The EVJ 700
EVJ 700 EVJ 700
EVJ 700 compact controller is a modern alternative to
electro-mechanical devices for managing horizontal cooking
modules in professional kitchens. It offers maximum
configurability as it can be used with nine different applications:
electric hot plates, ovens, tilting pans, boiling pans, fry-tops,
fryers, pasta cookers, bain-marie and grills.
Depending on the application, cooking can be controlled by power or
temperature, combined with a timer or needle probe as re uired.
Temperature can be ON-OFF or PI controlled for greater regulation
precision.
The smart 2.8 inch LCD graphic display with 6 capacitive touch
keys and/or a push encoder provides constant information about
the processes in progress, as well as making it easy to set the
cooking cycle.
E uipped with IP65 front protection, the controller can be fitted to
the panel in the conventional way, built into the front, or concealed
under the panel (if made of glass or methacrylate), ensuring high
cleaning and hygiene standards.

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 6
Ma n features and purchas ng codes
Ma n features and purchas ng codesMa n features and purchas ng codes
Ma n features and purchas ng codes
The table below shows the main features and their purchasing codes
Features
FeaturesFeatures
Features
EVJ705J9
EVJ705J9EVJ705J9
EVJ705J9 EVJ705Z9
EVJ705Z9EVJ705Z9
EVJ705Z9 EVJ725J9
EVJ725J9EVJ725J9
EVJ725J9
EVJ705J9VG
EVJ705J9VGEVJ705J9VG
EVJ705J9VG
Power supply
Power supplyPower supply
Power supply
115... 230 VAC • • • •
Installa
InstallaInstalla
Installat on
t ont on
t on
Recessed in the panel
•
•
•
Concealed under the panel (if made of glass or
metacrylate)
•
Analogue nputs
Analogue nputsAnalogue nputs
Analogue nputs
Regulation probe (Pt 1000 2 wires) •
Regulation probe (J/K/Pt 100 2 wires) • • •
Needle probe (Pt 1000 2 wires) •
Needle probe (J/K/Pt 100 2 wires) • • •
D g tal nputs
D g tal nputsD g tal nputs
D g tal nputs
Multi-purpose 1 • • • •
Multi-purpose 2 • • • •
D g tal outputs (electro
D g tal outputs (electroD g tal outputs (electro
D g tal outputs (electro-
--
-mechan cal relays, A res.
mechan cal relays, A res. mechan cal relays, A res.
mechan cal relays, A res.
at 250 VAC)
at 250 VAC)at 250 VAC)
at 250 VAC)
Load 1 (configurable) 16 A 16 A 16 A 16 A
Load 2 (configurable) 5 A 8 A 5 A
Load 4 (configurable) 8 A 8 A 8 A 8 A
Load 5 (configurable) 8 A 5 A 8 A 8 A
Load 6 (configurable) 5 A 5 A 5 A
D g tal outputs
D g tal outputs D g tal outputs
D g tal outputs (command for sol d state relays; 12
(command for sol d state relays; 12 (command for sol d state relays; 12
(command for sol d state relays; 12
VDC, 15 mA max)
VDC, 15 mA max)VDC, 15 mA max)
VDC, 15 mA max)
Load 2 (configurable) •
Load 6 (configurable •
User nterface
User nterfaceUser nterface
User nterface
2.8 inch graphic display • • • •
Commun cat ons ports
Commun cat ons portsCommun cat ons ports
Commun cat ons ports
TTL MODBUS • • • •
For encoder • • • •
Further features
Further featuresFurther features
Further features
Alarm buzzer • • • •
ON-OFF/PI control • • • •
For more information see the section “Technical specifications”.

