GEM eSyLite R629 User manual

GEMÜ R629 eSyLite
Motorized diaphragm valve
Operating instructions
EN
further information
webcode: GW-R629

All rights including copyrights or industrial property rights are expressly reserved.
Keep the document for future reference.
© GEMÜ Gebr. Müller Apparatebau GmbH & Co. KG
20.10.2023
www.gemu-group.com2 / 47GEMÜ R629 eSyLite

Contents
1 General information ............................................. 4
1.1 Information .................................................... 4
1.2 Symbols used ................................................ 4
1.3 Definition of terms ........................................ 4
1.4 Warning notes ............................................... 4
2 Safety information ............................................... 5
3 Product description ............................................. 5
3.1 Construction .................................................. 5
3.2 Description ..................................................... 5
3.3 Function ......................................................... 6
3.4 Product label ................................................. 6
4 Correct use .......................................................... 6
5 Order data ........................................................... 7
6 Technical data ..................................................... 9
7 Electrical connection ........................................... 14
8 Dimensions .......................................................... 16
8.1 Actuator dimensions ..................................... 16
8.2 Actuator dimensions with distance piece ... 17
8.3 Actuator dimensions with GEMÜ 1215 posi-
tion indicator .................................................. 18
8.4 Actuator dimensions with GEMÜ 1235 posi-
tion indicator .................................................. 19
8.5 Body dimensions ........................................... 20
8.5.1 Spigot DIN/inch (code 0, 30) ........... 20
8.6 Valve body mounting .................................... 33
8.7 Mounting plate .............................................. 33
9 Manufacturer's information .................................. 34
9.1 Delivery .......................................................... 34
9.2 Packaging ...................................................... 34
9.3 Transport ....................................................... 34
9.4 Storage ........................................................... 34
10 Installation in piping ............................................ 34
10.1 Preparing for installation .............................. 34
10.2 Installation position ....................................... 35
10.3 Installation with butt weld spigots ............... 35
10.4 Installation with threaded sockets ............... 35
10.5 Installation with threaded spigots ................ 35
10.6 Installation with union ends .......................... 35
10.7 Installation with solvent cement sockets .... 36
10.8 Installation with flare connection ................. 36
10.9 Installation with flanged connection ............ 36
11 Operation ............................................................. 36
11.1 Manual override ............................................. 36
12 Inspection and maintenance ................................ 37
12.1 Spare parts .................................................... 38
12.2 Removing the actuator .................................. 38
12.3 Removing the diaphragm .............................. 38
12.4 Mounting the compressor ............................ 38
12.5 Mounting the diaphragm .............................. 38
12.6 Mounting the actuator .................................. 39
13 Troubleshooting .................................................. 41
14 Removal from piping ............................................ 42
15 Disposal .............................................................. 42
16 Returns ................................................................ 42
17 EU Declaration of Incorporation according to the
EC Machinery Directive 2006/42/EC, Annex II B ... 43
18 EU Declaration of Conformity in accordance with
2014/68/EU (Pressure Equipment Directive) ........ 44
19 EU Declaration of Conformity in accordance with
2014/30/EU (EMC Directive) ................................ 45
20 EU Declaration of Conformity in accordance with
2011/65/EU (RoHS Directive) ............................... 46
GEMÜ R629 eSyLitewww.gemu-group.com 3 / 47

www.gemu-group.com4 / 47GEMÜ R629 eSyLite
1 General information
1 General information
1.1 Information
- The descriptions and instructions apply to the standard ver-
sions. For special versions not described in this document
the basic information contained herein applies in combina-
tion with any additional special documentation.
- Correct installation, operation, maintenance and repair work
ensure faultless operation of the product.
- Should there be any doubts or misunderstandings, the Ger-
man version is the authoritative document.
- Contact us at the address on the last page for staff training
information.
1.2 Symbols used
The following symbols are used in this document:
Symbol Meaning
Tasks to be performed
Response(s) to tasks
– Lists
1.3 Definition of terms
Working medium
The medium that flows through the GEMÜ product.
Diaphragm size
Uniform seat size of GEMÜ diaphragm valves for different
nominal sizes.
1.4 Warning notes
Wherever possible, warning notes are organised according to
the following scheme:
SIGNAL WORD
Type and source of the danger
Possible
symbol for the
specific
danger
Possible consequences of non-observance.
Measures for avoiding danger.
Warning notes are always marked with a signal word and
sometimes also with a symbol for the specific danger.
The following signal words and danger levels are used:
DANGER
Imminent danger!
▶Non-observance can cause death or
severe injury.
WARNING
Potentially dangerous situation!
▶Non-observance can cause death or
severe injury.
CAUTION
Potentially dangerous situation!
▶Non-observance can cause moderate
to light injury.
NOTICE
Potentially dangerous situation!
▶Non-observance can cause damage to
property.
The following symbols for the specific dangers can be used
within a warning note:
Symbol Meaning
Danger of explosion!
Corrosive chemicals!
Hot plant components!
Damage to the product!

