Exor JSmart700 Series User manual

JSmart700 Series
Operating Instructions
User’s Manual for JSmart700 Series Touchscreen Products
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A.

2
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
Copyright © 2019 Exor International S.p.A. – Verona, Italy
Subject to change without notice
The information contained in this document is provided for informational purposes only. While efforts were made to verify the accuracy of the information
contained in this documentation, it is provided “as is” without warranty of any kind.
Third-party brands and names are the property of their respective owners.
www.exorint.com

3
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
Table of Contents
Introduction 4
Safety Guide 5
1 Product Overview 6
2 Standards and Approvals 7
3 Technical Specications 9
4 Technical Data 13
4.1 Dimensions 15
4.2 Installation Environment and Procedure 18
4.3 Safety instruction 19
5 Connections 20
5.1 Ethernet Port 20
6 Power Supply, Grounding and Shielding 21
7 Battery 22
8 Special Instruction for Use 24
9 Getting Started 24
10 System Settings 25
11 Unpacking and Packing Instructions 27

4
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
Introduction
The operational guidelines described below is information which relates to the device, installation, transpor-
tation, storage, assembly, use and maintenance.
This Operating Instruction describes the main features of the Exor operator panels. The Manual refers to
the following models:
JSmart707 Field-ready HMI 7” color TFT, PCAP touchscreen, Ethernet port PoE
JSmart710 Field-ready HMI 10.1” color TFT, PCAP touchscreen, Ethernet port PoE
JSmart715 Field-ready HMI 15.6” color TFT, PCAP touchscreen, Ethernet port PoE
JSmart721 Field-ready HMI 21.5” color TFT, PCAP touchscreen, Ethernet port PoE

5
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
Safety Guide
The manual contains safety standards that must be respected for the personal safety and to avoid damage.
Indications of attention are divided into three levels of severity:
DANGER: indicates a failure to observe safety rules and such failure may cause death or serious injuries.
ATTENTION: indicates a failure to observe safety rules and that deciency may cause damage.
CAUTION: indicates a failure to observe safety rules and that deciency may cause defects to the equipment
or inconsistencies.
CAUTION
ATTENTION
DANGER

!
!

6
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
1 Product Overview
JSmart700 products are ideal for eld installation in critical areas. High-resolution displays and multitouch
PCAP touchscreen with a robust glass front.
Power-over-Ethernet (PoE) for maximum simplicity of connection using standard shielded CAT 5 wiring. Full
IP protection with the use of dedicated connectors for the maximum flexibility of installation, from mounting
arm to a simple M22 hole. The product includes environment and motion sensors to make this device a true
IIoT edge device for Industry 4.0 applications.
The JSmart product family has been optimized for use as an embedded browser or as a JMobile HMI device.
• Open platform for Linux applications
• Performing HTML5-compatible browser with graphic accelerator
• JMobile runtime with OPC UA Server and Client
• Optional CODESYS V3 PLC for integrated HMI and control applications
• Built-in sensors (temperature and acceleration)

7
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
The products have been designed for use in an industrial environment in compliance with the 2014/53/EU
Directive.
The products have been designed in compliance with:
EN 61000-6-4
EN 61000-6-2
EN 61000-6-3
EN 61000-6-1
ETSI EN 301 489-1
ETSI EN 301 489-17
ETSI EN 300 328
EN 62311 *
EN 61010-1
EN 61010-2-201
* Standard radio signal and minimum distance from the body calculated according to EN 62311
Standard radio signal WiFi 2,4GHz
Minimum distance form the body (cm)* 2
* The WiFi antenna is positioned behind the black band above the display.
The products are in compliance with the Restrictions on Certain Hazardous Substances (RoHS) Directive
2011/65/EU
In compliance with the above regulations the products are CE marked.
2 Standards and Approvals

8
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
Product Identication
The product may be identied by the indications in the back cover. You will have to know the type of unit you
are using for correct usage of the information contained in the guide.
An example of the information reported is shown below:
product model name JSmart707
year/week of production 1920
serial number AA00012P9000000561AA
manufacturer address Exor International S.p.A.
Via Monte Fiorino 9
IT-37057 San Giovanni Lupatoto (VR)
Ordering code key
Example: +JS707BB1U5P1
2 Standards and Approvals

