Dura Trel CAMELOT PLANTER ARBOR SEAT User manual

Dura-Trel Inc. ~ PO Box 122, Sheboygan Falls, WI 53085 ~ Toll Free 877-258-6020
TOOLS NEEDED
Drill with #2 Phillips Bit or
Phillips Screwdriver
Super or Crazy Glue
CAMELOT PLANTER ARBOR SEAT
assembly INSTRUCTIONS
Note: Camelot Planter Arbor
sold separately.
SEAT ASSEMBLY
(Refer to Drawing 1)
On a clean flat surface lay the three 1 ½ x 5 ½ x 54” rails with pilot holes facing up. Set the 14”
brackets over rail lining up brackets with the pilot holes. Fasten loosely with ¾” screws.
Apply household glue to inside of the 7/8 x 1 ½” end caps and slide onto the ends of 7/8 x 1 ½ x
16 ½” center brace. Set the 7 /8 x 1 ½ x 16 ½” center brace in place over pilot holes, fasten with
the 2” screws.
Apply glue to the inside edges of the 7/8 x 1 ½ x 17” end cap and push end cap onto edge of seat
(do not slide from end), sliding the end cap under bracket as you do. Tighten all the ¾" screws on
brackets.
Seat is now ready to set between the two large planter boxes.
If you encounter missing or defective parts, please contact manufacturer direct at
toll free # below.

PACKING LIST
#11144 camelot Planter Arbor seat
PARTS CONTAINED:
QTY. PART NO. PART DESCRIPTION
3 41555-54000W 1½ x 5½ x 54” SEAT RAIL (w/wood inserts)
2 4TBCK-14001 14” SEAT BRACKET
1 47815-15750
⅞x 1½ x 15¾” SEAT BRACE
2 5ECAP-16750
⅞x 1½ x 16¾” END CAP
Hardware Bag Includes:
2 7CAPS-7815E
⅞x 1½” END CAP
12 7HDWR-06034 ¾” SCREW
6 7HDWR-06200 2” SCREW
1 CAMELOT SEAT KIT INSTRUCTIONS
NOTE: Some parts may be packed inside of others.
If you encounter missing or defective parts, please contact manufacturer direct at toll free # below.
Dura-Trel, Inc. ~ PO Box 122, Sheboygan Falls, WI 53085 ~ Toll Free 877-258-6020
