fantastic furniture Tailor Utility 6 Drawer 3 Shelf User manual

Version 1.0
Tailor
Utility 6 Drawer 3 Shelf
fantasticfurniture.com.au

Secure it!
Wall attachment guide
(with available wood stud)
Screw directly into
stud.
Please seek professional advice if you are in doubt of what fixing device to use.
•
•
• Do not
•
•
Reduce the risk of furniture
tip-over accidents
(with available wood stud)
S
.
Screw
fantasticfurniture.com.aufantasticfurniture.com.au
Recommended Weight Capacity :15kg/shelf

fantasticfurniture.com.au Page 3
Looks like you’ve found
your Fantastic!
We’re thrilled you’ve chosen Fantastic Furniture
to help create a home you’ll love!
Love it? Share it!
Fantastic buy! Share how it looks at home on Instagram for
your chance to win a $250 Fantastic Furniture Gift Card!
@fantasticfurniture

Page 4
Read through the instructions carefully
before you begin.
Assembly Checklist
Identify and lay out all of the
components before you begin assembly.
Unless instructed, do not fully tighten
screws until the item is fully assembled.
! Never use power tools unless specifically instructed. They can damage your
components or hardware if used incorrectly.
! The most common mistakes made during assembly are using the wrong hardware or
getting components back to front.
! Always use a soft surface (such as carpet or cardboard) when assembling your
product to avoid scratching or damaging the surface of the product.
! Bulky items such as wardrobes and bunk beds should be assembled in the room they
will be used in as they may not fit through a door once assembled.
! Never use any glue until you are certain that the parts belong together.
! Periodically check and re-tighten all fasteners. Check the product care label or
website for product care instructions.
! If you are having any diculties assembling your product, missing any hardware or
components please visit our website Help Centre for further assistance.
! Please see page 2 for any safety requirements or weight restrictions.
Make sure you have all the required tools.
Never use power tools unless instructed.
Useful Information
fantasticfurniture.com.au

Right Side
Panel
(P3)
Left Side
Panel
(P2)
Back Panel
(P6)
Parts list
2 x Top/Bottom Panels (P1);
2 x Adjustable Shelf Panels (P4);
Shelf Panel (P5);
Back Panel (P6);
Small Drawer Front (P7);
Small Left Drawer Side (P8);
Small Right Drawer Side (P9);
Drawer Base (P10);
Small Drawer Back (P11);
Drawer Front (P12);
Left Drawer Side (P13);
Right Drawer Side (P14);
Drawer Back (P15);
Left Side Panel (P2);
Right Side Panel (P3);
Hardware pack
Adjustable
Shelf Panel
(P4)
Adjustable
Shelf Panel
(P4)
Shelf Panel
(P5)
x4 x2
Small Left
Drawer Side
(P8)
Small
Drawer Front
(P7)
Small
Right Drawer
Side
(P9)
Small
Drawer Back
(P11)
Drawer Base
(P10)
Left
Drawer Side
(P13)
Drawer Front
(P12)
Right Drawer
Side
(P14)
Drawer Back
(P15)
Drawer Base
(P10)
Top/Bottom Panel
(P1)
Top/Bottom Panel
(P1)
24 x Long
Screws
(H18)
24 x Small
Cam Bolts
(H15)
24 x Small
Cam Nuts
(H16)
6 x DL
Runners
(H11)
6 x DR
Runners
(H12)
24 x Small
Screws
(H13)
26 x Screws
(H14)
1 x Metal
Bracket
(H17)
4 x Cam Nut
Screws
(H19)
1 x Screw
(H7)
1 x Safety
Strap
(H6)
2 x Washer
(H8)
6 x CL Runner
Tracks
(H9)
6 x CR Runner
Tracks
(H10)
8 x Cam
Bolts
(H3)
8 x Cam
Nuts
(H4)
8 x Dowels
(H1)
30 x Nails
(H5)
8 x Shelf
Supports
(H2)
What you need
to assemble the product
Other tools you need:
Phillips head screwdriver;
Hammer; Tape
DO NOT USE
Page 5
fantasticfurniture.com.au

