Festo Checkbox Compact CHB-C-C User manual

Manual
Checkbox Compact
Type CHB-C-C
Type CHB-C-P
Manual
533 412
en 0211a
[663 484]
Checkbox Compact

Festo Checkbox ® is a registered trademark of Festo AG&Co,
D-73726 Esslingen, Deutschland

Contents and general instructions
I
Festo P.BE-CB-COMP-EN en 0211a
Author G. Neumann-Rasaei..........................
Editor M. Holder...................................
Original de.......................................
Translation transline Deutschland.....................
Layout Festo AG & Co., Dept. KG-GD...................
Layout Festo AG & Co., Dept. KI-DT...................
Edition en 0211a..................................
Designation P.BE-CB-COMP-EN.......................
Order no. 533 412.................................
E(Festo AG & Co., D-73726 Esslingen, Federal Republic of
Germany, 2002)
Internet: http://www.festo.com
e-mail: [e-mail]
The copying, distribution and utilization of this document as
well as the communication of its contents to others without
expressed authorization is prohibited. Offenders will be held
liable for the payment of damages. All rights reserved, in par-
ticular the right to carry out patent, utility model or orna-
mental design registrations.

Contents and general instructions
II Festo P.BE-CB-COMP-EN en 0211a

Contents and general instructions
III
Festo P.BE-CB-COMP-EN en 0211a

Contents and general instructions
IV Festo P.BE-CB-COMP-EN en 0211a
Contents
Designated use VII........................................................
Operating requirements VIII.................................................
Target group VIII..........................................................
Service VIII...............................................................
Scope of delivery VIII.......................................................
Accessories VIII...........................................................
Important user instructions IX..............................................
Notes on the use of this manual XII...........................................
DocumentationontheCheckbox XII..........................................
Product-specific terms and abbreviations XIII...................................
1. System summary 1-1...............................................
1.1 The Festo Checkbox 1-3.............................................
1.2 Software packages for the Checkbox 1-4...............................
1.3 Scope of functions 1-5..............................................
1.4 Method of operation 1-6............................................
1.5 Buffer zone 1-9....................................................
2. Fitting and commissioning 2-1.......................................
2.1 Fitting the Checkbox 2-3.............................................
2.2 Connections 2-8...................................................
2.3 Electrical connection 2-9............................................
2.3.1 Selecting the power unit 2-11.........................................
2.3.2 Connecting the operating voltage 2-12..................................
2.3.3 Power supply for external components 2-13.............................
2.4 Commissioning 2-14.................................................
2.5 Fault diagnosis 2-19.................................................

Contents and general instructions
V
Festo P.BE-CB-COMP-EN en 0211a
3. The I/O module 3-1................................................
3.1 Interfaces 3-3.....................................................
3.2 ACTUATORS 3-5...................................................
3.3 BUFFER/FEEDER 3-7...............................................
3.4 DIAG 3-10.........................................................
4. I/O module extensions of the Checkbox PLC 4-1........................
4.1 Interfaces 4-3.....................................................
4.2 ENCODER 4-4.....................................................
4.3 PLC 4-6...........................................................
4.3.1 Start/stop mode 4-8................................................
4.3.2 Selecting the parts type 4-10..........................................
4.3.3 Counter function 4-11................................................
4.3.4 Actuators 4-13.....................................................
4.3.5 Buffer zone sensors/small parts conveyor 4-14...........................
4.3.6 Fault messages 4-17.................................................
4.3.7 Control panel lock 4-18..............................................
5. Teaching parts 5-1.................................................
5.1 Preparing the teach procedure 5-3....................................
5.2 The teach procedure 5-5............................................
5.2.1 Positioning sample parts 5-7.........................................
5.2.2 Observe the scatter of characteristics 5-8..............................
5.2.3 Scanning further orientations 5-9.....................................
6. Testing parts 6-1..................................................
6.1 The test procedure 6-3..............................................
6.2 Test mode 6-3.....................................................
6.3 Influence of the tolerance 6-6........................................
6.4 Assessing the test results 6-8........................................
6.4.1 Visual check 6-8...................................................
6.4.2 Checking the features 6-8...........................................
6.4.3 Checking the orientation 6-9.........................................