9
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
3 Technical Specications
Electromagnetic Compatibility (EMC)
Radiated disturbance test Class A CISPR 22
CISPR 16-2-3
Electrostatic discharge immunity test 8 kV (air electrostatic discharge) EN 61000-4-2
4 kV (contact electrostatic discharge)
Radiated, radio-frequency, 80 MHz ÷ 1 GHz, 10V/m EN 61000-4-3
electromagnetic eld immunity test 1,4 GHz ÷ 2 GHz, 3 V/m
2 GHz ÷ 2.7 GHz, 1 V/m
Burst immunity test ± 2 KV dc power port EN 61000-4-4
± 1 KV signal line
Surge immunity test ± 0,5 KV dc power port (line to earth) EN 61000-4-5
± 0,5 KV dc power port (line to line)
± 1 KV signal line (line to earth)
Immunity to conducted disturbances
inducted by radiofrequency eld 0.15 ÷ 80 MHz, 10V EN 61000-4-6
Power frequency magnetic eld
immunity test Enclosure, 50/60Hz, 30A/m EN 61000-4-8
Environmental conditions
Operating temperature (surrounding -20 ÷ +55°C (vertical installation) EN 60068-2-14
air temperature)
Storage temperature -30 ÷ +80°C (JSmart707, 710) EN 60068-2-1
-20 ÷ +70°C (JSmart715, 721) EN 60068-2-2
EN 60068-2-14
Operating and storage humidity 5 ÷ 85 % RH not-condensing EN 60068-2-30
Vibrations 5 ÷ 9 Hz, 7 mm p-p EN 60068-2-6
9 ÷ 150 Hz, 1 g
Shock ± 50 g, 11 ms, 3 pulses per axis EN 60068-2-27
Protection class IP67 (requires appropriate connectoris EN 60529
and cables)
Touchscreen technology Projected capacitive - Multitouch
Back-up battery 3V 7mAh Vanadium-Lithium, rechargeable, not user-replacea
ble, model VL1220.
Flash 4GB (8GB for JSmart715 and JSmart721)
RAM 1GB (2GB for JSmart715 and JSmart721)
Hardware clock Clock/Calendar with back-up battery
Accuracy RTC (at 25°C) <100ppm

10
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
3 Technical Specications
Durability information
Backlight service life 40000 Hrs. or more
(LED type) (Time of continuos operation until the brightness of the
backlight reaches 50% of the rated value when the
surrounding air temperature is 25°C) - see Note 1
Note 1: Extended use in environments where the surrounding air temperature is 40°C or higher may
degrade backlight quality/reliability/durability.
Viewing angles
For the viewing angles values (U,D,R,L) of the display types, see the technical data of the respective device.
The viewing angles are specied for the horizontal (L,R) and vertical (U,D) axes in reference to the vertical
axis of the display. The specied viewing angles above always refer to the standard mounting orientation.
Legend: Display viewing angle
U From top
D From bottom
LFrom left
R From right

11
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
Surface resistance
Chemical resistance of the front glass for an exposure time of 24 hours without visible changes:
• Betadine (10% Povidone Solution)
• Cola
• Electrode Gel/Paste
• Hydrogen Peroxide (3% Solution)
• NaCl (0.9% Solution)
• Coffee
• Dextrose (5% Glucose Solution)
• Hydrogen chloride (0.5% Solution PH=1)
• Isopropyl Alcohol
• Sodium Hypochlorit
• Ethyl Alcohol (70%-90%)
• Quaternary ammonium compound
3 Technical Specications

12
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
3 Technical Specications
Properties multitouch PCAP touchscreen
Operation with gloves
Projected capacitive touch screens (PCAP) are suitable for operation with or without gloves.
A large number of gloves (rubber gloves, light/heavy leather gloves, disposable latex gloves, etc.) are sup-
ported.
Due to the variety of commercially available gloves, however, EXOR cannot guarantee all types.
Number of ngers 5
Glove operation Yes
Passive stylus pens Yes
Active stylus pens No
Hardened front glass Yes