6 x CL Runner
Tracks (H9)
24 x Screws
(H14)
You will need
Step 1
Phillips head
screwdriver
6 x CR Runner
Tracks (H10)
(P2) H9
H10
H10
H10
H10
H10
H10
H9
H9
H9
H9
H9
31
26
21
16
9
21
(P3)
31
26
21
16
9
21
Attach 6 x CL Runner Tracks (H9) to Left Side Panel (P2) with 12 x Screws (H14).
Attach 6 x CR Runner Tracks (H10) to Right Side Panel (P3) with 12 x Screws (H14).
CR
H10 H10
CR
H14
H14
H9
CL
H14
CL
H9
H14
Page 6
fantasticfurniture.com.au
glide on bottom

You will need
Step 2
You will need
Step 3
(P2)
(P3)
H4
H4
(P3)
(P1)
(P1)
H3
H3
H3
H3
H3
H3
H3
H3
Attach 8 x Cam Bolts (H3) into Side Panels (P2, P3).
Attach 4 x Cam Nut Screws (H19) into Side Panels (P2, P3).
Make sure raw edge
is facing up.
1
35
35
1
H19
H19
H19
H19
H4
8 x Cam Bolts
(H3)
4 x Cam Nut
Screws (H19)
Phillips head
screwdriver
4 x Cam Nuts
(H4)
4 x Dowels
(H1)
Insert 4 x Dowels (H1) into 2 x Top/Bottom Panels (P1).
Insert 4 x Cam Nuts (H4) into the holes of 2 x Top/Bottom Panels (P1).
Rotate the cam nuts so the arrows point towards the incoming cam bolts.
Attach 2 x Top/Bottom Panels (P1) to Right Side Panel (P3), then tighten the
cam nuts.
H1
H1
H1
Page 7
fantasticfurniture.com.au
Phillips head
screwdriver
This is how a cam nut works........
The head of the cam
bolt goes into the
open mouth of the
cam nut. You then
turn the cam nut so
it tightens over the
bolt.

You will need
Step 4
4 x Cam Nuts
(H4)
4 x Dowels
(H1)
H4
H4
H1
H1
(P1)
(P1)
(P3)
(P2)
H1
H1
(P3)
(P2)
Insert 4 x Dowels (H1) into 2 x Top/Bottom Panels (P1).
Insert 4 x Cam Nuts (H4) into the holes of 2 x Top/Bottom Panels (P1).
Rotate the cam nuts so the arrows point towards the incoming cam bolts.
Push Left Side Panel (P2) into place and tighten the cam nuts.
(P5)
(P5)
You will need
Step 5
H4
Make sure raw edge
is facing up.
Adjust the opening of cam locks is facing the cam nut screws,
then push Shelf Panel (P5) into place and tighten the cam locks.
Page 8
fantasticfurniture.com.au
Phillips head
screwdriver
Phillips head
screwdriver
This is how a cam lock works........
The head of the cam
nut screw goes into
the open mouth of
the cam lock. You
then turn the cam
lock so it tightens
over the screw.

You will need
Step 7
2 x Screws
(H14)
1 x Metal
Bracket (H17)
Phillips head
screwdriver
Attach Metal Bracket (H17) to Side Panels (P2, P3) with 2 x Screws (H14).
Step 6
You will need
30 x Nails
(H5) Hammer (P6)
(P2)
(P3)
Tape
(P3)
(P2)
Attach Back Panel (P6) to the cabinet with 30 x Nails (H5) using hammer.
H14 H17
H5
A = B
AB
Ensure the diagonal of section A
is equal to the section B.
Make sure the edge of back panel is well
aligned with side, top and bottom panels
before nailing the back panel.
Page 9
fantasticfurniture.com.au

(P7)
H15
H15
H15 H15
Phillips head
screwdriver
4 x Small Cam
Bolts (H15)
You will need
Step 8
You will need
4 x Small Cam
Nuts (H16)
Step 9
Step 10
(P7)
(P10)
(P8)
(P9)
H16
H16
(P7)
(P8)
(P9)
H16
H16
Attach 4 x Small Cam Bolts (H15) into Small Drawer Front (P7).
Insert 4 x Small Cam Nuts (H16) into the holes of Small Drawer Sides (P8, P9).
Rotate the cam nuts so the arrows point towards the incoming cam bolts.
Push Small Drawer Sides (P8, P9) into place and tighten the cam nuts.
Slide Drawer Base (P10) into the groove
in Small Drawer Sides (P8, P9).
Page 10
fantasticfurniture.com.au
Phillips head
screwdriver

