Exor JSmart705 User manual

JSmart705
Operating Instructions
User’s Manual for JSmart705 Product
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A.

2
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
Copyright © 2020 Exor International S.p.A. – Verona, Italy
Subject to change without notice
The information contained in this document is provided for informational purposes only. While efforts were made to verify the accuracy of the information
contained in this documentation, it is provided “as is” without warranty of any kind.
Third-party brands and names are the property of their respective owners.
www.exorint.com
Software available in these products is based on OpenSource. Visitoss.exorint.netfor more details.

3
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
Table of Contents
Introduction 4
Safety Guide 5
1 Product Overview 6
2 Standards and Approvals 7
3 Technical Specications 9
4 Technical Data 13
4.1 Dimensions 14
4.2 Installation Environment and Procedure 15
4.3 Safety instruction 16
5 Connections 17
5.1 Ethernet Port 17
6 Power Supply, Grounding and Shielding 18
7 Battery 19
8 Special Instruction for Use 20
9 Getting Started 20
10 System Settings 21
11 Unpacking and Packing Instructions 23

4
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
Introduction
The operational guidelines described below is information which relates to the device, installation, transpor-
tation, storage, assembly, use and maintenance.
This Operating Instruction describes the main features of the Exor operator panels. The Manual refers to
the following model:
JSmart705 Field-ready HMI 5” color TFT, PCAP touchscreen, Ethernet port PoE

5
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
Safety Guide
The manual contains safety standards that must be respected for the personal safety and to avoid damage.
Indications of attention are divided into three levels of severity:
DANGER: indicates a failure to observe safety rules and such failure may cause death or serious injuries.
ATTENTION: indicates a failure to observe safety rules and that deciency may cause damage.
CAUTION: indicates a failure to observe safety rules and that deciency may cause defects to the equipment
or inconsistencies.
CAUTION
ATTENTION
DANGER

!
!

6
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
1 Product Overview
JSmart700 products are ideal for eld installation in critical areas. High-resolution displays and multitouch
PCAP touchscreen with a robust glass front.
Power-over-Ethernet (PoE) for maximum simplicity of connection using standard shielded CAT 5 wiring. Full
IP protection with the use of dedicated connectors for the maximum flexibility of installation, from mounting
arm to a simple M22 hole. The product includes environment and motion sensors to make this device a true
IIoT edge device for Industry 4.0 applications.
The JSmart product family has been optimized for use as an embedded browser or as a JMobile HMI device.
• Open platform for Linux applications
• Performing HTML5-compatible browser with graphic accelerator
• JMobile runtime with OPC UA Server and Client
• Optional CODESYS V3 PLC for integrated HMI and control applications
• Built-in sensors (temperature and acceleration)

7
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
The products have been designed for use in an industrial environment in compliance with the 2014/30/EU
EMC Directive.
The products have been designed in compliance with:
EN 61000-6-4 CISPR 22 Class B
EN 61000-6-3 CISPR 16-2-3
EN 61000-6-2 EN 61000-4-2
EN 61000-6-1 EN 61000-4-3
EN 61000-4-4
EN 61000-4-5
EN 61000-4-6
EN 61000-4-8
The products are in compliance with the Restrictions on Certain Hazardous Substances (RoHS) Directive
2011/65/EU
In compliance with the above regulations the products are CE marked.
2 Standards and Approvals

8
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
Product Identication
The product may be identied by the indications in the back cover. You will have to know the type of unit you
are using for correct usage of the information contained in the guide.
An example of the information reported is shown below:
product model name JSmart705
year/week of production 1920
serial number AA00012P8000000561AA
manufacturer address Exor International S.p.A.
Via Monte Fiorino 9
IT-37057 San Giovanni Lupatoto (VR)
Ordering code key
Example: +JS705BA0U5P1
2 Standards and Approvals

