Deltech Fitness DF908 User manual

DF908
*NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE [phone]
FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY
[phone]
The DF908 consists of the DF910 Lat
Machine andthe DF935 Stack Kit
LAT PULLDOWN MACHINE
WITH 200 LB WEIGHT STACK
Assembly Manual

LAT MACHINE COMPONENTS
*NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE [phone]
REAR SUPPORT
QTY 1
A
FRONT SUPPORT
QTY 1
B
BOTTOM FRAME
QTY 1
C
REVOLVING CHROME
ROW BAR
QTY 1
D
LAT CABLE
QTY 2
E
FOOT PLATE
QTY 1
C1
FOOT REST
QTY 1
C2

LAT BAR
QTY 1
F
*NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE [phone]
SEAT SUPPORT
QTY 1
J
SEAT BRACKET
QTY 1
I
UPPER PULLEY
FRAME
QTY 1
G
SEAT PAD
QTY 1
H
REAR CROSSMEMBER
QTY 1
N
HOLD-DOWN SUPPORT
QTY 1
M
HOLD-DOWN
TUBE
L
ROLLER PAD
QTY 2
P
FLANGE
QTY 2
Q
BOTTOM PULLEY
FRAME
QTY 1
R
LAT MACHINE COMPONENTS

*NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE [phone]
FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY
[phone]
LAT MACHINE HARDWARE
S
MUSHROOM CAP
QTY 2
4-1/2” PULLEY
QTY 3
U
3-1/2” PULLEY
QTY 3
PULLEY BUSHING
QTY 6
SNAP HOOK
QTY 6
CHAIN
QTY 2
M12 x 70MM BOLT
QTY 2
AA
M10 x 45MM BOLT
QTY 4
DD
EE
M10 x 20MM BOLT
QTY 2
FF
M10 x 70MM
FLAT HEAD BOLT
QTY 3
RUBBER SHOE
QTY 2
T V
W X Y
M12 x 65MM BOLT
QTY 2
BB
M10 x 70MM BOLT
QTY 3
CC
GG
M10 x 65MM
CARRIAGE BOLT
QTY 9

KK
M10 LOCKNUT
QTY 19
M12 WASHER
QTY 8
HH
M10 WASHER
QTY 20
I I JJ
M12 LOCKNUT
QTY 4
LAT MACHINE HARDWARE

*NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE [phone]
BOTTOM SUPPORT
QTY 1
LL
UPPER PULLEY
FRAME
QTY 1
MM
WEIGHT STACK COMPONENTS
WEIGHT STACK
RODS
QTY 2
NN
WEIGHT STACK
(19) 10 LB. PLATES
QTY 1
OO
WEIGHT STACK
TOP PLATE
QTY 1
QQ
SELECTOR ROD
QTY 1
PP

*NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE [phone]
FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY
[phone]
RUBBER SHOE
QTY 3
RR
WEIGHT STACK HARDWARE
M10 x 75MM BOLT
QTY 3
SS
RUBBER DOUGHNUTS
QTY 2
WW
M10 WASHER
QTY 6
TT
M10 LOCKNUT
QTY 3
UU
WEIGHT STACK
ADJUSTMENT PIN
QTY 1
VV
SPRING PIN
QTY 1
XX
M10 x 25MM
BOLT
QTY 2
YY
WEIGHT STACK
BOLT
QTY 1
ZZ

*NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE [phone]
FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY
[phone]
RUBBER SHOE
QTY 3
RR
WEIGHT STACK HARDWARE
M10 x 75MM BOLT
QTY 3
SS
RUBBER DOUGHNUTS
QTY 2
WW
M10 WASHER
QTY 6
TT
M10 LOCKNUT
QTY 3
UU
WEIGHT STACK
ADJUSTMENT PIN
QTY 1
VV
SPRING PIN
QTY 1
XX
M10 x 25MM
BOLT
QTY 2
YY
WEIGHT STACK
BOLT
QTY 1
ZZ

ROTATE THE ASSEMBLY TO THE UPRIGHT POSITION AND SLIDE THE REAR
CROSSMEMBER (N) INTO PLACE AND INSTALL TO THE BOTTOM FRAME USING
THE M12 x 70MM BOLTS (AA), M12 WASHERS (HH), AND M12 LOCKNUTS (JJ).
INSTALL THE RUBBER BOOTS (T) OVER THE ENDS OF THE CROSSMEMBER.
ATTACH THE FOOT PLATE (C2) AND FOOT REST (C1) TO THE BOTTOM FRAME
USING M10 x 70 MM FLAT HEAD BOLTS (FF), M10 WASHERS (II), AND M10 LOCK-
NUTS (KK).
AA
T
T
N
HH
HH
JJ
KK
I I
FF
C2
C1

