Geco GH10TA User manual

MANUAL
FOR CONTROLLER
GH10TA
FOR CONTROLLING
CENTRAL HEATING BOILERS
WITH PISTON FEEDER
Program versio : 03a
USER MANUAL
We request that users carefully study applicable Instructions before connecting and
starting up any of our products.
Should a y doubts arise, please co tact our Compa y betwee 8 a.m. a d 4 p.m.
Atte tio !!! At the bottom of each page you will fi d last docume t’s update date. Please, always use the
most rece t versio of the I structio s, which is available free of charge a d will be mailed to you if ordered.

GH10TA USER MANUAL PAGE 2
Issue I July 2017
TABLE OF CO TE TS
1. I TRODUCTIO ............................................................................................................................ 3
1.1. G RAPHIC SYMBOLS ................................................................................................................................ 3
1.2. K EYBOARD AND F UNCTION K EYS ............................................................................................................. 4
2. GE ERAL FEATURES ...................................................................................................................... 5
3. TECH ICAL DATA .......................................................................................................................... 6
4. ELECTRICAL SYSTEM A D CO ECTIO RULES .............................................................................. 6
5. QUICK START ................................................................................................................................ 7
6. THE GH10TA OPERATIO ............................................................................................................. 9
6.1. O PERATED H EATING S YSTEM .................................................................................................................. 9
6.2. A UTOMATIC OPERATION MODE . ............................................................................................................ 10
6.3. M ANUAL O PERATION M ODE ................................................................................................................ 11
6.4. V IEWING T EMPERATURES ..................................................................................................................... 11
6. . A LARM C ONDITIONS ........................................................................................................................... 12
6.6. P OWER F AILURE ................................................................................................................................. 12
6.7. B OILER B URNOUT D ETECTION ............................................................................................................... 13
6.8. M AXIMUM F EEDER T EMPERATURE D ETECTION ........................................................................................ 13
7. USER SETTI GS ........................................................................................................................... 14
7.1. B OILER T EMPERATURE S ETTING (U0) ..................................................................................................... 14
7.2. F EEDER S TANDSTILL D URATION (U1) ..................................................................................................... 14
7.3. M AINTAIN P ERIOD (U2) ...................................................................................................................... 14
7.4. F AN SPEED (U3) ................................................................................................................................. 1
7. . HUW/ R ETURN T EMPERATURE S ETTING (U4) ........................................................................................ 1
7.6. A NTI -L EGIONELLA F UNCTION (U ) ........................................................................................................ 1
8. OPERATI G THE HUW BOILER ..................................................................................................... 15
8.1. I NSTALATION AND C ONNECTIONS .......................................................................................................... 16
8.2. C ONFIGURATION OF A DDITIONAL P UMP ................................................................................................. 16
8.3. HUW P RIORITY .................................................................................................................................. 17
8.4. S UMMER M ODE ................................................................................................................................. 17
9. ROOM THERMOSTAT .................................................................................................................. 17
10. TEMPERATURE LIMITER (STB) ...................................................................................................... 18
11. CO ECTIO DEVICES TO THE GH10TA CO TROLLER .................................................................. 18
12. I FORMATIO O LABELLI G A D COLLECTIO OF WOR OUT ELECTRICAL A D ELECTRO IC
EQUIPME T ................................................................................................................................ 19

GH10TA USER MANUAL PAGE 3
Issue I July 2017
1. I TRODUCTIO
1.1. Graphic symbols
Symbols intended to indicate and at the same time emphasise the importance of text containing
information that warns against dangerous situation have the following graphic forms:
Warning
This symbol is used when it is necessary in described instructions to follow the
sequence of carried out operations. The unit may be damaged or destroyed in case of
any error or proceeding in discord with the description.
Important!
This symbol indicates information of particular importance.
⇒
Reference
This symbol indicates occurrence of additional information in a chapter.

