dams UHS800 User manual

1 2
1
UHS800
11.09.2020
RM-INS150
DH-WB-A
DH-WB-B
IMPORTANT - PLEASE READ
Before starting please ensure you are aware of the type of wall that you are about to install to.
No wall fixings are supplied with this unit, it is the resposibility of the installer to ensure they are using
fittings that are suitable for the wall type.
The following steps will only show guidance for assembly of the bookcase, location of brackets to align
with the hangers of the bookcase as well as connection instructions to hang the bookcase.
If you are anyway unsure about fixing to your wall please contact a local builder or tradesperson to have
this unit hung by a professional.

1,2,3...
TOOLS REQUIRED
FOR ASSEMBLY
DONT STRUGGLE
2 MAN LIFT
ALWAYS HANDLE
ITEMS WITH CARE
IF UNSURE CALL
FOR ASSISTANCE
KEEP FITTINGS AWAY
FROM CHILDREN
2
4mm

Please check that you have all the panels
3
1
DH-WB-A
2
DH-WB-B
WALL BOOKCASE PACK A
WALL BOOKCASE PACK B
Please check that you have all the hardware
24mm QUICKFIX PIN
RM-BLT006 15mm QUICKFIX CAM RM-CAM03 70mm CONFIRMAT SCREW RM-CFM02
QUANTITY - 12 QUANTITY - 12 QUANTITY - 8
QUANTITY - 8QUANTITY - 6 QUANTITY - 8
QUANTITY - 4
30 x 5mm WOOD DOWEL
RM-WOW01
BACK
RM-BAC162
RH SIDE
RM-SID245
LH SIDE
RM-SID244
SHELF
RM-SHE044
PARTITION
RM-PRT020
BASE
RM-BAS088 TOP
RM-TOP462
CONNECTOR SCREW
RM-PIN01 SHELF HOUSING RM-BUN02 SHELF DOWELS RM-PIN07 WALL HANGER BRACKET
LH WALL HANGER RH WALL HANGER
QUANTITY - 1 QUANTITY - 1
QUANTITY - 1
SHELF
RM-SHE044

2
1
Prepare all the panels by inserting the listed fittings into the corresponding holes.
4
Step 1
Insert pins and dowels into the pre drilled holes
on both top and base panels.
Qty 4
WOW01
Qty 8
BLT06
Step 2
Insert the pins and shelf pins into pre drilled holes
on LH & RH side panels.
Qty 4
PIN01
Qty 4
BLT06
Qty 4
PIN07
Top Edge
Top Edge

Top Edge
5
4
Step 4
Insert the cams into pre
drilled holes on back panel.
See diagram B for details on
inserting the cam fittings.
3
Step 3
Insert the bung shelf supports
into the pre drilled holes on the
underside of each shelf.
Note:
Ensure the opening in the bung
aligns with the opening in the
edhe of the shelf.
See Diagram A
Prepare all the panels by inserting the listed fittings into the corresponding holes.
Qty 12
CAM03
Qty 8
BUN02
Diagram A
CAM
EDGEEDGE
adjacent edge which has the smaller hole.
Insert the cam into the 'surface' hole with the arrow aimed at the
Diagram B

Top Edge
Top Edge
180'
96mm
128mm
Top Edge
Bottom Edge
Back Edge
Front Edge
Top Edge
Bottom Edge
Front Edge
Back Edge
42mm
26mm
Face A
Face B
6
6
5
Step 5
Before inserting any fittings familiarise yourself
with the panel ensuring that you have it in the
same orientation as the image below.
Use the distance between the
drill holes as a guide.
Insert shelf support pins into the pre drilled holes
in face A, then flip panel and insert shelf support
pins into face B. Finally insert the pins into the
drilling on the top edge of the partition panel.
Step 6
Attach partition to back
panel using confirmat
screws provided.
A 4mm Allen key is required
to insert these screws.
70mm CONFIRMAT SCREW
RM-CFM02
QUANTITY - 2
Prepare all the panels by inserting the listed fittings into the corresponding holes.
Qty 4
PIN07
Qty 2
PIN01

Top Edge
Top Edge
Top Edge
Top Edge
8
7
Step 7
Attach sides to back panel.
Once the cams and pins are
engaged ensure that the
cams are fully tightened.
7
Step 8
Attach top panel to unit.
Once the cams and pins are
engaged ensure that the
cams are fully tightened.
Join the panels together and tighten all cam fittings

