fantastic furniture Java Bedside 1 Drawer User manual

Version 1.0
Java
Bedside 1 Drawer
fantasticfurniture.com.au
Required
Two People

fantasticfurniture.com.au Page 2
Warning: Ensure the wall strap is attached
to avoid serious injury
To avoid any serious or fatal injury, a wall strap has been provided with
this product to prevent toppling. We strongly recommend that this
product is permanently fixed to the wall or other suitable surface. Fixing
of what fixing device to use.
Rattan
Rattan is a natural material that will respond to humidity in the
environment. Low humidity may cause the rattan to shrink.
High humidity may cause the rattan to absorb moisture and expand,
causing the weaving to look loose and wavy.
This is a natural phenomenon and not a defect.
Looks like you’ve found
your Fantastic!
Love it? Share it!
We’re thrilled you’ve chosen Fantastic Furniture
to help create a home you’ll love!
Fantastic buy! Share how it looks at home on Instagram
for your chance to win a $250 Fantastic Furniture Gift Card!
@fantasticfurniture

Read through the instructions carefully
before you begin.
Assembly Checklist
Identify and lay out all of the
components before you begin assembly.
Unless instructed, do not fully tighten
screws until the item is fully assembled.
!Never use power tools unless specifically instructed. They can damage your
components or hardware if used incorrectly.
!The most common mistakes made during assembly are using the wrong hardware or
getting components back to front.
!Always use a soft surface (such as carpet or cardboard) when assembling your
product to avoid scratching or damaging the surface of the product.
!Bulky items such as wardrobes and bunk beds should be assembled in the room they
will be used in as they may not fit through a door once assembled.
!Never use any glue until you are certain that the parts belong together.
!Periodically check and re-tighten all fasteners. Check the product care label or
website for product care instructions.
!If you are having any diculties assembling your product, missing any hardware or
components please visit our website Help Centre for further assistance.
!Please see page 2 for any safety requirements or weight restrictions.
Make sure you have all the required tools.
Never use power tools unless instructed.
Useful Information
fantasticfurniture.com.au Page 3

Parts list
1 x Top Panel (P1)
1 x Bottom Panel (P2)
1 x Left Side Panel (P3)
1 x Right Side Panel (P4)
1 x Shelf (P5)
1 x Back Panel (P6)
1 x Drawer Front (P7)
1 x Drawer Left Side (P8)
1 x Drawer Right Side (P9)
1 x Drawer Back (P10)
1 x Drawer Base (P11)
4 x Legs (P12)
Top Panel (P1)
What you need
to assemble the product
Other tools you need
Flat Head Screwdriver;
Phillips Head Screwdriver;
Mallet
fantasticfurniture.com.au
Page 4
Bottom Panel (P2)
Left Side Panel
(P3)
Back Panel
(P6)
Drawer Front
(P7)
Drawer Back
(P10)
Drawer Base
(P11)
Leg (P12)
Drawer Left
Side (P8)
Drawer Right
Side (P9)
Right Side Panel
(P4)
Shelf (P5)
Leg (P12)

fantasticfurniture.com.au
Page 5
Hardware Pack
16 x Cam Bolts
(H1)
12 x Large Cam
Nuts (H2)
12 x Dowels ø8mm
(H3)
1 x Handle
(H4)
4 x Screws 16mm
(H6)
10 x Flat Washers
(H9)
8 x Spring
Washers (H10)
2 x Screws 28mm
(H11)
1 x Allen Key
(H12)
4 x Felt Feet
(H5)
8 x Bolts
(H8)
4 x Back Panel
Connectors (H7)
1 x Screw 25mm
(H14)
4 x Small Cam
Nuts (H15)
1 x Wall Strap
(H13)
2 x Dowels ø6mm
(H16)
4 x Screws 38mm
(H17)
2 x Slides
(H19)
12 x Screws 12mm
(H18)

