Friant My-hite fsqahbt-24-2 User manual

Please Read Instructions Before Use

ASSEMBLY INSTRUCTIONS

MY-HITE ADJUSTABLE TABLE

STRAIGHT 2 STAGE T LEG BASE

Model Number : FSQAHBT-24-2

ALL

WORKSTYLES

WELCOME

1.Read instructions carefully.

Check that no parts are

missing.

Single Sided

Wrench

Socket Head

Wrench Electric Drill

Friant & Associates, LLC does not assume any responsibility for product that is altered in any

way.

2.Carefully identify each

component, especially those

that are similar. The most

common mistake is mixing up

the order and placement of

parts.

WARNING: Failure to follow the assembly instructions in this manual can result in product

damage, or personal injury.

IMPORTANT:When placing table in nal location, be sure there is ample room for adjustment

around ALL sides, and at the highest (45.1”) and lowest (27”) points the table can reach. Make

sure table will not come into contact with any xed objects (xed tops, storage, shelving, etc.)

while adjusting.

Thank you for choosing Friant. We appreciate the trust and condence

you have placed in us and are committed to providing you the best

possible product.

1. As with all power-operated products, please follow instructions closely and handle with

care.

2. When moving My-Hite tables, please lift the tables, do not drag or tilt the table on one leg

as misalignment may occur.

3. Check that the load on the table does not exceed limits (220lbs maximum on straight,

330lbs maximum on corner).

4. The input voltage should be within 108-132V.

5. Use the glides to properly level the table before use.Table should be level and aligned at all

times.

6. Before rst use, perform reset operation.

7. If, after trouble shooting the problem persists, contact Customer Service for further

assistance.

Tools Needed

Introduction

Friant offers a comprehensive line of ofce furniture for every space and requirement, now

including My-Hite, a height adjustable table that allows for standing or sitting while working.

User Notes

Parts List Installation Steps

Step 1

Place worksurface nished side down on a blanket.

Step 2

Insert Acolumn leg into Dcrossbeam assembly and slide back to lock into place. Repeat on

other side.

Step 3

Insert MPressure Retainer Lever into Dcrossbeam and insert Lpin into MPressure Retainer

Lever, then rotate the lever to clamp Aleg. Repeat on other side.

Column Leg

Crossbeam

Worksurface

Pressure Retainer Lever

PART# IMAGE NAME PIECES

A Column Leg 2

B Feet 2

C Socket Button Head Bolt M6x35 8

D Crossbeam 2

E Wood Screw M5x20 12

F Metal Screw M10x25 8

G Wood Screw M5x15 2

H Control Box 1

I Connecting Beam 2

J Wire Clips 10

K Wood Screw M3.5x16 10

L Pin 2

M Pressure Retainer Lever 2

N Display 1

O Wood Screw M3.5x15 2

P Rubber Washer 12

Q Hex Wrench 1

R Control Wires 2

SPowercord 1

Step 4

Insert IConnecting beams into Dcrossbeams, then use (8) Fmetal screws, M10*25mm to

secure crossbeams as shown. Recommended: A: 0-32 in

Step 5

Use E(12) wood screws, 5*20 mm to secure crossbeams to worksurface as shown

Step 9

Use Kwood screws, M3.5*16 and Jwire clips to secure Rcontrol wires below the worksurface.

Step 6

Attach Bfeet to Acolumn leg with C(8) socket button head bolts, M6*35. Tighten bolts

securely.

Crossbeam

Connecting beam

Metal Screw

0 - 32 in

Wood Screw

M5*15

Wood Screw

M3.5*16

Column Leg

Feet

Control Box

Display

Control Wires

Wood screw

with washer

Wire Clips

Socket Button

Head Bolt

Wood Screw

Step 7

Secure Hcontrol box in the desired location with G(2) wood screws, M15*15.

Step 8

Secure the Ndisplay in the desired location with O(2) wood screws, M3.5*15 with washers.

Schematic view of My-Hite wiring Step 10

Turn table right side up, adjust the glides as necessary, and plug the power cord into a 110v

outlet.

Make sure the length of the plug-in cord is appropriate to both reach the outlet, AND for

the distance the table will travel up and down.

Range: 27” at lowest to 45.1” highest.

Control Wires

Power Cord

Display

First Time Use:

Step 11:

It is important to perform the reset procedure stated below

before using your My-Hite table for the rst time.

(a) The reset procedure must be completed after table is installed or parts replaced.

(b) If reset process is interrupted, the system will stop running and will need to be reset to

operate again.

1) Reset Operation

2) Set Memory Position

3) Removing Presets

4) Set Maximum Height

5) Set Minimum Height

7) Display in Inches or Centimeters

6) Clear Minimum/Maximum Height

Notes:

1. Press and hold ˄ & ˅ simultaneously for more than 3 seconds till legs begin to move

down at half speed of normal operation.

2. Keep pressing buttons till legs move down to the lowest position and rebound 2-5 mm,

then stop.

3. Release together. Reset is completed

1. Adjust table to desired height. Then press and hold ˄& ˅ buttons.Display will ash. Then

release.

2. Press S, then press button 1 or 2 or 3 or 4 within next 3 seconds. Display position 1,2,3,4 is

saved.

1. Press and hold button S more than 10 seconds. Display will ash “———”

2. Release button S. Press button 1 within 3 seconds. The screen displays “H-0” or “H-1”

indicating preset is off or on.

3. Press ˄ or ˅ to change the current function of turn on or off.

“H-0” - express function is off. “H-1” - express function is on.

4. Touch and hold button S for 2 seconds. Preset is on or off.

1. Press and hold S.Without releasing button S, press and hold 2 for 3 seconds.

2. Press and hold S, then press and hold 3 for about 3 seconds. Release. Letter “ ¯C¯” flashes

on the screen. This means the position is locked at the maximum height.

Press and hold S. Without releasing button S, press and hold ˅ for 3 seconds.Release both

buttons. The height information will toggle between inches and centimeters.

1. Press and hold ˄then release. Adjust table to desired maximum height.

2. Press and hold S, then press and hold 3 for about 3 seconds. Release. Letter “ ¯L¯” flashes

on the screen.This means the position is locked at the maximum height.

1. Press and hold ˅ then release . Adjust table to desired minimum height.

2. Press and hold S, then press and hold 3 for about 3 seconds. Release both buttons. Letter

“ ¯C¯” flashes on the screen. This means the table is locked at the minimum height.

• Follow assembly instructions closely

• Do not overload the tables (220 lbs maximum straight, 330 lbs maximum corner)

• The input voltage should be within 108-132V

• Use the glides to properly level the table before use

• When moving the table, do not tilt the table on one leg or misalignment may occur

• Before rst use, perform reset operation

• If after trouble shooting the problem persists, contact Customer Service for further

assistance

GENERAL TIPS

ALL

WORKSTYLES

WELCOME

Troubleshooting 2 stage My-Hite

Error Code Explanation Cause Solution

E01 Connection Issue The leg is disconnected from the control box.

Check the cable connections between leg and computer. Reset

display.