www.gemu-group.com 5 / 47 GEMÜ R629 eSyLite
2 Safety information
The safety information in this document refers only to an indi-
vidual product. Potentially dangerous conditions can arise in
combination with other plant components, which need to be
considered on the basis of a risk analysis. The operator is re-
sponsible for the production of the risk analysis and for com-
pliance with the resulting precautionary measures and re-
gional safety regulations.
The document contains fundamental safety information that
must be observed during commissioning, operation and main-
tenance. Non-compliance with these instructions may cause:
- Personal hazard due to electrical, mechanical and chemical
effects.
- Hazard to nearby equipment.
- Failure of important functions.
- Hazard to the environment due to the leakage of dangerous
substances.
The safety information does not take into account:
- Unexpected incidents and events, which may occur during
installation, operation and maintenance.
- Local safety regulations which must be adhered to by the
operator and by any additional installation personnel.
Prior to commissioning:
1. Transport and store the product correctly.
2. Do not paint the bolts and plastic parts of the product.
3. Carry out installation and commissioning using trained
personnel.
4. Provide adequate training for installation and operating
personnel.
5. Ensure that the contents of the document have been fully
understood by the responsible personnel.
6. Define the areas of responsibility.
7. Observe the safety data sheets.
8. Observe the safety regulations for the media used.
During operation:
9. Keep this document available at the place of use.
10. Observe the safety information.
11. Operate the product in accordance with this document.
12. Operate the product in accordance with the specifications.
13. Maintain the product correctly.
14. Do not carry out any maintenance work and repairs not de-
scribed in this document without consulting the manufac-
turer first.
In cases of uncertainty:
15. Consult the nearest GEMÜ sales office.
3 Product description
3.1 Construction
12
3
6
7
9
4
8
5
Ite
m
Name Materials
1 Optical position indicator PA 12
2 Manual override
3 Motorized actuator Reinforced polyamide
4 CONEXO actuator RFID chip
(see Conexo information)
5 Valve body Inliner PP-H, grey / outliner
PP, reinforced
Inliner PVDF / outliner PP,
reinforced
PVC-U, grey
ABS
PP
PP, reinforced
PP-H, natural | PVDF
6 Diaphragm EPDM, FKM, NBR, PTFE/
EPDM
7 CONEXO diaphragm RFID
chip
(see Conexo information)
8 CONEXO body RFID chip
(see Conexo information)
9 Electrical connection
3.2 Description
The GEMÜ R629 eSyLite 2/2-way diaphragm valve is motor-
ized. It is available in an Open/Closed version. An integrated
optical position indicator is standard. The self-locking actu-
ator holds its position in a stable manner in the event of
power supply failure.
3 Product description

www.gemu-group.com6 / 47GEMÜ R629 eSyLite
4 Correct use
3.3 Function
The product controls a flowing medium by being closed or
opened by a motorised actuator. The product is designed as
an OPEN/CLOSED valve and is not intended for control applic-
ations.
The product has an optical position indicator as standard. The
optical position indicator indicates the OPEN and CLOSED po-
sitions.
3.4 Product label
The product label is located on the actuator. Product label
data (example):
Design in accordance with order data
Device-specific data
Year of manufacture
Item number Traceability number Consecutive number
The month of manufacture is encoded in the traceability num-
ber and can be obtained from GEMÜ. The product was manu-
factured in Germany.
The operating pressure stated on the product label applies to
a media temperature of 20 °C. The product can be used up to
the maximum stated media temperature. You can find the
pressure/temperature correlation in the technical data.
4 Correct use
DANGER
Danger of explosion!
▶Risk of death or severe injury
●Do not use the product in potentially
explosive zones.
WARNING
Improper use of the product!
▶Risk of severe injury or death
▶Manufacturer liability and guarantee will be void.
●Only use the product in accordance with the operating
conditions specified in the contract documentation and in
this document.
The product is designed for installation in piping systems and
for controlling a working medium.
The product is not intended for use in potentially explosive
areas.
1. Use the product in accordance with the technical data.
2. The product is designed as an OPEN/CLOSED valve and is
not intended for control applications. Due to the minimum
actuation time, sufficiently accurate control is not pos-
sible.

