Exor eTOP-MON User manual

EXOR International
www.exorint.net
Industrial Computing Solutions
eTOP-MON
eTOP-MON 1600P/1800P/2100P
User Manual

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. ii eTOP-MON 1600P/1800P/2100P User Manual
Content
CONTENTS
Preface
Copyright ............................................................................................. iv
Disclaimer.............................................................................................. iv
Acknowledgements ............................................................................... iv
Regulatory Compliance Statements........................................................ iv
Declaration of Conformity...................................................................... iv
RoHS Compliance ................................................................................... v
Warranty and RMA ................................................................................ vi
Safety Information ................................................................................. ix
Installation Recommendations................................................................ ix
Safety Precautions................................................................................... x
Technical Support and Assistance........................................................... xi
Conventions Used in this Manual........................................................... xi
Package Contents..................................................................................xii
Ordering Information ............................................................................xiii
Chapter 1: Product Introduction
Overview - eTOP-MON 1600P.................................................................1
Key Features ...........................................................................................1
Overview - eTOP-MON 1800P.................................................................2
Key Features ...........................................................................................2
Overview - eTOP-MON 2100P.................................................................3
Key Features ...........................................................................................3
Specifications..........................................................................................4
eTOP-MON 1600P...............................................................................4
Specifications..........................................................................................5
eTOP-MON 1800P...............................................................................5
Specifications..........................................................................................6
eTOP-MON 2100P...............................................................................6
Knowing Your eTOP-MON Series.............................................................7
Rear View............................................................................................7
Power & OSD Menu Button Description...............................................7
Rear Bottom View ...............................................................................8
External I/O Description .......................................................................8
Rear View of eTOP-MON 1600P ..........................................................9
Rear View of eTOP-MON 1800P ........................................................10
Rear View of eTOP-MON 2100P ........................................................11
Mechanical Dimensions.........................................................................12
eTOP-MON 1600P.............................................................................12
eTOP-MON 1800P.............................................................................13
eTOP-MON 2100P.............................................................................14
Chapter 2: Connector Pin Definitions
External I/O Interfaces ...........................................................................15
VGA Port...........................................................................................16
DVI Port (DVI-D).................................................................................16
USB Port............................................................................................17

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. iii eTOP-MON 1600P/1800P/2100P User Manual
Content
Chapter 3: System Setup
Panel Mounting ....................................................................................18
Chapter 4: Adjusting the Display
OSD Menu Functions ............................................................................20
Appendix A: Extended Display Identification
Data Timing Support..............................................33

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. iv eTOP-MON 1600P/1800P/2100P User Manual
Preface
PREFACE
Copyright
This publication, including all photographs, illustrations and software, is
protected under international copyright laws, with all rights reserved. No
part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written consent from EXOR
International S.p.A.
Disclaimer
The information in this document is subject to change without prior notice
and does not represent commitment from EXOR International S.p.A. However,
users may update their knowledge of any product in use by constantly checking
its manual posted on our website: http://www.exorint.net. EXOR shall not be
liable for direct, indirect, special, incidental, or consequential damages arising
out of the use of any product, nor for any infringements upon the rights
of third parties, which may result from such use. Any implied warranties of
merchantability or fitness for any particular purpose is also disclaimed.
Acknowledgements
ETOP-MON 1600P, ETOP-MON 1800P and ETOP-MON 2100P are trademarks
of EXOR International S.p.A. All other product names mentioned herein are
registered trademarks of their respective owners.
Regulatory Compliance Statements
This section describes how to keep the system CE compliant.
Declaration of Conformity
CE
The product(s) described in this manual complies with all applicable
European Union (CE) directives if it has a CE marking. For computer systems
to remain CE compliant, only CE-compliant parts may be used. Maintaining
CE compliance also requires proper cable and cabling techniques.

