Custom Dynamics® Smart Triple Play®
Installation Instructions
We thank you for purchasing the Custom Dynamics® Smart Triple
Play®. Our products utilize the latest technology and high quality
components to ensure you the most reliable service. We offer one of
the best warranty programs in the industry and we back our prod-
ucts with excellent customer support, if you have questions before
or during installation of this product please call Custom Dynamics®
at 1(800) 382-1388.
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
12-2017
Package Contents:
- SMART Triple Play® Module with Posi-Lock™ Connectors
- Instructions
Part Number: GEN-SMART-TPU-SS8
Fits: 2010-2012 Street Glide® CVO™, 2013 Road King®
CVO™, 2009 Road Glide® CVO™ and 2012-2013 Road
Glide® Custom CVO™ with OEM LED Panels
Note: The Smart Triple Play® will cause the BAGZ™ and OEM LED
Panels to have a full contrast turn signal flash and to flash/strobe
when the brake is applied.
1. Secure motorcycle on level surface. Disconnect negative battery
cable from the battery. Locate the lighting connector under the
seat.
2. Remove the MPR-SS8-PLUG plug and play adapter for
BAGZ™ and plug the Smart Triple Play® Module, in-line, into
the rear lighting harness under the seat. Signal Stabilizer™ or
load equalizer should be installed on the input side of the Smart
Triple Play® unit (page 3).
Note: Wiring Diagram on page 3.
3. Cut and remove the 3 pin plug from each LED BAGZ™ light to
expose the black, yellow, and brown (right side) or purple (left
side) wires. Cap off the yellow wire from each BAGZ™ light.
4. Connect the pigtail output wires from the Smart Triple Play®
using the supplied Posi-Lock™ connectors to the exposed black
and brown (right side) or (left side) purple wires on the Custom
Dynamics® BAGZ™ LEDs.
5. Connect the brown wire to the right side (brown) LED high wire
[+]. Connect the purple wire to the left side (purple) LED high
wire [+]. Connect the black wire of left side LED neg. and the
right side LED neg. to the [ - ] black wire of the unit.
6. Re-connect the battery’s negative battery cable to the battery.
7. Locate a secure place for the Smart Triple Play® unit that will
not interfere with the secure placement of the seat or side cover.
Secure with tie-wraps, tape or other means so that unit cannot
move.
8. Program Smart Triple Play® and select desired brake strobe
pattern. See Programming Instructions on page 2.
9. Test for proper run, brake and turn function.
Installation:
Important: This system is designed to work with Custom Dynam-
ics® BAGZ™ LED Lights. They will not work with the any Amber/
Red saddle bag lights.
Caution: This unit is designed for a maximum load of 27 watts
per channel. Do no exceed 27 watts per left turn signal output, 27
watts per right turn signal output, and 27 watts per brake signal
output. Overloading unit could cause damage to the unit and
cause the unit to malfunction.
Important: A load equalizer or Signal Stabilizer™ is required for
the Smart Triple Play® to function properly. The load equalizer
MUST be installed on the input side of the Smart Triple Play®
unit. NEVER install a load equalizer downstream of this unit.
Important: Module must be secured after installation. Find safe
area away from any moving parts and out of the way of normal
operation of the bike. Use Tie-wraps, tape, (not included) or other
means to secure. Custom Dynamics® is not liable for damage to
the module or the bike as a result of improperly securing the
module.
ATTENTION
Please read all warning Information before Installation

Installation Instructions - Page 2
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
12-2017
O O
On On
12
Rotary
Diagram - Module Controls
• Running Lights: BAGZ™ Lights are now illuminated dimly.
• Apply Right turn signal and check operation of right turn signal, should
flash off to bright. Disable turn.
• Apply Left turn signal and check operation of left turn signal, should flash
off to bright. Disable turn.
• Apply brake light. Check to see that all lights flash 4 times then remain
bright.
• Apply Left turn signal then apply brake. Check to see that only center light
flashes 4 times then remains bright. If no center tail light is applicable,
when the left turn signal is on and the brake is applied, the right side turn
signal will stop strobing. This is normal operation.
1. The Smart Triple Play® allows you to program the running light brightness of the BAGZ™ Lights so they are a match to your taillights. To en-
ter the modules program mode:
Program Mode:
• Turn ignition key off, be sure Switch 1 and Switch 2 are in the OFF position and the rotary dial in in the 0 position.
• Turn ignition key on, immediately turn Switch 2 On-Off-On. Turn Switch 1 On-Off-On. Do not depress Brake or Turns Signals
during this action.
• The turn signals should now fade up and down slowly, do not proceed unless this confirmation takes place.
• Turn the rotary dial clockwise to increase the brightness of the running lights, 0-being the dimmest setting and 9-being the bright-
est. Match the running light brightness to the taillight. Once happy with the setting, press and hold the brake for a couple of sec-
onds. The setting will now be saved.
2. Turn ignition key OFF and set switches for desired Operation.
Program Menu:
Switch Functions:
Switch 1 On, Switch 2 On: Strobes/Flashes on all three Rear Lights
Switch 1 On, Switch 2 Off: Strobes/Flashes on rear turn signals only
Switch 1 Off, Switch 2 On: Strobes/Flashes on center light only
Switch 1 Off, Switch 2 Off: No Strobes/Flashes
1. Locate the two switches and rotary dial on the Smart Triple Play® module. Be sure the
rotary dial is set to position 0. There is a small arrow on the rotary dial, this is the pointer
that should now be at position 0. Be sure Switch 1 and Switch 2 are both in the ON posi-
tion.
2. Turn the ignition key on and check operation as follows:
Testing for Proper Operation:

Installation Instructions - Page 3
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
12-2017
Wiring Diagram:Module Installation:
Smart Triple Play®
Right Bagz™
Light
Purple
Black (ground)
Brown
Bike’s Front
Harness Male
Plug
Input Female
Plug
Output Male
Plug
Red and blue wires are
capped. (not needed)
+
Left Bagz™
Light
+
Yellow (capped off)
Yellow (capped off)
Bike’s Rear
Harness Female
Plug
Purple
Posi
Posi
Posi
Flash Pattern Information:
8
0
19
2
4
3
6
5
7
Pattern 0: Four Flashes then Solid
Pattern 1: Four Flashes, Solid for
3 Seconds, Repeat
Pattern 2: Seven Flashes then
Solid
Pattern 3: Seven Flashes, Solid
for 3 Seconds, Repeat
Pattern 4: Quad Strobe then Solid
for 1 Second then Quad Strobe
Pattern 5: Quad Strobe, Solid for 1 Sec-
ond, then Quad Strobe, Solid for 3 Sec-
onds, then Repeat
Pattern 6: Blaster X Pattern for 6
seconds, then Solid
Pattern 7: Constant Blaster X Pat-
Pattern 8: Constant Fast Strobe 4
Seconds, then Solid
Pattern 9: Constant Fast Strobe Pattern
Incandescent or LED
Incandescent or LED
Incandescent or LED
Incandescent or LED
LED Only
LED Only
LED Only
LED Only
LED Only
LED Only
