Friant MIDZONE User manual

1
Backrest can be pulled up and down.
Raise the backrest to the top position
when you would like to adjust it to the
intial position.
The Mechanism with Multi-Functions
Pneumatic Seat Height - Control Seat
height
Seat Angle Control - Seat angle can be
adjusted independently
Back Angle Control & Height Adjustments
- Adjust back and lock at desired positions
and heights
Control of Seat Forward Tilt - Lock
and release of forward tilt for intensive
keyboard activities
Adjustable Tilt/Tension Control - Tension
of seat & back tilt can be increased or
decreased as desired
Press this button to
move the armrest up
and down
The lock button can adjust
the armrest width.
Seat Slider can slide seat
back and forth by up to 2”
and lock in 4 poistions.
FRONT VIEW
User Guide and Assembly Instructions
MIDZONE

2
Item Parts Qty.
J
Seat Mechanism Bolt
1/4 x 7/8mm
4
K
Flat Pad
19 x 8.3 x 2mm
6
L Adjusted Width Button 2
M
Inner Hexagon Screws
5/16 x 3/4mm
3
N Flat Pad 16 x 8.3 x 2mm 3
O M2 Wrench 1
P M5 Wrench 1
Item Parts Qty.
A Back Assembly 1
B Seat Assembly 1
C Seat Mechanism 1
D Armrest L/R 1
E Gas Lift 1
F Base 1
G Caster 5
HLever 1
I
Bolt
4 x 8.5mm
1
Attention: Carefully check all parts according to the instructions before assembling. Please assemble carefully to avoid scratching surfaces,
especially powder coated surfaces.
Parts and Hardware

3
G
F
E
1. Assemble the Base, Casters, & Gas Lift
Insert ve casters [G] into the base [F].
Push hard until you feel or hear the casters
snap into place. With the base upright and
the casters on the oor, insert the gas lift
[E] into the base.
2. Assemble the Seat Mechanism & Seat
Attach lever [H] to the seat mechanism
[C] using bolt [I] and secure with wrench
[O]. Attach the assembled seat mechanism
to the seat using at pads [K] and seat
mechanism bolt [J] using wrench [P].
3. Assemble the Seat Assembly & Back
Keep the seat assembly [C+H+B] on a
table rst, then insert the back assembly
[A] between connected seat assembly and
seat plane. Turn the back assembly into
the center of three holes. Attach using a
wrench [P]. Fully tighten the inner hexagon
socket screws [M] and at pad [N].
5. Assemble the Seat, Gas Lift & Base
Insert the seat assembly [C+H+B] with the
armrests into the gas lift E] with base [F].
O
P
B
J 4pcs
K 2pcs
K 4pcs
I
H
C
C+H C+H+B
C+H+B
P
A
M 3pcs
N 3pcs
D right D left
C+H+B
L
L
C+H+B
E+F
4. Assemble the Armrest & Seat
Attach the armrests [D] to the seat
assembly [C+H+B] using the adjusted
width button [L] to fasten the armrests
over the seat assembly.

4
Product Dimensions
