Evco Vcolor 539 Series User guide

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 1 of 4
Vcolor 539 M & L
Controllers for food processing cabinets and rooms
ENGLISH
INS ALLER MANUAL ver. 1.0
CODE 144VC539E104

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 2 of 4
Important
Read this document carefully before installation and before using the device and take all the prescribed precautions. Keep this
document with the device for future consultation.
Only use the device in the ways described in this document. Do not use the device as a safety device.
Disposal
The device must be disposed of according to local regulations governing the collection of electrical and electronic equipment.

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 3 of 4
Index
1 INTRODUCTION .................................................... 4
1.1 Product description ............................................... 4
1.2 Table listing the models available, their main features
and purchasing codes ............................................ 5
2 MEASUREMENTS AND INSTALLATION ...................... 7
2.1 Vcolor 539 M user interface measurements .............. 7
2.2 Vcolor 539 L user interface measurements ............... 7
2.3 User interface installation ......................................
2.4 Control module measurements ...............................
2.5 Control module installation ....................................
2.6 Expansion measurements EVC20P52N9XXX10 .......... 9
2.7 Installation precautions ......................................... 9
2. Vcolor 539M electrical connection ......................... 10
2.9 Vcolor 539L electrical connection .......................... 11
3 FIRST-TIME USE ................................................. 12
3.1 Operating modes ................................................ 12
3.2 Operating the device ........................................... 12
4 NAVIGATION ...................................................... 13
4.1 Initial information ............................................... 13
4.2 Home screen ...................................................... 13
4.3 Run screen ........................................................ 14
4.3.1 Regulator status icons ......................................... 14
4.3.2 Function keys ..................................................... 15
4.4 Screen saver ...................................................... 15
4.5 Settings screen .................................................. 16
4.5.1 Service .............................................................. 16
5 AN OVERVIEW OF THE FUNCTIONS ....................... 17
5.1 Automatic and manual cycles ............................... 17
5.2 Settable features for each phase .......................... 17
5.2.1 Management of temperature, humidity, ventilation
speed, duration .................................................. 17
5.2.2 Air change management ...................................... 17
5.2.3 Management of product rest intervals ................... 1
5.3 Settable features for the aging cycle ..................... 1
5.3.1 Cabinet restart ................................................... 1
5.3.2 Heating control ................................................... 1
5.3.3 Final holding ...................................................... 1
5.3.4 Final air change .................................................. 19
5.4 Other functions .................................................. 19
5.4.1 Product sterilisation/oxygenation cycle .................. 19
5.4.2 Product smoking cycle ......................................... 19
5.4.3 Manual rest cycle ................................................ 20
5.4.4 Manual air change cycle....................................... 20
5.4.5 Manual defrosting ............................................... 20
5.4.6 Light on/off ........................................................ 20
6 MAIN FUNCTIONS ............................................... 21
6.1 Manual cycle ...................................................... 21
6.2 Automatic cycle .................................................. 22
6.2.1 Start-up and interruption of an automatic cycle ...... 22
6.2.2 Setting/Making changes to an automatic cycle ........ 23
6.2.3 Saving an automatic cycle .................................... 23
6.3 Recipe book ....................................................... 23
7 REGULATIONS .................................................... 24
7.1 Temperature regulation ....................................... 24
7.1.1 Generating cooling .............................................. 24
7.1.2 Generating heat .................................................. 24
7.2 Humidity regulation ............................................. 25
7.2.1 Humidification management ................................. 25
7.2.2 Dehumidification management.............................. 26
LOAD MANAGEMENT ............................................ 27
.1 Compressor management .................................... 27
.2 Pump-down management .................................... 27
.3 Evaporator fan management ................................ 27
.4 Defrost management ........................................... 2
.5 Heater management ............................................ 2
.6 Steam generator output management ................... 2
.7 Humidifier output management ............................ 2
.7.1 Managing the humidifier output without a transducer
(rU0 = 1, E12 = 0 or 1) ....................................... 2
.7.2 Managing the humidifier output with a transducer
and a humidifier with a steamer (rU0 = 0, E12 = 0) 2
.7.3 Managing the humidifier output with a transducer
and an instant generation humidifier (rU0 = 0, E12 =
1) ..................................................................... 29
. Dehumidification management.............................. 29
. .1 Management using an extractor fan/dehumidifier .... 29
. .2 Management by activating the refrigeration plant .... 29
.9 Condenser fan management ................................. 29
.10 Cabinet light management ................................... 29
.11 Air change fan management ................................. 29
.12 Sterilisation/oxygenation management .................. 29
.13 Smoker management .......................................... 30
.14 Alarm output management ................................... 30
9 MANAGEMENT OF EQUIPMENT WITH HEAT PUMP .... 30
9.1 Food processing rooms with heat pump ................. 30
10 USB PORT MANAGEMENT ..................................... 32
11 PARAMETERS...................................................... 33
12 ALARMS ............................................................. 40
13 ACCESSORIES .................................................... 43
13.1 Non-optoisolated RS-4 5/USB serial interface ........ 43
13.2 USB plug for panel installation .............................. 43
13.3 Connecting cables 0 1050001 /0 10500020 ......... 43
13.4 4GB USB flash drive EVUSB4096M ........................ 43
14 TECHNICAL SPECIFICATIONS ............................... 44
14.1 Technical specifications ........................................ 44