9
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
3 Technical Specications
Electromagnetic Compatibility (EMC)
Radiated disturbance test Class B CISPR 22
CISPR 16-2-3
Electrostatic discharge immunity test 8 kV (air electrostatic discharge) EN 61000-4-2
4 kV (contact electrostatic discharge)
Radiated, radio-frequency, 80 MHz ÷ 1 GHz, 10V/m EN 61000-4-3
electromagnetic eld immunity test 1,4 GHz ÷ 2 GHz, 3 V/m
2 GHz ÷ 2.7 GHz, 1 V/m
Burst immunity test ± 2 KV dc power port EN 61000-4-4
± 1 KV signal line
Surge immunity test ± 0,5 KV dc power port (line to earth) EN 61000-4-5
± 0,5 KV dc power port (line to line)
± 1 KV signal line (line to earth)
Immunity to conducted disturbances
inducted by radiofrequency eld 0.15 ÷ 80 MHz, 10V EN 61000-4-6
Power frequency magnetic eld
immunity test Enclosure, 50/60Hz, 30A/m EN 61000-4-8
Environmental conditions
Operating temperature (surrounding -20 ÷ +55°C (vertical installation) EN 60068-2-14
air temperature)
Storage temperature -30 ÷ +80°C EN 60068-2-1
EN 60068-2-2
EN 60068-2-14
Operating and storage humidity 5 ÷ 85 % RH not-condensing EN 60068-2-30
Vibrations 5 ÷ 9 Hz, 7 mm p-p EN 60068-2-6
9 ÷ 150 Hz, 1 g
Shock ± 50 g, 11 ms, 3 pulses per axis EN 60068-2-27
Protection class IP67 (requires appropriate connectoris EN 60529
and cables)
Touchscreen technology Projected capacitive - Multitouch
Back-up battery 3V 7mAh Vanadium-Lithium, rechargeable, not user-replacea
ble, model VL1220.
Flash 4GB
RAM 1GB
Hardware clock Clock/Calendar with back-up battery
Accuracy RTC (at 25°C) <100ppm

10
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
3 Technical Specications
Durability information
Backlight service life 40000 Hrs. or more
(LED type) (Time of continuos operation until the brightness of the
backlight reaches 50% of the rated value when the
surrounding air temperature is 25°C) - see Note 1
Note 1: Extended use in environments where the surrounding air temperature is 40°C or higher may
degrade backlight quality/reliability/durability.
Viewing angles
For the viewing angles values (U,D,R,L) of the display types, see the technical data of the respective device.
The viewing angles are specied for the horizontal (L,R) and vertical (U,D) axes in reference to the vertical
axis of the display. The specied viewing angles above always refer to the standard mounting orientation.
Legend: Display viewing angle
U From top
D From bottom
L From left
R From right

11
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
Surface resistance
Chemical resistance of the front glass for an exposure time of 24 hours without visible changes:
• Betadine (10% Povidone Solution)
• Cola
• Electrode Gel/Paste
• Hydrogen Peroxide (3% Solution)
• NaCl (0.9% Solution)
• Coffee
• Dextrose (5% Glucose Solution)
• Hydrogen chloride (0.5% Solution PH=1)
• Isopropyl Alcohol
• Sodium Hypochlorit
• Ethyl Alcohol (70%-90%)
• Quaternary ammonium compound
3 Technical Specications

12
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
3 Technical Specications
Properties multitouch PCAP touchscreen
Operation with gloves
Projected capacitive touch screens (PCAP) are suitable for operation with or without gloves.
A large number of gloves (rubber gloves, light/heavy leather gloves, disposable latex gloves, etc.) are sup-
ported.
Due to the variety of commercially available gloves, however, EXOR cannot guarantee all types.
Number of ngers 5
Glove operation Yes
Passive stylus pens Yes
Active stylus pens No
Hardened front glass Yes

13
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
Model JSmart705
Display /
Backlight TFT Color / LED
Colors 16M
Resolution 800X480
Diagonal
(inches) 5” widescreen
Viewing angles
horizontal
Direction L / Direction R
Typ. 70°
Viewing angles
vertical
Direction U Typ. 50°
Direction D Typ. 70°
Dimming yes to 0%
CPU ARM Cortex-A9 dual core
800 MHz
Operating
System Linux RT
Flash 4GB
RAM 1GB
Ethernet port 10/100 PoE 802.3af/at
USB port 1 (Host v. 2.0, request special
connector)
Battery rechargeable
Real Time Clock yes
Power supply 802.3af
Current
consumption 6W
Weight 0.5 Kg