GH10TA USER MANUAL PAGE 4
Issue I July 2017
1.2. Keyboard a d Fu ctio Keys
2.
3.
USER CA TUR OFF A D TUR O CO TROLLER BY USI G BUTTO .
ACTIVATE ALL BUTTO O PA EL TOUCH KEYBORD TAKES PLACE AFTER TOUCH
EACH OF THEM A D HOLD FOR MOME TS.
ON/OFF
MANUAL
CONTROL
AUTO-OPERATION
INDICA
TOR
MANUAL FAN AND CH PUMP
ACTIVATION / INCREASE
PARAMETER VALUE
AUTO
MAINTAIN OPERATION
INDICATOR
MANUAL FEEDER AND DHW PUMP
ACTIVATION
/ DECREASE PARAMETER
VALUE

GH10TA USER MANUAL PAGE 5
Issue I July 2017
2. GE ERAL FEATURES
The GH10TA Controller is a microprocessor-based device manufactured using the Surface Mount
Technology (SMT).
It is designed to control the processes of Hot Utility Water (HUW) heating and the main Central
Heating (CH) water circuit. Control parameters can be adjusted to the current operating conditions and
boiler type. The Controller includes a system protecting from power outages and other different
disturbances.
The GH10TA Controller is fitted with:
•inputs:
1. boiler output water temperature measurement (NTC sensor),
2. fuel feeder temperature measurement (NTC sensor),
3. HUW boiler / return water temperature measurement (NTC sensor),
• digital input:
1. feeder cotter pins removal sensor – reed relay,
2. input for connection of the room thermostat panel.
It also contains four outputs allowing direct connection of 230 V AC devices, i.e.: fan, fuel feeder, CH
circulation pump, HUW pump or mixing pump, depending on the type of the controlled heating system (⇒
section 6, page 8).
ALWAYS DISCONNECT THE CONTROLLER
FROM POWER DURING THUNDERSTORMS

GH10TA USER MANUAL PAGE 6
Issue I July 2017
3. TECH ICAL DATA
Power supply 230V AC +10% -1 %
TC sensor resistance
characteristics
Operating temperature range + °C to +40°C
Humidity 20% to 80% RH
Temperature
Resistance
Fan protection 3.1 A
0
7174.89
Sensor type NTC 2.2kΩ
10
4374.83
Sensor operating temperature 0°C÷100°C
20
2747.10
30
1774.91
40
1172.09
Output Maximum continuous
load
0
79 .08
60
47.9
HUW pump / mixing pump 1A 200W
70
384.62
CH pump 1A 200W
80
27 .86
Fuel feeder* 2A 400W
90
202.37
Fan * 1A 200W
100
149.16
*Whe a co tactor or relay proxy is co ected, use a dedicated
blowout system (eg varistor). Omissio of this security measure may
result i malfu ctio or damage to the co troller output.
4. ELECTRICAL SYSTEM A D CO ECTIO RULES
1. The boiler room should be equipped with a 230V/ 0Hz electrical system, according to the
applicable regulations.
2. The electrical system (regardless of its type) should be terminated with a connection outlet fitted
with a protective terminal. Use of an outlet without a protective terminal causes electrical shock
hazard!!!
3. Connect the Controller to a separately installed power line protected with a properly selected
quick circuit-breaker or a residual-current device (RCD breaker). Do not connect any other devices
to this line!!!
THE CONTROLLER IS POWERED FROM 230V/50HZ MAINS
ANY REPAIRS MAY BE CARRIED OUT ONLY WITH POWER SUPPLY
CUT OFF AT THE FUSE