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 4 of 4
1IN RODUC ION
1.1 Product description
Vcolor 539 is a split controller with a capacitive TFT touch-screen colour graphic display (5” or 7") for flush panel fitting and total
management of food processing cabinets or rooms for different types of products such as meat, charcuterie and cheese.
It has manual conservation cycles and automatic aging cycles (up to 30 sequential phases) whose duration, temperature, humidity and
ventilation can all be fully configured.
It is possible to set automatic air change and pause/work cycles, as well as managing optional sterilisation, oxygenation and smoking
processes either automatically or manually.
Standard 4-20 mA transducers (such as EVHP503) may be used to manage humidity or read the acidity level of a product; alternatively
humidity can be controlled using a dedicated probe T+RH EVTHP500 (RH 5-95% / T -20/ 0°C).

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 5 of 4
1.2 able listing the models available, their main features and purchasing codes
The table below lists the models available.
Models available
Vcolor 539 M
5-inch capacitive TFT touch-
screen graphic display in glass
Vcolor 539 L
7-inch capacitive TFT touch-
screen graphic display in glass
EVC20P52N9XXX10
Optional 4 relay expansion
The table below shows the main features of the device.
Power supply Vcolor 539 M Vcolor 539 L EVC20P52N9XXX10
Control module 115...230 VAC 115...230 VAC 115...230 VAC
User interface Powered by the control
module 12 VAC
Analogue inputs Vcolor 539 M Vcolor 539 L EVC20P52N9XXX10
Cabinet probe (PTC/NTC) • •
Evaporator probe (PTC/NTC) • •
Condenser probe (PTC/NTC) • •
Humidity probe EVHTP500 (NTC) • •
Humidity or pH transducer (4-20 mA) • •
Digital inputs (for normally
open/normally closed contact) Vcolor 539 M Vcolor 539 L EVC20P52N9XXX10
Door switch • •
Compressor thermal switch • •
Low pressure switch • •
High pressure switch • •
Analogue outputs Vcolor 539 M Vcolor 539 L EVC20P52N9XXX10
PWM (evaporator fan) • •
Digital outputs (electro-mechanical
relays; A res. @ 250 VAC) Vcolor 539 M Vcolor 539 L EVC20P52N9XXX10
Configurable K1 (default compressor) 16 A 16 A
Configurable K2 (default cabinet light) A A
Configurable K3 (default humidifier) A A
Configurable K4 (default air change) A A
Configurable K5 (default heater) A A
Configurable K6 (default alarm) 16 A 16 A
Configurable K7 (default condenser fan) 16 A 16 A
Configurable K (default pump-down
solenoid valve) 10 A 10 A
Configurable K9 (default defrost) 10 A 10 A
Configurable K10 (default
steriliser/oxygenator) 30 A
Configurable K11 (default smoker) 16 A
Configurable K12 (default steam generator) A