5 Order data
Order codes
The order data provide an overview of standard configurations.
Please check the availability before ordering. Other configurations available on request.
1 Type Code
Diaphragm valve, electrically operated,
plastic diaphragm valve
R629
2 DN Code
DN 12 12
DN 15 15
DN 20 20
DN 25 25
DN 32 32
DN 40 40
DN 50 50
DN 65 65
3 Body configuration Code
2/2-way body D
4 Connection type Code
Spigot
Spigot DIN 0
Spigot for IR butt welding 20
Spigot for IR butt welding, BCF 28
Spigot – inch,
for welding or solvent cementing, depending on the
body material
30
Body with threaded spigots for unions 7X
Union end
Union end with insert (socket) – DIN 7
Union end with insert (Rp threaded socket) – DIN 7R
Union end with inch insert – BS (socket) 33
Union end with inch insert – ASTM (socket) 3M
Union end with insert – JIS (socket) 3T
Union end with insert (for IR butt welding) – DIN 78
Threaded socket
Threaded socket DIN ISO 228 1
Solvent cement socket
Solvent cement socket DIN 2
Flange
Flange EN 1092, PN 10, form B,
face-to-face dimension FTF EN 558 series 1, ISO 5752,
basic series 1
4
Flange ANSI Class 125/150 RF,
face-to-face dimension FTF EN 558 series 1, ISO 5752,
basic series 1,
length only for body configuration D
39
Flare
Flare connection with PVDF union nut 75
5 Valve body material Code
PVC-U, grey 1
5 Valve body material Code
ABS 4
PP, reinforced 5
PVDF 20
Inliner PP-H, grey,
outliner PP, reinforced
71
Inliner PVDF/outliner PP, reinforced 75
PP-H, natural N5
6 Diaphragm material Code
Elastomer
NBR 2
FKM 4
EPDM 29
PTFE
PTFE/EPDM one-piece 54
PTFE/EPDM two-piece 5M
Note: The PTFE/EPDM diaphragm (code 5M) is
available from diaphragm size 25.
7 Voltage/Frequency Code
24 V DC C1
8 Control module Code
ON/OFF actuator (economy) A0
ON/OFF actuator (economy)
Emergency power supply module (NC)
A1
ON/OFF actuator (economy)
Emergency power supply module (NO)
A2
OPEN/CLOSE control with mounted GEMÜ 1235
position indicator
Y0
OPEN/CLOSE control with mounted GEMÜ 1235
position indicator
Emergency power supply module (NC)
Y1
OPEN/CLOSE control with mounted GEMÜ 1235
position indicator
Emergency power supply module (NO)
Y2
OPEN/CLOSE control with mounted GEMÜ 1215
position indicator
Z0
OPEN/CLOSE control with mounted GEMÜ 1215
position indicator
Emergency power supply module (NC)
Z1
OPEN/CLOSE control with mounted GEMÜ 1215
position indicator
Emergency power supply module (NO)
Z2
9 Actuator version Code
Actuator size 1
diaphragm size 10
1C
Actuator size 1
diaphragm size 20
1E
5 Order data
www.gemu-group.com 7 / 47 GEMÜ R629 eSyLite

9 Actuator version Code
Actuator size 1
diaphragm size 25
1F
Actuator size 3
diaphragm size 40
3H
Actuator size 3
diaphragm size 50
with distance piece
K3
10 Mounting plate Code
Including mounting plate M
Without mounting plate O
Standard
Order example
Ordering option Code Description
1 Type R629 Diaphragm valve, electrically operated,
plastic diaphragm valve
2 DN 25 DN 25
3 Body configuration D 2/2-way body
4 Connection type 7 Union end with insert (socket) – DIN
5 Valve body material 1 PVC-U, grey
6 Diaphragm material 29 EPDM
7 Voltage/Frequency C1 24 V DC
8 Control module A0 ON/OFF actuator (economy)
9 Actuator version 1E Actuator size 1
diaphragm size 20
10 Mounting plate Standard
5 Order data
www.gemu-group.com8 / 47GEMÜ R629 eSyLite