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 7
Measurements and nstallat on
Measurements and nstallat onMeasurements and nstallat on
Measurements and nstallat on (mm)
(mm)(mm)
(mm)
Models for bu lt- n nstallat on.
Front installation on a plastic or metal panel (with elastic holding flaps).
N.B.
The metal panel must be between 0.8 and 1.5 mm (1/32 and 1/16 in) thick, while the plastic panel must be between 0.8 and 3.4 mm (1/32 and
1/8 in).
INSTALLATION PRECAUTIONS
INSTALLATION PRECAUTIONSINSTALLATION PRECAUTIONS
INSTALLATION PRECAUTIONS
–Ensure that the wor ing conditions are within the limits stated in the “Technical specifications” section.
–Do not install the device close to heat sources, equipment with a strong magnetic field, in places subject to direct
sunlight, rain, damp, excessive dust, mechanical vibrations or shoc s.
–In compliance with safety regulations, the device must be installed properly to ensure adequate protection from
contact with electrical parts. All protective parts must be fixed in such a way as to need the aid of a tool to remove
them.

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 8
Models for concealed nstallat on under the panel
Installation from behind on a glass or methacrylate panel (with double-sided adhesive tape) personalising the keys on the front of the unit.
N.B.
- the maximum thickness of a glass panel must be 4.0 mm (3/16 in), while that for a methacrylate panel must be 2.0 mm (1/16)
- the panel and the material used to carry out screen printing must not contain conductive substances
- keep the device and the panel at a temperature of between 15 and 38°C (59 and 100°F) for about an hour before carrying out the installation
- before installation, carefully clean the panel surface that will be in contact with the double-sided adhesive tape, making sure that the
product used for cleaning is suitable for the panel material (we recommend using isopropyl alcohol, in the case of surfaces greased with a
hydrocarbon solvent). Continue cleaning with a cloth until it is clean and dry after use
- during installation, apply uniform and constant pressure for about 30 seconds on the panel surface in contact with the double-sided
adhesive tape. Then leave the device and the panel in a horizontal position for about 48 hours at a temperature of between 15 and 38°C (59
and 100°F).

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 9
Electr cal connect ons
Electr cal connect onsElectr cal connect ons
Electr cal connect ons
Electr cal connect on model EVJ705Z9
PRECAUTIONS FOR ELECTRICAL CONNECTIONS
PRECAUTIONS FOR ELECTRICAL CONNECTIONSPRECAUTIONS FOR ELECTRICAL CONNECTIONS
PRECAUTIONS FOR ELECTRICAL CONNECTIONS
–Use cables of an adequate section for the current running through them
–To reduce any electromagnetic interference, locate the power cables as far away as possible from the signal cables
–If using an electrical or pneumatic screwdriver, adjust the tightening torque
–If the device is moved from a cold to a warm place, humidity may cause condensation to form inside; wait for about
an hour before switching on the power
–Ma e sure that the supply voltage, electrical frequency and power are within the set limits
–Disconnect the power supply before carrying out any type of maintenance
–Do not use the device as a safety device
–For repairs and further information, contact the EVCO sales networ ; returned goods without the data label will
not be accepted

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 10
Electr cal connect on model EVJ705J9 and EVJ705J9VG

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 11
Electr cal connect on model EVJ725J9

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 12
Nav gat on
Nav gat onNav gat on
Nav gat on
Introduct on
Introduct onIntroduct on
Introduct on
The controllers in the EVJ 700 range have 6
capacitive eys and a push encoder (optional).
All the functions can be activated by both the eys
and the encoder.
Later sections in this manual will describe the
platform used for each of the 9 available
applications in detail,
while the normal navigation and configuration
procedures are illustrated below.
Keypad
KeypadKeypad
Keypad
The eypad has 6 capacitive eys; 2 have set functions (ON-
OFF and REFRESH), while 4 have functions which vary
according to the menu the user is in. Pressing a "function" ey
enables the function indicated on the icon above the ey.
ON-OFF
Pressing this ey for 2 seconds
switches the controller on/off
REFRESH
At the end of the countdown, pressing this ey
will refresh the time previously set on the
selected timer
FUNCTION
Depending on the application activated, the
four function eys are used to select:
–type of coo ing
–temperature setpoint
–heating power
–coo ing time
Once the function has been selected (e.g. the
timer), the relative icon goes from grey to white, as
does the value which is to be modified.
If a value needs to be changed from the
eypad, the function eys are momentarily
used as icons
“-”, “+”, “SET”.
Push encoder
Push encoderPush encoder
Push encoder
The functions can also be selected using the encoder by
simply pressing the push button. When the icons are
selected, they change colour:
–grey not selected
–white selected and ready to be modified
The value of the selected function is changed by
turning the encoder cloc wise or anticloc wise.
Encoder purchasing codes
EVC99C00X0XXX03 Encoder push soft torque
EVC99C00X0XXX04 Encoder push heavy torque
PUSH
to choose the desired function
TURN
to change the chosen value