GH10TA USER MANUAL PAGE 7
Issue I July 2017
5. QUICK START
To quickly start the GH10TA Controller, perform the following actions:
1. Touch keyboard calibration.
After connecting the controller to the power supply, the controller for about 4 seconds calibrates the
touch keyboard. During calibration you can not bring your hands to the sensors, because it would cause
incorrect calibration, and consequently malfunction of the keyboard. After calibration process, the device
performs a 3-second start sequence, during which it displays various information, including the firmware
version. When the start sequence is complete, the controller goes into the STANDBY mode. If the keyboard
does not work correctly, you should repeat the calibration process. To do this, disconnect controllers and
then connect the controller to a power supply and calibrate the keyboard touch one more time,
remembering not to put your hands to the sensors..
2. Connect the device to the 230V AC power system (put the plug in the power outlet).
⇒
3. Turn the Controller ON by pressing . Screen appears:

GH10TA USER MANUAL PAGE 8
Issue I July 2017
4. Press . Screen appears:
and the Controller starts automatic operation according to the factory settings.
Table 1 Factory settings table
Parametr Opis parametru Min Max Krok Nastawa
fabryczna
U00
Boiler temperature setting
’F03’
’F04’ 1°C 60°C
U01
Feeder standstill duration
2 0 1s 30s
U02
Maintain period
2 0 1min 1 min
U03
Fan speed
1 10 1
U04
DHW/return set temperature
3 6 1°C 40°C
U0
Anti-Legionella function
0 1 1 0

GH10TA USER MANUAL PAGE 9
Issue I July 2017
6. THE GH10TA OPERATIO
6.1. Operated Heati g System
6.1.1. Central Heating cycle + HUW cycle
I PUTS
OUT
PUTS
T1 – Boiler temp. P1 – Fuel feeder
T2 – Feeder temp. P2 – Fan
T3 – HUW temp. P3 – HUW pump
C1 – Reed relay P4 – CH pump
6.1.2. Central Heating cycle + mixing pump
I PUTS
OUTPUTS
T1 – Boiler temp. P1 – Fuel feeder
T2 – Feeder temp. P2 – Fan
T8 – Return temp. P4 – CH pump
C1 – Reed relay P8 – mixing pump

GH10TA USER MANUAL PAGE 10
Issue I July 2017
6.2. Automatic operatio mode.
By pressing , you can turn on the automatic operation mode – the Controller lights the upper indicator
on ( ).
6.2.1. Fuel Feeder
In the AUTO mode, the fuel feeder operates according to the value set in the user settings U1 –
“Feeder standstill duration”. The amount of fuel supplied in one feeder cycle is specified in the F21 service
parameter.
After going from MANUAL mode into AUTO mode or after power fail the controller starts the
feeder until reaching the position of maximum withdrawal (reed response), after that the feeder starts to
work normally.
The feeder work is suspended after STOP & GO function activation. The mechanism of fan and
feeder suspension (STOP & GO) does not apply if the temperature drop will be greater than 6 degrees
below the setpoint. This function can be disabled via the F23 service parameter.
Activation and operation of the fuel feeder is indicated by the lower indicator on .
6.2.2. CH Pump
In the AUTO mode, the CH pump starts when the temperature of the boiler water is higher or equal
to the value set in the F06 service setting (factory setting is 40°C).
Turning the CH pump on and its operation is indicated by a vertical line at the left side of the
Controller main display screen.
The Controller turns off the pump when the water temperature drops to the activation
temperature minus 4°C. (If the CH pump start temperature is 40°C, then the CH pump stop temperature is
36°C).
6.2.3. Fan
In the AUTO mode, the fan runs continuously until the boiler temperature reaches the value set by the user
in the U0 setting. During that period the fan runs at its maximum speed. Activation and operation of the
fan is indicated by the upper indicator on .
6.2.4. Maintain Operation Mode
The Controller gets into that mode when the boiler temperature reaches the value set by the user
in the U0 setting.
This mode of operation is indicated by lighting the lower indicator on ( ).
The fuel feeder and fan remain off in that mode for the period set by the user in the U2 setting. When the
period ends, the Controller turns on the feeder and fan for on fuel feeding cycle.
The fan will operate for the period respectively longer that the feeder for the time set in the F18 service
setting in order to fire up the added coal.
The Controller will exit the MAINTAIN mode and return to the AUTO mode if the boiler temperature drops
to the value equal to the U0 – F05.
The CH pump operates identically as in the AUTO mode.

