EtherWAN EX94000 User manual

W70G-EX94000Q1 Page 1
Installation Guide
EX94000 Series | Hardened Unmanaged Switch
Copyright 2023 EtherWAN Systems, Inc. All Rights Reserved 01/31/2023
1Unpacking
Open the carton and unpack the items. Your package
should include:
▪One EX94000 Switch
If any items are missing or damaged, notify your
EtherWAN representative. If possible, save the carton
and packing material in case you need to ship or store
the switch in the future.
2Equipment Needed
▪Category 5 or better cable for RJ-45 ports
▪Appropriate fiber cable for fiber ports
3Select a Location
▪Installation: DIN rail. Place the device on the DIN
rail from above using the slot. Push the front of
the device toward the mounting surface until it
audibly snaps into place.
▪Choose a dry area with ambient temperature
between -40 and 75°C (-40 and 167°F).
▪Keep away from heat sources, sunlight, warm air
exhausts, hot-air vents, and heaters.
▪Be sure there is adequate airflow.
4Connect to the Data Ports
Depending on the model, your switch can have the
following ports:
▪6 or 8 10/100BASE-TX ports
▪4 or 6 10/100BASE-TX ports + 1 or 2 100BASE-FX
ports
5Connect Power
Two power inputs are via a 12-48VDC terminal block,
and the third power input is via a 12VDC DC Jack.
Power consumption is:
▪9.12W Max. 0.76A @12VDC
▪0.38A @24VDC
▪0.19A @48VDC
Power Input Assignment
Power 2
+
12-48VDC
Terminal Block
-
Power Ground
Power 1
+
12-48VDC
-
Power Ground
Earth Ground
Relay Output
Rating
1A @ 250VAC
Power-Up Sequence
When the switch is powered up:
▪All Link/ACT LEDs blink momentarily.
▪The Power LEDs light up and stay lit.
▪LEDs for every port connected to a device will
flash, as the switch conducts a brief Power On Self-
Test (POST).
6DIP Switch Settings
DIP
No.
On
Off
1
Port 1 Alarm Enable
Port 1 Alarm Disable
2
Port 2 Alarm Enable
Port 2 Alarm Disable
3
Port 3 Alarm Enable
Port 3 Alarm Disable
4
Port 4 Alarm Enable
Port 4 Alarm Disable
5
Port 5 Alarm Enable
Port 5 Alarm Disable
6
Port 6 Alarm Enable
Port 6 Alarm Disable
7
Port 7 Alarm Enable
Port 7 Alarm Disable
8
Port 8 Alarm Enable
Port 8 Alarm Disable
9
Broadcast Storm
Protection Enable
(Broadcast Storm
will be dropped off
when more than
3000pps)
Broadcast Storm
Protection Disable
10
Reserved

W70G-EX94000Q1 Page 2
Installation Guide
EX94000 Series | Hardened Unmanaged Switch
Copyright 2023 EtherWAN Systems, Inc. All Rights Reserved 01/31/2023
7LED Indicators
LED
State
Description
Power 1, 2
(Green)
On
Switch is powered ON
correctly
Off
Switch is not receiving power
Fault (Red)
On
Relay alarm on
Off
Relay alarm off
10/100BaseTX or 100Base FX/BX Ports
Link/Act
(Green)
On
Network connection
established
Off
No link
Blinking
Transmitting or receiving
data
8DIN Rail Installation
DIN-Rail Assembly Startup, and Dismantling
▪Assembly: Place the Switch on the DIN rail from
above using the slot. Push the front of the Switch
toward the mounting surface until it audibly snaps
into place.
▪Startup: Connect the supply voltage to start up the
Switch via the terminal block.
▪Dismantling: Pull out the lower edge and then
remove the Switch from the DIN rail.
Manufacturer information:
EtherWAN Systems, Inc.
33F, No. 93, Sec. 1, Xintai 5th Rd., Xizhi Dist., New
Taipei City, 221 Taiwan
The full product manual can be downloaded from:
www.etherwan.com
