Custom Dynamics ProBEAM Dynamic Strips User manual

Quesons? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
We thank you for purchasing the Custom Dynamics® ProBEAM® Dynamic Strips™ LED Turn Signals! Our LEDs oer mainte-
nance free service and higher visibility. Our ProBEAM® product line ulizes the latest technology and automove grade com-
ponents to ensure the highest level of reliable service. Custom Dynamics® oers one of the best warranty programs and cus-
tomer support in the industry. If you have any quesons during the installaon of this product please call us at 1(800) 382-
1388.
Custom Dynamics® ProBEAM®
Dynamic Strips™ LED Turn Signals
Installaon Instrucons
Package Contents:
- ProBEAM® Dynamic Strips™ (pair)
- 4” Black Tie Wraps (8)
- 5/16”x 1-1/4” Buon Head Bolt(4)
- Finished Flat Washer (4)
Fitment: All 2014 -2022 Street Glide Models
(including CVO) and 2014-2022 FLHT Models
Without Driving Light Buckets
Part Numbers:
PB-DS2-14-B (Black)
PB-DS2-14-C (Chrome)
PB-DS2-14-CON (Contrast Cut)
Warning: Disconnect negave baery cable from baery; refer to own-
er’s manual. Failure to do so may result in electrical shock, injury, or re.
Secure negave baery cable away from posive side of baery and all
other posive voltage sources on vehicle.
Safety First: Always wear appropriate safety gear including safety glasses
when performing any electrical work. It is highly recommended that
safety glasses be worn throughout this installaon process. Be sure
vehicle is on level surface, secure and cool.
Cleaning: Take special care in cleaning the nish. Use only a non-
abrasive cleaner and a ne microber cloth to remove dirt or debris.
Never use abrasive polishes or cleaners as these can scratch the nish.
ATTENTION
Please read all Informaon below before Installaon
02-2022
Installaon:
1. Remove the 1/2” nuts that secure the turn signal assembly to the
fork shown in Picture 1. Pull assembly away from the fork to re-
veal the black wiring connector as shown in Picture 2.
2. Unplug the connector by pushing in on the tab located on the male
side of the connecon as shown in Picture 3. Push the tab and pull
apart both sides at the same me. Remove the turn signal assem-
bly from the bike completely.
1

Installaon Instrucons - Page 2
Quesons? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
05/2021
3
23. Remove the mounng studs on the fork with a 9/16” wrench or deep well
socket.
4. Repeat steps 1 through 3 on the opposing side turn signal assembly.
5. Plug in the male connector of the of the ProBEAM® Dynamic Strips™ harness
into female connector on the turn signal factory wiring harness.
6. Push the tun signal connectors into the hole in the fork frame
7. Install the ProBEAM® Dynamic Strips™ onto the fork frame and secure with
the provided 5/16” buon head bolts and washers. The LEDs should be on
the boom of the ProBeam® Dynamic Strips™ when mounted to the fork.
Repeat step for the opposing side.
8. Run the 4 way hazard ashers, with the ignion in the o posion, for 3
minutes to sync BCM with the ProBEAM® Dynamic Strips™. Aer you have
sync’d the BCM
9. Check all lighng for proper operaon in all modes.