13
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
Model JSmart707 JSmart710 JSmart715
Display /
Backlight TFT Color / LED TFT Color / LED TFT Color / LED
Colors 16M 16M 16M
Resolution 1024X600 1280X800 1366X768
Diagonal
(inches) 7” widescreen 10.1” widescreen 15.6” widescreen
Viewing angles
horizontal
Direction L / Direction R
Typ. 75°
Direction L / Direction R
Typ. 85°
Direction L / Direction R
Typ. 80°
Viewing angles
vertical
Direction U / Direction D
Typ. 75°
Direction U / Direction D
Typ. 85°
Direction U / Direction D
Typ. 80°
Dimming yes to 0% yes to 0% yes
CPU ARM Cortex-A9 dual core
800 MHz
ARM Cortex-A9 dual core
800 MHz
ARM Cortex-A9 quad core
800 MHz
Operating
System Linux RT Linux RT Linux RT
Flash 4GB 4GB 8GB
RAM 1GB 1GB 2GB
Ethernet port 10/100 PoE 802.3af/at 10/100 PoE 802.3af/at 10/100 PoE 802.3af/at
USB port 1 (Host v. 2.0, request special
connector)
1 (Host v. 2.0, request special
connector)
1 (Host v. 2.0, request special
connector)
Battery rechargeable rechargeable rechargeable
Real Time Clock yes yes yes
Power supply 802.3af 802.3af 802.3at
Current
consumption 9W 12W 19W
Weight 0.7 Kg 1.2 Kg 4.0 Kg

14
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
Model JSmart721
Display /
Backlight TFT Color / LED
Colors 16M
Resolution 1920X1080
Diagonal (in-
ches) 21.5” widescreen
Viewing angles
horizontal
Direction L / Direction R
Typ. 89°
Viewing angles
vertical
Direction U / Direction D
Typ. 89°
Dimming yes
CPU ARM Cortex-A9 quad core
800 MHz
Operating
System Linux RT
Flash 8GB
RAM 2GB
Ethernet port 10/100 PoE 802.3af/at
USB port 1 (Host v. 2.0, request special
connector)
Battery rechargeable
Real Time Clock yes
Power supply 802.3bt
Current
consumption 32W
Weight 6.0 Kg

15
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
4.1 Dimensions
4 Technical Data
MODEL A B C D
JSmart707 131.6mm/5.18” 195.2mm/7.68” 16,5mm/0.64” 17mm/0.66”
MODEL A B C D
JSmart710 183.1mm/7.20” 264.5mm/10.41” 16,5mm/0.64” 17mm/0.66”

16
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
MODEL A B C D
JSmart715 248mm/9.76” 398.6mm/15.69” 26,5mm/1.04” 17mm/0.66”
MODEL A B C D
JSmart721 325.6mm/12.81” 534.1mm/21.02” 26,5mm/1.04” 17mm/0.66”

17
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
Rear view

18
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
4.2 Installation Environment and procedure
Avoid prolonged exposition to direct sunlight to avoid the risk of overheating the device.
The equipment is not intended for installation in contact with corrosive chemical compounds. Check the
resistance of the front panel to a specic compound before installation.
Do not use tools of any kind (screwdrivers, etc.) to operate the touch screen of the panel.
The IP67 is guaranteed only if:
• max deviation from the plane surface to the cut-out: O0.5mm
• thickness of the case where is mounted the equipment: from 1,5mm to 6mm
•max surface roughness where the gasket is applied: O120 um
CAUTION
Tightening torque: 1000Ncm for nut, 130Ncm for screws

19
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
4.3 Safety instruction
For all installation notes, please refer to the Installation Guide provided with the product.
!

20
MANUGENJSMART7xxW - Version 1.00
© 2019 EXOR International S.p.A. - Subject to change without notice
5 Connections
Reserved
Pin Description
1 TX+
2TX-
3 RX+
4 n/c
5 n/c
6RX-
7 n/c
8 n/c
5.1 Ethernet Port
Red
OFF: Valid link has NOT been detected
ON: Valid link has been detected
Green
ON: No activity
BLINKING: Activity
The Ethernet port have two status indicators. Please see description in gure.
