Eterna VECOMEM3 User manual

Model:
VECOMEM3
(No Legend)
KEM3ML / VECOMEM3L
(Legend Included)
LED Maintained Emergency Bulkhead
These instructions are provided as a guideline to assist you.
PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLATION
AND RETAIN FOR FUTURE REFERENCE
INSTALLATION INSTRUCTIONS
A guide for qualied electricians
BATTERY REPLACEMENT:
If after routine operation check, the lamp does not
remain lit for the three hour period, a new battery
pack may be required.
01) Switch o the electricity at the mains, both
switched and permanent supply.
02) Allow batteries to fully discharge then reconnect
to supply and allow to charge for 24 hours.
03) Test again for 3 hours, if light does not remain lit
change the battery pack as follows:
04) Disconnect from the mains supply - both
permanent and switched supply and then
remove the diuser.
05) Press the two tabs and open the gear tray.
06) Unplug the battery lead from the circuit board.
07) Remove the battery pack and lift the battery
pack out of the tting.
08) Write current date on the new battery pack.
09) Fit new battery pack and secure in place.
10) Plug battery pack into circuit board.
11) Close and secure gear tray
12) Replace diuser.
13) Restore power and allow to charge for 24 hours.
14) Perform full operation check and update test
record.
REPLACEMENT BATTERY TYPE:
3.6V Ni-Cad 800mAh
CLEANING:
Clean this light tting only with a soft dry cloth.
Do not use any chemical or abrasive cleaners.
INDUSTRIAL BATTERIES:
Within certain products Eterna Lighting Ltd places
lead acid, lithium ion, nickel cadmium & nickel
metal hydride batteries on the market. Industrial
batteries are subject to waste regulation under
the Waste Batteries and Accumulators Regulations
2009 and should be disposed of responsibly.
Purchasers may be able to dispose of their waste
industrial batteries locally via legitimate licensed
trade waste contractors. Eterna is obliged to take
back, free of charge and within a reasonable time,
waste industrial batteries of the same chemistry
supplied to a Purchaser, for treatment and recycling
and is required to do this in any calendar year new
industrial batteries are placed on the market. In
certain circumstances, this may include batteries
not originally supplied by Eterna. If any Purchaser
requires Eterna to take back Industrial batteries,
they should write to the Operations Director, Eterna
Lighting Ltd, Huxley Close, NN8 6AB, who will then
advise on the necessary arrangements for the
receipt, proper treatment and recycling of, the waste
industrial batteries.
EVENTUALLY, YOU MAY WANT TO
REPLACE THIS PRODUCT:
Regulations require the recycling of Waste from
Electrical and Electronic Equipment (European
“WEEE Directive” eective August 2005—UK
WEEE Regulations eective 2nd January 2007).
Environment Agency Registered Producer: WEE/
GA0248QZ.
WHEN YOUR PRODUCT COMES TO THE END OF
ITS LIFE OR YOU CHOOSE TO REPLACE IT, PLEASE
RECYCLE IT WHERE FACILITIES EXIST DO NOT
DISPOSE WITH HOUSEHOLD WASTE.
IF YOU EXPERIENCE PROBLEMS:
If you believe your product is defective, please return
it to the place where you bought it. Our Technical
Team will gladly advise on any Eterna Lighting
product, but may not be able to give specic
instructions regarding individual installations.
3 HOURS DURATION IN EMERGENCY MODE
DANGER! Please note that there are two live supplies, one switched and one permanent; please ensure you
isolate both before you undertake any work on the emergency tting.
Visit our website: www.eterna-lighting.co.uk Made in ChinaIssue 0821
Pack contents:
1 x LED ftting
1 x Maintenance check record

