GEA VARIVENT Vacuum Valve V User manual

Operating Instructions
VARIVENT®
Vacuum Valve V
Edition 2016-06-30
English

2
Operating Instructions · VARIVENT® Vacuum Valve V
Edition 2016-06-30
Product Vacuum Valve V
Document Operating Instructions
Edition 2016-06-30
English
Manufacturer GEA Tuchenhagen GmbH
Am Industriepark 2-10
D-21514 Büchen
Phone:[phone]
Fax: [phone]
Mail: sales.geatuchenhage[email protected]
Web: http://www.tuchenhagen.com
This document is protected by copyright. All rights reserved. The document may not, in
whole or in part, be copied, reproduced, translated or reduced to an electronic medium
of machine-readable form without the express permission of GEA Tuchenhagen GmbH.
Wordmarks The designation VARIVENT®is a protected trademark of GEA Tuchenhagen GmbH.

3
Table of Contents
Notes for the Reader ...................................................................................................................................... 5
Binding Character of These Operating Instructions ......................................................................................... 5
Notes on the Illustrations.................................................................................................................................. 5
Symbols and Highlighting................................................................................................................................. 6
Abbreviations and Terms ................................................................................................................................. 7
Safety............................................................................................................................................................... 9
Safety Note....................................................................................................................................................... 9
Operator's Duties.............................................................................................................................................. 9
Qualification of Staff ....................................................................................................................................... 10
Supplementary Regulations ........................................................................................................................... 11
Instructions for the Safe Operation................................................................................................................. 12
•General Principles ...................................................................................................................................... 12
•Installation .................................................................................................................................................. 12
•Commissioning/Setup Mode ...................................................................................................................... 13
•Setting into Operation................................................................................................................................. 13
•Operation.................................................................................................................................................... 13
•Shutting Down ............................................................................................................................................ 14
•Maintenance and Repair ............................................................................................................................ 14
•Disassembly ............................................................................................................................................... 15
•Environmental Protection ........................................................................................................................... 15
•Electrical Equipment................................................................................................................................... 15
Signage .......................................................................................................................................................... 16
Residual Risk ................................................................................................................................................. 16
•Hazard Areas ............................................................................................................................................. 16
•Residual Dangers....................................................................................................................................... 17
•Declaration of Incorporation ....................................................................................................................... 18
Transport and Storage................................................................................................................................. 19
Scope of Supply ............................................................................................................................................. 19
Transport ........................................................................................................................................................ 19
Storage........................................................................................................................................................... 19
Intended Purpose ......................................................................................................................................... 20
Designated Use.............................................................................................................................................. 20
Requirements for the Operation ..................................................................................................................... 20
Improper Operating Conditions ...................................................................................................................... 20
Conversion Work............................................................................................................................................ 21
Design ........................................................................................................................................................... 22
Installation and Commissioning ................................................................................................................. 23
Notes on Installation....................................................................................................................................... 23
Valve with Detachable Pipe Connection Elements ........................................................................................ 23
Valve with Welding Ends................................................................................................................................ 24
Pneumatic Connections ................................................................................................................................. 24
Electrical Connections.................................................................................................................................... 25
Commissioning............................................................................................................................................... 26

