war ning sig nals
ATTENTION: Installation must be carried out by an electrician in compliance
with the latest codes and regulations.
ATTENTION: Disconnect from power source before
installation or service to prevent electric shock.
D152-00-501-IS Issue 2
SWEEPING
H100 B
SOUNDER
N~ L~
PCB
2
1
4
3
- +
through grommet
Cable entry: 1 x 5-7mm push
230V ac 50/60Hz 10mA
1.5mm² terminals
•
Dimensions : 79.5 x 94.2mm
2
1
3
1
2
3
3
2
1
@ 1Hz
115V ac 50/60Hz 19mA
TONE 3 800/1000Hz
TONE 1 BUZZER
@ 7Hz
Buzzer Horn
IP Rating: IP65
Temp: -25 C to +50 C
Unit weight: 118g
CE, UKCA
Order code Voltage
H100B030G 12-30V AC/DC
12V dc 10mA•
24V dc 24mA•
12V ac 50/60Hz 30mA•
24V ac 50Hz 62mA•
H100B230G 40-260V AC/DC
48V dc 15mA•
48V ac 50/60Hz 25mA•
115V dc 6mA•
230V dc 3mA•
TONE 2 1200/500Hz
Tel : +44 (0)2 8743 8880
www.e2s.com
L/+
•
1
2
L/+
3
N/-
MIN
MAX
SHOWN SET TO MAX
VOLUME CONTROL
N/-
TERMINAL
BLOCK
E
Sheet 1 of 2
19/01/2022
TONE FREQUENCY DESCRIPTION
1 BUZZER
2 1200/500Hz SWEEPING @ 1Hz
3 800/1000Hz @ 7Hz
war ning sig nals
L/+ N/- E
100.0
7
86
5
7
6
2
1
TERMINAL
BLOCK
A/C
INPUT
D/C
INPUT
N/- N~ -
N/- N~(FROM BEACON) -(FROM BEACON)
L/+ L~ +
L/+ L~(FROM BEACON) +(FROM BEACON)
E
3
4
5
8
CONNECT
CABLE AS
SHOWN IN
DETAIL E
9
Dimensions in mm
L~N~
- +
D152-00-501-IS Issue 2 Sheet 2 of 2
19/01/2022
Tel : +44 (0)2 8743 8880
www.e2s.com
Sheet 2 of 2
19/01/2022
CUSTOMER SUPPLIED
SCREWS 2 OFF TO SUIT
4.5mm HOLE, No.
8/M4.
45
1
2
PLACE THE HEADER
PIN TO REQUIRED TONE
SEE SHEET 1 FOR DETAIL.
3
TERMINAL
BLOCK
CUSTOMER
POWER CABLE
N L
20
5
INSERT CABLE THROUGH
GROMMET,
STRIP CABLE TO LENGTH.
2 POS'NS
INTO CABLE LOCKS IN
MAKE SURE THE
CABLE IS TUCKED FIRMLY
SCREWS
REMAIN
CAPTIVED
IN GRILLE