Phillips head
screwdriver
You will need
4 x Long
Screws (H18)
Step 11
4 x Small
Screws (H13)
You will need
1 x DL Runner
(H11)
1 x DR Runner
(H12)
H12
DR
H13 H13
H11
DL
H13 H13
Step 12
Phillips head
screwdriver
Step 13
(P8)
(P9)
H12
H11
H13
H13
H13
H13
H18
(P10)
(P11)
(P7)
(P8)
(P9)
H18
H18
H18
Attach Small Drawer Back (P11) to Small Drawer Sides (P8, P9) with 4 x Long Screws (H18),
make sure that the groove lines up the whole way around the drawer.
Attach 1 x DL Runner (H11) to the bottom of Small Left Drawer Side (P8) and 1 x DR Runner (H12)
to the bottom of Small Right Drawer Side (P9) with 4 x Small Screws (H13).
Repeat step 8 to step 12 to assemble the rest of 3 x Small Drawers.
Page 11
fantasticfurniture.com.au

Phillips head
screwdriver
Phillips head
screwdriver
4 x Small Cam
Bolts (H15)
You will need
Step 14
You will need
4 x Small Cam
Nuts (H16)
Step 15
Step 16
H15H15
(P12)
H15 H15
H16
H16
H16
H16
(P12)
(P13)
(P14)
(P12)
(P10)
(P13)
(P14)
Attach 4 x Small Cam Bolts (H15) into Drawer Front (P12).
Insert 4 x Small Cam Nuts (H16) into the holes of Drawer Sides (P13, P14).
Rotate the cam nuts so the arrows point towards the incoming cam bolts.
Push Drawer Sides (P13, P14) into place and tighten the cam nuts.
Slide Drawer Base (P10) into the groove
in Drawer Sides (P13, P14).
Page 12
fantasticfurniture.com.au

Phillips head
screwdriver
You will need
4 x Long
Screws (H18)
Step 17
4 x Small
Screws (H13)
You will need
1 x DL Runner
(H11)
1 x DR Runner
(H12)
H12
DR
H13 H13
H11
DL
H13 H13
Step 18
Phillips head
screwdriver
Step 19
H18
(P10)
(P15)
(P12)
(P13)
(P14)
H18
H18
H18
(P13)
(P14)
H12
H11
H13
H13
H13
H13
Attach Drawer Back (P15) to Drawer Sides (P13, P14) with 4 x Long Screws (H18),
make sure that the groove lines up the whole way around the drawer.
Attach 1 x DL Runner (H11) to the bottom of Left Drawer Side (P13) and 1 x DR Runner (H12)
to the bottom of Right Drawer Side (P14) with 4 x Small Screws (H13).
Repeat step 14 to step 18 to assemble the rest of Drawer.
Page 13
fantasticfurniture.com.au

You will need
Step 20
Step 21
(P4)
(P4)
(P3)
(P2)
8 x Shelf
Supports (H2)
Insert 8 x Shelf Supports (H2) into the holes of Side Panels (P2, P3) as shown.
Insert 2 x Adjustable Shelf Panels (P4) into the cabinet.
Put the drawers into the cabinet.
Align the Shelf Support
to the hole of Adjustable
Shelf Panel.
H2
(P4)
Page 14
fantasticfurniture.com.au

You will need
Step 22
Step 23
You will need
(P6)
(P1)
Use Screw (H7) and Washer (H8) to connect Safety Strap (H6)
on Top Panel (P1) through the gap of Back Panel (P6).
Phillips head
screwdriver
1 x Safety
Strap (H6)
1 x Screw
(H7)
1 x Washer
(H8)
Phillips head
screwdriver
1 x Washer
(H8)
H6
H8
H7
H8
wall
Screw
Move the cabinet to the final position. Attach the safety strap to the wall.
Make sure it is firmly attached and make sure it is a snug fit.
Page 15
fantasticfurniture.com.au
We strongly advise that you use
the wall safety strap provided to
prevent the unit toppling
Seek advice from a qualified
trades person on how to
attach this safety strap to
your specific wall.
Screw and Wall Plug are not
provided. Please use
appropriate fixtures for
your wall.

Page 16
fantasticfurniture.com.au
Job Complete!
In the interest of our environment please dispose of all packaging thoughtfully.