4
Operating Instructions · VARIVENT® Vacuum Valve V
Edition 2016-06-30
Malfunctions ..................................................................................................................................................27
Maintenance ..................................................................................................................................................28
Inspections ......................................................................................................................................................28
•Product Contact Seals ................................................................................................................................28
•Pneumatic Connections ..............................................................................................................................28
•Electrical Connections ................................................................................................................................29
Maintenance Intervals.....................................................................................................................................29
Removing the Valve ........................................................................................................................................29
Disassembling the Valve.................................................................................................................................30
•Disconnecting the Valve from the Housing .................................................................................................30
•Type V... Without Feedback........................................................................................................................31
•Type V...E With Feedback ..........................................................................................................................31
•Type V...A With Lifting Actuator ..................................................................................................................32
•Type V...R With Lifting Actuator and Feedback ..........................................................................................32
Maintenance....................................................................................................................................................33
•Cleaning the Valve......................................................................................................................................33
•Replacing Wearing Parts ............................................................................................................................34
•Lubricating Seals and Threads ...................................................................................................................35
Assembling the Valve......................................................................................................................................35
Torques for the Cast Clamps and Clamp joints ..............................................................................................35
Setting the Proximity Switches........................................................................................................................36
•Vacuum Valve with Lifting Actuator Type V...R ..........................................................................................36
•Vacuum Valve with Lifting Actuator Type V...E...........................................................................................37
Disposal ..........................................................................................................................................................38
Technical Data...............................................................................................................................................39
Type Plate .......................................................................................................................................................39
Technical Data ................................................................................................................................................39
Resistance of Sealing Materials......................................................................................................................41
Pipe Ends........................................................................................................................................................42
Tools ...............................................................................................................................................................42
Lubricants........................................................................................................................................................43
Weights ...........................................................................................................................................................43
Spare Parts Lists...........................................................................................................................................44
Performance Curves .......................................................................................................................................47
Dimension Sheet ...........................................................................................................................................48

5
Notes for the Reader
Notes on the Illustrations
Notes for the Reader
The present Operating Instructions are part of the user information for the valve. The
Operating Instructions contain all the information you need to transport, install, commis-
sion, operate and carry out maintenance for the valve.
Binding Character of These Operating Instructions
These Operating Instructions contain the manufacturer's instructions to the owner of the
valve and to all persons who work on or use the valve regarding the procedures to
follow.
Carefully read these Operating Instructions before starting any work on or using the
valve. Your personal safety and the safety of the valve can only be ensured if you act as
described in the Operating Instructions.
Store the Operating Instructions in such a way that they are accessible to the owner and
the operating staff during the entire life cycle of the valve. When the location is changed
or the valve is sold make sure you also provide the Operating Instructions.
Notes on the Illustrations
The illustrations in these Operating Instructions show the valve in a simplified form. The
actual design of the valve can differ from the illustration. For detailed views and dimen-
sions of the valve please refer to the design documents.

Notes for the Reader
Symbols and Highlighting
6
Operating Instructions · VARIVENT® Vacuum Valve V
Edition 2016-06-30
Symbols and Highlighting
In these Operating Instructions, important information is highlighted by symbols or
special formatting. The following examples illustrate the most important types of high-
lighting.
DANGER
Warning: Fatal injuries.
Failure to observe the warning can cause serious damage to health, or even death.
The arrow identifies a precautionary measure you have to take to avoid the hazard.
EXPLOSION HAZARD
Warning: Explosions.
Failure to observe the warning may result in a severe explosion.
The arrow identifies a precautionary measure you have to take to avoid the hazard.
WARNING
Warning: Serious Injuries.
Failure to observe the warning note can result in serious damage to health.
The arrow identifies a precautionary measure you have to take to avoid the hazard.
CAUTION
Warning: Injuries.
Failure to observe the warning note can result in minor or moderate damage to health.
The arrow identifies a precautionary measure you have to take to avoid the hazard.

7
Notes for the Reader
Abbreviations and Terms
IMPORTANT NOTE
Warning: Damage to Property.
Non-observance of the warning note can cause serious damage to the valve or the
vicinity of the valve.
The arrow identifies a precautionary measure you have to take to avoid the hazard.
Carry out the following steps: = Start of a set of instructions.
1. First step in a sequence of operations.
2. Second step in a sequence of operations.
Result of the previous operation.
The operation is complete, the goal has been achieved.
NOTE
Further useful information.
Abbreviations and Terms
Abbreviation Explanation
BS British Standard
bar Unit of measurement of pressure [bar]
All pressure ratings [bar/psi] stand for over pressure [barg/psig]
if this is not explicitly described differently.
approx. approximately
°C Unit of measurement of temperature [degree Celsius]
dm3nUnit of measurement of volume [cubic decimetre]
Volume (litre) at standard temperature and pressure
DN DIN nominal width
DIN German standard issued by DIN (Deutsches Institut für Normung e.V,
German Institute for Standardization)
EN European Standard
EPDM Material designation
Short designation according to DIN/ISO 1629:
Ethylene Propylene Diene Rubber
°F Unit of measurement of temperature [degree Fahrenheit]
FKM Material designation, short designation according to DIN/ISO 1629:
Fluorine rubber
h Unit of measurement of time [hour}

