EtherWAN EX33000 Series User manual

W70G-NX33000Q2 Page 1
Installation Guide
EX33000 Series | Industrial Unmanaged Switch
Copyright 2023 EtherWAN Systems, Inc. All Rights Reserved 05/15/2023
1Unpacking
Open the carton and unpack the items. Your package
should include:
▪One EX33000 Switch
▪DIN rail mounting kit
If any items are missing or damaged, notify your
EtherWAN representative. If possible, save the carton
and packing material in case you need to ship or store
the switch in the future.
2Equipment Needed
▪Category 5 or better cable for RJ-45 ports
▪Appropriate fiber cable for fiber ports
3Select a Location
▪Installation: DIN rail. Place the device on the DIN
rail from above using the slot. Push the front of
the device toward the mounting surface until it
audibly snaps into place.
▪Choose a dry area with ambient temperature
between -10°C to +60°C (14°F to 140°F).
▪Keep away from heat sources, sunlight, warm air
exhausts, hot-air vents, and heaters.
▪Be sure there is adequate airflow.
▪This device has been evaluated for conformity for
use in a business environment. If used in a home
environment, there is a danger of interference.
4Connect to the Data Ports
Depending on the model, your switch can have the
following ports:
▪16 10/100Base-TX Ports
▪15 100Base-FX Port + 1 100BASE-FX port
▪14 100Base-FX Port + 2 100BASE-FX ports
5Connect Power
The switch has two pairs of power inputs:
▪A 12-48VDC terminal block
▪A 12VDC jack
Only one power input is required to operate the
switch. However, redundant power supply
functionality is supported.
Terminal Block
The switch provides two power inputs on a 12-48VDC
terminal block. The terminal block has 5 terminal
posts.
Pin
Description
Power 2
+
12-48VDC
−
Power Ground
Power 1
+
12-48VDC
−
Power Ground
Earth Ground
Relay Output
Rating
1A @ 24VDC
DC Jack
Pin
Description
Power 3
12VDC
Power Failure Alarm
A 2-pin terminal block is provided for power failure
detection. Do not connect a power source to these
pins.
The relay contact closes if:
▪Power 1 and Power 2 are both failed, but Power 3
is ON.
▪Power 3 is failed, but Power 1 and Power 2 are
both ON.
Power-Up Sequence
When the switch is powered up:
▪All Link/ACT LEDs blink momentarily.
▪The Power LED lights up and stays lit.
▪LEDs for every port connected to a device will
flash, as the switch conducts a brief Power On Self-
Test (POST).

W70G-NX33000Q2 Page 2
Installation Guide
EX33000 Series | Industrial Unmanaged Switch
Copyright 2023 EtherWAN Systems, Inc. All Rights Reserved 05/15/2023
6LED Indicators
LED
State
Indication
10/100Base-TX, 100Base-FX
LINK/ACT
Steady
Network connection
established
Flashing
Transmitting or receiving data
7DIN Rail Installation
DIN-Rail Assembly Startup, and Dismantling
▪Assembly: Place the Switch on the DIN rail from
above using the slot. Push the front of the Switch
toward the mounting surface until it audibly snaps
into place.
▪Startup: Connect the supply voltage to start up the
Switch via the terminal block.
▪Dismantling: Pull out the lower edge and then
remove the Switch from the DIN rail.
Manufacturer information:
EtherWAN Systems, Inc.
33F, No. 93, Sec. 1, Xintai 5th Rd., Xizhi Dist., New
Taipei City, 221 Taiwan
The full product manual can be downloaded from:
www.etherwan.com