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 13
Chang ng values
Chang ng valuesChang ng values
Chang ng values
Values can be changed either by using the eypad or
the push encoder.
–Keypad:
Select the desired function, the value will become
white. Press one of the function eys on the monitor
and the “-”, “+”, “SET” values will appear.
The value can be increased or decreased by pressing
the relative ey and then confirmed with the “SET” ey.
–Push encoder:
Select the desired function by pressing the push
button on the encoder. The value will become white.
Turn the encoder to set the value and press the
push button once again to confirm.
If neither of these two procedures are carried out
within 5 seconds, the controller will automatically
save the displayed value.
The display will return to the ON screen:
Function
Select the
function
VALUE
change the value
using the “-”, “+”,
“SET” eys
Power fa lure
Power fa lurePower fa lure
Power fa lure
In the event of a power failure during normal operation, the controller will start wor ing again according to the
configuration of parameter “A13”.
Commun cat on
Commun cat onCommun cat on
Commun cat on
The following products can be connected through the TTL port:
–EVJKEY (programming ey)
–EVIF22TSX (TTL/RS-485 serial interface)
01 00:00
3
4
5 00:00
-
+

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 14
Bas c funct ons
Bas c funct onsBas c funct ons
Bas c funct ons
The following basic functions are available for all the configurations.
Technical room fans (only for models with J/K thermocouples)
When the temperature recorded by the on-board probe exceeds the threshold set by parameter “r37”, the relay
configured as “Fans” is activated.
The hysteresis to deactivate the relay is set at 2°C.
If one of the relays is set as “Fans” but there is no on-board probe or there is a probe error, the relay will always
be active.
When the heating output is active (either in power-controlled and in temperature-controlled models), the icon will be
displayed in the top-left corner.
Heating
When regulation is managed with a temperature setpoint, the relay output for the heaters can be
managed by conventional or PI-type regulation.
Activating the buzzer when the setpoint is reached
For applications with temperature regulation, the first time the setpoint regulation temperature is reached (including the
MELT function), the buzzer will sound according to the configuration set by parameter “e2”.
The buzzer will wor with the same logic as the “green light” which indicates the setpoint has been reached.

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 15
OFF
Ma n menu
Ma n menu Ma n menu
Ma n menu
Once the controller has been connected to the power supply, the OFF
screen will be displayed.
–The main screen is accessed by pressing the
function ey on the OFF screen.
–The configuration screen is accessed by pressing
the function ey on the OFF screen.
Conf gurat on screen
Conf gurat on screenConf gurat on screen
Conf gurat on screen
From the configuration screen, it is possible to
choose the controller settings from various different
menus.
To choose the menu to change, select it by pressing
the function eys corresponding to the “UP” and
“DOWN” arrows. The writing will become white when
selected. Press the “SET” function ey to confirm.
Setting the password
Some of the menus in the configuration screen require
a password to be entered to be changed:
–“Configuration”:
allows the user to configure the type of application
to be managed by the controller
–“Service”:
manages the parameters
–“Restore parameters”:
reloads the default values (except the
PAS and P0 parameters); the password is "149".
Once the “Configuration” menu has been selected,
the password must be entered.
Press the function eys corresponding to the “UP” and
“DOWN” arrows to set the password, then press the “SET”
function ey to confirm.
01 00:00
OFF
CONFIGURATION
SERVICE
LANGUAGE
INTERNAL VALUES
RESTORE PARAMETERS
SET
CONFIGURATION
SERVICE
LANGUAGE
INTERNAL VALUES
RESTORE PARAMETERS
SET
-19
SET