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 6 of 4
Configurable K13 (default dehumidifier) 16 A
Communications ports Vcolor 539 M Vcolor 539 L EVC20P52N9XXX10
RS-4 5 MODBUS • • •
USB • •
Other features Vcolor 539 M Vcolor 539 L EVC20P52N9XXX10
Clock • •
Alarm buzzer • •
Management of automatic aging cycles and
manual conservation cycles • •
Fan intensity management • •
HACCP function • •
“Programmes" function • •
For more information see the section 14 “TECHNICAL SPECIFICATIONS”.
The table below shows the purchasing codes.
Purchasing codes
Vcolor 539 M (control module + 5-inch user interface kit)
EVCMC539N9E
Vcolor 539L (control module + 7-inch user interface kit)
EVCLC539N9E
EVC20P52N9XXX10 (optional 4 relay expansion)
EVC20P52N9XXX10
EVH P500 (optional temperature/humidity probe)
EVHTP500
For more models contact the EVCO sales network.

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 7 of 4
2MEASUREMEN S AND INS ALLA ION
2.1 Vcolor 539 M user interface measurements
The figure below shows the measurements of the 5-inch user interface; measurements are expressed in mm (inches).
2.2 Vcolor 539 L user interface measurements
The figure below shows the measurements of the 7-inch user interface; measurements are expressed in mm (inches).

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page of 4
2.3 User interface installation
The figure below shows the installation of the user interface.
The user interface installed from behind using threaded studs enables it to be placed flush with the panel thus making it fit perfectly
with the design of the unit.
2.4 Control module measurements
The figure below shows the measurements of the control module; measurements are expressed in mm (inches).
2.5 Control module installation
Installation of the control module is on a flat surface with spacers.

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 9 of 4
2.6 Expansion measurements EVC20P52N9XXX10
The figure below shows the measurements of the 4 relay expansion.
2.7 Installation precautions
- Ensure that the working conditions for the device (operating temperature, humidity, etc.) are within the set limits. See the section 14
“TECHNICAL SPECIFICATIONS”.
- Do not install the device close to heat sources (heaters, hot air ducts, etc.), equipment with a strong magnetic field (large diffusers,
etc.), in places subject to direct sunlight, rain, damp, excessive dust, mechanical vibrations or shocks.
- Any metal parts close to the control module must be far enough away so as not to compromise the safety distance.
- In compliance with safety regulations, the device must be installed properly to ensure adequate protection from contact with electrical
parts. All protective parts must be fixed in such a way as to need the aid of a tool to remove them.

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 10 of 4
2.8 Vcolor 539M electrical connection
The diagram below shows the Vcolor 539 M electrical connection.

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 11 of 4
2.9 Vcolor 539L electrical connection
The diagram below shows the Vcolor 539 L electrical connection.

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 12 of 4
3FIRS - IME USE
3.1 Operating modes
The controller has the following operating modes:
- “off” (no power to the device);
- “stand-by” (the device is powered but switched off);
- “on” (the device is powered, switched on and awaiting start-up of an operating cycle);
- “run” (the device is powered, switched on and running an operating cycle).
Terminology: “switch on the device” means moving from “stand-by” to “on” mode and “switch off the device” means moving from “on”
to “stand-by” mode.
If there is a power failure, when power is restored the device will return to the mode set before the failure.
3.2 Operating the device
Follow these instructions to operate the device.
1. Install the device as shown in section 2 “MEASUREMENTS AND INSTALLATION”, taking all the precautions mentioned in
paragraph 2.6 “Installation precautions”.
2. Make the electrical connection as shown in sectionErrore. L'origine riferimento non è stata trovata. “ELECTRICAL
CONNECTION”.
3. Connect the power supply to the device:if parameter E9 is set at 1 (default), the device will show the EVCO splash screen
for 10 seconds; if the parameter is set at 0, a system loading screen will be shown:
E9=1 E9=0
Once loading is complete, the device will display the mode it was in before being powered down:
- On/stand-by screen, press the central area to move to the Home screen;
- the Home screen.
On/stand-by screen Home screen
To switch the device on, press the central key on the On/stand-by screen; to switch the device off, press the key
on the lower part of the Home screen.
N.B. If the power supply has been cut off long enough to cause a clock error (RTC alarm), it will be necessary to reset the
day and time.
4. When switching on from the settings key on the On/stand-by screen, enter the SET DATE/TIME menu, touch the data
to change and confirm with .
5. From the settings key on the On/stand-by screen, enter the SERVICE menu and from here the PARAMETERS menu.
Enter the password -19 and configure the device as you wish in the order in which the parameters are listed in the table
below. Then check that the remaining parameters have been set in a consistent way. See later sections and in particular
the section PARAMETERS.

