Exor eX700M Series User manual

eX700M Series
Operating Instructions
User’s Manual for eX700M Series Touchscreen Products
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A.

2
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
Copyright © 2022 Exor International S.p.A. – Verona, Italy
Subject to change without notice
The information contained in this document is provided for informational purposes only. While efforts were made to verify the accuracy of the information
contained in this documentation, it is provided “as is” without warranty of any kind.
Third-party brands and names are the property of their respective owners.
www.exorint.com
Software available in these products is based on OpenSource. Visitoss.exorint.netfor more details.

3
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
Table of Contents
Introduction 4
Safety Guide 5
1 Product Overview 6
2 Standards and Approvals 7
3 Technical Specications 9
4 Technical Data 11
4.1 Dimensions 13
4.2 Installation Environment 16
4.3 Safety instruction 16
4.4 Installation Procedure 16
5 Connections 17
5.1 Serial Port 19
5.2 Ethernet Port 19
5.3 Optional plugin module 20
5.4 Optional plugin module identication 21
5.5 Optional plugin module installation procedure 22
6 Power Supply, Grounding and Shielding 25
7 Battery 26
8 Special Instruction for Use 27
9 Getting Started 27
10 Unpacking and Packing Instructions 28

4
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
Introduction
The operational guidelines described below is information which relates to the device, installation, transpor-
tation, storage, assembly, use and maintenance.
This Operating Instruction describes the main features of the Exor operator panels. The manual refers to
the following models:
Model Part Number Description
eX705M EX705MU5P1 HMI 5” TFT 800x480, PCAP Touch, 8 GB Flash Memory, 2x Ethernet, JMobile runtime
eX707M EX707MU5P1 HMI 7” TFT 800x480, PCAP Touch, 8 GB Flash Memory, 3x Ethernet, JMobile runtime
eX710M EX710MU5P1 HMI 10” TFT, 1280x800, PCAP Touch, 8 GB Flash Memory, 3x Ethernet, JMobile
runtime
eX712M EX712MU5P1 HMI 12” TFT, 1920x720, PCAP Touch, 8 GB Flash Memory, 3x Ethernet, JMobile
runtime
eX715M EX715MU5P1 HMI 15” TFT, 1366x768, PCAP Touch, 8 GB Flash Memory, 3x Ethernet, JMobile
runtime
eX721M EX721MU5P1 HMI 21” TFT, 1920x1080, PCAP Touch, 8 GB Flash Memory, 3x Ethernet, JMobile
runtime
eX705M EX705MU5PW Web HMI 5” TFT 800x480, PCAP Touch, 8 GB Flash Memory, 2x Ethernet, Web
browser
eX707M EX707MU5PW Web HMI 7” TFT 800x480, PCAP Touch, 8 GB Flash Memory, 3x Ethernet, Web
browser
eX710M EX710MU5PW Web HMI 10” TFT, 1280x800, PCAP Touch, 8 GB Flash Memory, 3x Ethernet, Web
browser
eX712M EX712MU5PW Web HMI 12” TFT, 1920x720, PCAP Touch, 8 GB Flash Memory, 3x Ethernet, Web
browser
eX715M EX715MU5PW Web HMI 15” TFT, 1366x768, PCAP Touch, 8 GB Flash Memory, 3x Ethernet, Web
browser
eX721M EX721MU5PW Web HMI 21” TFT, 1920x1080, PCAP Touch, 8 GB Flash Memory, 3x Ethernet, Web
browser

5
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
Safety Guide
The manual contains safety standards that must be respected for the personal safety and to avoid damage.
Indications of attention are divided into three levels of severity:
DANGER: indicates a failure to observe safety rules and such failure may cause death or serious injuries.
ATTENTION: indicates a failure to observe safety rules and that deciency may cause damage.
CAUTION: indicates a failure to observe safety rules and that deciency may cause defects to the equipment
or inconsistencies.
CAUTION
ATTENTION
DANGER

!
!