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 16
Ava lable menus
Ava lable menusAva lable menus
Ava lable menus
The following menus are available on the configuration screen:
–Configuration
–Service
–Language
–Internal values
–Restore parameters
Configuration
In this menu it is possible to set the application to be managed using the controller through the dedicated parameter “e1”.
Once the application has been selected, the relative default parameters will be automatically uploaded.
Service
Parameters can be displayed and changed in this menu.
The complete list of the parameters with their labels, descriptions and values can be found in the section “Table of
parameters. After entering the password, the complete list of parameters will appear on the screen.
The parameters to change can be selected by pressing the function eys corresponding to the “UP” and “DOWN”
arrows and then the “SET” function ey to confirm.
Language
The required language can be chosen in this menu:
–Italian
–English
–French
–German
–Spanish
The language to set can be selected by pressing the function eys corresponding to the “UP” and “DOWN” arrows
and then the “SET” function ey to confirm.
Internal values
The status of the inputs and outputs available for the application in use can be viewed in this menu:
–Probes
–Digital inputs
Restore parameters
The parameter values can be restored in this menu, restoring the controller to the factory
settings.

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 17
Conf gur ng nputs/outputs for the d fferent appl cat ons
Conf gur ng nputs/outputs for the d fferent appl cat onsConf gur ng nputs/outputs for the d fferent appl cat ons
Conf gur ng nputs/outputs for the d fferent appl cat ons
The basic configuration of the inputs/outputs for each individual application is as follows:
I/O
I/OI/O
I/O
No
No No
No appl cat on
appl cat on appl cat on
appl cat on Electr c
Electr c Electr c
Electr c hot plates
hot plates hot plates
hot plates Ba n
Ba n Ba n
Ba n-
- -
-mar e
mar e mar e
mar e
T lt ng
T lt ng T lt ng
T lt ng pans
pans pans
pans Bo l ng pans
Bo l ng pans Bo l ng pans
Bo l ng pans Fry
Fry Fry
Fry-
- -
-tops
tops tops
tops
Cast
Cast Cast
Cast ron
ron ron
ron
gr lls
gr lls gr lls
gr lls
Fryers
Fryers Fryers
Fryers Pasta
Pasta Pasta
Pasta cookers
cookers cookers
cookers Ovens
Ovens Ovens
Ovens
Analogue inputs
Analogue inputsAnalogue inputs
Analogue inputs
Regulat on
Regulat on Regulat on
Regulat on
probe
probeprobe
probe
√
√√
√ √
√√
√ √
√√
√ √
√√
√ √
√√
√
Needle probe
Needle probeNeedle probe
Needle probe √
√√
√ √
√√
√ √
√√
√
Digital inputs
Digital inputsDigital inputs
Digital inputs
d1
d1d1
d1 √
√√
√
LEVEL
LEVEL LEVEL
LEVEL
SENSOR
SENSORSENSOR
SENSOR
DOOR SWITCH
DOOR SWITCHDOOR SWITCH
DOOR SWITCH
√
√√
√ √
√√
√ √
√√
√ √
√√
√ √
√√
