Friant MADISON User manual

User Guide and Assembly Instructions
MADISON
1
FRONT VIEW ADJUSTMENT KNOBS
The backrest tilt is
adjusted and locked
with the handhold.
Vertical
adjustment is
controlled with
the handhold.
Adjustable
armrests allow
each user to
customize for
maximum comfort.
Adjustable tension
knob for back tilt to
maximize comfort for
varying sized users.

2
Item Parts Qty.
A Backrest 1
B Armrest L/R 1 ea
C Mechanism 1
D Seat Cushion 1
E Gas Lift 1
F Base 1
G Caster 5
H Telescoping Cover 1
Hardware Headrest Parts/
Hardware Qty.
A Screw 5/16” x 1-1/4” 2
B Screw 5/16” x 1” 2
C Screw 5/16” x 3/4” 3
D Screw 5/16” x 7/8” 2
E Screw 5/16” x 1-1/8” 2
F Flat Washer 5
G Spring Washer 5
H Four-angle Washer 2
I L Shape Wrench 1
J T Shape Wrench 1
K Inverse Cup 2
L Big Cap 4
M Small Cap L/R 1 ea
Attention: Carefully check all parts according to the instructions before assembling. Please assemble carefully to
avoid scratching surfaces, especially powder coated surfaces.
Parts and Hardware

3
1. Attach the mechanism [C] to the seat cushion [D]
to fasten with screws [A & B]. Screw [A] is for the
front of the seat cushion and screw [B] is for the
back of the seat cushion.
2. Attach caster [G] to the base [F]. Insert the gas
lift [E] to the center hole of the 5 star base [F] and
place telescoping cover [H] to the gas lift [E].
3. First add the gas lift [E] into the hole of the
mechanism [C] that assembled in the seat cushion
[D]. Then assemble the backrest [A] into the steel
beneath the mechanism [C]. Insert screws.
Note: Do not tighten the screws until after assembling
the arm rest.
Before fastening the screws, add the spring
washer [G] and common washer [F] into the
screw [C]. Make sure the steel shell of the backrest
[A] and the steel mechanism [C] are at the same
level.
4. Attach the armrest [B] to the chair, using
instructions on the next page.
See next page for Armrest Assembly Guide.
Chair Assembly Instructions

4
1. Insert the armrest [B] into the circular of Z1 and Z2.
Insert the inverse cup [K] into the circular hole of Z1
and Z2.
2. Insert the square washer [H] into the square bulge of
Z2, and fasten the screw [E] into the column.
Note: Only tighten the screws halfway.
3. Before fastening the screw [D], add the spring washer
[G] and the at washer [F] into the screw [D]. Then
fasten the screw [D] and tighten.
4. Put the big cap [I] and small cap [M] into the
appropriate round holes separately in the armrest [B].
Note: The small cap [M] differs for left and right. See
drawing for assembly.
5. Tighten the 4 screws that connect the backrest [A]
and mechanism [C].
6. Ensure that all screws are fully tightened before using
the chair.
Armrest Assembly Instructions

5
Product Dimensions
ALL
WOR KSTYLES
WELCOME
Aug 2019