READ THIS FIRST:
Check the pack and make sure you have all of the
parts listed on the front of this booklet. If not,
contact the outlet where you bought this product.
This product must be installed by a competent
person in accordance with the current building and
IEE wiring regulations.
As the buyer, installer and/or user of this product it
is your own responsibility to ensure that this tting
is t for the purpose for which you have intended
it. Eterna Lighting cannot accept any liability for
loss, damage or premature failure resulting from
inappropriate use.
This light tting must be installed in accordance with
the Building Regulations making reference to the
Wiring Regulations BS7671.
Switch o the mains before commencing installation
and remove the appropriate circuit fuse.
Suitable for indoor or outdoor use.
This product is suitable for installation on surfaces
with normal amibility e.g wood, plasterboard and
masonry.
Before making xing hole(s), check that there are no
obstructions hidden beneath the mounting surface
such as pipes or cables.
The chosen location of your new tting should
allow for the product to be securely mounted (e.g.
to a ceiling joist) and safely connected to the mains
supply (lighting circuit).
Ensure that the tting will be accessible after
installation for maintenance.
If the location of your new tting requires the
provision of a new electrical supply, the supply
must conform with the requirements of the Building
Regulations making reference to the Wiring
Regulations (see above).
You are advised at every stage of your installation to
double-check any electrical connections you have
made. After you have completed your installation
there are electrical tests that should be carried out:
these tests are specied in the Wiring Regulations
(BS7671) referred to in the Building Regulations.
The batteries supplied with this tting are a
consumable part and therefore may be outside of
any warranty oered.
INSTALLATION:
DANGER! Please note that there are two live
supplies, one switched and one permanent; please
ensure you isolate both before you undertake any
work on the emergency tting.
01) Undo the screws at each end of the diuser and
lift o.
02) Press the tabs protruding from the gear tray to
open.
03) Make the cable entry and xing holes as required.
Inside the back of the tting, there are markings
to assist you.
04) Using the back of the tting as a template, mark
the position of the xing holes on your mounting
surface.
05) Make xing holes and t plugs as appropriate.
06) Secure the back of the tting to the mounting
surface using suitable xings (not supplied).
07) Apply a silicon sealant to the xings if moisture or
weather-proong is required.
08) Fitting a cable gland will also be necessary if
moisture or weather-proong is required.
09) Thread the supply cable through the entry point
and into the tting.
10) Make connection to the mains supply according
to the colour code below. Take care not to leave
any strands protruding from the terminals and
that the terminals clamp onto the bare wire and
not onto the insulation.
N- Neutral (Blue/Black)
L- Permanent Live (Brown/Red)
This product is double insulated. Do not connect
any part to Earth.
11) Mark the current date on the battery pack.
12) Connect the battery pack to the circuit board.
13) Close the gear tray and press back onto the clips.
14) Replace the diuser and tighten securely.
15) Restore the power supply. The LED should light to
indicate correct charging.
MAINTAINED VERSION ONLY: if the link has been
left in place, the tting should also light. If you have
connected a switch across the terminals, test the
operation of your switch.
OPERATION CHECKS:
Periodic testing should be carried out to ensure
emergency lighting is operating correctly.
Interruption of the supply, causing the tting to be
energised from the battery, should be carried out by
the operation of a local keyswitch or other isolation
device. During this period all ttings should be
examined visually to ensure that they are functioning
correctly. At the end of the test period the supply
shall be restored and all indicator lamps or devices
checked to ensure that the normal supply has been
restored.
DAILY:
Visual inspection of the battery charge LED.
EACH MONTH:
Isolate the power supply for a period sucient to
ensure that each lamp is illuminated. Endorse the
test record form supplied.
ONCE EACH YEAR:
Isolate the power supply and check that the light is
still illuminated after 3 hours. Endorse the test record
form.
Because of the possibility of a failure of the normal
lighting supply occurring shortly after a period of
testing of the emergency lighting system or during
the subsequent recharge period, all full duration
tests shall wherever possible be undertaken
preceding time of low risk to allow for battery
recharge.
NOTE: please keep this instruction booklet and
the test record in a safe place. A re ocer or
other authorised person may want to see your
record of inspection and testing.
SPECIFICATIONS:
• Power: Non Maintained: 1.5W / Maintained: 4.5W
• Continuous illumination: >3 hours in emergency
operation
• Battery: 3.6V Ni-Cad, 800mAh
• Recharge time: 24 hours
• Over-discharge protection: Yes
IMPORTANT NOTES:
The control gear must be operated only within the
enclosure supplied. The gear must not be operated
outside of the enclosure.
When energised by a constant mains supply, the
battery will be constantly charged whether or not
the lamp is illuminated. On failure of the constant
mains supply, the tting will switch automatically
using transistorised switching from battery charging
to battery discharge powering the lamp whether
or not the lamp was illuminated before the power
failure.
LAMP REPLACEMENT:
DANGER!
NOTE: this unit has a permanent live mains supply,
please ensure you isolate before removing cover.
There may also be a seperate switched supply that
controls the emergency light tting - this also needs
to be isolated.
The light source contained in this luminaire
shall only be replaced by the manufacturer,
service agent or a similar qualied person.
CAUTION, RISK OF ELECTRIC SHOCK.
The light source is designed to last the lifetime of the
luminaire.
PL N
Blue
Brown
Black
Neutral
Permanent Live
Switched Live
MAINTAINED MODEL ONLY:
NOTE: To convert the maintained tting to non-
maintained operation, remove the link between
terminals “PL” and “SL”.
NOTE: If the lamp is to be switched, remove the
link from between the terminals “PL” and “SL” and
connect cable from your switch into ‘SL’.

Month
Test
Year: Year: Year: Year: Year:
Sign Date Sign Date Sign Date Sign Date Sign Date
01 Short
02 Short
03 Short
04 Short
05 Short
06 Short
07 Short
08 Short
09 Short
10 Short
11 Short
12 3 Hour
Endurance
INSTALLATION, MAINTENANCE
AND OPERATION CHECK RECORD
Product
Code:
Product
Description:
Product
Location:
Installation
Date:
Installation
Test Duration:
Installed
By:
This manual suits for next models
2
Other Eterna Lighting Equipment manuals

Eterna
Eterna ELEGAN5EM3 User manual

Eterna
Eterna SFLWW9 Setup guide

Eterna
Eterna SAP70MINI User manual

Eterna
Eterna MSCSLEDCR User manual

Eterna
Eterna YD630M Setup guide

Eterna
Eterna ML5040 User manual

Eterna
Eterna D087 Setup guide

Eterna
Eterna LED4WH Setup guide

Eterna
Eterna EAC158EM3 Setup guide

Eterna
Eterna SL1WH Setup guide

Eterna
Eterna PERLED20 User manual

Eterna
Eterna EML3MISO User manual

Eterna
Eterna RDL12 User manual

Eterna
Eterna D040 Setup guide

Eterna
Eterna TAB10PIRWH User manual

Eterna
Eterna EMLED3M User manual

Eterna
Eterna GDL50SS Setup guide

Eterna
Eterna SEEMLED3M User manual

Eterna
Eterna LDLEM3 User manual

Eterna
Eterna SQPRISMW User manual
