape, or other means to secure. Custom Dynamics® is not liable for dam-
age to the module or the bike as a result of improperly securing the module.
Noce: Product is Not DOT approved.
ATTENTION
Please read all warning Information below before Installation
Installation:
1. Secure motorcycle on level surface. Confirm the
ignition switch is in the off position. Remove the
seat and disconnect the negative [-] battery cable
from the battery.
2. Locate rear lighting connectors to the rear fender
and the Power and Accessory connector as
shown in Picture 1.
3. Plug the Smart Triple Play® module, into the rear
lighting connectors as shown in Picture 2.
4. Mount the Smart Triple Play® as shown in Picture
3. Secure with tie-wraps, double sided tape or
other means to insure the unit cannot move.

Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
04/2019
1
3
2
Installation Instructions - Page 2
5. Locate the two switches and rotary dial. Be sure the rotary dial is set
to posion 0. There is small arrow on the dial, this is the pointer that
should now be at posion 0. Be sure Switch 1 and Switch 2 are both
in the ON posion. (See Module Controls Diagram)
6. Turn the ignion key on and check operaon as follows:
• Running Lights: Turn Signals and Taillight are now illuminated dimly.
• Apply Right Turn Signal and check operaon of right turn signal,
should ash o to bright. Disable turn.
• Apply Le Turn Signal and check operaon of le turn signal, should
ash o to bright. Disable turn.
• Apply Brake Light. Check to see that all 3 lights ash 4 mes then
remain bright.
• Apply Le Turn Signal then Apply Brake, Check to see that Only Cen-
ter Light Flashes 4 mes then remains bright.
O O
On On
12
Rotary
Diagram - Module Controls

Installation Instructions - Page 3
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
11-2018
7. The Smart Triple Play® allows you to program the running light brightness of the turn signals so they are a match to
your center taillight. To enter the modules program mode:
• Turn ignition key off, be sure Switch 1 and Switch 2 are in the OFF position and the Rotary Dial in in the 0 position.
• Turn ignition key on, immediately turn Switch 1 On-Off-On, turn Switch 2 On-Off-On. Do not depress Brake or Turns
Signals during this action.
• The turn signals should now fade up and down slowly, do not proceed unless this confirmation takes place.
Opt 1 - Turn the rotary dial clockwise to increase the brightness of the running lights, 0-being the dimmest setting and 8-
being the brightest. Match the running light brightness to the taillight. Once happy with the setting, press and hold the brake
for a couple of seconds. The setting will now be saved.
Opt 2 - To disable the run function and receive only brake and turn signal function on the rear turn signals, turn the rotary
dial to 9. Press and hold the brake for a couple of seconds. The setting will now be saved.
8. Turn ignition key OFF and set switches for desired Operation.
Switch Functions:
Switch 1 On, Switch 2 On: Strobes/Flashes on all three rear lights
Switch 1 On, Switch 2 Off: Strobes/Flashes on center light only
Switch 1 Off, Switch 2 On: Strobes/Flashes on rear turn signals only
Switch 1 Off, Switch 2 Off: No Strobes/Flashes
Dial Strobe Functions: (Note that Patterns 0-3 are compatible with incandescent bulbs) See Diagram on page 4.
9. Turn ignition key on and Test Operation based on your desired switch settings. Once programming is complete, re-
install the seat. Installation is complete
Program Mode

Installation Instructions - Page 4
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
11-2018
Flash Pattern Information:
8
0
19
2
4
3
6
5
7
Pattern 0: Four Flashes then Solid
Pattern 1: Four Flashes, Solid for
3 Seconds, Repeat
Pattern 2: Seven Flashes then
Solid
Pattern 3: Seven Flashes, Solid
for 3 Seconds, Repeat
Pattern 4: Quad Strobe then Solid
for 1 Second then Quad Strobe
Pattern 5: Quad Strobe, Solid for 1 Sec-
ond, then Quad Strobe, Solid for 3 Sec-
onds, then Repeat
Pattern 6: Blaster X Pattern for 6
seconds, then Solid
Pattern 7: Constant Blaster X Pat-
Pattern 8: Constant Fast Strobe 4
Seconds, then Solid
Pattern 9: Constant Fast Strobe Pattern
Incandescent or LED
Incandescent or LED
Incandescent or LED
Incandescent or LED
LED Only
LED Only
LED Only
LED Only
LED Only
LED Only
