We thank you for purchasing the Custom Dynamics® ProBEAM® BCM COMPLIANT TURN SIGNAL CONVERSION KIT
(1157 REAR, 1157 FRONT) LED turn signals! Our LEDs oer maintenance free service and higher visibility. Our
ProBEAM® product line ulizes the latest technology and automove grade components to ensure the highest level
of reliable service. Custom Dynamics® oers one of the best warranty programs and customer support in the indus-
try. If you have any quesons during the installaon of this product please call us at 1(800) 382-1388.
CD #: PB-BCM-KIT1
Package Contents:
- Choice of Front ProBEAM® Amber/ White LED Dynamic Ringz™ with Smoke Lenses or ProBEAM® Amber LED Turn Signals With
Amber Lenses
- ProBEAM® 1157 Rear LED Turn Signal Inserts: Choice of ProBEAM® 1157 Red Ring LED Turn Signals or ProBEAM® 1157 Solid
Red LED Turn Signals with Red Lenses
Note:
• Use care in removing the OEM lens and bulbs from
the housing, so as not to scratch or mar the chrome
housing. Custom Dynamics® is not liable for damage
to chrome housing during installaon.
• Dielectric grease does not need to be used with this
LED product, it can actually prevent them from work-
ing. Remove any excess grease from your turn signal
sockets before inserng.
***IMPORTANT***
This LED product is BCM compliant. However, you must
run the 4 way hazard ashers for 3 minutes with ignion
switch in the “OFF” posion to allow the BCM to sync the
ATTENTION
Please read all Informaon below before Installaon
11-2018
Fitment: 2014-2019 Harley-Davidson® Street Glide, Street
Glide Special, Road Glide, Road Glide Special, Road King
Special, 2018-2019 Soail Slim, Soail Breakout, Soail
Street Bob, Soail Fat Bob, Soail Fat Boy, 2011-2017 Har-
ley-Davidson® Blackline, Slim, Slim S, Breakout, Street Bob,
2012-2017 Dyna Wide Glide, Dyna Low Rider S, 2014-2019
XL1200X, XL883N, XL1200V, XL1200CX, XL1200NS, 2011-
2012 Soail Converble CVO, 2014-2015 Soail Deluxe
CVO, & 2014 Soail Breakout CVO.

Quesons? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
Installation Instructions - Page 2
11-2018
3
Installaon:
1. Remove the exisng lens from turn signal hous-
ing.
2. Remove exisng bulb from turn signal housing.
3. Remove any corrosion or dielectric grease from
the socket to insure the socket contacts are
clean.
4. Using a small at blade screwdriver, go around
the perimeter of the reector and slightly push
the black gasket into the housing to allow prop-
er clearance of the new LED turn signal (Refer to
Figure 1).
5. Conrm the proper orientaon of the socket
base and insert the base into the socket. If it
seems hard to twist the base in the socket or
hard to remove, it is probably orientated the
wrong way.
6. Twist the LED turn signal a few rotaons to coil
wire from the turn signal to the socket base. In-
sert LED turn signal into housing and install new
lens.
7. Insure the notch in the lens gasket is aligned
with the notch in the lens. (Refer to Figure 2.)
8. Install the lens on the turn signal housing with
the lens notch located at the boom of the turn sig-
nal housing. (Refer to Figure 3.) Cauon: If there is a
gap between the lens and the housing, water will
leak into the unit and cause damage, be sure the
lens is full seated.
9. Check operaon of turn signals in all modes.