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 13 of 4
4 NAVIGA ION
4.1 Initial information
Navigating the menus is intuitive, based on touch technology.
-To enter into a procedure, touch the menu or the corresponding icon.
-To exit the procedure and, in general, to return to the previous level, press the Back key.
-To scroll up and down a menu, use the and keys.
-To confirm the settings and/or changes, press the key.
-To start up a cycle, press .
-To interrupt a cycle, hold down for at least 4 seconds.
-To regulate a setting, use the – and + keys or press and drag the relevant bar.
-To silence the buzzer, touch any key while it is sounding. If the buzzer is sounding for the end of an automatic cycle or
because the pre-cooling temperature has been reached, the buzzer will be deactivated automatically after the number of
seconds set by parameter E11 (unless it is silenced manually).
4.2 Home screen
The Home screen is the departure point for navigating the user interface.
The Home screen displays the functions enabled, the date and the time.
All the end user’s selections start from the Home screen.
The 4 interactive keys grant access to the following functions:
MANUAL
select, set and start up a manual conservation cycle of infinite duration
AUTOMATIC
select, set and start up a complete automatic aging cycle
RECIPE BOOK
select and/or change automatic aging cycles saved in the memory

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 14 of 4
4.3 Run screen
Once a manual or automatic cycle has been started up, the Run screen will appear for the type of cycle selected.
MANUAL
AUTOMATIC
4.3.1 Regulator status icons
While a manual or automatic cycle is being run, the status of the principal loads is displayed as icons on the upper part of the screen.
The table below gives their description when switched on:
compressor active
heating active
heating control not active
fans working and fan speed (LO, HI speed or speed%)
defrosting in progress
humidification in progress
dehumidification in progress
humidity control not active
alarm in progress

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 15 of 4
4.3.2 Function keys
While a manual or automatic cycle is being run, the lower part of the screen displays the function keys, which are as follows.
switch light on/off
access the modify working setpoint/set cycle pages and the service screen
manual activation of rest cycle
manual activation of smoking cycle (presence can be activated/deactivated from parameter)
manual activation of air change cycle
UV
manual activation of sterilisation cycle (presence can be activated/deactivated from parameter), as an
alternative to oxygenation
manual activation of oxygenation cycle (presence can be activated/deactivated from parameter), as an
alternative to sterilisation
manual activation of defrosting cycle (presence can be activated/deactivated from parameter)
4.4 Screen saver
After a period of inactivity set by parameter E (from 1 to 240 minutes), the Run screen will switch to the screen saver showing the
values detected by the probes in use. This function can be disabled by setting parameter E to 0.
Just touch the screen to exit the screen saver. When an alarm is in progress, the Run screen will be restored.
Screen saver with manual cycle Screen saver with automatic cycle

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 16 of 4
4.5 Settings screen
The settings key on the On/Stand-by screen grants access to the Set-up screen with the relevant function menu (for the
INPUTS/OUTPUTS STATUS function, data are only displayed). To access the various procedures, touch the screen near the
information/function required. The following screen is displayed:
If parameter E12 is set at 1, the screen will also display the configuration details for the serial control humidifier.
4.5.1 Service
This option gives access to the following menu:
REGISTRATIONS SET-UP
This enables selection of the variables to be recorded for the HACCP history.
RESTORE FACTORY DATA
Touching on this option grants access to the following password-protected functions (149):
-delete records
-restore default parameters
-delete recipes
INTERNAL PARAMETERS
Touching on this option grants access to the password-protected parameter configuration (-19); to configure the parameter
appropriately, consult the list in the section PARAMETERS.