Step 1
Page 6fantasticfurniture.com.au
You will need
Attach 1 x felt foot (H5) onto each leg (P12) as shown.
Step 2
You will need
8 x Bolts
(H8)
Attach 1 x leg (P12) onto bottom panel (P2),
using 2 x bolts (H8), 2 x spring washers (H10)
and 2 x flat washers (H9).
Tighten the bolt with allen key (H12).
Repeat this step for the other 3 x legs (P12).
Turn the assembled frame over.
4 x Felt Feet
(H5)
X4
H5
8 x Flat
Washers (H9)
8 x Spring
Washers (H10)
1 x Allen Key
(H12)
Step 3
You will need
(P2)
H1
Screw 4 x cam bolts (H1)
into bottom panel (P2),
using a phillips head screwdriver.
4 x Cam Bolts
(H1)
Phillips Head
Screwdriver
(P12)
H12
H8
H10
H9
(P2)
(P12)
H1
H1
H1
(P2)
(P12)
(P12)
(P12)
(P12)

Step 4
Page 7fantasticfurniture.com.au
You will need
Phillips Head
Screwdriver
6 x Screws
12mm (H18)
2 x Slides
(H19)
Mallet
H19
Separate the 2 x slide runners (H19-2) and slide tracks (H19-1)
from the slides (H19) by following the steps below:
Extend the slide runner (H19-2) all the way out.
Press down the plastic release lever on the slide and pull out
the slide runner (H19-2) completely.
H19
Slide runner H19-2 Slide track H19-1
H19-1
H19-1
Note the position of the rubber stopper
Attach 2 x separated slide tracks (H19-1) onto side panels (P3, P4) with 6 x screws (H18),
using a phillips head screwdriver as shown.
Ensure the slide tracks (H19-1) are attached so the rubbber stopper is near
the grooves on side panels.
Screw 4 x cam bolts (H1) into side panels (P3, P4), using a phillips head screwdriver
as shown.
Insert 4 x dowels (H3) into the left side panel (P3) and 4 x dowels (H3) into
the right side panel (P4).
If needed use a mallet to gently tap the dowels into place.
Adjust runner to access the screw holes.
H19-1
8 x Dowels
ø8mm (H3)
(P3)
H3
H18
H3
H3
H3
H3
H3
H3
H3
(P4)
H19-1 H19-1
H1
H1
H1
H1
H18 H18
H18
4 x Cam Bolts
(H1)
H19-1
Please fasten the screws
through these holes for this step

Step 5
Page 8fantasticfurniture.com.au
You will need
Position side panels (P3, P4) onto shelf (P5) as shown.
Insert 4 x large cam nuts (H2) into shelf (P5).
Rotate the cam nuts so the arrow faces incoming cam bolts.
Using a flat head screwdriver turn clockwise to lock.
(P5)
(P3)
This is how a cam nut works........
The head of the cam
bolt goes into the open
mouth of the cam nut.
You then turn the cam
nut so it tightens over
the bolt.
(P5)
(P3)
(P4)
H2
H2
H2
H2
Step 6
You will need
Flat Head
Screwdriver
4 x Large Cam
Nuts (H2)
(P5)
Insert 4 x dowels (H3) into shelf (P5) as shown.
Use a mallet to gently tap the dowels into place if needed.
Mallet
4 x Dowels
ø8mm (H3)
H3
H3
H3
H3
Laminated edge

Step 7
Page 9fantasticfurniture.com.au
You will need
Position side panels (P3, P4)
onto bottom panel (P2) as shown.
Insert 4 x large cam nuts (H2) into side panels (P3, P4). Rotate the cam nuts so the arrow
faces incoming cam bolts. Using a flat head screwdriver turn clockwise to lock.
Flat Head
Screwdriver
4 x Large Cam
Nuts (H2)
(P2)
H2
Step 8
(P3)
(P4)
H2
H2
Slide back panel (P6) into
the grooves of the side panels (P3, P4) and bottom panel (P2).
(P6)
(P2)
(P3)
(P4)

Step 9
Page 10fantasticfurniture.com.au
You will need
(P1)
H1
Screw 4 x cam bolts (H1) into top panel (P1), using a phillips head screwdriver.
4 x Cam Bolts
(H1)
Phillips Head
Screwdriver
H1
H1
H1
Flat Head
Screwdriver
4 x Large Cam
Nuts (H2)
Step 10
You will need
(P1)
H2
H2
H2
H2
(P3) (P4)
Position top panel (P1) onto assembled unit as shown.
Insert 4 x large cam nuts (H2) into panels (P3, P4).
Rotate the cam nuts so the arrow faces incoming cam bolts.
Using a flat head screwdriver turn clockwise to lock.