8
10
9
Step 9
Attach base panel to unit
using confirmat screws
provided.
A 4mm Allen key is required
to insert these screws.
Step 10
Stand unit upright and
insert the shelves into the
cupboard, ensure that the
shelf support bungs fully
engage into the shelf pins.
They may need to be lightly
knocked down to ensure the
fittings fully engage.
70mm CONFIRMAT SCREW
RM-CFM02
QUANTITY - 6

11
Step 11
Turn the unit around so you are now
working on the back of the bookcase.
Insert the wall hanger into the side panel.
9
IMPORTANT - PLEASE READ
Before starting please ensure you are aware of the type of wall that you are about to install to.
No wall fixings are supplied with this unit, it is the resposibility of the installer to ensure they are using
fittings that are suitable for your wall type.
The following steps will only show guidance for the location of brackets to align with the hangers of the
bookcase as well as connection instructions to hang the bookcase.
If you are anyway unsure about fixing to your wall please consult a local tradesperson or builder to have
this unit hung by a professional.
Hanging your bookcase
12
Step 12
Once inserted lift the tab of the
hanger to the locked position.
See diagram C
Repeat for both hangers.
Diagram C
Unlocked
Locked
13
Step 13
Split the wall hanging
bracket into 2 by
bending back and
forth at the perforation
point in the bracket.
Perforation
point LH Wall Bracket
RH Wall Bracket
Unlocked
Locked

820mm
410mm 410mm
370mm
397mm
370mm
397mm
CENTRE
POINT
OVERALL
LENGTH
MARK 1
MARK 2
MARK 1
MARK 2
WALL
BOOKCASE
10
15
14
Step 14
Once you have decided on the location
you want your bookcase we are going to
mark the wall for mounting the brackets.
Using a level and a tape measure we will
mark 4 points for the brackets.
Using a spirit level start by drawing a line
feintly using a pencil, this line should be
50mm lower than the top of your
bookcase and should be drawn 820mm
long.
Create a centre point on this line by
measuring in 410mm from either end and
marking with your pencil.
From this centre point measure out
370mm both to the left and right and
create a mark, create a 2nd set of marks
this time measuring out 396mm from the
centre point.
Step 15
Lift the wall bookcase into
position.
You will need to lift the unit
higher than the brackets,
push against the wall and
slowly lower ensuring that
the wall hangers engage
with the wall brackets.
Do not let go of the unit until
you are sure that it is
correctly connected to the
wall bracket.
There is 2 types of
adjustment on the bracket
that can be used to level
and adjust the position of
the unit.
Align brackets with the
marks and screw to the wall.
ADJUSTMENT POINTS
VERTICAL
ADJUSTMENT
LATERAL
ADJUSTMENT
LATERAL
ADJUSTMENT
VERTICAL
ADJUSTMENT

1 2
1
CSI-C
11.09.2020
RM-INS146
DH-SD
DH-SDHK

DOOR
RM-DOR094
Please check that you have all the hardware!
2
DH-SDHK
SINGLE DOOR HARDWARE KIT
Please check that you have all the panels!
2
1
DH-SD
SINGLE DOOR
M4 x 6mm SLOTTED SCREW
RM-SCR27 M4 x 20mm BOOK SCREW RM-SCR28
QUANTITY - 2 QUANTITY - 2
QUANTITY - 2QUANTITY - 2
QUANTITY - 4
CLIP ON HINGE PLATE110' CLIP ON - SOFT CLOSE
3.5 x 15mm WOOD SCREW
RM-SCR26
1 2
Step 1
Place the hinges into the pre drilled holes on the
inside face of the door panel.
Step 2
Attach the hinges using the 3.5 x 15mm
wood screws, 2 screws per hinge.
Qty 4
SCR26
QUANTITY - 1
LEATHER STRAP HANDLE
RM-HDL18
Qty 2
5mm Door Stop Peg
QUANTITY - 1

3
4
3
Step 3
Attach leather handle to
door using binding screws
provided.
Slotted part of screw to the
inside of door.
Join the panels together and tighten all cam fittings
Step 4
Attach the hinge plates to
the pre drilled holes on the
inside face of the bookcase
side panels, these plates
are fitted with pre attached
screws.
Ensure the plate is fitted as
per diagram 1.
EDGE OF UNIT
Diagram 1
Qty 2

4
5
Step 5
Attach door to the unit. Diagrams 2 & 3 show how to lock the hinge to the plate.
Always lock the top hinge into place first before repeating for bottom hinge.
Once the door is attached insert the door stop peg to prevent the door from closing in too far.
Diagram 2
Ensure the hook of the hinge
locates into the hinge plate.
Fasten the hinge to the plate
by applying pressure here.
Diagram 3
