Anson - Deluxe Executive Desk
ANS-DRD
ASSEMBLY
INSTRUCTIONS
Anson
Executive Desk &
Return Credenza
1
2 3 456
7 8 9 10 11 12
Pack 1:
Top Pack
1
2
3456
7 8 9 10 11 12
Pack 2:
Rail Kit
1 2
3
456
7 8 9 10 11 12
Pack 3:
Corner Kit
1 2 3
4
56
7 8 9 10 11 12
Pack 4:
1000 Leg
Kit
1 2 3 45
6
7 8 9 10 11 12
Pack 6:
Modesty Kit
1 2 3 456
7
8 9 10 11 12
Pack 7:
Modesty
Pack
1 2 3 4
5
6
7 8 9 10 11 12
Pack 5:
600 Leg Kit

1,2,3...
**mm
TOOLS REQUIRED
FOR ASSEMBLY
DONT STRUGGLE
2 MAN LIFT
ALWAYS HANDLE
ITEMS WITH CARE
IF UNSURE CALL
FOR ASSISTANCE
**mm
KEEP FITTINGS AWAY
FROM CHILDREN

Please check that you have all the panels
1 2 3 456
7 8 9 10 11 12
PACK 1:
1 x Top Panel
ANS-EXEC-TOP
1 2 3 456
7 8 9 10 11 12
PACK 2:
1 x Rail Kit
HN-RAIL-2200
1 2 3 456
7 8 9 10 11 12
PACK 3:
1 x Corner Kit
HN-CAST
1 2 3 456
7 8 9 10 11 12
PACK 4:
1 x 1000 Leg Kit
HN-LEG10-KIT
1 2 3 456
7 8 9 10 11 12
PACK 6:
1 x Modesty Kit
HN-MBKT-KIT
1 2 3 456
7 8 9 10 11 12
PACK 7:
1 x Modesty Panel
ANS-EXEC-DMOD
1 2 3 456
7 8 9 10 11 12
PACK 5:
1 x Support Kit
HN-LEG6-KIT

ANSON DELUXE DESK & RETURN ASSEMBLY
1
Step 1
2
Unpack your Anson
rectangular desk and
please recycle all packaging.
Place the top face down so that
the xing holes are face-up.
Step 2
image ‘b’.
image ‘a’.
M6 Connector Bolt
Size PCS
25mm 58
FITTINGS SUPPLIED
Please check that you have all the ttings
Adjustable Foot
Size PCS
25mm dia. 4
Assemble the legs as per
‘image a’ using parts from
both leg kit & corner kit.
Link all the legs together
attaching them to the side
rail as per ‘image b’

ANSON DELUXE DESK & RETURN ASSEMBLY
3
4
5
Step 3
Link both the end leg & top
support together attaching them
with the rail kit as per image
Ensure all xing bolts are
tightened turning in a clockwise
position.
Step 4
Once the frame is assembled place
on the underside of the top and afx
using the 16x M6 bolts as shown.
Step 5
Attach the modesty panel
xing brackets by hooking
onto the cross rail and afx
using the 4x M6 bolts as
shown.

ANSON DELUXE DESK & RETURN ASSEMBLY
6
7
8
Step 7
Align the modesty panel to the
modesty panel brackets and afx using
the 8x M6 bolts as shown.
Step 6
Fix the modesty brackets to the
underside of the top and afx using
the 2x M6 bolts as shown.
Step 8
Un-pack and place the
return credenza unit into
location, drill through
the 2x holes located on
the underside of the top
panel as shown either:
R = Right handed
L = Left handed
RR
LL

ANSON DELUXE DESK & RETURN ASSEMBLY
9
10
11
Step 10
Align the support
end with the desired
holes located on the
underside of the top
and afx using the 2x
M6 bolts provided.
Step 11
Once complete ensure all
xings bolts are tightened.
Step 9
With 2x person(s) lift
and turnover the desk
into it’s upright position
and place on the top of
the credenza.