Notes for the Reader
Abbreviations and Terms
8
Operating Instructions · VARIVENT® Vacuum Valve V
Edition 2016-06-30
HNBR Material designation
Short designation according to DIN/ISO 1629:
Hydrogenated Acrylonitrile Butadiene Rubber
IP Protection class
ISO International standard issued by the International Organization for Standardi-
zation
kg Unit of measurement of weight [kilogram]
kN Unit of measurement of force [kilonewton]
L Unit of measurement of volume [litre]
max. maximum
mm Unit of measurement of length [millimetre]
m Unit of measurement of length [micrometre]
Mmetric
Nm Unit of measurement of work [newton metre]
UNIT OF TORQUE 1 Nm = 0.737 lbft
Pound-Force (lb) + Feet (ft)
PA Polyamide
PE-LD Low-density polyethylene
SET-UP Self-learning installation
During commissioning and maintenance, the SET-UP procedure carries out
all the necessary settings for the generation of messages.
a/f Indicates the size of spanners
width across flats
T.VIS Tuchenhagen Valve Information System
V AC Volt alternating current
V DC Volt direct current
W Unit of measurement of power [Watt]
TIG Welding method
Tungsten inert gas welding
Inch OD Pipe dimension acc. to British standard
(BS), Outside Diameter
Inch IPS US pipe dimension
Iron Pipe Size
Abbreviation Explanation

9
Safety
Operator's Duties
Safety
Safety Note
The valve is operationally reliable. It was built according to state-of-the art standards.
Nevertheless, the valve can pose dangers, especially if
•the valve is not used in accordance with its intended use,
•the valve is not used correctly,
•the valve is operated under impermissible operating conditions.
Operator's Duties
In your capacity as operator of the facility you bear a particular responsibility for the
proper and safe handling of the valve in your facility. Only use the valve when it is in
perfect condition to prevent danger to persons and property.
These Operating Instructions contain the information you and your staff need for the
safe and reliable operation during the entire service life of the valve. Be sure to read
these Operating Instructions carefully and ensure that the measures described here are
observed.
The operator's duty of care includes planning the necessary safety measures and moni-
toring that these measures are observed. The following principles apply:
•Only allow qualified staff to work on the valve.
•The operator must authorize the staff to carry out the relevant tasks.
•Working areas and the entire environment of the valve must be neat and clean.
•The staff must wear suitable work clothing and personal protective equipment. As
the operator of the facility make sure that work clothing and personal protective
equipment are used.
•Instruct the staff with regard to any properties of the product which might pose a
health risk and the preventative measures to be taken.
•Have a qualified first-aider on call during the operation, who can initiate the neces-
sary first-aid measures in case of an emergency.
•Clearly define processes, lines of authority and responsibilities associated with the
valve. Everybody must know what to do in case of an emergency. Instruct the staff
in this respect at regular intervals.
•The signs relating to the valve must always be complete and legible. Check, clean
and replace the signs as necessary at regular intervals.
NOTE
Carry out regular checks. This way you can ensure that these measures are actually
observed.