GH10TA USER MANUAL PAGE 11
Issue I July 2017
6.2. . Reed relay
In AUTO mode the feeder sensor (reed relay) works according to the value set in F19 and F22
service parameters. After exceeding the time of ( /4 x (F19xF22)) and no reed relay activation the AL9
alarm will appear (⇒ section 6. , page 11).
6.3. Ma ual Operatio Mode
In this mode, you can manually and independently turn on and off the fuel feeder and the fan. To do
this, follow the below scheme:
In the manual operation mode, you can also start the CH and HUW pumps. To start the CH pump, press the
following key: and hold it for second. Starting and running of the CH pump is indicated by a vertical
line at the left side of the Controller main display screen.
To start the HUW pump, press the following key and hold it for second. Starting and running of the
HUW pump is indicated by a horizontal line at the bottom of the Controller main display screen.
Pressing causes the Controller to switch from automatic to manual mode, and immediately stops the
fan, the feeder and pumps.
6.4. Viewi g Temperatures
After pressing , the display shows water temperature at the boiler outlet. Viewing temperatures:
HUW/return and feeder is available in the AUTO and MAINTAIN modes, but only if the HUW/return sensor
or feeder are properly enabled.
Press to view the feeder temperature. Press the key again to cancel the view. The view is also
cancelled after 10s from pressing of the key.
Press to get a HUW/return temperature view. Press the key again to cancel the view. The view is also
cancelled after 10s from pressing of the key.
STEP 1
STEP 2
→
Controller
indicates water
temperature
measured on CH
boiler
Fuel feeder
Lower key indicator
lights. Press the key again to
stop feeder and turn off
indicator.
Fan
Upper key indicator
lights. Press the key again to
stop the fan and turn off
indicator.

GH10TA USER MANUAL PAGE 12
Issue I July 2017
6.5. Alarm Co ditio s
The Controller uses 8 different alarm conditions. In each alarm condition, the Controller displays the
alarm number and activates the alarm sound output. In case of several alarm conditions occurring
simultaneously, their numbers are displayed in sequence. You can exit an alarm condition only by pressing
. This does not include the AL12 alarm condition.
Alarm conditions:
• AL1 →
STB activated or fuse blown
• AL2 →
Boiler water outlet temperature sensor failure
• AL3 →
Feeder temperature sensor failure
• AL4 →
HUW/return temperature sensor failure
• AL9 →
No feeder rotation / reed switch failure
• AL11 →
Maximum feeder temperature exceeded
• AL12 →
Boiler overheating
• AL13 →
Boiler burnout
6.6. Power Failure
After a power failure the Controller starts to reactivate according to the condition it was in before the
power down. The Controller waits 1 minute to stabilise the mains power parameters, and then restores
operation with the previously programmed settings.
During the waiting period, the display shows time in seconds remaining until the end of the period,
along with indication of its condition before the power outage:
•blinking “A” for AUTO mode,
•blinking “P” for MAINTAIN mode,
•blinking “r” for MANUAL mode.
Respective indicators (AUTO or MAINTAIN ) are blinking along with the letters.