√ √
√√
√
d2
d2d2
d2 √
√√
√ √
√√
√ √
√√
√ √
√√
√ √
√√
√ √
√√
√ √
√√
√ √
√√
√ √
√√
√
Other inputs
Other inputsOther inputs
Other inputs
Push
Push Push
Push
encoder
encoderencoder
encoder
√
√√
√ √
√√
√ √
√√
√ √
√√
√ √
√√
√ √
√√
√ √
√√
√ √
√√
√
Digital outputs
Digital outputsDigital outputs
Digital outputs
K1
K1K1
K1
HEATING
HEATING HEATING
HEATING
ELEMENT
ELEMENTELEMENT
ELEMENT
HEATING
HEATING HEATING
HEATING
ELEMENT
ELEMENTELEMENT
ELEMENT
HEATING
HEATING HEATING
HEATING
ELEMENT
ELEMENTELEMENT
ELEMENT
HEATING
HEATING HEATING
HEATING
ELEMENT
ELEMENTELEMENT
ELEMENT
HEATING
HEATING HEATING
HEATING
ELEMENT
ELEMENTELEMENT
ELEMENT
HEATING
HEATING HEATING
HEATING
ELEMENT
ELEMENTELEMENT
ELEMENT
HEATING
HEATING HEATING
HEATING
ELEMENT
ELEMENTELEMENT
ELEMENT
HEATING
HEATING HEATING
HEATING
ELEMENT
ELEMENTELEMENT
ELEMENT
TOP HEATING
TOP HEATING TOP HEATING
TOP HEATING
ELEMENT
ELEMENTELEMENT
ELEMENT
K2
K2K2
K2
H
HH
H2
22
2O
OO
O CHARGE
CHARGE CHARGE
CHARGE
VALVE
VALVEVALVE
VALVE
H
HH
H2
22
2O
OO
O CHARGE
CHARGE CHARGE
CHARGE
VALVE
VALVEVALVE
VALVE
COLD
COLD COLD
COLD H
HH
H2
22
2O
OO
O
VALVE
VALVEVALVE
VALVE
AUXILIARY
AUXILIARY AUXILIARY
AUXILIARY
RELAY
RELAYRELAY
RELAY
MOTOR
MOTORMOTOR
MOTOR-
--
-
DRIVEN
DRIVEN DRIVEN
DRIVEN
BASKET 1
BASKET 1BASKET 1
BASKET 1
H
HH
H2
22
2O
OO
O FAST
FAST FAST
FAST
CHARGE
CHARGE CHARGE
CHARGE
VALVE
VALVEVALVE
VALVE
BOTTOM
BOTTOM BOTTOM
BOTTOM
HEATING
HEATING HEATING
HEATING
ELEMENT
ELEMENTELEMENT
ELEMENT
K4
K4 K4
K4
TECHNICAL
TECHNICAL TECHNICAL
TECHNICAL
ROOM FANS
ROOM FANSROOM FANS
ROOM FANS
H
HH
H2
22
2O
OO
O
DISCHARGE
DISCHARGE DISCHARGE
DISCHARGE
VALVE
VALVEVALVE
VALVE
TECHNICAL
TECHNICAL TECHNICAL
TECHNICAL
ROOM FANS
ROOM FANSROOM FANS
ROOM FANS
HOT
HOTHOT
HOT H
HH
H2
22
2O
OO
O
VALVE
VALVEVALVE
VALVE
TECHNICAL
TECHNICAL TECHNICAL
TECHNICAL
ROOM FANS
ROOM FANSROOM FANS
ROOM FANS
TECHNICAL
TECHNICAL TECHNICAL
TECHNICAL
ROOM FANS
ROOM FANSROOM FANS
ROOM FANS
TECHNICAL
TECHNICAL TECHNICAL
TECHNICAL
ROOM FANS
ROOM FANSROOM FANS
ROOM FANS
H
HH
H2
22
2O
OO
O SLOW
SLOW SLOW
SLOW
CHARGE
CHARGE CHARGE
CHARGE
VALVE
VALVEVALVE
VALVE
TECHNICAL
TECHNICAL TECHNICAL
TECHNICAL
ROOM FANS
ROOM FANSROOM FANS
ROOM FANS
K5
K5K5
K5
ON
ONON
ON-
--
-OFF
OFFOFF
OFF ON
ONON
ON-
--
-OFF
OFFOFF
OFF ON
ONON
ON-
--
-OFF
OFFOFF
OFF ON
ONON
ON-
--
-OFF
OFFOFF
OFF ON
ONON
ON-
--
-OFF
OFFOFF
OFF ON
ONON
ON-
--
-OFF
OFFOFF
OFF ON
ONON
ON-
--
-OFF
OFFOFF
OFF ON
ONON
ON-
--
-OFF
OFFOFF
OFF ON
ONON
ON-
--
-OFF
OFFOFF
OFF
K6
K6K6
K6
TECHNICAL
TECHNICAL TECHNICAL
TECHNICAL
ROOM FANS
ROOM FANSROOM FANS
ROOM FANS
TECHNICAL
TECHNICAL TECHNICAL
TECHNICAL
ROOM FANS
ROOM FANSROOM FANS
ROOM FANS
MOTOR
MOTORMOTOR
MOTOR-
--
-
DRIVEN
DRIVEN DRIVEN
DRIVEN
BASKET 2
BASKET 2BASKET 2
BASKET 2
TECHNICAL
TECHNICAL TECHNICAL
TECHNICAL
ROOM FANS
ROOM FANSROOM FANS
ROOM FANS