Safety
Qualification of Staff
10
Operating Instructions · VARIVENT® Vacuum Valve V
Edition 2016-06-30
Qualification of Staff
This section contains information about the qualifications that staff working on the valve
must have.
Operating and maintenance staff must
•have the necessary qualification to carry out their tasks,
•be instructed with regard to possible dangers,
•know and observe the safety instructions given in the documentation.
Only allow qualified electricians to carry out work on the electrical equipment or have a
qualified electrician supervise the work.
Only allow specially trained staff to carry out any work on explosion-protected equip-
ment. When working on explosion-protected equipment observe the standards DIN EN
60079-14 for gases and DIN EN 50281-1-2 for dusts.
The following minimum qualifications are required:
•Vocational training as a specialist who can work on the valve independently.
•Sufficient instruction to work on the valve under the supervision and direction of a
qualified specialist.
Each member of staff must meet the following requirements to be allowed to work on the
valve:
•Personal qualification for the relevant task.
•Sufficient professional qualification for the relevant task.
•Instructed with regard to the function of the valve.
•Instructed with regard to the operating sequences of the valve.
•Familiar with the safety devices and their function.
•Familiar with these Operating Instructions, especially with the safety instructions and
the information which is relevant for the task on hand.
•Familiar with the basic regulations with regard to occupational health and safety and
accident prevention.
For work to be carried out on the valve the following user groups are distinguished:
User groups
Staff Qualifications
Operating staff Adequate instruction and sound knowledge in the following
areas:
•Function of the valve
•Valve operating sequences
•What to do in case of an emergency
•Lines of authority and responsibilities with respect to the
task.

11
Safety
Supplementary Regulations
Supplementary Regulations
In addition to the instructions in this documentation the following also has to be
observed:
•pertinent accident prevention regulations,
•generally accepted safety rules,
•national regulations applicable in the country of use,
•work and safety instructions applicable in the facility,
•installation and operating regulations for use in potentially explosive areas.
Maintenance staff Adequate instruction as well as sound knowledge of the
design and function of the valve.
Sound knowledge in the following areas:
•Mechanical equipment
•Electrical equipment
•Pneumatic system
Authorization with regard to safety engineering standards to
carry out the following tasks:
•Setting devices into operation
•Earthing of devices
•Marking of devices
The relevant certificates of qualification must be submitted
before work can be carried out on ATEX certified machines.
User groups (Cont.)
Staff Qualifications

Safety
Instructions for the Safe Operation
12
Operating Instructions · VARIVENT® Vacuum Valve V
Edition 2016-06-30
Instructions for the Safe Operation
Dangerous situations during the operation can be avoided by safety-conscious and
proactive behaviour of the staff.
General Principles
To ensure the safe operation of the valve the following principles apply:
•The Operating InstructionsOperating Instructions must be kept ready to hand at the
valve's place of use. They must be complete and in clearly legible form.
•Only use the valve for its intended use.
•The valve must be functional and in good working order. Check the condition of the
valve before starting work and at regular intervals.
•Wear tight-fitting work clothing for all work on the valve.
•Ensure that nobody can get hurt on the parts of the valve.
•Immediately report any faults or noticeable changes on the valve to the person
responsible.
•Observe the accident prevention regulations and all local regulations.
Installation
For installation, the following principles apply:
•Only properly qualified staff is allowed to install, assemble and set the valve into
operation.
•Ensure that adequate working and traffic areas are available at the place of installa-
tion.
•Observe the maximum load-bearing capacity of the installation surface.
•Observe the transport instructions and markings on the part(s) to be transported.
•Remove any nails protruding from transport crates immediately after opening the
crate.
•Under no circumstances should anyone stand under a suspended load.
•During assembly, the valve safety devices might not be working effectively.
•Reliably secure machine parts which have already been connected against inadvert-
ently being switched on.

