Custom Dynamics® Magic Strobes™ Brake Flasher
Installation Instructions
We thank you for purchasing the Custom Dynamics® Magic Strobes
Brake Light Flasher! Our products utilize the latest technology and
high quality components to ensure you the most reliable service. We
offer one of the best warranty programs in the industry and we back
our products with excellent customer support, if you have questions
before or during installation of this product please call Custom
Dynamics® at 1(800) 382-1388.
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
08-2015SM
Part Number: MAGIC-STROBES-SS6
Installation
Package Contents:
- Magic Strobes™ Brake Flasher (1)
- Tie Wraps (5)
Fits: 2010-13 Street Glide, 2010-2013 Road Glide Custom
ATTENTION
Please read all Information below before Installation
Important: Module must be secured after installa-
tion. Find safe area away from any moving parts and
out of the way of normal operation of the bike. Use the
enclosed tie-wraps to secure. Custom Dynamics® is
not liable for damage as a result of improperly securing
or failing to secure the
module.
Note: When using a Magic Strobe™ with a Signal
Stabilizer™ or other Load Equalizer we recommend to
install the Magic Brake Strobe™ after (towards the
taillight) the Signal Stabilizer or Load Equalizer. (See
Diagram)
Important: Customers using this module with
standard incandescent bulbs should use patterns 0-3
only. Any other settings selected will result in dimin-
ished performance.
Caution: A stuck brake switch may cause this unit
to overheat and fail . Unplug module immediately if this
condition occurs.
Note: Although this device has been designed to significantly in-
crease your braking visibility, flash/strobe patterns may not be street
legal in your area. This Device is not DOT approved.
1. Secure motorcycle on level surface.
2. Remove kickstand side panel to access wiring.
3. Disconnect negative [ - ] battery cable from
the battery.
4. Locate and unplug the lighting connector to the
rear fender.
5. Plug the Magic Strobes™ Module, in-line, into
the rear lighting harness and into the bike’s
wiring harness.
6. Re-connect the battery’s negative battery
cable to the negative [ - ] of the battery.
7. Select Desired Pattern on the dial with power
Off. (See page 2 for Pattern Information)
8. Check Operation.
9. To change pattern, turn bike OFF and change
dial to desired pattern.
10. Locate a secure place for the Magic Strobes™
unit that will not interfere with the secure
placement of the seat. Secure with the en-
closed tie-wraps so that unit will not move.

Installation Instructions - Page 2
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
08-2015SM
Flash Pattern Information
8
0
1 9
2
4
3
6
5
7
Pattern 0: Four Flashes then Solid
Pattern 1: Four Flashes, Solid for 3
Seconds, Repeat
Pattern 2: Seven Flashes then
Solid
Pattern 3: Seven Flashes, Solid for
3 Seconds, Repeat
Pattern 4: Quad Strobe then Solid
for 1 Second then Quad Strobe
Pattern 5: Quad Strobe, Solid for 1 Second,
then Quad Strobe, Solid for 3 Seconds, then
Repeat
Pattern 6: Blaster X Pattern for 3
seconds, then Solid
Pattern 7: Constant Blaster X Pattern
Pattern 8: Constant Fast Strobe 5
Seconds, then Solid
Pattern 9: Constant Fast Strobe Pattern
Incandescent or LED
Incandescent or LED
Incandescent or LED
Incandescent or LED
LED Only
LED Only
LED Only
LED Only
LED Only
LED Only
Module Placement
Tail Light
Signal Stabilizer™
or load Equalizer
Magic Strobes™
Brake Flasher
Front of Bike
Correct Placement of Magic Strobes™ is after Signal Stabilizer™ or Load EQ
Incorrect installation - Wrong Location
Tail Light
Front of Bike