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. veTOP-MON 1600P/1800P/2100P User Manual
Preface
RoHS Compliance
EXOR RoHS Environmental Policy and Status
Update
EXOR is a global citizen for building the digital
infrastructure. We are committed to providing green
products and services, which are compliant with
European Union RoHS (Restriction on Use of Hazardous Substance in
Electronic Equipment) directive 2011/65/EU, to be your trusted green
partner and to protect our environment.
RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1%
or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium
(Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or
1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.
In order to meet the RoHS compliant directives, EXOR has established an
engineering and manufacturing task force to implement the introduction
of green products. The task force will ensure that we follow the standard
EXOR development procedure and that all the new RoHS components and
new manufacturing processes maintain the highest industry quality levels
for which EXOR are renowned.
The model selection criteria will be based on market demand. Vendors and
suppliers will ensure that all designed components will be RoHS compliant.

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. vi eTOP-MON 1600P/1800P/2100P User Manual
Preface
Warranty and RMA
Warranty Coverage
The warranty applies only to products manufactured or distributed by EXOR
and her subsidiaries. This warranty covers all the products/shipments except
for:
1. Any claimed defect, products that have been repaired or modified by
persons who have not been authorized by EXOR or, products which have
been subjected to misuse, abuse, accident, improper installation, or
usage not in accordance with the product instruction. EXOR assumes no
liability as a consequence of such events under the term of this warranty.
One example is the replacement of Tablet’s or Hand-held’s LCD display
due to scratching stains or other degradation; these will not be covered
under this warranty.
2. Damages caused by customers’ delivery/shipping of the product
or, product failure resulted from electrical power/voltage shock, or,
installation of parts/components which are not supplied/approved by
EXOR in advance.
3. Third-party products:
a. Software, such as the device drivers,
b. External devices such as HDD, printer, scanner, mouse, LCD panel,
battery, and so on,
c. Accessory/parts that were not approved by EXOR and,
d. Accessory/parts were added to products after they were shipped
from EXOR.
Product will be treated as “Out of Warranty “ if:
a. It expires the warranted period from the day it was purchased.
b. It had been altered by persons other than an authorized EXOR service
person or, which have been subjected to misuse, abuse, accident, or
improper installation.
c. It doesn’t have the original EXOR Serial Number labeling for EXOR’s
warranty period identification or, tracking.

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. vii eTOP-MON 1600P/1800P/2100P User Manual
Preface
RMA that EXOR has determined not to be covered by the warranty will
be charged the EXOR Standard Repair Fee for the repairing. If a RMA is
determined to be not repairable, customer will be notified and product(s)
may be returned to customer at their request; a minimum service fee may
be charged however.
EXOR Return Merchandise Authorization (RMA) Procedure
For the RMA (Return Merchandise Authorization) shipment, customer is
responsible for packaging and shipping the product to the designated EXOR
service sites, with shipping charges prepaid by the customer. The original
EXOR shipping box should be used whenever possible.
1. Customers should enclose the EXOR Return Autorization (RMA) with
the returned products.
2. Customers need to write down all the information related to the
problem on the EXOR web site form when applying for the RMA service;
information will help to understand the problem, including the fault
description, on-screen messages, and pictures if possible.
3. Customers could send back the faulty product with or without the
accessories and key parts such as the CPU and DIMM. If the key parts
are included, please be noted clearly within the return form. EXOR takes
no responsibility for the parts which are not listed in the return form.
4. Customers hold the responsibility to ensure that the packing of defective
products is durable enough to be resistant against further damage due
to the transportation; damage caused by transportation is treated as “
Out of Warranty “ under our Warranty specification.
5. RMA product(s) returned by EXOR to any location other than the
customer registered delivery address will incur an extra shipping charge,
the customer is responsible for paying the extra shipping charges, duties,
and taxes of this shipment.
Product Repairing
1. EXOR will repair defective products covered under this limited warranty
that are returned to EXOR; if products do prove to be defective, they will
be repaired during their warranty period unless other warranty terms
have been specified.
2. EXOR owns all parts removed from repaired products.
3. EXOR will use parts made by various manufacturers in performing the
repair.
4. The repaired products will be warranted subjected to the original
warranty coverage and period only.
5. For products returned as defective but, proved to be no defect/fault after
the RMA process, EXOR reserves the right to claim for a NDF (No Defect
Found) Service Charge.
6. EXOR will issue RMA Report which included Repair Detailed Information
to the customer when the defective products were repaired and returned.
7. In addition to the above, EXOR may authorize Independent/Third- party
suppliers to repair the defective products for EXOR.