13
Safety
Instructions for the Safe Operation
Commissioning/Setup Mode
For commissioning, the following principles apply:
•Take protective measures against dangerous contact voltages in accordance with
pertinent regulations.
•The valve must be completely assembled and correctly adjusted. All screw connec-
tions must be securely tightened. All electrical cables must be installed correctly.
•Reliably secure machine parts which have already been connected against inadvert-
ently being switched on.
•Relubricate all lubricating points.
•Make sure lubricants are used properly.
•After conversion of the valve, residual risks must be reassessed.
Setting into Operation
For setting into operation, the following principles apply:
•Only allow properly qualified staff to set the valve into operation.
•Establish all connections correctly.
•The safety devices for the valve must be complete, fully functional and in perfect
condition. Check the function before starting any work.
•When the valve is switched on, the danger zones must be free.
•Remove any liquids that have escaped without leaving residues.
Operation
For operation, the following principles apply.
•Monitor the valve during the operation.
•Safety devices must not be changed, removed or taken out of service. Check all
safety devices at regular intervals.
•All guards and hoods must be fitted as intended.
•The place of installation of the valve must be adequately ventilated at all times.
•Structural alterations of the valve are not permitted. Immediately report any changes
on the valve to the person responsible.
•Always keep danger zones clear. Do not leave any objects in the danger zone. Only
allow persons to enter the danger zone when the machine is de-energized.
•Regularly check that all emergency stop devices are working correctly.

Safety
Instructions for the Safe Operation
14
Operating Instructions · VARIVENT® Vacuum Valve V
Edition 2016-06-30
Shutting Down
For shutting down, the following principles apply:
•Switch off the compressed air.
•Switch off the valve via the main switch.
•Padlock the main switch (if fitted) in the off position to prevent it from being switched
back on. The key to the padlock must be deposited with the person responsible until
the machine is restarted.
•For longer periods of standstill, observe the storage conditions, see Storage
(Page 19).
Maintenance and Repair
Before starting any maintenance and repair work on the electrical devices of the valve,
carry out the following steps in accordance with the "5 safety rules":
•Isolate from the power supply
•Take appropriate measures to prevent switch on
•Test absence of voltage
•Earthing and short-circuiting
•Cover or safeguard any adjacent live parts.
For maintenance and repair, the following principles apply:
•Observe the intervals specified in the maintenance schedule.
•Only allow qualified staff to carry out maintenance or repair work on the valve.
•Before starting any maintenance or repair work, the valve must be switched off and
secured against being switched back on. Work may only be started once any
residual energy has been discharged.
•Block access for unauthorized persons. Put up notice signs which draw attention to
the maintenance or repair work going on.
•Do not climb on the valve. Use suitable access aids and working platforms.
•Wear suitable protective clothing.
•Only use suitable and undamaged tools to carry out maintenance work.
•When replacing parts only use approved, fully functional load lifting devices and
lifting accessories which are suitable for the intended purpose.
•Before setting the valve back into operation refit all safety devices as originally
provided in the factory. Then check that all safety devices are working correctly.
•Make sure lubricants are used properly.
•Check pipes are firmly secured, also check for leaks and damage.
•Check that all emergency stop devices are working correctly.

15
Safety
Instructions for the Safe Operation
Disassembly
For disassembly, the following principles apply:
•Only allow qualified staff to disassemble the valve.
•Before starting disassembly, the valve must be switched off and secured against
being switched back on. Work may only be started once any residual energy has
been discharged.
•Disconnect all power and utility lines.
•Markings, e.g. on lines, must not be removed.
•Do not climb on the valve. Use suitable access aids and working platforms.
•Mark the lines (if unmarked) prior to disassembly to ensure they are not confused
when re-assembling.
•Protect open line ends with blind plugs against ingress of dirt.
•Pack sensitive parts separately.
•For longer periods of standstill, observe the storage conditions, see Storage
(Page 19).
Environmental Protection
Harm to the environment can be avoided by safety-conscious and proactive behaviour
of the staff.
For environmental protection the following principles apply:
•Substances harmful to the environment must not be discharged into the ground or
the sewage system.
•Always observe the pertinent regulations relating to waste avoidance, disposal and
utilization.
•Substances harmful to the environment must be collected and stored in suitable
containers. Clearly mark the containers.
•Dispose of lubricants as hazardous waste.
Electrical Equipment
For all work on electrical equipment, the following principles apply:
•Access to electrical equipment should only be allowed to qualified electricians.
Always keep unattended switch cabinets locked.
•Modifications of the control system can affect the safe and reliable operation. Modifi-
cations are only permitted with the express permission of the manufacturer.
•After completion of all work, check that the protective devices are fully functional.