Contents and general instructions
VI Festo P.BE-CB-COMP-EN en 0211a
7. Maintenance 7-1..................................................
7.1 General information 7-3.............................................
7.2 Cleaning 7-4......................................................
A. Technical appendix A-1.............................................
A.1 Malfunctioning A-3.................................................
A.1.1 General cause of faults A-3..........................................
A.1.2 Fault messages and warnings A-4.....................................
A.2 Status displays on the control panel A-9................................
A.3 Examples for ascertaining the features A-12..............................
A.3.1 Bandwidth and tolerance A-12.........................................
A.3.2 Scatter of characteristics A-14.........................................
A.3.3 Test part deviation A-15..............................................
A.4 Connections A-17...................................................
A.5 Technical specifications A-22..........................................
A.6 Accessories A-25....................................................
B. Index B-1.........................................................

Contents and general instructions
VII
Festo P.BE-CB-COMP-EN en 0211a
Designated use
The Festo Checkbox has been designed for use under normal
operating conditions in enclosed work rooms in industrial
applications.
The Checkbox Compact described in this manual is intended
exclusively for use as follows:
For contactless checking of the position and quality of small
conveyed parts such as e.g. screws, springs, bolts.
Use the Festo Checkbox only as follows:
– in accordance with designated use
– in faultless technical condition.
– without any modifications by the user.
No guarantee claims can be accepted if the device is opened.
Laser radiation
The Checkbox Compact is a device of laser class 2 as per
EN 60825-1:1997 (class II as per CFR 21 §1040.10, USA).
SDo not open the device.
SDo not dismantle any parts (e.g. prism supports).
SDo not look directly into the laser beam.
Only in this way is the observance of laser class 2 guaran-
teed and you can avoid damage to the eyes and skin.
The specified limits for pressure, temperature, electrical con-
nections etc. must be observed.
Please observe the standards specified in the relevant
chapters and comply with technical regulations, as well as
with national and local regulations.

Contents and general instructions
VIII Festo P.BE-CB-COMP-EN en 0211a
Operating requirements
– The features of the conveyed part which determine the
orientation or quality must be recognizable and distin-
guishablefortheFestoCheckbox.
– It must be possible to integrate the Festo Checkbox in the
material flow.
Target group
This manual is intended exclusively for technicians trained in
control and automation technology, who have experience in
installing and commissioning electronic systems.
Service
Please consult your local Festo repair service if you have any
technical problems.
Scopeofdelivery
Checkbox Compact Module with control panel, I/O interface, laser light source
and camera
Documentation Description of the Checkbox Compact
Accessories For Checkbox type CHB-C-P: 24-pin connecting cable for the
PLC connection.
Accessories
A summary with accessories available can be found in
chapter A.6.

Contents and general instructions
IX
Festo P.BE-CB-COMP-EN en 0211a
Important user instructions
Danger categories
This manual contains instructions on the possible dangers
which can occur if the product is not used correctly. These
instructions are marked with a signal word (warning, caution,
etc), printed on a shaded background andmarked addition-
ally with a pictogram. A distinction is made between the fol-
lowing danger warnings:
Warning
This means that failure to observe this instruction may
result in serious personal injury or damage to property.
Caution
This means that failure to observe this instruction may
result in personal injury or damage to property.
Please note
This means that failure to observe this instruction may
result in damage to property.
The following pictograms also mark passages in the text
which warn about the incorrect handling of certain compo-
nents.
Electrostatically sensitive components These may be dam-
aged if they are not handled correctly.
Danger of injury caused by laser radiation
Do not look into the laser beam. Incorrect handling can
lead to damage to the eyes or skin.

Contents and general instructions
XFesto P.BE-CB-COMP-EN en 0211a
Marking special information
The following pictograms mark passages in the text contain-
ing special information.
Pictograms
Information
Recommendations, tips and references to other sources of
information.
Accessories
Information about suitable accessories.
Environment
Sections dealing with environmetal aspects.
Text markings
SThe bullet indicates activities which may be carried out in
any order.
1. Figures indicate activities which must be carried out in the
sequence shown from top to bottom.
– Hyphens indicate general activities.