6
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
1 Product Overview
eX700M Series HMI products combine state-of-the-art connectivity features and top performance in a great
design. Products have been designed as IoT edge devices with the combination of a powerful controller with
networking capability and outstanding communication options including client/server OPC UA. They are the
ideal choice for all demanding IoT edge applications in factory, marine and building automation.
The glass projected capacitive touchscreen and the brilliant displays with size up to 21.5” and resolution up to
1920x1080 guarantee great optical performance; with the support of multitouch gesture programming they
can create the most natural human interfaces.
eX700M HMI products have been designed to run the JMobile software.
eX700M Web version HMI products combine state-of-the-art connectivity features and top browsing perfor-
mance in a great design. They are the ideal choice for all demanding IoT edge applications in factory, marine
and building automation where powerful and performing HTML5 web browser is needed.
eX700M Web version HMI products include a Chromium based HTML5 browser supporting kiosk mode ope-
ration. Supports Corvina Cloud secure connectivity with full network separation.
• Chromium based HTML5 Browser
• Easy to use browser setting application

7
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
The products have been designed for use in an industrial environment in compliance with the 2014/30/EU
EMC Directive.
The products have been designed in compliance with:
EN 61000-6-4 CISPR 22 Class A
CISPR 16-2-3
EN 61000-6-2 EN 61000-4-2
EN 61000-4-3
EN 61000-4-4
EN 61000-4-5
EN 61000-4-6
EN 61000-4-8
EN 61000-4-11
EN 61000-4-29
EN60945
IECEx IECEx: IECEx ULD 17.0019X
IEC 60079-0 Ex ec IIC T5...T4 Gc -20°C≤Tamb≤+60°C or 0°C≤Tamb≤+50°C
IEC 60079-7 Ex tc IIIC T95°C Dc
IEC 60079-31
ATEX DEMKO 17 ATEX 1871X
EN IEC 60079-0 II 3G Ex ec IIC T5...T4 Gc -20°C≤Tamb≤+60°C or 0°C≤Tamb≤+50°C
EN IEC 60079-7+A1 II 3D Ex tc IIIC T95°C Dc
CENELEC EN 60079-31
The installation of these devices into the residential, commercial and light-industrial environments is allowed
only in the case that special in measures are taken in order to ensure conformity to EN 61000-6-3.
The products are in compliance with the Restrictions on Certain Hazardous Substances (RoHS) Directive
2011/65/EU
In compliance with the above regulations the products are CE marked.
Products described in this manual may have other approvals and certicates.
Please refer to product datasheets available at www.exorint.com
2 Standards and Approvals

8
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
Product Identication
The product may be identied through a plate attached to the rear cover. You will have to know the type of
unit you are using for correct usage of the information contained in the guide.
An example of this plate is shown in the gure below:
Note: the eX707M label is used as an example for eX700M Series and eX700M Web version.
product model name eX707M
product part number EX707MU5P1
year/week of production 1816
serial number AA00011FT000000561AA
version id of the product 120408A04002000
manufacturer address Exor International S.p.A.
Via Monte Fiorino 9
IT-37057 San Giovanni Lupatoto (VR)
ATEX Marking DEMKO 17 ATEX 1871X
II 3G Ex ec IIC T5...T4 Gc 0°C≤Tamb≤+50°C or -20°C≤Tamb≤+60°C
II 3D Ex tc IIIC T95°C Dc
IECEx Marking IECEx: IECEx ULD 17.0019X
Ex ec IIC T5...T4 Gc 0°C≤Tamb≤+50°C or -20°C≤Tamb≤+60°C
Ex tc IIIC T95°C Dc
2 Standards and Approvals