Safety
Residual Risk
16
Operating Instructions · VARIVENT® Vacuum Valve V
Edition 2016-06-30
Signage
Dangerous points on the valve are indicated by warning signs, prohibition signs and
mandatory signs.
The signs and notes on the valve must always be legible. Any illegible signs must be
replaced immediately.
Residual Risk
Hazard Areas
Please observe the following notes:
•In the event of malfunctions, shut down the valve (disconnect from the power and air
supply) and secure it against being used.
•Before starting any service, maintenance or repair work, disconnect the valve from
the power supply and secure it against inadvertently being switched back on again.
•Only allow a qualified electrician to carry out any work on the electrical power
supply.
•Check the electrical equipment of the valve at regular intervals. Immediately remedy
loose connections and molten cables.
•If work on live parts cannot be avoided, call in a second person, who can operate
the main switch in case of an emergency.
•The housing sockets have very sharp edges. When transporting and assembling the
valve be sure to wear suitable protective gloves.
•During cleaning via lifting function, cleaning agents can spray out of the collecting
pan for the vacuum valve as a result of excess pressure in the container to be
cleaned, sometimes in considerable quantities. Only use the lifting function when the
container is unpressurized and the collecting pan for the vacuum valve is empty.
Signs on the valve
Sign Meaning
General hazard warning
Warning Crushing
Explosive atmosphere hazard warning

17
Safety
Residual Risk
Residual Dangers
Dangerous situations can be avoided by safety-conscious and proactive behaviour of
the staff and by wearing personal protective equipment.
Residual dangers on the valve and measures
Danger Cause Measure
Danger to life Inadvertent switch-on of the valve Effectively disconnect all components, effectively prevent
switch-on.
Electric power Observe the following safety rules:
1Isolate from the power supply.
2Take appropriate measures to prevent switch on.
3Test absence of voltage.
4Earthing and short-circuiting.
5Cover or safeguard any adjacent live parts.
Danger of injury Danger presented by moving or
sharp-edged parts The operator must exercise caution and prudence.
For all work:
•Wear suitable work clothing.
•Never operate the machine if the cover panels are not
correctly fitted.
•Never open the cover panels during the operation.
•Never reach into openings.
As a precautionary measure, wear personal protective
equipment in the vicinity of the valve:
•Protective gloves
•Safety shoes
Cleaning agents can spray out
during cleaning by lifting as a
result of excess pressure in the
container to be cleaned.
If the container to be cleaned is under excess pressure, the
pressure is released into the atmosphere during lifting. If
this happens during cleaning, when cleaning solution is
continuously sprayed into the valve housing, the air flowing
out carries the cleaning solution along. This liquid can spray
out of the collecting pan for the vacuum pan. Depending on
the level of the excess pressure, a considerable amount of
cleaning solution can emerge. These effects are physical
and cannot be avoided.
Observe the following points:
•Use the lifting function only when the container is not
under pressure.
•Lift the pressure relief valve disk before lifting the
vacuum valve disk, in order to reduce spraying if a
residual overpressure exists.
•Use the lifting function only when the collecting pan for
the vacuum valve is empty.
If this is not possible due to process-related reasons, the
following step could reduce the amount of cleaning fluid
spraying out. Validation must be carried for each individual
application to determine whether the remaining amount of
cleaning liquid is sufficient to clean the valve seat.
•Stop the supply pump before lifting the valve disks.
Environmental
damage Operating materials with proper- ties which are harmful to the envi-
ronment
For all work:
•Collect lubricants in suitable containers.
•Dispose of lubricants in accordance with the pertinent
regulations.

