Custom Dynamics® MagicFLEX2® Indian® LED War Bonnet Light Kit
Installation Instructions
We thank you for purchasing the Custom Dynamics® MagicFLEX2®
Indian® LED War Bonnet Accent Light Kit! Our products utilize the lat-
est technology and high quality components to ensure you the bright-
est, most reliable LED’s on the market. We offer one of the best war-
ranty programs in the industry and we back our products with excel-
lent customer support, if you have questions before or during installa-
tion of this product please call Custom Dynamics® at 1(800) 382-1388.
Package Contents:
- MagicFLEX2® 6 LED Light Strip (1)
- 3M Tape Primer (1)
- Black wire 22 AWG (5 feet)
- 4” Tie Wraps (16)
- Heat Shrink Tubing (2)
Optional Items Sold Separately:
- Indian Engine LED Accent Light Kit (M2EK1-IND)
- Indian Wheel LED Kit (M2WK1-IND)
- Cage Clamp® (CG01) for wire connection (included w/lighting kits)
- Winter Kill Switch (SW01) to kill power to LED. (included w/lighting kits)
Questions? Call us at: 1 [phone] M-TH 9AM-6PM / FR 10AM-6PM EST
12-2017
Tools Needed:
- Screwdriver (Philips)
- Wire Cutter/stripper
- Heat Gun
- Open end wrenches
- Razor blade cutting tool
Strip wire 9-10 mm. Use the stripped wire
gauge on the back of the connector to verify
correct strip length.
Push up lever and insert conductor
Push down lever to its closed position.
Cage Clamp® Instructions
Important: Read all directions before starting project.
Caution: Always wear appropriate safety gear including safety glasses when
soldering or performing any electrical work. It is highly recommended that
safety glasses be worn throughout this installation process. Temperature of
bike must be at least 60 degrees F. for tape to properly cure. Be sure bike is
on level surface and secure and cool.
Important: Disconnect negative battery cable from battery; refer to owner’s
manual. Failure do to so may result in electrical shock, injury, or fire. Secure
negative battery cable away from positive side of battery and all other positive
voltage sources on bike.
Note: If the War Bonnet LED is to be illuminated as a running light, the posi-
tive wire will need to be connected to a running light circuit.
If the War Bonnet LED is to be illuminated as an accent light, you must have
an on off switch and a fusible link between the LED and the power source.
See page 2 for wiring diagram.
1. Remove fender. Refer to your service manual for fender removal instruc-
tions.
2. Remove War Bonnet from the front fender by removing two 10mm nuts
on the under side of fender.
3. Remove 3 Phillips head screws from the bottom of the War Bonnet hous-
ing.
Note: 2 longer screws are for each side and the shorter screw is for the
back.
Fits: Indian® Motorcycles with the War Bonnet installed on front fender.
Part Number: CD-IND-WB

Installation Instructions - Page 2
Questions? Call us at: 1 [phone] M-TH 9AM-6PM / FR 10AM-6PM EST
4. Remove the unserviceable LED horseshoe puck housing from behind the War Bonnet lens.
5. Place one piece of provided heat shrink tubing over the red and black wires of the MagicFLEX2 LED strip. Using the
provided 22 AWG wire, attach red wire to red wire and black wire to black wire by soldering or twisting the wires togeth-
er. Slide the heat shrink for the Red wire over the connection and apply heat using a hair dryer or heat gun until heat
shrink has shrunk around connection. Repeat process for the black wire.
6. Apply 3M® primer on the front of the LED horseshoe puck housing. Allow to dry.
7. Remove the red protective tape from the back of the MagicFLEX2® LED and press into place.
8. Reassemble the War Bonnet Light and install on the fender.
9. Attach the MagicFLEX2® LED light strip wire harness with the War Bonnet wire harness.
10. Re-install the front fender. Refer to your service manual for fender installation instructions.
11. Continue routing the MagicFLEX2® LED light strip wire harness back to a central point near battery compartment under
seat. Route wires such that they not interfere with normal operation of bike. Cut off any excess wires, strip back insula-
tion as required.
12. Secure wires to the frame using some of the tie wraps provided.
Note: If installing with Indian Engine Accent Light Kit (M2EK1-IND), stop here and follow the wiring instructions for
that kit.
13. Connect the Black wire to the bike’s ground or the ground terminal of the battery.
14. Connect the Red wire to a on/off switch that is connected to a fused connection to the positive side of the battery. Take
necessary precautions when making connection and refer to bike’s owner’s manual.
Caution: DO NOT allow any tools to touch both positive (+) side of battery and any metal surface on bike as it will cause a
short which could result in serious injury and damage to the battery or other electrical circuits.
15. Secure any remaining wires with tie wraps.
16. Turn on switch and check operation of all lights.
Wiring Diagram
12-2017
(Optional)
Connector (Required)
Connector
(Required)
(-)
Either ground
