fantastic furniture Eden Utility 6 Drawer MK2 User manual

Eden
Utility 6 Drawer MK2
fantasticfurniture.com.au
Version 1.0

Secure it!
Wall attachment guide
(with available wood stud)
Screw directly into
stud.
Please seek professional advice if you are in doubt of what fixing device to use.
•
•
• Do not
•
•
Reduce the risk of furniture
tip-over accidents
(with available wood stud)
S
.
S crew
fantasticfurniture.com.aufantasticfurniture.com.au
Recommended Weight Capacity :15kg/drawer

fantasticfurniture.com.au Page 3
Looks like you’ve found
your Fantastic!
We’re thrilled you’ve chosen Fantastic Furniture
to help create a home you’ll love!
Love it? Share it!
Fantastic buy! Share how it looks at home on Instagram for
your chance to win a $250 Fantastic Furniture Gift Card!
@fantasticfurniture

Page 4
Read through the instructions carefully
before you begin.
Assembly Checklist
Identify and lay out all of the
components before you begin assembly.
Unless instructed, do not fully tighten
screws until the item is fully assembled.
! Never use power tools unless specifically instructed. They can damage your
components or hardware if used incorrectly.
! The most common mistakes made during assembly are using the wrong hardware or
getting components back to front.
! Always use a soft surface (such as carpet or cardboard) when assembling your
product to avoid scratching or damaging the surface of the product.
! Bulky items such as wardrobes and bunk beds should be assembled in the room they
will be used in as they may not fit through a door once assembled.
! Never use any glue until you are certain that the parts belong together.
! Periodically check and re-tighten all fasteners. Check the product care label or
website for product care instructions.
! If you are having any diculties assembling your product, missing any hardware or
components please visit our website Help Centre for further assistance.
! Please see page 2 for any safety requirements or weight restrictions.
Make sure you have all the required tools.
Never use power tools unless instructed.
Useful Information
fantasticfurniture.com.au

Parts list
Top Panel (P1);
Base Panel (P2);
Left Side Panel (P3);
Right Side Panel (P4);
3 x Back Panels (P5);
2 x Rails (P6);
2 x Rails (P7);
2 x Rails (P8);
6 x Drawer Fronts (P9);
6 x Left Drawer Sides (P10);
6 x Right Drawer Sides (P11);
6 x Drawer Bases (P12)
6 x Drawer Backs (P13);
6 x Support Rails (P14)
Hardware pack
Top Panel
(P1)
Right Side
Panel (P4)
Left Side
Panel (P3)
Rail
(P6)
Rail
(P6)
Rail
(P7)
Rail
(P7)
Rail
(P8) Rail
(P8)
Back
Panel
(P5)
Back
Panel
(P5)
Back
Panel
(P5)
Left
Drawer
Side (P10)
Drawer
Front (P9)
Right
Drawer
Side
(P11)
Drawer
Back (P13)
Drawer
Base (P12)
Base Panel
(P2)
What you need
to assemble the product
Other tools you need:
Phillips head screwdriver;
Hammer
Page 5
fantasticfurniture.com.au
DO NOT USE
26 x Dowels
(H1)
36 x Long
Screws
(H2)
60 x Small
Screws
(H5)
50 x Cam Bolts
(H3)
50 x Cam Nuts
(H4)
8 x Wedges
(H11)
4 x Plastic
Glides
(H10)
8 x Wedge
Screws
(H12)
1 x Safety
Strap
Screw
(H14)
1 x Safety
Strap
(H13)
2 x Washers
(H15)
6 x CL Runner
Tracks
(H6)
6 x CR Runner
Tracks
(H7)
6 x DL
Runners
(H8)
6 x DR
Runners
(H9)
x6
Support
Rail (P14)