Safety
Residual Risk
18
Operating Instructions · VARIVENT® Vacuum Valve V
Edition 2016-06-30
Declaration of Incorporation
Declaration of Incorporation
in accordance with the EC Machinery Directive 2006/42/EC
We herewith declare that this consignment contains the subsequently identified – but
incomplete – machine and that putting into service is not permitted until it has been estab-
lished that the machinery into which this machine is to be incorporated is in conformity with
the provisions of the EC Machinery Directive.
We declare that the incomplete machine identified here complies with the "Essential Health
and Safety Requirements" defined in Annex I, section 1 and section 2.1. The technical
documentation is compiled in accordance with Annex VII, part B. In response to a
reasoned request the relevant information will be transmitted to the appropriate national
authorities.
This declaration will become invalid if any alterations are made to the machine which have
not been agreed with us.
Büchen, 06/02/2009
Franz Bürmann i.V. Peter Fahrenbach
Managing Director Head of Development and Design
Designation of the machine: Vacuum Valve V
Machine type: VARIVENT®
Relevant EC directives: 2006/42/EC
Applicable harmonized standards: DIN EN ISO 12100

19
Transport and Storage
Storage
Transport and Storage
Scope of Supply
On receipt of the valve check whether
•the details on the type plate correspond to the data in the order and delivery docu-
ments,
•the equipment is complete and all components are in good order.
Transport
For transport, the following principles apply:
•Only use suitable lifting gear and slings for transporting the package units/valves.
•Observe the pictograms on the package.
•Handle valves with care to avoid damaged caused by impact or careless onloading
and unloading. The outside synthetic materials are susceptible to breaking.
•The control modules must be protected from animal and vegetable fats.
•Only allow qualified staff to transport the valve.
•Movable parts must be properly secured.
•Only use approved, fully functional load lifting devices and lifting accessories which
are suitable for the intended purpose. Observe the maximum load-bearing capaci-
ties.
•Secure the valve against slipping. Take the weight of the valve into account and the
position of the point of gravity.
•Under no circumstances should anyone stand under a suspended load.
•Take care when transporting the valve. Do not grip sensitive parts of the valve to lift
or push the valve or support yourself. Avoid putting the valve down with a jerk.
Storage
Valves, valve inserts or spare parts should be stored in a dry place, free of vibrations
and dust. To avoid damage, leave the components in their original packaging if possible.
If, during transport or storage, the valve is going to be exposed to temperatures 0°C, it
must be dried and suitable measures be taken to protect it from damage.
NOTE
We recommend that the valve should be stored at a temperature of 5 °C for a period
of 24 hours prior to any handling so that any ice crystals formed by condensation water
can melt.

Intended Purpose
Improper Operating Conditions
20
Operating Instructions · VARIVENT® Vacuum Valve V
Edition 2016-06-30
Intended Purpose
Designated Use
The vacuum valve V is used for the automatic compensation of vacuum pressures in
tanks or pipes.
Since there is a risk that the valve disk may freeze at temperatures < 0°C, it is essential
to equip the vacuum valve with a heating device. Otherwise, a reliable function is not
ensured.
Tuchenhagen vacuum valves are generally designed for prevention of vacuum caused
by free emptying of tanks. Protection against vacuum caused by the hot/cold cleaning of
the tank/vessel is not provided.
NOTE
The manufacturer will not accept any liability for damage resulting from any use of the
valve which is not in accordance with the designated use of the valve. The risk of such
misuse lies entirely with the operator of the facility.
Requirements for the Operation
The prerequisite for the reliable and safe operation of the valve is proper transportation
and storage as well as professional installation and assembly. Operating the valve within
the limits of its designated use also involves adhering to the operating, inspection and
maintenance instructions.
Improper Operating Conditions
The operational reliability of the valve cannot be ensured under improper operating
conditions. Therefore avoid improper operating conditions.
Operating the valves is not permitted if
•Persons or objects are in the danger zone.
•Safety devices are not working or were removed.
•Malfunctions have been detected on the valve.
•Damage has been detected on the valve.
•Maintenance intervals have been exceeded.