ATTACH THE SEAT PAD (H) TO THE SEAT BRACKET (I) USING THE M10 x 20MM
BOLTS (EE) AND M10 FLAT WASHERS (II). THEN SLIDE THE SEAT BRACKET (I)
INTO THE SEAT SUPPORT (J).
INSTALL THE 3 ½” PULLEY (V) INTO THE SEAT SUPPORT TUBE (J) USING THE
M10 x 45MM BOLT (DD) , M10 WASHERS (II), AND M10 LOCK NUT (KK).
SEAT FRAME ASSEMBLY
H
I
EE
I I
J
V
DD
I I
I I
KK

BOTTOM PULLEY FRAME ASSEMBLY
ASSEMBLE THE 4 ½” PULLEY (U) INTO THE BOTTOM PULLEY FRAME (R) USING
THE M10 x 45MM BOLT (DD), M10 WASHERS (II), AND M10 LOCKNUT (KK).
U
R
KK
I I
I I
DD

SLIDE THE HOLD-DOWN TUBE (L) INTO THE HOLD-DOWN SUPPORT (M) . LOCK
INTO PLACE WITH PULL-PIN.
SLIDE THE ROLLER PADS (P) OVER THE LEG PAD TUBE AND INSERT THE MUSH-
ROOM CAPS (S). TAP INTO PLACE WITH A RUBBER HAMMER.
LEG HOLD DOWN ASSEMBLY
L
M
S
P
S
P

ASSEMBLE THE UPPER PULLEY FRAME (G) ONTO THE FRONT AND REAR SUPPORTS
USING THE M12 x 65MM BOLTS(BB), AND M12 WASHERS (HH).
DO NOT INSTALL WASHERS AND LOCKNUTS ON BOLTS AT THIS TIME.
HH
HH
BB
BB
G

INSTALL 3-1/2” PULLEY (V) INTO UPPER PULLEY FRAME (MM) USING M10 x
75MM BOLT (SS), PULLEY BUSHINGS (W), AND M10 NUT (TT). DO NOT OVER-
TIGHTEN NUT.
UPPER PULLEY ASSEMBLY
TT
MM
W
V
W
SS

UPPER PULLEY ASSEMBLY INSTALLATION
INSTALL THE UPPER PULLEY ASSEMBLY (MM) TO THE FRONT AND REAR SUPPORT USING
M12 WASHERS (HH), AND M12 LOCKNUTS (JJ).
MM
JJ
HH

WEIGHT STACK FRAME ASSEMBLY
INSTALL THE RUBBER SHOES (LL) ON TO THE BOTTOM SUPPORT(LL). ATTACH THE BOTTOM
SUPPORT (LL) TO THE LAT MACHINE USING THE M10 x 75MM BOLTS (SS) M10 FLAT WASHERS
(TT) AND THE M10 LOCK NUTS (UU).
RR
TT
TT
UU
UU
LL
SS
TT
RR

WEIGHT STACK ASSEMBLY
INSTALL THE RUBBER DOUGHNUTS (WW) ONTO THE BOTTOM OF THE WEIGHT STACK RODS
(NN) , LEAVING APPROXIMATELY 2” PROTRUDING. INSERT THE WEIGHT STACK RODS INTO
THE TWO OUTER HOLES IN THE BOTTOM FRAME.
WW
NN

WEIGHT STACK ASSEMBLY
LEAN WEIGHT STACK RODS OUT SLIGHTLY AND BEGIN INSTALLING WEIGHT STACK PLATES
(OO), USING TWO OUTER HOLES ON EACH WEIGHT STACK PLATE. SLIDE EACH WEGIHT STACK
DOWN BEFORE INSTALLING THE NEXT. THERE ARE 19 WEIGHT STACK PLATES.
OO

WEIGHT STACK ASSEMBLY
LEAN WEIGHT STACK RODS OUT SLIGHTLY AND BEGIN INSTALLING WEIGHT STACK PLATES
(OO), USING TWO OUTER HOLES ON EACH WEIGHT STACK PLATE. SLIDE EACH WEGIHT STACK
DOWN BEFORE INSTALLING THE NEXT. THERE ARE 19 WEIGHT STACK PLATES.
OO

WEIGHT STACK ASSEMBLY
INSTALL TOP WEIGHT PLATE ASSEMBLY USING TWO OUTER HOLES OVER WEIGHT STACK
RODS. SLIDE DOWN AND INSERT SELECTOR ROD INTO WEIGHT PLATE STACK.