9
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
3 Technical Specications
Electromagnetic Compatibility (EMC)
Radiated disturbance test Class A CISPR 22
CISPR 16-2-3
Electrostatic discharge immunity test 8 kV (air electrostatic discharge) EN 61000-4-2
4 kV (contact electrostatic discharge)
Radiated, radio-frequency, 80 MHz ÷ 1 GHz, 10V/m EN 61000-4-3
electromagnetic eld immunity test 1,4 GHz ÷ 2 GHz, 3 V/m
2 GHz ÷ 2.7 GHz, 1 V/m
Burst immunity test ± 2 KV dc power port EN 61000-4-4
± 1 KV signal line
Surge immunity test ± 0,5 KV dc power port (line to earth) EN 61000-4-5
± 0,5 KV dc power port (line to line)
± 1 KV signal line (line to earth)
Immunity to conducted disturbances
inducted by radiofrequency eld 0.15 ÷ 80 MHz, 10V EN 61000-4-6
Power frequency magnetic eld
immunity test Enclosure, 50/60Hz, 30A/m EN 61000-4-8
Environmental conditions
Operating temperature (surrounding -20 ÷ +60°C (vertical installation) EN 60068-2-14
air temperature) Plug-in modules and USB devices
may limit max temperature to +50°C
Storage temperature -20 ÷ +70°C EN 60068-2-1
EN 60068-2-2
EN 60068-2-14
Operating and storage humidity 5 ÷ 85 % RH non-condensing EN 60068-2-30
Vibrations 5 ÷ 9 Hz, 7 mm p-p EN 60068-2-6
9 ÷ 150 Hz, 1 g
Shock ± 50 g, 11 ms, 3 pulses per axis EN 60068-2-27
Protection class Front panel IP66, Rear IP20 EN 60529
Touchscreen technology Projected capacitive
Back-up battery 3V 50mAh Lithium, rechargeable, not user-replaceable,
model VL2330.
Fuse Automatic
Serial Port RS-232, RS-485, RS-422 software congurable
Flash 8GB
RAM 2GB
Hardware clock Clock/Calendar with back-up battery
Accuracy RTC (at 25°C) <100ppm

10
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
3 Technical Specications
Voltage dips, short interruptions and
voltage variations immunity test Port: AC mains; Level:
100% duration: 1 cycle and 250 cycles (50Hz);
1 cycle and 300 cycles (60Hz);
40% duration: 10 cycles (50Hz);
12 cycles (60Hz);
70% duration: 25 cycles (50Hz);
30 cycles (60Hz);
Phase: 0°-180°
Test executed on the 230Vac side of the Exor International S.p.A. Power Supply EN 61000-4-11
Port: DC mains; Level:
0% duration: 10ms 20 spaces by 1s
Test executed on the 24Vdc of the EUT EN 61000-4-29
Durability information
Backlight service life 40000 Hrs. or more
(LED type) (Time of continuous operation until the brightness of the
backlight reaches 50% of the rated value when the
surrounding air temperature is 25°C) - see Note 1
Note 1: Extended use in environments where the surrounding air temperature is 40°C or higher may
degrade backlight quality/reliability/durability.
Surface resistance
Chemical resistance of the front glass for an exposure time of 24 hours without visible changes:
• Betadine (10% Povidone Solution)
• Cola
• Electrode Gel/Paste
• Hydrogen Peroxide (3% Solution)
• NaCl (0.9% Solution)
• Coffee
• Dextrose (5% Glucose Solution)
• Hydrogen chloride (0.5% Solution PH=1)
• Isopropyl Alcohol
• Sodium Hypochlorit
• Ethyl Alcohol (70%-90%)
• Quaternary ammonium compound