6 Technical data
6.1 Medium
Working medium: Corrosive, inert, gaseous and liquid media which have no negative impact on the physical and
chemical properties of the body and diaphragm material.
The valve will seal in both flow directions up to full operating pressure (gauge pressure).
6.2 Temperature
Media temperature: Valve body material Media temperature
PVC-U, grey (code 1) 10 — 60 °C
ABS (code 4) -10 — 60 °C
PP, reinforced (code 5) 5 – 80 °C
PVDF (code 20) -10 — 80 °C
Inliner PP-H grey / outliner PP, reinforced (code
71)
5 – 80 °C
Inliner PVDF / outliner PP, reinforced (code 75) -10 — 80 °C
PP-H, natural (code N5) 5 – 80 °C
Ambient temperature: Valve body material Ambient temperature
PVC-U, grey (code 1) 10 — 50 °C
ABS (code 4) -10 — 50 °C
PP, reinforced (code 5) 5 — 50 °C
PVDF (code 20) -10 — 50 °C
Inliner PP-H grey / outliner PP, reinforced (code
71)
5 — 50 °C
Inliner PVDF / outliner PP, reinforced (code 75) -5 — 50 °C
PP-H, natural (code N5) 5 — 50 °C
If the emergency power module is used (control module code A1, A2, Z1, Z2), the maximum ambi-
ent temperature is reduced to 40 °C.
Storage temperature: 0 — 40 °C
6.3 Pressure
Operating pressure: 0 — 6 bar
All pressures are gauge pressures. Operating pressure values were determined with static operating pressure
applied on one side of a closed valve. Sealing at the valve seat and atmospheric sealing is ensured for the given
values.
Information on operating pressures applied on both sides and for high purity media on request.
The operating pressures apply at room temperature. In case of deviating temperatures, observe the
pressure / temperature correlation.
Pressure rating: PN 10
GEMÜ R629 eSyLitewww.gemu-group.com 9 / 47
6 Technical data

Pressure/temperature
correlation:
Valve body
material
Temperatures in °C (valve body)
Materials Code -10 0 5 10 20 30 40 50 60 70 80
PVC-U 1 - - - 6.0 6.0 6.0 6.0 3.5 1.5 - -
ABS 4 6.0 6.0 6.0 6.0 6.0 6.0 6.0 4.0 2.0 - -
PP-H 5 - - 6.0 6.0 6.0 6.0 6.0 5.5 4.0 2.7 1.5
PP-H 71 - - 6.0 6.0 6.0 6.0 6.0 5.5 4.0 2.7 1.5
PVDF 20 6.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 5.4 4.7
PVDF 75 6.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 5.4 4.7
PP-H,
natural
N5 - - 6.0 6.0 6.0 6.0 6.0 5.5 4.0 2.7 1.5
The pressure rating (PN) depends on the diaphragm size.
Data for extended temperature ranges on request. Please note that the ambient temperature and media temper-
ature generate a combined temperature at the valve body which must not exceed the above values.
Leakage rate: Leakage rate A to P11/P12 EN 12266-1
Kv values: MG DN Kv values
10 12 2.8
15 3.5
20 3.5
20 15 6.0
20 10.0
25 12.0
25 32 20.0
40 40 42.0
50 46.0
50 65 70.0
MG = diaphragm size, Kv values in m³/h
Kv values determined acc.to DIN EN 60534 standard, inlet pressure 5 bar, Δp 1 bar, PVC-U valve body and soft
elastomer diaphragm. The Kv values for other product configurations (e.g. other diaphragm or body materials)
may differ. In general, all diaphragms are subject to the influences of pressure, temperature, the process and
their tightening torques. Therefore the Kv values may exceed the tolerance limits of the standard.
The Kv value curve (Kv value dependent on valve stroke) can vary depending on the diaphragm material and dur-
ation of use.
www.gemu-group.com10 / 47GEMÜ R629 eSyLite
6 Technical data

6.4 Product compliance
Machinery Directive: 2006/42/EC
Pressure Equipment Dir-
ective:
2014/68/EU
Food: FDA*
* depending on version and / or operating parameters
EMC Directive: 2014/30/EU
RoHS Directive: 2011/65/EU
6.5 Materials
Materials: Diaphragm material O-ring material
PTFE FPM
NBR EPDM
FPM FPM
EPDM EPDM
GEMÜ R629 eSyLitewww.gemu-group.com 11 / 47
6 Technical data