GH10TA USER MANUAL PAGE 13
Issue I July 2017
6.7. Boiler Bur out Detectio
6.7.1. No Fuel
If during automatic operation the boiler outlet water temperature remains below the F08 setting
for a period of time set in the F09 setting, then the Controller considers the boiler as “burned out” and
enters the AL13 alarm condition.
6.7.2. Sudden Drop of Outlet Water Temperature
If during automatic operation the boiler outlet water temperature drops by 10°C, and during that
dropping period the temperature does not rise by 4°C, then the CH and HUW pumps are switched off, and
the Controller goes into the burnout detection mode.
The Controller waits for the period of time set in the F10 setting, during which it checks whether a rise of
4°C occurs.
If YES, then the burnout detection condition is stopped, and the CH and HUW pumps (if necessary) are
started.
If NOT, this means that the furnace is burned out – the Controller enters the AL13 alarm condition.
6.8. Maximum Feeder Temperature Detectio
The GH10TA Controller is equipped with an additional option of protecting from temperature rise in the
fuel feeder above the permissible value to prevent backfires into the fuel feeder.
The detection is active only in the automatic boiler operation mode (AUTO, MAINTAIN).
When the measured temperature exceeds the value set in the F14 service setting, the fuel feeder activates
for the period of time set in the F16 service setting to eject the ignited fuel from the feeder. During the F16
period the fan remains stopped.
When the time set in F15 service setting elapses, the Controller restores the maximum feeder temperature
detection process.
When the feeder T > 90°C, then fan is stopped, the fuel feeder is started for a period of 2xF16, and the
display indicates the alarm condition AL11 – “Maxi u feeder te perature exceeded”. (⇒ section 6.
page 11).
The Controller remains in the alarm condition until user response.
IF F14=0, THEN FEEDER SENSOR OPERATION IS OFF AND THE FUNCTION
OF FEEDER MAX. TEMPERATURE INCREASE DETECTION IS NOT ACTIVE.

GH10TA SERVICE MANUAL STRONA 14
7. USER SETTI GS
7.1. Boiler Temperature Setti g (U0)
You can change the boiler temperature setting using the following procedure:
7.2. Feeder Sta dstill Duratio (U1)
This is the period of time between two consecutive fuel feeds in the AUTO mode.
Settings are within the range from s to 2 0s.
You can change the setting using the following procedure:
STEP 1 STEP 2 STEP 3 STEP 4
→ →
or →
Green LED lights on
the key.
Display shows the U0
setting value.
Move to
the U1
setting.
Set the desired value.
Save the new
setting.
Move to the U2
setting.
7.3. Mai tai Period (U2)
This is the period of time after which the Controller activates the feeder and fan for the period set by
the manufacturer for the MAINTAIN mode to prevent burning out of the boiler. Settings range is from
min. to 2 0 min. You can modify this setting in a similar way to the described in sections 7.1 and 7.2.
STEP 1 STEP 2 STEP 3
→ or →
Green LED lights on the
key.
Display shows current
temperature setting.
Set a new desired
temperature within range
permitted by the boiler
manufacturer.
Save the new
temperature setting.
Move to the U1 setting
If duri g setti g the ew temperature
o e of the followi g keys , ,
is pressed for 15 s, the ew temperature will ot be saved
a d the Co troller will exit the programmi g mode.

GH10TA USER MANUAL PAGE 15
Issue I July 2017
7.4. Fa speed (U3)
This setting determines the fan rotation speed, and thus the amount of air delivered. It allows to adjust
the fan speed according to the type and quality of the fuel used.
This setting can be set within the range of 1÷10, where “1” denotes minimum speed, and “10” maximum
speed.
You can modify this setting in a similar way to the described in sections 7.1. and 7.2.
7.5. HUW/ Retur Temperature Setti g (U4)
This setting is available to the user only if the HUW heating option or return temperature stabilisation
are used, and the user configured the pump with the F00 service parameter by setting it to the values “01”,
“02”, “03”, “04” (⇒ section 8.2 page 1 ). You can modify this setting in a similar way to the described in
sections 7.1 and 7.2. Settings are within the range of 3 °C to 6 °C.
7.6. A ti-Legio ella Fu ctio (U5)
The GH10TA controller is equipment in Anti-Legionella function which limit growth Legionella
pneu ophilia bacterium on HUW installation. This function is available for users when value F00
service parameter was adjust on „02”, „03” or „04”.
The Legionella bacterium growth in water environment and the best condition is on 38–42
0
C
temperature. The Legionella bacterium can cause variety pneumonia disease, called Legion fever.
To activate the ANTI-LEGIONELLA function, set the U setting to 1.
When the function is active, a blinking letter “L” is visible on the left part of the display, before the
displayed temperature value.
You can turn off the function by modifying the U setting to 0, or by pressing . The anti-legionella
function is also cancelled after a power down.
The ANTI-LEGIONELLA function has higher priority over other functions, therefore it is performed
by the Controller in the first order (superior function).
When the function is activated, the temperature of water in the boiler is increased to 70°C and maintained
for a period of 10 minutes.
8. OPERATI G THE HUW BOILER
TURNING ON OF THE ANTY-LEGIONELLA FUNCTION CAUSES RISE OF
THE TEMPERATURE OF HUW WATER UP TO 70
0
C.
EXTRA CAUSION WHEN USING HUW.
MAY RESULT IN BURNING !!!

