Model SCS-104 Line Card
Description
The SCS-104 provides four digital dialer (DD) lines and a network
connection for communication to DMP panels. Each card includes one
shielded eight-pin modular connector (J1) for the Ethernet network
connection. This allows the SCS-1R Receiver to accept alarm and
system messages over a network from DMP panels. Each card also
includes a non-shielded eight-pin modular connector (J3) that supports
up to four digital dialer lines, when connected to a standard RJ61 jack.
An optional PC software application, SCS-CTM Check-in Table Manager,
is available to backup the SCS-104 records of all supervised network
accounts for up to 32 different SCS-104 line cards. The SCS-CTM program
is compatible with SCS-104 Version 100 or higher. For complete operation
information, refer to the SCS-CTM User’s Guide (LT-0940). Contact DMP
Customer Service to purchase a copy of the SCS-CTM Check-in Table
Manager software.
Installing the SCS-104
Install the SCS-104 in any one of the SCS-1R positions
with the card puller in the up position. Connect the
10-position line card cable from the SCS-150 processor
card. The line card number is determined by the
processor card cable it is connected to.
THE LIGHT BROWN (PIN 1) WIRE OF THE FLAT CABLE
CONNECTOR MUST FACE UP ON THE LINE CARD.
Connecting the Phone Lines
Connect the phone line cable from the line card to
the customer supplied RJ61 jacks. Use a
standard 103J voice grade (analog) line.
Cables can be fed through the slot in
the receiver back plate. Maximum line
impedance is 100 Ohms.
The SCS-104 is registered with the FCC,
registration number CCKCN03BSCS-104;
Ringer Equivalence 0.3B.
Connecting the Network
Connect an IP network cable between
the J1 Ethernet connector on the front of
the line card and the network LAN/WAN
connection. Maximum line impedance is
100 Ohms. The SCS-104 automatically communicates UDP or TCP with DMP panels and automatically communicates with
encrypted panels using 128-bit or 256-bit AES Encryption.
Note: 256-bit encrypted messages sent to the SCS-1R receiver from an XR550E Control Panel Version 104 or higher software
will only communicate with SCS-104 Line Cards with Version 102 or higher software.
Phone Line Monitor
The SCS-104 monitors incoming phone line voltage. During a loss of phone line voltage, the SCS-104 sends a Warning: Phone
Line Trouble message (System Message 153) to the host automation or LCD display.
Power Monitor LED
The green LED labeled PWR turns on when the power supply on the line card is working properly.
SCS-104 Line Card
Red
Black
J8
Ethernet J1
Phone
Line J3
Power
DTR
Line 1
Line 2
Line 3
Line 4
Line Card Connector
SCS-150 Receiver
Processor Card
Rack-Mounting
holes
SCS-104 Line Cards
SCS-150 Network
Connection
InstallatIon GUIDE

800-641-4282
      
www.dmp.com 2500 North Partnership Boulevard

 
LT-1207 © 2015 Digital Monitoring Products, Inc.
15155
SCS-104 LED Indicators
The SCS-104 provides eight LEDs on the card. The table below describes the LED operation.
LED Description
Solid Flashing Off
POWER Power On N/A Power Off
DTR Data Terminal Ready N/A Processor is nearly full
LINE 1 Connected (off hook) Ringing Idle
LINE 2 Connected (off hook) Ringing Idle
LINE 3 Connected (off hook) Ringing Idle
LINE 4 Connected (off hook) Ringing Idle
LINK Indicates a valid Network connection
Indicates a valid Network connection No Connection
LINK SPEED Connected at 100 Base-T N/A Connected at 10 Base-T
SCS-104 Programming
The SCS-104 is programmed through the SCS-150 Receiver Processor Board using a Membrane keypad or Browser
programming. For more information see the SCS-1R Installation Guide (LT-1037).
SCS-104 Software Update
Updating the software for SCS-104 Receiver Line Cards can be done using Remote Link Version 1.61 or higher.
Use the following steps to perform the SCS-104 update:
1. Remove the SCS-104 Line Card from the SCS-1R
Receiver.
2. Connect a Model 399 Programming Cable to the PROG
header (J8) on the line card and to a computer with
Remote Link.
3. Place a shorting clip across the 2 pins of the LOAD (J18)
header.
4. Reinstall the SCS-104 Line Card into the SCS-1R Receiver
to power up line card.
5. Open Remote Link and select System > Remote Update
from the drop-down menu.
6. In the Remote Update window, use the browse button
to nd the SCS104.RU software update le on your
computer's hard drive. Remote Link automatically recognizes the update for the SCS-104 and allows you to select the
COM port where the line card is connected.
7. Select Update. After the update is complete, remove the SCS-104 from the receiver and disconnect the 399 cable and
remove the shorting clip from the LOAD header. Reinstall the Line Card to begin normal operation.