18 x Small
Screws (H5)
10 x Cam Bolts
(H3)
(P3)
(P3)
You will need
Step 1
Step 2
You will need
Attach 6 x CL Runner Tracks (H6) to Left Side Panel (P3) with 18 x Small Screws (H5) by
tightening with the Phillips Head Screwdriver.
fantasticfurniture.com.au Page 6
Phillips Head
Screwdriver
Phillips Head
Screwdriver
Attach 10 x Cam Bolts (H3) to Left Side Panel (P3) as shown by tightening with the
Phillips Head Screwdriver.
H6
CL
H5
H3
6 x CL Runner
Tracks (H6)
H3
H3
H3 H3
H3
H3
H3 H3
H3
H5
H5
H5
H5
H5
H5
H5
H5
H5
H5
H5
H5
H5
H6
H6
H6
H6
H6
H6
H5
H5
H5
H5
H5

18 x Small
Screws (H5)
10 x Cam Bolts
(H3)
Attach 10 x Cam Bolts (H3) to Right Side Panel (P4) as shown by tightening with the
Phillips Head Screwdriver.
(P4)
(P4)
fantasticfurniture.com.au Page 7
Step 4
You will need
Phillips Head
Screwdriver
Step 3
You will need
Phillips Head
Screwdriver
Attach 6 x CR Runner Tracks (H7) to Right Side Panel (P4)
with 18 x Small Screws (H5) by tightening with the Phillips Head Screwdriver.
H7
CR
H5
H3
H3
H3
H3
H3
H3 H3
H3
H3
H3
H7
H5
H7
H5
H7
H5
H7
H5
H7
H5
H7
H5
6 x CR Runner
Tracks (H7)

Step 5
You will need
Step 6
You will need
Insert 10 x Cam Nuts (H4) into Top Panel (P1), Base Panel (P2) and Rails (P6 x 2, P7 x 2, P8 x 2).
Rotate the nuts so the arrows point towards the incoming bolts. Attach Top Panel (P1),
Base Panel (P2) and Rails (P6 x 2, P7 x 2, P8 x 2) to Left Side Panel (P3) by tightening
all nuts with the Phillips Head Screwdriver.
fantasticfurniture.com.au Page 8
10 x Dowels
(H1)
Insert 10 x Dowels (H1) into Left Side Panel (P3) as shown.
Phillips Head
Screwdriver
10 x Cam Nuts
(H4)
This is how a cam nut works........
The head of the cam
bolt goes into the
open mouth of the
cam nut. You then
turn the cam nut so
it tightens over the
bolt.
(P3)
(P3)
(P1)
(P2)
(P6)
(P6)
(P7)
(P7)
(P8)
(P8)
H4
H4
H4
H4 H4 H4
H4
H4
H1
H1
H1
H1
H1
H1 H1
H1
H1
H1

Step 7 Ensure laminated
side of panels are
facing inwards.
Slide Back Panels (P5 x 3) into the grooves
of Top Panel (P1), Base Panel (P2), Rails (P6 x 2)
and Left Side Panel (P3).
You will need
Step 8
(P6)
(P6)
(P5)
(P5)
(P6)
(P3)
(P6)
(P2)
(P1)
(P5)
fantasticfurniture.com.au Page 9
(P1)
(P2)
(P7)
(P7)
(P8)
(P8)
Insert 10 x Dowels (H1) into Top Panel (P1), Base Panel (P2)
and Rails (P6 x 2, P7 x 2, P8 x 2) as shown.
H1
H1
H1
H1
H1
H1
H1
10 x Dowels
(H1)
H1
H1
H1

You will need
Step 9
You will need
Step 10
(P3)
(P4)
(P4)
(P1)
(P2)
(P6)
(P6)
(P7)
(P7)
(P8)
(P8)
fantasticfurniture.com.au Page 10
Secure 4 x Plastic Glides (H10) to the bottom of Left & Right Side Panels (P3 & P4)
as shown using the Hammer.
Hammer
4 x Plastic
Glides (H10)
Insert 10 x Cam Nuts (H4) into Top Panel (P1),
Base Panel (P2) and Rails (P6 x 2, P7 x 2, P8 x 2).
Rotate the nuts so the arrows point towards the
incoming bolts. Attach Right Side Panel (P4) to Top
Panel (P1), Base Panel (P2) and Rails (P6 x 2, P7 x 2, P8 x 2)
by tightening all nuts with the Phillips Head Screwdriver.
H4
H4
H4
H4
H4 H4
Phillips Head
Screwdriver
10 x Cam Nuts
(H4)
H4
H4
H10
H10
H10
H10