11
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
Model eX705M eX707M eX710M
Display /
Backlight TFT Color / LED TFT Color / LED TFT Color / LED
Colors 64K 16M 16M
Resolution 800X480 800X480 1280X800
Diagonal (inches) 5” widescreen 7” widescreen 10.1” widescreen
Dimming yes yes yes
CPU 64-bit RISC quad core -
1.6GHz
64-bit RISC quad core -
1.6GHz
64-bit RISC quad core -
1.6GHz
Operating System Linux Linux Linux
Flash 8GB 8GB 8GB
RAM 2GB 2GB 2GB
Real Time Clock yes yes yes
Ethernet port 2 10/100Mb 2 10/100Mb,
1 10/100/1000Mb
2 10/100Mb,
1 10/100/1000Mb
USB port 1 Host interface version 2.0
max. 500mA
2 Host interface version 2.0
max. 500mA
2 Host interface version 2.0
max. 500mA
Serial Port RS-232,RS-485, RS-422
software congurable
RS-232,RS-485, RS-422
software congurable
RS-232,RS-485, RS-422
software congurable
SD card slot yes yes yes
Expansion slot 1 Optional Plugin 2 Optional Plugin 2 Optional Plugin
Voltage 24Vdc (*) 24Vdc (*) 24Vdc (*)
Current rating (at
24VDC) 0.6A 0.7A 1.00A
Battery rechargeable rechargeable rechargeable
Weight 1 Kg 1.3 Kg 1.7 Kg
(*) 10-32Vdc
For applications requiring compliance with EN 61131-2 and specically in reference to 10 ms voltage dips (accor-
ding to EN 61000-4-29), the lower power supply voltage limit is 20,4Vdc.

12
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
Model eX712M eX715M eX721M
Display /
Backlight TFT Color / LED TFT Color / LED TFT Color / LED
Colors 16M 16M 16M
Resolution 1920x720 1366X768 1920X1080
Diagonal (inches) 12.3” widescreen 15.6” widescreen 21.5” widescreen
Dimming yes yes yes
CPU 64-bit RISC quad core - 1.6GHz 64-bit RISC quad core -
1.6GHz
64-bit RISC quad core -
1.6GHz
Operating System Linux Linux Linux
Flash 8GB 8GB 8GB
RAM 2GB 2GB 2GB
Real Time Clock yes yes yes
Ethernet port 2 10/100Mb,
1 10/100/1000Mb
2 10/100Mb,
1 10/100/1000Mb
2 10/100Mb,
1 10/100/1000Mb
USB port 2 Host interface version 2.0
max. 500mA
2 Host interface version 2.0
max. 500mA
2 Host interface version 2.0
max. 500mA
Serial Port RS-232, RS-485, RS-422
software congurable
RS-232,RS-485, RS-422
software congurable
RS-232,RS-485, RS-422
software congurable
SD card slot yes yes yes
Expansion slot 2 Optional Plugin 2 Optional Plugin 2 Optional Plugin
Voltage 24Vdc (*) 24Vdc (*) 24Vdc (*)
Current rating (at
24VDC) 1.10A 1.20A 1.70A
Battery rechargeable rechargeable rechargeable
Weight 1.8 Kg 4.1 Kg 6.1 Kg
(*) 10-32Vdc
For applications requiring compliance with EN 61131-2 and specically in reference to 10 ms voltage dips (accor-
ding to EN 61000-4-29), the lower power supply voltage limit is 20,4Vdc.

13
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
4.1 Dimensions
4 Technical Data
Cut out
MODEL A B C D E F
eX705M 147mm/5.78” 107mm/4.21” 136mm/5.35” 96mm/3.78” 56mm/2.40” 8mm/0.31”

14
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
Cut out
MODEL A B C D E F
eX707M 187mm/7.36” 147mm/5.79” 176mm/6.90” 136mm/5.35” 47mm/1.85” 8mm/0.31”
eX710M 282mm/11.10” 197mm/7.80” 271mm/10.67” 186mm/7.32” 56mm/2.20” 8mm/0.31”
eX712M 344,5mm/13.56” 163mm/6.41” 332,5mm/13,09” 163mm/6,41” 49mm/1,92” 8mm/0,31”
eX715M 422mm/16.60” 267mm/10.50” 411mm/16.18” 256mm/10.00” 56mm/2.20” 8mm/0.31”
eX721M 552mm/21.73” 347mm/13.66” 541mm/21.30” 336mm/13.22” 56mm/2.20” 8mm/0.31”