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. viii eTOP-MON 1600P/1800P/2100P User Manual
Preface
Out Of Warranty Service
There will be a service charge from EXOR for the “Out Of Warranty”
product service; they are the Basic Diagnostic Service Fee and the Advanced
Component Replacement Fee respectively. And, if the product can not be
repaired, EXOR will either return the product to the customer or, just scrap
it, followed by customer’s instruction.
1. Testing and Parts Replacement
EXOR will have the following Handling Charges for those OoW products
that returned:
a. Basic Labor Cost and Testing Fee.
b. Parts Fee: EXOR will charge for main IC chipsets such as the N.B.,
S.B., Super-IO, LAN, Sound, Memory, and so on.
c. 3rd-party Device Fee: products replacement for CPU, DIMM, HDD,
Chassis, and UPS.
2. Out of Warranty product will have a three months warranty for the fixed
issues. If the product failed with different problem within 3 months, they
will still incur the service charge of “Out of Warranty”.
3. Out of Warranty “products will not be repaired without a signed PO
from the customer, the agreement of the repair process.
Add-on card, 3rd Party Device and board level repair cost higher than
new product prices, customer can abandon to sign PO to repair and,
please contact with sales to buy new products.

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. ix eTOP-MON 1600P/1800P/2100P User Manual
Preface
Installation Recommendations
Ensure you have a stable, clean working environment. Dust and dirt can get
into components and cause a malfunction. Use containers to keep small
components separated.
Adequate lighting and proper tools can prevent you from accidentally
damaging the internal components. Most of the procedures that follow
require only a few simple tools, including the following:
A Philips screwdriver
A flat-tipped screwdriver
A grounding strap
An anti-static pad
Using your fingers can disconnect most of the connections. It is recommended
that you do not use needle-nose pliers to disconnect connections as these
can damage the soft metal or plastic parts of the connectors.
Safety Information
Before installing and using the device, note the following precautions:
Read all instructions carefully.
Do not place the unit on an unstable surface, cart, or stand.
Follow all warnings and cautions in this manual.
When replacing parts, ensure that your service technician uses parts
specified by the manufacturer.
Avoid using the system near water, in direct sunlight, or near a heating
device.
The load of the system unit does not solely rely for support from the
rackmounts located on the sides. Firm support from the bottom is highly
necessary in order to provide balance stability.