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 17 of 4
5AN OVERVIEW OF HE FUNC IONS
5.1 Automatic and manual cycles
The controller provides complete control for food processing cabinets or rooms for different types of products such as meat,
charcuterie, cheese and other types of product.
5.2 Settable features for each phase
An automatic aging cycle can consist of a maximum of 30 different sequential phases, for each of which the user can set the following
features:
5.2.1 Management of temperature, humidity, ventilation speed, duration
Regulation of temperature and humidity is carried out in the neutral zone. The resolution of the setpoint setting and the temperature
reading is 0.1°C, while the resolution of the setting and the humidity reading is 1 %RH.
Heating control can be deactivated by the user for the whole duration of the cycle in progress using the general cycle settings.
Humidity control can be deactivated by the user for some phases: by setting humidity under 0%, the "OFF" value or "humidity control
deactivated for the phase in progress" will be set (the icon will appear on the display, showing humidity control is not active).
The ventilation, depending on the type chosen by the OEM, may be SINGLE SPEED (in this case it cannot be regulated by the end
user), DOUBLE SPEED (in this case the user can select LOW or HIGH speed) or modulating through the external phase cutting module
EVDFAN1 (in this case the user can select the speed from the minimum settable by the user to 100%).
Cycle duration can be set from 0 minutes to 30days23h59' with a resolution of 1 minute.
By setting the cycle duration to INF (the equivalent of value 0), the phase will have infinite duration and no following phases will ever
be carried out.
5.2.2 Air change management
During the aging process, the air in the cabinet needs changing periodically to ensure it is always rich in oxygen in order to prevent
smells or impurities which could ruin the product.
The interval and duration of the air change fan are set by the user phase by phase.
For phases in which NO automatic air change is required (only manual), just set the activation interval to MANUAL (the equivalent of 0).

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 1 of 4
If the user also wishes to deactivate the MANUAL air change, just set the air change duration to OFF (the equivalent of 0) for the
desired phase.
5.2.3 Management of product rest intervals
During the aging process, products need frequent and long periods of complete rest, when the equipment does not regulate either the
temperature, humidity or ventilation inside the chamber.
During a rest phase, the only load that can be activated is the recirculation fan and this can be done either automatically or manually
(loads which do not concern regulation, such as light, obviously remain on or can be activated).
Product rest periods can be set by the user, phase by phase, in the following way:
- interval: how often the rest period takes place
- duration: how long the rest period lasts
- delay: how long after the beginning of the phase the first rest interval begins
- days: once the initial delay has elapsed, how many days the rest periods are repeated for, with the established interval and duration.
By setting the interval to MANUAL (the equivalent of 0), the rest period will only be manual.
By setting the duration to OFF (the equivalent of 0), manual rest period will also be disabled.
By setting the delay to 0', the rest period will begin immediately at the beginning of the phase.
The number of days can be set from 1 to 30.
5.3 Settable features for the aging cycle
As well as the individual features of each stage, the aging cycle has a number of special features which can be selected/deselected by
the user during the setting phase. These are:
5.3.1 Cabinet restart
When the "Cabinet restart” function is enabled at the end of the set aging cycle, a pop-up appears on the display and, by simply
touching it, the same aging cycle is restarted.
The next time an automatic programme is entered, the controller will return to the last cycle carried out which can easily be retrieved
by the user.
5.3.2 Heating control
By enabling/disabling the "Heating control” function, the heaters (and their connected loads) will be activated/deactivated for the whole
duration of the cycle if the cabinet temperature goes below the neutral zone value established.
If heating control is disabled, the icon on the display will stay on for the duration of the cycle.
5.3.3 Final holding
By enabling/disabling the "Final holding” function, the user decides if, at the end of the final phase in the cycle, the equipment must
maintain the temperature and humidity in the cabinet at the same values of the last phase before the cycle was STOPPED, or if it must
switch off all the regulation loads, losing control of the temperature and humidity.