GH10TA USER MANUAL PAGE 16
Issue I July 2017
The GH10TA Controller allows connection of an additional pump to control the Hot Utility Water (HUW)
in the boiler.
8.1. I stalatio a d Co ectio s
To use the Hot Utility Water (HUW) heating option, perform the following actions:
1. connect the boiler according to the enclosed diagram (⇒ section 6.1.1 page 8).
2. install the HUW temperature sensor in the HUW storage
We recomme d mou ti g HUW temperature se sor i GECO
measuri g drai .
You ca ot mou ted temperature se sors i measuri g drai with
water or oil !!!
3. connect the HUW temperature sensor to the Controller at the appropriate
terminals as shown in Fig. 2
4. configure the HUW pump for operation (⇒ section 8.2 page 1 ).
8.2. Co figuratio of Additio al Pump
This procedure allows you to connect an additional pump that can be used as a mixing pump or a Hot
Utility Water (HUW) pump operating with or without higher priority.
The HUW pump is started when the boiler outlet water temperature is higher than 40°C and higher
than the water in the HUW boiler (to prevent cooling of the HUW boiler), and the HUW boiler temperature
is lower than the temperature set in the U4 setting (⇒ section 7.5 page 14).
Pump operation is indicated by a dot on the display next to the fan symbol.
If the boiler room is configured as shown in the diagram (⇒ section 6.1.1 page 8) then the boiler
controller has no external alarm output, but allows to view the HUW boiler temperature
by pressing .
Use the following procedure to program operation of an additional pump in the Controller:
HUW temperature se sor is additio al equipme t a d it’s ot i cludes
to the sta dard set co troller GH10TA.
Additio al equipme t ca be delivery accordi g with additio al order.

GH10TA USER MANUAL PAGE 17
Issue I July 2017
STEP 1 STEP 2 STEP 3 STEP 4
→ →
or
→
Display shows
„─ ─ ─ ─”
Press and
hold for 2s
Set the desired F00 value
00 – no pump operation
01 – mixing pump
02 – HUW pump winter mode without
priority
03 – HUW pump winter mode with
priority
04 – HUW pump summer mode
Save the
new setting
8.3. HUW Priority
The GH10TA Controller allows to set operation of the HUW pump with priority. If you choose this mode
of HUW pump operation, the hot utility water heating is a higher priority function in the Controller.
To do this, set the F00 service setting to the value of “3”.
8.4. Summer Mode
The GH10TA Controller is equipped with a SUMMER MODE option that allows you to turn off the CH
pump for the summer season, and the boiler operates only to supply the HUW water. To do this, set the
F00 service setting to the value of “4”.
9. ROOM THERMOSTAT
The GH10TA controller can cooperate with external room thermostat (⇒ Fig.1), which can put coal boiler in
blockade position when temperature is reached in room.
During blockade position C.H. pump stay off after 4 minutes, for the moment when temperature in
room is reached (short circuit contact). The boiler start working in maintain operation mode.
The controller GH10TA passing from automatic operation to maintain operation mode just from time to
time, when the boiler temperature is higher than minimum temperature adjust in F03 service parameter or
when HUW circulation require automatic operation controller ( it depend of HUW Priority).
When room thermostat put controller in blockade position, the boiler is in maintain operation mode and
boiler temperature fall down less than F03 service parameter or HUW circulation need heating, than the
controller come back to automatic operation mode until both conditions will be accomplish.
The controller supports the room panel of our manufacture. The controller responses to the panel orders if
the controller is under the automatic operation mode. Where the malfunction occurs to the connection
with the panel, the controller will resume the operation with the user programmed settings.
The illuminated dot on the segment on the left-hand side of the display shows that the communication link
is operable.