Contents and general instructions
XI
Festo P.BE-CB-COMP-EN en 0211a
Conventions
– The names of operating, display and connecting elements
are represented in the text with upper-case letters e.g.
START, TEACH.
– Inputs and outputs of the plug connectors are specified
with the pin number as follows:
Input pin 1 I/1
Output pin 2 O/2
– Plug connectors are shown viewed towards the connec-
tions on the device. This view shows the (cable) connec-
tions to be wired.

Contents and general instructions
XII Festo P.BE-CB-COMP-EN en 0211a
Notesontheuseofthismanual
This manual refers to the standard designs of the Checkbox
Compact Classic (type CHB-C-C) and Compact PLC (type
CHB-C-P) with operating system version 3.x.
When the Checkbox is switched on, the version number of the
operating system will be displayed briefly (see chapter 2.4).
The options and parameters available depend on the operat-
ing system, the type of Checkbox connected and the pre-set-
tings made at the factory. Special customer-specific designs
may differ in technical data, parameter settings and function-
ality.
The pre-setting of the Checkbox can be modified if required
with the software packages CheckKon (function “Modify sys-
tem”) or CheckOpti (see chapter 1.2).
DocumentationontheCheckbox
InformationonusingtheCheckboxcanbefoundinthefol-
lowing manuals:
Manual Contents
DocumentationontheCheckbox:
– Identbox, Countbox, Sortbox:
type P.BE-Checkbox-..
– Checkbox Compact Classic, PLC
type P.BE-CB-COMP-..
Description of the function, commissioning,
operation and maintenance of the relevant
Checkbox type.
Manuals on software packages
– Checkbox Configurator:
type P.SW-CB-KON-..
– Checkbox Optimizer:
type P.SW-CB-OPTI-..
Operating the Checkbox Configurator
Operating the Checkbox Configurator

Contents and general instructions
XIII
Festo P.BE-CB-COMP-EN en 0211a
Product-specific terms and abbreviations
Term/abbreviation Meaning
Deviation The Checkbox assesses the feature of a test part which differs most
from the teach data. The smaller the value of the test part deviation,
themoreexactlythetestpartcorrespondstothesampleparts.
AUTO mode Operating mode of the Checkbox for automatic parts test (preset
when the Checkbox is started).
Checkbox A device of type CHB-C...(Checkbox Compact) in the design Classic or PLC
CBC Classic A device of type CHB-C-C (Checkbox Compact Classic) for identifying
conveyed parts.
Checkbox PLC AdeviceoftypeCHB-C-P(CheckboxCompactPLC)foridentifying
conveyed parts. Additional connections for a higher-order controller
and encoder.
C-value The C-value indicates the extent of the scatter of the features
ofthesampleparts.
Good part A test part on which all features lie within the tolerances.
Laser class Identifying the laser radiation as per DIN EN 60825-1:1997
Laser devices are classified according to increasing degree of danger
in the classes 1, 2, 3A, 3B and 4.
Class 2
The eye is not damaged after a brief random influence (up to 0.25 s).
Long-term influences may cause damage. Laser devices of class 2 may
be used without further protective measures, providing it can be as-
sured that for the application neither intentional long viewing (longer
than 0.25 s) nor repeated viewing of the laser beam or mirror reflected
laser beam is necessary.
Class 3a
Comparable danger as with laser devices of class 2. When used with
convex optic instruments (magnifying glasses, telephoto lenses, tele-
scopes), damage comparable to that caused by class 3B can however
occur (damage to eyes and skin).
Teach procedure During the teach procedure, sample parts on the conveyor belt are
shown to the Checkbox and the features are scanned. This is also
referred to as “Teaching parts.”

