Dakota Digital Retrotech RTX-68D-STD User manual

Manual # 650770
RTX-68D-STD
Dakota Digital RTX Instrument Installation
For 1968-70 Dodge/Plymouth B-Body Non-Rallye
Your new RTX-68D-STD kit includes:
Installation Manuals
Control Box
36” Main Harness
Universal Sender
Pack
RTX Display
Switch Assembly
4x 0.5” Oval Head Screws
3x 0.5” Pan Head Screws
Buzzer

Manual # 650770
Installation
2. Remove the two upper and four lower screws securing the gauge cluster to the dash. The factory
gauge cluster can now be taken out of the dash.
1. Remove the lower dash pad and switch panel, retaining the hardware recovered for reassembly.
3. Remove the nine screws securing the plastic bezel to the gauge cluster. Four are located on the
bottom rear of the cluster, five are located on the top. Save these screws for the next step.

Manual # 650770
5. Connect the provided 36” main harness and buzzer cable (optional for audio feedback) to the back
of the RTX system. Carefully route the other ends to the control box and buzzer mounting
locations as you mount the RTX system into the dash.
4. Mount the factory gauge bezel to the RTX system by reusing the nine screws that held it to the
factory gauge cluster.
6. Mount the RTX system to the dash using the top two original factory screws. Use the provided four
replacement oval head screws for the lower mounting points.
BUZZER CABLE

Manual # 650770
WARNING: This product can expose you to chemicals including lead, which is known to the State of
California to cause cancer and birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov
7. Re-install the lower dash pad using the three provided pan-head screws. Then mount the switch
panel to the dash using the factory hardware from disassembly.
8. Refer to the main manual for wiring instructions to complete the RTX installation.
