Custom Dynamics ProBEAM PB-BCM-KIT1 User manual

We thank you for purchasing the Custom Dynamics® ProBEAM® BCM COMPLIANT TURN SIGNAL CONVERSION KIT (1157 REAR,
1157 FRONT) LED turn signals! Our LEDs oer maintenance free service and higher visibility. Our ProBEAM® product line ulizes
the latest technology and automove grade components to ensure the highest level of reliable service. Custom Dynamics®
oers one of the best warranty programs and customer support in the industry. If you have any quesons during the installaon
of this product please call us at 1(800) 382-1388.
P/N: PB-BCM-KIT1
Package Contents:
- Front 1157 LED Turn Signals: Choice of Amber/
White w/ Smoke lens or Amber w/ Amber
Lens (1pr)
- Rear 1157 LED Turn Signals: Choice of Red Ring or
Solid Red w/ Red Lens (1pr)
US Patent 830597, 830595, 830596, 851817, 851327
Chinese Patent ZL-201830045649.4, ZL-201830409102.8, ZL-
201830409095.1, Other Patent Pending
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
Note:
• Use care in removing the OEM lens and bulbs from
the housing, so as not to scratch or mar the chrome
housing. Custom Dynamics® is not liable for damage
to chrome housing during installaon.
• Dielectric grease does not need to be used with this
LED product, it can actually prevent them from work-
ing. Remove any excess grease from your turn signal
sockets before inserng.
***IMPORTANT***
This LED product is BCM compliant. However, you must
run the 4 way hazard ashers for 3 minutes with ignion
switch in the “OFF” posion to allow the BCM to sync the
new LED turn signals aer they are installed.
ATTENTION
Please read all Informaon below before Installaon
Fitment: 2014-2022 Harley-Davidson® Street Glide (FLHX),
Street Glide Special (FLHXS), Road Glide (FLTRX), Road Glide
Special (FLTRXS), Road King Special (FLHRXS), 2018-2022 Soail
Street Bob (FXBB/FXBBS), Fat Boy (FLFB/FLFBS), Fat Bob (FXFB/
FXFBS), Soail Standard (FXST), Slim (FLSL) and Breakout (FXSB/
FXSR) 2011-2017 Blackline (FXS), Slim (FLS), Slim S (FLSS),
Breakout (FXSB), Street Bob (FXDB), 2012-2017 Dyna Wide Glide
(FXDWG), Low Rider S (FXDLS), 2014-2022 XL883N, XL1200X,
XL1200V, XL1200CX, XL1200NS, 2011-2012 Soail Converble
CVO (FLSTSE2), 2014-2015 Soail Deluxe CVO (FLSTNSE), and
2014 Soail Breakout CVO (FXSBES).
Installation:
1. Remove the existing lens from turn signal housing. Use care in re-
moving the OEM lens and bulbs from the housing, so as not to
scratch or mar the chrome housing.
2. Remove existing bulb from turn signal housing.
3. Remove any corrosion or dielectric grease from the socket to insure
the socket contacts are clean.
4. Using a small flat blade screwdriver, go around the perimeter of the
reflector and slightly push the black gasket into the housing to allow
proper clearance of the new LED turn signal. (see Figure 1)
5. Confirm the proper orientation of the socket base and insert the base
into the socket. If it seems hard to twist the base in the socket or
hard to remove, it is probably orientated the wrong way.
6. Twist the LED turn signal a few rotations to coil wire from the turn
signal to the socket base. Insert LED turn signal into housing and
install new lens.
7. Confirm lens is installed correctly to prevent excess moisture or water
from entering the turn signal housing (see back page).
8. Check operation of turn signal in all modes.
Cauon: If there is a gap between the lens and the hous-
ing, water will leak into the unit and cause damage, be
sure the lens is fully seated all the way around the pe-
rimeter.
Figure 1
02-2022
PREVENTING WATER DAMAGE
SEE BACK OF PAGE

Custom Dynamics® ProBEAM® LED Turn Signals are coated with a thick layer of conformal coating which protects
the circuit board from a normal amount of moisture or water damage. Follow the steps below to ensure your new
ProBEAM® LED turn signal is installed properly to prevent excess moisture or water from entering the turn signal
housing.
1. ProBEAM® turn signals are installed with lenses provided by Custom Dynamics® included in original packag-
ing.
2. The lens is fully seated against the turn signal housing when installed; there are no gaps between the turn sig-
nal housing and the lens all the way around the perimeter.
3. The notch built into the lens is oriented towards the bottom of the turn signal housing. (See image 2 & 3 below)
Questions? Call us at: 1 [phone] M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
• If there is a gap between the lens and the housing, water will leak into the unit and cause damage, be sure the
lens is fully seated all the way around the perimeter.
• If the lens will not fully seat on the housing, it may be necessary to trim any excess gasket with a small at blade
screw driver. Refer to image 4 below.
• Do not use the lens if any of the tabs are broken, doing so may cause water to enter the housing.
• Do not install the lens without the ProBEAM lens gasket in place, do-
ing so will cause water to leak into the housing.
PREVENTING WATER DAMAGE
Caution
Custom Dynamics® is not liable for damage to product as a result of incorrect installation.
4
2
3