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 19 of 4
5.3.4 Final air change
By enabling/disabling the "Final air change” function, the user decides if the equipment must carry out an air change cycle or not at the
end of the final phase of the cycle in progress. A final holding can be set to begin after the air change.
5.4 Other functions
During both automatic and manual aging cycles, a series of functions/loads can be activated manually by the end user to further
process/transform the products.
All these functions are activated/deactivated from parameter, therefore the function activation keys will only appear on the RUN screen
if they have been enabled.
5.4.1 Product sterilisation/oxygenation cycle
This cycle can be activated manually by the user during either an automatic or a manual aging cycle.
Parameter u1 establishes the type of icon to set, depending on the type of load connected: STERILISATION icon or OXYGENATOR icon.
Once the relevant key has been pressed, a pop-up screen will appear which will establish:
a) duration of the function (consisting of a sequence of Ton + Toff; duration in hh:mm with value 0 = UP TO MANUAL STOP)
b) activation time (in seconds)
c) switch-off time (in seconds)
When the switch-off time is set at 0 seconds, the output will be continuously active for the whole duration set by the user.
It is important to save the last value set by the user and repropose it at the next activation request.
The settings default is: duration = MANUAL, Ton = 1 0sec, Toff = 0sec
The activation of the function lasts for the duration of the cycle: a sterilisation/oxygenation cycle can be activated while an aging cycle
is taking place.
If the aging cycle changes phase, the sterilisation/oxygenation cycle continues.
If the aging cycle goes into the rest or air change phase, the sterilisation/oxygenation cycle is paused.
If the door is opened or there is a defrosting cycle, the sterilisation cycle will be SUSPENDED and will resume when the door is closed or
after the defrosting cycle and when the ventilation is reactivated.
If the aging cycle ends, the sterilisation/oxygenation cycle continues until the end of its counter time or until it is manually deactivated.
The STERILISATION output is only activated when the EVAPORATOR FAN IS ACTIVATED.
Temperature and humidity are regulated regularly. All the other outputs can be activated/deactivated.
The STERILISATION or OXYGENATION key will become one of 3 colours to indicate the activation, deactivation or pausing of the
function/output. They are:
U V U V U V
white icon key = function disabled
green icon key = function enabled and output activated
orange icon key = function enabled and output deactivated
5.4.2 Product smoking cycle
This cycle can be activated manually by the user during either an automatic or a manual aging cycle.
Once the relevant key has been pressed, a pop-up screen will appear which will establish the duration of the function (duration in
hh:mm with value 0 = UP TO MANUAL STOP).
It is important to save the last value set by the user as it will be reproposed at the next activation request.
The settings default is: duration = MANUAL.
The activation of the function lasts for the duration of the cycle: a smoking cycle can be activated while an aging cycle is taking place.
If the aging cycle changes phase, the smoking cycle is stopped.
If the aging cycle goes into the rest or air change phase, the smoking cycle is paused.
If the door is opened or there is a defrosting cycle, the smoking cycle will be SUSPENDED and will resume when the door is closed or
after the defrosting cycle.
If the aging cycle finishes, the smoking cycle is stopped. When the cycle is terminated, it is not possible to launch a smoking cycle.
Temperature and humidity are regulated regularly. All the other outputs can be activated/deactivated.
The SMOKING key will become one of 3 colours to indicate the activation, deactivation or pausing of the function/output. They are:

EVCO S.p.A. Vcolor 539 M & L | Installer manual ver. 1.0 | Code 144VC539E104
page 20 of 4
white icon key = function disabled
green icon key = function enabled and output activated
orange icon key = function enabled and output deactivated
5.4.3 Manual rest cycle
The operation of this cycle is described in the section "Management of product rest intervals". Similarly to what happens in the
sterilisation/oxygenation and smoking cycles (see previous sections), the relative key will become one of 3 colours to indicate the
activation, deactivation or pausing of the function/output.
5.4.4 Manual air change cycle
The operation of this cycle is described in the section "Air change management". Similarly to what happens in the
sterilisation/oxygenation and smoking cycles (see previous sections), the relative key will become one of 3 colours to indicate the
activation, deactivation or pausing of the function/output.
5.4.5 Manual defrosting
Pressing the appropriate key sets off the manual defrosting cycle. There is also an automatic defrosting cycle which is active at intervals
during all the automatic and manual phases. Similarly to what happens in the sterilisation/oxygenation and smoking cycles (see
previous sections), the relative key will become one of 3 colours to indicate the activation, deactivation or pausing of the
function/output.
5.4.6 Light on/off
This manually switches the light on/off. The switching on/off of the light can also be associated with the digital door switch input status.
Similarly to what happens in the sterilisation/oxygenation and smoking cycles (see previous sections), the relative key will become a
different colour to indicate the activation or deactivation of the function/output (without the orange output status “paused").