Step 11
Page 11fantasticfurniture.com.au
You will need
Step 12
You will need
If necessary, gently adjust the top panel (P1) sideways in either direction
until XX and YY are equal.
Holding it in place, fix 4 x back panel connectors (H7) to assembled unit with 4 x screws (H6)
as shown, using a phillips head screwdriver as shown.
Phillips Head
Screwdriver
4 x Cam Bolts
(H1)
H1 (P7)
H1
H1
H1
Screw 4 x cam bolts (H1) into drawer front (P7), using a phillips head screwdriver as shown.
Phillips Head
Screwdriver
4 x Screws
16mm (H6)
4 x Back Panel
Connectors (H7)
(P6)
H7 H7
H6
(P6)
XX
YY
XX=YY
Required
Two People
(P1)
(P1)
XX
YY
(P1)
(P6)
(P1)

Step 13
Page 12fantasticfurniture.com.au
You will need
Step 15
Position drawer sides (P8, P9)
onto drawer front (P7).
Insert 4 x small cam nuts (H15)
into drawer sides (P8, P9).
Rotate the cam nuts so the arrow faces
incoming cam bolts.
Using a flat head screwdriver turn clockwise to lock.
(P7)
(P9)
(P8)
H15
H15
(P9)
(P8)
(P11)
Slide drawer base (P11) into
the grooves on panels (P7, P8, P9).
Step 14
You will need
Insert 2 x dowels (H16) into drawer side panels (P8, P9) as shown.
If needed use a mallet to gently tap the dowels into place.
Mallet
2 x Dowels
ø6mm (H16)
(P8)
(P9)
Flat Head
Screwdriver
4 x Small Cam
Nuts (H15)
(P7)

Step 16
Page 13fantasticfurniture.com.au
You will need
Step 18
You will need
4 x Screws
38mm (H17)
Phillips Head
Screwdriver
(P8)
(P9)
(P10)
H17
H17
Ensure the pre-drilled holes
on drawer panels (P8, P9)
align with the holes on (P10).
Step 17
You will need
Attach drawer back (P10) to assembled drawer
with 4 x screws (H17), using a phillips head screwdriver as shown.
Attach 1 x slide runner (H19-2) to each drawer side (P8, P9) with 3 x screws (H18),
using a phillips head screwdriver as shown.
2 x Slide
Runners (H19-2)
Phillips Head
Screwdriver
6 x Screws
12mm (H18)
H19-2
H19-2
H19-2
H18
H18
H18
H18
H18
H18
(P8)
(P9)
H19-2
H19-2
2 x Screws
28mm (H11)
Phillips Head
Screwdriver
1 x Handle
(H4)
H11
(P7) H4
Attach 1 x handle (H4) onto drawer front (P7) with 2 x screws (H11),
using a phillips head screwdriver as shown.
Please fasten the screws
through these holes for this step.

Step 19
Page 14fantasticfurniture.com.au
Move inner ball bearing track
to front of slide track (H19-1).
H19-2
H19-1
Gently insert drawer slide runner (H19-2)
in between the ball bearing tracks.
Position drawer so that slide runners (H19-2) align with slide tracks (H19-1) as shown.
Gently push drawer into the closed position.

Step 20
Page 15fantasticfurniture.com.au
You will need
Step 21
You will need
Fix 1 x wall strap (H13) to top panel (P1) with 1 x screw (H14) and 1 x flat washer (H9) as shown,
using a phillips head screwdriver.
1 x Flat
Washer (H9)
1 x Screw
25mm (H14)
1 x Wall Strap
(H13)
Phillips Head
Screwdriver
(P1)
H13
H9
H14
1 x Flat
Washer (H9)
Phillips Head
Screwdriver
Seek advice from a qualified
trades person on how to
attach this wall strap to
your specific wall.
Screw and wall plug are not included.
Please use appropriate fixtures for your wall.
With assistance, move the bedside to its final position.
Attach the wall strap to the wall.
Make sure it is firmly attached and secure.
H9
Wall
H13
H13
We strongly recommend
that this product is
permanently fixed to the wall
or other suitable surface.
Required
Two People

Step 22
Page 16fantasticfurniture.com.au
Job complete!
In the interest of our environment please dispose
of all packaging thoughtfully.