14
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
4.1 Dimensions
MODEL A B C D
JSmart705 105.1mm/4.13” 148.3mm/5.83” 16,5mm/0.64” 17mm/0.66”
4 Technical Data
Rear view

15
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
4.2 Installation Environment and procedure
Avoid prolonged exposition to direct sunlight to avoid the risk of overheating the device.
The equipment is not intended for installation in contact with corrosive chemical compounds. Check the
resistance of the front panel to a specic compound before installation.
Do not use tools of any kind (screwdrivers, etc.) to operate the touch screen of the panel.
IP67 is guaranteed only if a JSCAxxxx cable is used and if:
• max deviation from the plane surface to the cut-out: O0.5mm
• thickness of the case where is mounted the equipment: from 1,5mm to 3mm
• max surface roughness where the gasket is applied: O120 um
CAUTION
Tightening torque: 1000Ncm for nut, 130Ncm for screws
D
D Usable cable
Max 3mm JSCAxxxx (IP67)
Max 10mm Standard Ethernet

16
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
4.3 Safety instruction
For all installation notes, please refer to the Installation Guide provided with the product.
!

17
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
5 Connections
Reserved
Pin Description
1 TX+
2TX-
3 RX+
4 n/c
5 n/c
6RX-
7 n/c
8 n/c
5.1 Ethernet Port
Red
OFF: Valid link has NOT been detected
ON: Valid link has been detected
Green
ON: No activity
BLINKING: Activity
The Ethernet port have two status indicators. Please see description in gure.

18
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
6 Power Supply, Grounding and Shielding
The power supply terminal block is shown in the gure below.
The unit must always be grounded to earth with shielded CAT 5 cable. Grounding helps limit the effects of
noise due to electromagnetic interference on the control system.
The earth connection can also be made using the screws located near the connector. A label helps identify
the ground connection.
All the electronic devices in the control system must be properly grounded. Grounding must be performed
according to applicable regulations.
Fig. 6.1
Use a shielded CAT 5 cable or higher
Note: Ensure that the power supply has enough power capacity for the operation of the equipment.

19
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
Battery
7 Battery
These devices are equipped with rechargeable Lithium battery, not user-replaceable.
The following information is maintained by the battery:
• hardware real-time clock (date and time)
Charge:
At rst installation must be charged for 48 hours.
When the battery is fully charged, it ensures a period of 3 months of date and time back-up at 25°C.
Fig. 7.1: JSmart705
ATTENTION
Dispose of batteries according to local regulations.
!
ATTENTION
This device cannot be disposed of as a domestic waste but according to WEEE European
Directive 2012/19/EU
!

20
MANUGENJSMART705 - Version 1.00
© 2020 EXOR International S.p.A. - Subject to change without notice
- The equipment shall only be used in an area of not more than pollution degree 2, as dened in IEC/EN 60664-1.
- The equipment shall be installed in an enclosure that provides a degree of protection not less than IP 54 in
accordance with IEC/EN 60079-15.
- Transient protection shall be provided that is set at a level not exceeding 140 % of the peak rated voltage
value at the supply terminals to the equipment.
- Install the HMI device according to the accompanying installation instructions.
- Ground the HMI device according to the accompanying installation instructions.
- Only qualied personnel may install the HMI device or repair it.
- Care shall be taken not to allow layers of dust to form on the graphic panel in a way that might cause the
accumulation of static charges. Keep the faceplate of the HMI device clean: the equipment must be clea-
ned only with a soft cloth and neutral soap product. Do not use solvents.
- This device should not be used for purposes and methods other than indicated in this document and
in the documentation accompanying the product.
JSmart 700 HMI products delivery conguration is based on a loader. Use the services of the loader to
install applications on the device such as JMobile runtime or browsers.
JMobile Studio version V2.6 or higher is required. JMobile Studio is a software tool that must be properly
installed on a computer running Microsoft Windows.
There are two options to transfer a JMobile application project to a HMI device:
Ethernet Connect the HMI device to the computer with an Ethernet network. In JMobile Studio
select the command Run/Download to target. You may have to ensure that the proper
rewall policy has been congured in the computer to allow JMobile Studio to access
the network.
USB Create an Update Package using JMobile Studio and copy it to a USB Flash drive
(to transfer via USB, use the dedicated accessory cable).
8 Special Instruction for Use
9 Getting Started