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. xeTOP-MON 1600P/1800P/2100P User Manual
Preface
Safety Precautions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a
damp cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a stable surface during installation. Dropping it or
letting it fall may cause damage.
7. The openings on the enclosure are for air convection to protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting
the equipment to the power outlet.
9. Place the power cord in a way so that people will not step on it. Do not
place anything on top of the power cord. Use a power cord that has been
approved for use with the product and that it matches the voltage and
current marked on the product’s electrical range label. The voltage and
current rating of the cord must be greater than the voltage and current
rating marked on the product.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical
shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b.Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d.The equipment does not work well, or you cannot get it to work
according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. Do not place heavy objects on the equipment.
16. The unit uses a three-wire ground cable which is equipped with a third
pin to ground the unit and prevent electric shock. Do not defeat the
purpose of this pin. If your outlet does not support this kind of plug,
contact your electrician to replace your obsolete outlet.
17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. xi eTOP-MON 1600P/1800P/2100P User Manual
Preface
Technical Support and Assistance
1. For the most updated information of EXOR products, visit EXOR’s website
at www.exorint.net.
2. For technical issues that require contacting our technical support team or
sales representative, please have the following information ready before
calling:
– Product name and serial number
– Detailed information of the peripheral devices
– Detailed information of the installed software (operating system,
version, application software, etc.)
– A complete description of the problem
– The exact wordings of the error messages
Warning!
1. Handling the unit: carry the unit with both hands and handle it with care.
2. Maintenance: to keep the unit clean, use only approved cleaning products
or clean with a dry cloth.
Conventions Used in this Manual
Warning:
Information about certain situations, which if not observed,
can cause personal injury. This will prevent injury to yourself
when performing a task.
UT
UT
UT
UT
UT
UT
IO
IO
UT
UT
IO
IO
IO
IO
IO
IO
IO
UT
UT
IO
IO
N!
N!
N!
N!
UT
UT
IO
IO
UT
UT
UT
UT
UT
CA
UT
UT
CA
CA
CA
UT
UT
UT
IO
CACACACAUTUTUTUTIOIOIOIO
N!
N!N!N!
CA
IO
N!
N!
N!
N!
N!
N!
N!
N!
N!
N!
CAUTION!CAUTION!
Caution:
Information to avoid damaging components or losing data.
Note:
Provides additional information to complete a task easily.

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. xii eTOP-MON 1600P/1800P/2100P User Manual
Preface
Package Contents
Before continuing, verify that the package you received is complete. The
ETOP-MON series package, ETOP-MON 1600P/1800P/2100P, should have
all the items listed in the table.
Note: Package contents may vary depending on your country
region, some items may be optional. Please contact your local
distributor for more information.
Item Description Qty
1 USB Touch Cable (1.8m) 1
2 VGA Cable (1.8m) 1
3 Terminal blocks 3-pin Phoenix Contact Plug 1
Terminal blocks
3-pin Phoenix
Contact Plug
VGA CableUSB Touch Cable

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. xiii eTOP-MON 1600P/1800P/2100P User Manual
Preface
Ordering Information
The following provides ordering information for the Industrial Panel Display
series.
• Barebone
ETOP-MON 1600P
15.6” WXGA Heavy Industrial 16:9 LED backlight P-Cap touch monitor
with VGA, DVI-D and DisplayPort input, 12~24VDC input
ETOP-MON 1800P
18.5” WXGA Heavy Industrial 16:9 LED backlight P-Cap touch monitor
with VGA, DVI-D and DisplayPort input, 12~24VDC input
ETOP-MON 2100P
21.5” Full HD Heavy Industrial 16:9 LED backlight P-Cap touch monitor
with VGA, DVI-D and DisplayPort input, 12~24VDC input US Power Cord
Power Adapter DIN Rail Power Supply
UK Power Cord
EU Power Cord 1.8m DVI-D Cable
Optional
• 12V, 60W AC/DC power adapter w/o power cord
• 1.8m DVI-D male to DVI-D male cable
• 1.8m DisplayPort cable

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. 1
Chapter 1: Product Introduction
eTOP-MON 1600P/1800P/2100P User Manual
CHAPTER 1: PRODUCT INTRODUCTION
Key Features
IP66 compliant and metal housing with robust aluminum front zero bezel
for harsh environment
10 points P-Cap multi-touch with zero bezel flush front design
3 display input interface: Analog VGA/DVI-D/DisplayPort
Shares identical appearance with ETOP-IPC series
Ultra slim in depth
OSD multi-language function
All connectors with lock
Mounting support: panel/wall/stand/VESA 100mm x 100mm
Wide range power input 12V~24V DC
Overview - eTOP-MON 1600P
Photo is for reference. Please refer to the mechanical engineering drawing for final
appearance.
Note:

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. 2
Chapter 1: Product Introduction
eTOP-MON 1600P/1800P/2100P User Manual
Key Features
IP66 compliant and metal housing with robust aluminum front zero bezel
for harsh environment
10 points P-Cap multi-touch with zero bezel flush front design
3 display input interface: Analog VGA/DVI-D/DisplayPort
Shares identical appearance with ETOP-IPC series
Ultra slim in depth
OSD multi-language function
All connectors with lock
Mounting support: panel/wall/stand/VESA 100mm x 100mm
Wide range power input 12V~24V DC
Overview - ETOP-MON 1800P
Photo is for reference. Please refer to the mechanical engineering drawing for final
appearance.
Note:

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. 3
Chapter 1: Product Introduction
eTOP-MON 1600P/1800P/2100P User Manual
Key Features
IP66 compliant and metal housing with robust aluminum front zero bezel
for harsh environment
10 points P-Cap multi-touch with zero bezel flush front design
3 display input interface: Analog VGA/DVI-D/DisplayPort
Shares identical appearance with ETOP-IPC series
Ultra slim in depth
OSD multi-language function
All connectors with lock
Mounting support: panel/wall/stand/VESA 100mm x 100mm
Wide range power input 12V~24V DC
Overview - ETOP-MON 2100P
Photo is for reference. Please refer to the mechanical engineering drawing for final
appearance.
Note:

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. 4
Chapter 1: Product Introduction
eTOP-MON 1600P/1800P/2100P User Manual
Specifications
ETOP-MON 1600P
Panel
LED Size: 15.6”, 16:9
Resolution: WXGA 1366 x 768
Luminance: 300cd/m2
Contrast ratio: 500
LCD color: 16.7M
Viewing Angle: 80(U), 80(D), 85(L), 85(R)
Backlight: LED
Touch Screen
Ten points P-Cap (Projected Capacitive Touch)
Touch light transmission: 87%
Anti-scratch surface: 7H hardness
Touch interface: USB
Windows 8 compliance
Rear I/O
Touch interface port: USB with Lock
Video port: VGA (1xDB15)/DVI-D (1xDVI-D connector)/DisplayPort
DC power input connector: 3-Pin terminal block
OSD Function
OSD keypad
Multilanguage OSD
Mechanical & Environment
Color: Pantone 425C/RAL 70 24 front bezel
IP protection: IP66 front
Mounting: panel/wall/stand/VESA 100mm x 100mm
System with panel mounting kit w/o panel mounting hole
Power input: 12V~24VDC
Power adapter: optional AC to DC power adapter (+12V, 60W)
Vibration:
- IEC 68 2-64 (w/ HDD)
- 1Grms @ sine, 5~500Hz, 1hr/axis (HDD operating)
- 2Grms @ sine, 5~500Hz, 1hr/axis (CFast operating)
- 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (non-operating)
Shock:
- IEC 68 2-27
- HDD: 20G@wall mount, half sine, 11ms
Operating temperature: -10°C to 60°C
Storage temperature: -20°C to 75°C
Operating humidity: 10%~90% relative humidity, non-condensing
Dimension: 417.4 x 312.4 x 51.75mm
Weight: 5.48Kg
Certifications
CE (including EN61000-6-1/EN61000-6-2/EN61000-6-3/EN61000-6-4)

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. 5
Chapter 1: Product Introduction
eTOP-MON 1600P/1800P/2100P User Manual
Specifications
ETOP-MON 1800P
Panel
LED Size: 18.5”, 16:9
Resolution: WXGA 1366 x 768
Luminance: 400cd/m2
Contrast ratio: 1000
LCD color: 16.7M
Viewing Angle: 80(U), 80(D), 85(L), 85(R)
Backlight: LED
Touch Screen
Ten points P-Cap (Projected Capacitive Touch)
Touch light transmission: 87%
Anti-scratch surface: 7H hardness
Touch interface: USB
Windows 8 compliance
Rear I/O
Touch interface port: USB with Lock
Video port: VGA (1xDB15)/DVI-D (1xDVI-D connector)/DisplayPort
DC power input connector: 3-Pin terminal block
OSD Function
OSD keypad
Multilanguage OSD
Mechanical & Environment
Color: Pantone 425C/RAL 70 24 front bezel
IP protection: IP66 front
Mounting: panel/wall/stand/VESA 100mm x 100mm
System with panel mounting kit w/o panel mounting hole
Power input: 12V~24VDC
Power adapter: optional AC to DC power adapter (+12V, 60W)
Vibration:
- IEC 68 2-64 (w/ HDD)
- 1Grms @ sine, 5~500Hz, 1hr/axis (HDD operating)
- 2Grms @ sine, 5~500Hz, 1hr/axis (CFast operating)
- 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (non-operating)
Shock:
- IEC 68 2-27
- HDD: 20G@wall mount, half sine, 11ms
Operating temperature: -10°C to 60°C
Storage temperature: -20°C to 75°C
Operating humidity: 10%~90% relative humidity, non-condensing
Dimension: 490.8 x 320.6 x 50.65mm
Weight: 6.24Kg
Certifications
CE (including EN61000-6-1/EN61000-6-2/EN61000-6-3/EN61000-6-4)