GH10TA USER MANUAL PAGE 18
Issue I July 2017
10. TEMPERATURE LIMITER (STB)
The GH10TA Controller can be equipped with an additional independent temperature limiter STB
via terminals 1 and 16.
WHEN THE TEMPERATURE LIMITER IS NOT USED,
TERMINALS 15 AND 16 SHOULD BE SHORTED.
If due to boiler temperature rise the temperature limiter is activated and opens its terminals, it will disable
feeder and fan power supply in order to stop fuel and air delivery do the boiler. After approximately s
from limiter activation the Controller indicates the AL1 alarm.
Return to normal boiler operation is possible when the boiler temperature drops to a level enabling limiter
reset (temperature level depends on the limiter model used).
For safety reasons the Controller does not resume automatic operation on its own.
For the Controller to resume operation you have to, after resetting the limiter, press twice:
– pressing for the first time cancels the alarm and disables the Controller,
– pressing for the second time reactivates the Controller,
– pressing causes the Controller to switch to automatic operation mode.
CAPILLARY TUBE PUNCTURE OR BREAKAGE INDICATES THAT
TEMPERATURE LIMITER FILLED WITH LIQUID LEAKS, WHICH RESULTS IN
ABNORMAL OPERATION OF THE GH10TA CONTROLLER.
IN CASE IF THE ABOVE-MENTIONED DEFECT IS FOUND, IT WILL BE
NECESSARY TO DISCONNECT TEMPERATURE LIMITER FROM THE GH10TA
CONTROLLER, REMOVE IT AND REPLACE WITH A NEW DEVICE.
11. CO ECTIO DEVICES TO THE GH10TA CO TROLLER
OUTPUTS
I PUTS
14 L — Fan 50, 51 — Out water temperature sensor
12 N — Fan 52, 53 —
H.U.W
/ Return
temp. sensor
11 L — Feeder 54, 55 — Fedder temperature sensor
09 N — Feeder 56, 57 — Reed relay / Thermostat
06 L — Central Heating Pump C.H.
05 N — Central Heating Pump C.H.
08 L —
H.U.W. Pump/ Mixing Pump
07 N —
H.U.W. Pump/ Mixing Pump
02 N — Power Supply 230V
01 L — Power Supply 230V

GH10TA USER MANUAL PAGE 19
Issue I July 2017
Fig. 1 Diagram of connection outputs and inputs devices and temperature sensor in the GH10TA controller.
ANY ADDITIONAL EQUIPMENT MAY BE CONNECTED TO THE GH10TA
CONTROLLER ONLY BY PERSON LICENSED TO PERFORM ELECTRICAL
INSTALLATION WORKS.
12. I FORMATIO O LABELLI G A D COLLECTIO OF WOR OUT ELECTRICAL
A D ELECTRO IC EQUIPME T
CAUTION!
This symbol placed on the product or its packaging indicates the need for
selective collection of worn out electrical and electronic equipment. It
means that this product should not be disposed of with other household
wastes. Proper disposal of aged and worn out electrical and electronic
equipment will help to avoid potentially adverse effects for environment
and human health.
It is the user’s responsibility to collect worn out equipment separately,
and to return it to an authorized disposal company.

P.P.U.H. „Geco” Sp. z o.o.
Cholerzyn 376, 32-060 Liszki, Poland
ph. 012/636-98-11, 636-12-90
fax. [phone]
http://www.geco.pl
e-mail: [email protected]