Contents and general instructions
XIV Festo P.BE-CB-COMP-EN en 0211a
Term/abbreviation Meaning
Features Characteristic features are ascertained from the contour data of the
sample and test parts. These are, e.g. length, height etc., as well as a
feature for each configuration tool (CheckOpti).
Scatter of characteristics The value range of a feature ascertained from several parts.
Sample parts Good parts selected for the teach procedure which show all features
necessary for identifying the parts type.
Orientation The parts to be checked by the Checkbox may lie in different align-
ments on the conveyor belt. During the teach procedure, you can
define the orientations by showing the different alignments.
Orientation 1 is the preferred orientation (nominal orientation).
(System) parameter Checkbox settings (in some cases settings can only be made with
configuration software)
Test d a t a Thetestdataarethedatausedforthetest.Thesecorrespondtothe
teach data plus the specified tolerances.
Te st p a r ts All parts shown during the test process.
Test p roc e dure During the test procedure, test parts on the conveyor belt are shown
to the Checkbox and classified according to their features with regard
to orientation and observance of tolerances. This is also referred to as
“Testing parts.”
Bad part A test part on which at least one feature lies outside the tolerances.
Teach data All features ascertained during teaching, in each case with min./max.
limits and average value.
TEACH mode Operating mode of the Checkbox in which the teach procedure is
carried out.
Parts type Conveyed part defined by the teach data of the sample parts.
Tole ranc e Factor in percent related to the average values and which has an effect
on the min./max. limits of all the features.

System summary
1-1Festo P.BE-CB-COMP-EN en 0211a
Chapter 1

1. System summary
1-2 Festo P.BE-CB-COMP-EN en 0211a
Contents
1. System summary 1-1...............................................
1.1 The Festo Checkbox 1-3.............................................
1.2 Software packages for the Checkbox 1-4...............................
1.3 Scope of functions 1-5..............................................
1.4 Method of operation 1-6............................................
1.5 Buffer zone 1-9....................................................

1. System summary
1-3
Festo P.BE-CB-COMP-EN en 0211a
1.1 The Festo Checkbox
The Festo Checkbox can be used for visual positioning (with-
out contact) and for the quality check of conveyed parts. Dif-
ferent variants of the Checkbox are available for this purpose,
depending on requirements. The Checkbox Compact is avail-
able in the designs Classic and PLC:
Checkbox Compact – device variants
Checkbox Classic
Compactdevice(withouttransportde-
vice).
Separate sorting out of good parts, in-
correctly orientated parts and bad parts
Checkbox PLC
Functions as with Checkbox Classic
plus:
– Extended I/O function
(PLC connection)
–Encoderinput
1)
– with CheckKon: Counting of good
parts with preselectable nominal
amount:
Identifying max. 4 parts types, 1 or 2
buffer zone sensors
1) Encoder input: Operating system version ...E must be used for evalua-
ting the encoder signals (see chapter 4.2 ).
Information on further Checkbox variants available can be
obtained from:
– a Festo technical advisor
– or in Internet under the adress http://www.festo.com

1. System summary
1-4 Festo P.BE-CB-COMP-EN en 0211a
1.2 Software packages for the Checkbox
Various software packages are available for user-friendly
commissioning, optimizing and monitoring of the products in
the Checkbox family. These software packages have been
developed specially for the products in the Checkbox family
and can be used with all the devices in the Checkbox family.
Software package Functions
CheckKon
Checkbox Configurator
– Display and evaluation of the last regis-
tered test part.
– Display and protocolling the parts
contouraswellasthefeaturesderived
from the contour.
– Display of the light intensity registered
by the camera.
– Display and print out of the system
configuration.
– Display and modification of the system
parameters.
– Loading a new operating system into
the Checkbox
CheckOpti
Checkbox Optimizer
– User-friendly learning of the sample
parts.
– Monitored checking of parts, display of
the registered features.
– Grading of the parts test with regard to
reliability (evaluation).
– Graphical representation of the test
sequence.
– Optimization of the parts test by man-
ual adaption of the min./max. values of
the teach data or by configuration tools.
– Support in project planning, administra-
tion and documentation.
The software package CheckKon, operating system updates
and current product information on the Checkbox Compact
can be found in Internet under the address www.festo.com
(Business Area Pneumatic, Checkbox).