15
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
4.2 Installation Environment
Avoid prolonged exposition to direct sunlight to avoid the risk of overheating the device.
The equipment is not intended for installation in contact with corrosive chemical compounds. Check the
resistance of the front panel to a specic compound before installation.
Do not use tools of any kind (screwdrivers, etc.) to operate the touch screen of the panel.
In order to meet the front panel protection classications, proper installation procedure must be followed:
•the borders of the cutout must be flat
• screw up each xing screw until the bezel corner get in contact with the panel.
•the cutout for the panel must be of the dimensions indicated in this manual.
The IP66 is guaranteed only if:
• max deviation from the plane surface to the cut-out: O0.5mm
• thickness of the case where is mounted the equipment: from 1,5mm to 6mm
•max surface roughness where the gasket is applied: O120 um
A. HMI
B. Installation cut-out

16
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
4.4 Installation Procedure
Place the xing brackets contained in the xing kit as shown in gure
4.3 Safety instruction
For all installation notes, please refer to the Installation Guide provided with the product.
!
CAUTION
Tightening torque: 130Ncm or screw each xing screw until the bezel corner gets in contact with the panel.

17
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
5 Connections
1. USB Port V2.0, max. 500 mA - for maintenance only
2. Power Supply
3. Serial port
4. Ethernet Port 0 (10/100Mb)
5. Ethernet Port 1 (10/100Mb)
6. Expansion slot for Plugin module
7. SD Card Slot
eX705M
Fig. 5.1

18
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
5 Connections
1. USB Port V2.0, max. 500 mA - for maintenance only
2. Ethernet port 2 (10/100Mb)
3. Ethernet port 1 (10/100Mb)
4. Serial Port
5. Ethernet port 0 (10/100/1000Mb)
6. Power Supply
7. 2x Expansion slot for Plugin module
8. SD Card Slot
eX707M, eX710M, eX712M, eX715M, eX721M
Fig. 5.2

19
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
5 Connections
5.1 Serial Port
5.2 Ethernet Port
Pin Description
1 CHB-
2 CHA-
3CHB+
4CHA+
5+5V output
6 GND
7
8 SHIELD
The serial port is used to communicate with the PLC or with another type of controller.
Different electrical standards are available for the signals in the PLC port connector: RS-232, RS-422, RS-485.
The serial port is software programmable. Make sure you select the appropriate interface in the programming
software.
The communication cable must be chosen for the type of device being connected.
SERIAL PORT
To operate in RS-485 pins
1-2 and 3-4 must be con-
nected externally.
RS-232 RS-422, RS-485
Pin Description
1 RX
2 TX
3CTS
4RTS
5+5V output
6 GND
7
8 SHIELD
Yellow
ETH0 > 1000Mb link > ON
ETH0 > 10/100Mb link > OFF
ETH1/2 > 100Mb link > ON
ETH1/2 > 10Mb link > OFF
On eX705M
100Mb link > ON
10Mb link > OFF
Green
ON: No activity
BLINKING: Activity
The Ethernet port have two status indicators. Please see description in gure.
1 8

20
MANUGENEX7xxM - Version 1.00
© 2022 EXOR International S.p.A. - Subject to change without notice
5.3 Optional plugin module
5 Connections
eX Series 700M panels have several optional plugin module, multiple modules congurations are possible.
Slot#2 and Slot#4 are available only if plugin module has the “bus extension connector”.
Each slot carries three communication channels:
• 1 serial interface
• 1 CAN interface
• 1 SPI interface
• 1 2G/3G interface
Note: It is not possible to stack two modules that are using the same type of interface.