You will need
Step 12
Phillips Head
Screwdriver
Attach 5 x Cam Bolts (H3) to Drawer Front (P9) as shown by tightening with the
Phillips Head Screwdriver. Repeat this step for the remaining five Drawer Fronts (P9 x 5).
Attach Drawer Back (P13) to Left & Right Drawer Sides (P10 & P11) and Rail (P14) with
6 x Long Screws (H2) by tightening with the Phillips Head Screwdriver. Repeat this step
for the remaining Drawer Backs (P13 x 5), Drawer Sides (P10 x 5 & P11 x 5) and Rails (P14 x 5).
H3
(P14)
You will need
Step 11
Phillips Head
Screwdriver
(P9)
(P13)
(P10)
(P11)
fantasticfurniture.com.au Page 11
H3
H3
H2
H3
H3
H2
36 x Long
Screws (H2)
30 x Cam
Bolts (H3)
H2
H2
H2H2

You will need
Step 14
Step 13
Slide Drawer Base (P12) into the grooves of Left & Right Drawer Sides (P10 & P11) and
Drawer Back (P13). Repeat this step for the remaining Drawer Bases (P12 x 5).
Phillips Head
Screwdriver
Ensure laminated
side of panel is
facing inwards.
(P14)
6 x Dowel
(H1)
(P9)
(P10)
(P10)
(P13)
(P11)
(P11)
(P12)
30 x Cam Nuts
(H4)
fantasticfurniture.com.au Page 12
H4
H4
H1
H4
H4
H4
Insert 1 x Dowel (H1) into Rail (P14).
Insert 5 x Cam Nuts (H4) into Left & Right
Drawer Sides (P10 & P11) and Rail (P14).
Rotate the nuts so the arrows point towards
the incoming bolts. Attach Drawer Front (P9)
to Left & Right Drawer Sides (P10 & P11) and Rail (P14)
by tightening all nuts with the Phillips Head Screwdriver.
Repeat this step for the remaining Drawer Sides (P10 x 5 & P11 x 5) and Drawer Fronts (P9 x 5).

Step 16
Attach 1 x DL Runner (H8) to the bottom of Left Drawer Side (P10) and 1 x DR Runner (H9)
to the bottom of Right Drawer Side (P11) with 4 x Small Screws (H5) by tightening with the
Phillips Head Screwdriver. Repeat this step for the remaining five Drawers.
You will need
Step 15
Phillips Head
Screwdriver
Gently insert the assembled drawers into the unit by carefully lining up the drawer
runners with the drawer runner tracks.
(P10)
(P11)
fantasticfurniture.com.au Page 13
H5
H5
H5
H8
H9
H5
24 x Small
Screws (H5)
6 x DL Runners
(H8)
6 x DR Runners
(H9)

You will need
Step 17
Phillips Head
Screwdriver
Job Complete!
In the interest of our environment please dispose of all packaging thoughtfully.
Secure Back Panels (P5 x 2) in place with 8 x Wedges (H11) and 8 x Wedge Screws
(H12) by tightening with the Phillips Head Screwdriver. Attach the Safety Strap (H13) to the
Top Panel (P1) with 1 x Safety Strap Screw (H14) & 1 x Washer (H15) by tightening with the
Phillips Head Screwdriver.
Move the unit to the final
position, and attach the safety
strap to the wall securely.
Make sure it is firmly attached
and snug fit.
Seek advice from a qualified
trades person on how to
attach this safety strap to
your specific wall.
1 x Safety Strap
Screw (H14)
1 x Safety
Strap (H13)
1 x Washer
(H15)
(P1)
(P5)
(P5)
H11
H12
8 x Wedges
(H11)
8 x Wedge
Screws (H12)
H13
H13
H14
H14
H15
H15
fantasticfurniture.com.au Page 14
H15
wall
Screw
You will need
Step 18
Phillips Head
Screwdriver
1 x Washer
(H15)
We strongly advise that you
use the wall safety strap
provided to prevent the unit
toppling.
Screw and Wall Plug are not
provided. Please use
appropriate fixtures for
your wall.