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. 6
Chapter 1: Product Introduction
eTOP-MON 1600P/1800P/2100P User Manual
Specifications
ETOP-MON 2100P
Panel
LED Size: 21.5”, 16:9
Resolution: Full HD 1920 x 1080
Luminance: 300cd/m2
Contrast ratio: 5000
LCD color: 16.7M
Viewing Angle: 89(U), 89(D), 89(L), 89(R)
Backlight: LED
Touch Screen
Ten points P-Cap (Projected Capacitive Touch)
Touch light transmission: 87%
Anti-scratch surface: 7H hardness
Touch interface: USB
Windows 8 compliance
Rear I/O
Touch interface port: USB with Lock
Video port: VGA (1xDB15)/DVI-D (1xDVI-D connector)/DisplayPort
DC power input connector: 3-Pin terminal block
OSD Function
OSD keypad
Multilanguage OSD
Mechanical & Environment
Color: Pantone 425C/RAL 70 24 front bezel
IP protection: IP66 front
Mounting: panel/wall/stand/VESA 100mm x 100mm
System with panel mounting kit w/o panel mounting hole
Power input: 12V~24VDC
Power adapter: optional AC to DC power adapter (+12V, 60W)
Vibration:
- IEC 68 2-64 (w/ HDD)
- 1Grms @ sine, 5~500Hz, 1hr/axis (HDD operating)
- 2Grms @ sine, 5~500Hz, 1hr/axis (CFast operating)
- 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (non-operating)
Shock:
- IEC 68 2-27
- HDD: 20G@wall mount, half sine, 11ms
Operating temperature: -10°C to 60°C
Storage temperature: -20°C to 75°C
Operating humidity: 10%~90% relative humidity, non-condensing
Dimension: 562.4 x 382.4 x 50.85mm
Weight: 7.87Kg
Certifications
CE (including EN61000-6-1/EN61000-6-2/EN61000-6-3/EN61000-6-4)

Copyright © 2015 EXOR International S.p.A. All Rights Reserved. 7
Chapter 1: Product Introduction
eTOP-MON 1600P/1800P/2100P User Manual
Knowing Your ETOP-MON Series
Rear View
Power & OSD
Menu Buttons
Power & OSD Menu Button Description
LED
Power Switch
Increase Brightness/
move down/
increase value Menu
Decrease Brightness/
move up/
decrease value
AUTO|EXIT
LED
Displays the power status of the display. Green LED indicates the display is
switched on, if the display is not connected to a computer, the LED will flash red.
Power Switch
Press to power-on or power-off the display.
|▼
Inside OSD menu: Press to move the selection down in OSD menu.
Configuring options: Press to increase the value.
▶|▲
Inside OSD menu: Press to move the selection up in OSD menu.
Configuring options: Press to decrease the value
OSD Menu
No OSD Menu: Press to load the OSD menu.
Inside OSD Menu: Press to select the highlighted option in OSD menu.
AUTO|EXIT
Press to exit the OSD menu, or return to main menu.