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 18
Conf gurable appl cat ons
Conf gurable appl cat onsConf gurable appl cat ons
Conf gurable appl cat ons
The controller firmware can manage up to nine different applications. The desired application can be enabled using parameter “e1”
as per the following list:
–0 = “None”
–1 = “Electric hot plates”
–2 = “Bain-marie”
–3 = “Tilting pans”
–4 = “Boiling pans”
–5 = “Fry-Tops”
–6 = “Cast iron grills”
–7 = “Fryers”
–8 = “Pasta coo ers”
–9 = “Ovens”

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 19
Electr c hot plates
Electr c hot platesElectr c hot plates
Electr c hot plates
Inputs available
–Push encoder
–Technical room fans
–ON-OFF
Outputs available
–Heater
Information displayed
The display shows the power value and the coo ing time.
After switch-on During regulation
Available functions
Device ON/OFF
When the display is switched on, the default values are loaded:
Power: 0
Time: 00:00mm:ss
Power regulation:
Selection interval: [0<->6]
Selection of coo ing time
Selection range: [00:00<->59:59 mm:ss]
Refresh
This reloads the last time value set on the selected timer

EVJ 700
EVJ 700 EVJ 700
EVJ 700 -
--
- Application Manual:
144EVJ700E204 EVCO | 29.01.2021 | 20
Operation
–All the functions listed above can be selected using the function eys or the push encoder, as described in the general
introduction.
–During setting, the value to change will flash.
The hours/minutes or minutes/seconds on the timer are modified separately.
If confirmation is not given within 5 seconds, it will automatically validate the displayed value.
–The controller begins regulation when the value of the energy regulator is anything other than “0”, based on the
regulation value set by the relative parameters:
–Regulator 1: 2” (r19) ON/10” (r20) OFF
–Regulator 2: 4” (r21) ON/10” (r22) OFF
–Regulator 3: 6” (r23) ON/10” (r24) OFF
–Regulator 4: 8” (r25) ON/10” (r26) OFF
–Regulator 5: 10” (r27) ON/10” (r28) OFF
–Regulator 6: 12” (r29) ON/10” (r30) OFF
–Heating is interrupted when the power regulator is set with a value of “0” or when the controller is switched OFF.
–At the end of the countdown (when the time is 00:00), the buzzer will sound until the button on the push encoder (or
one of the six function eys) is pressed or until the timeout interval set by the relative parameter (e2) elapses, with a
cycle of 0.5 ”ON/0.5” OFF. This does not affect the regulation, the device will continue normal regulation.
Management of technical room fan output and ON-OFF output
– If one of the available outputs is configured as “technical room fans” (value set to 11), the fans are always on
(except for models with J/K thermocouples, where they are activated when the threshold set by parameter r37
is exceeded).
–
– If one of the available outputs is configured as “ON-OFF” (value set to 14), the relay will operate as follows:
–OFF when the device is on stand-by mode
–ON under all other conditions