6.6 Mechanical data
Protection class: IP 65 acc. to EN 60529
Actuating speed: Max. 3 mm/s
Flow direction: Optional
Installation position: Optional
Observe the angle of rotation to achieve an installation for optimized draining
Weight: Actuator
MG 10: 0.8 kg
MG 20: 0.88 kg
MG 25: 0.94 kg
MG 40: 1.4 kg
MG 50: 2.8 kg
Valve body
MG DN Spigot Union end Flange Threade
d socket
Solvent
cement
socket
Flare
Connection type code
0, 30 20 28 7, 7R 33 3M,
3T
78 4, 39 1 2 75
10 12 - - - - - - - - 0.08 0.06 -
15 - - 0.13 0.18 0.13 - 0.20 - - - 0.08
20 - - - - - - - - - - 0.125
20 15 0.12 0.10 - 0.17 0.24 0.26 0.27 0.67 - - -
20 0.13 0.12 - 0.21 0.28 0.30 0.36 0.84 - - -
20 25 0.16 0.14 - 0.26 0.33 0.38 0.37 1.28 - - -
25 32 0.22 0.18 - 0.40 0.70 0.73 0.63 1.89 - - -
40 40 0.50 0.40 - 0.73 0.83 0.93 1.13 2.36 - - -
50 0.57 0.47 - 1.00 1.40 1.50 1.60 3.08 - - -
50 65 0.92 3.57 - - - - - 3.20 - - -
MG = diaphragm size
Weights in kg
Mechanical environ-
mental conditions:
Class 4M8 acc. to EN 60721-3-4:1998
Vibration: 5g acc. to IEC 60068-2-6 Test Fc
Shock: 25g acc. to 60068-2-27 Test Ea
www.gemu-group.com12 / 47GEMÜ R629 eSyLite
6 Technical data

6.7 Actuator duty cycle and service life
Service life: Class A acc. to EN 15714-2
Minimum 100,000 switching cycles at room temperature and permissible duty cycle.
Duty cycle: max. 30% duty
6.8 Electrical data
Supply voltage: 24 V DC
Tolerance ± 10 %
Operating time: MG 10: 2,5 s
MG 20: 3,5 s
MG 25: 4,0 s
MG 40: 4,5 s
MG 50: 7,0 s
Close tight current / rated
current:
MG 10: 0,5 A
MG 20: 1,4 A
MG 25: 1,3 A
MG 40: 2,3 A
MG 50: 2,3 A
Starting current / max-
imum current:
MG 10: ca. 2,4 A
MG 20: ca. 2,4 A
MG 25: ca. 2,4 A
MG 40: ca. 4,5 A
MG 50: ca. 4,5 A
Standby current con-
sumption:
approx. 10 mA
6.8.1 Digital input signals
Input voltage: max. 30 V DC
≥ 56 kΩ
High level: ≥ 18 V DC
Low level: ≤ 5 V DC
Minimum actuation dura-
tion:
600 ms
Input current: < 0.6 mA
6.8.2 Emergency power supply module
Charging current: MG 10, MG 20, MG 25: max. 0,16 A
MG 40: 0,32 A
MG 50: not available
Charging time: approx. 13 min
Service life: Guide value at 25 °C ambient temperature, approx. 3 years
GEMÜ R629 eSyLitewww.gemu-group.com 13 / 47
6 Technical data

7 Electrical connection
NOTICE
Appropriate cable socket/appropriate mating connector
▶The appropriate connector is included for X1.
7.1 Position of the connectors
X1
7.2 Electrical connection
Connection X1
13
2
654
7-pin plug, Binder, type 693
Pin Signal name
1 24 V supply voltage
2 GND
3 Digital input OPEN
4 Digital input CLOSED
5 n.c.
6 n.c.
7 n.c.
Preferred direction if both digital inputs are present
for device version 00
(see operating instructions – Product label)
Control module ordering
option
Preferred direction
A0, Y0, Z0 OPEN
A1, Y1, Z1 CLOSED
www.gemu-group.com14 / 47GEMÜ R629 eSyLite
7 Electrical connection

Preferred direction if both digital inputs are present
for device version 00
(see operating instructions – Product label)
A2, Y1, Z2 OPEN
Preferred direction if both digital inputs are present
for device version 01
(see operating instructions – Product label)
Control module ordering
option
Preferred direction
A0, Y0, Z0 OPEN
A1, Y1, Z1 OPEN
A2, Y2, Z2 CLOSED
7.3 Connection diagram
X1
Device side Connections / customer
eSyLite
Uv 24 V DC
Uv GND Power supply
PLC
Digital input 1
Digital input 2
24 V DC
24 V DC
1
2
3
4
5
6
7-pin plug
Binder, type 693
Switch
Consumer
Signal direction
Power supply
=
=
=
=
13
2
654
GEMÜ R629 eSyLitewww.gemu-group.com 15 / 47
7 Electrical connection

8 Dimensions
8.1 Actuator dimensions
B2
A
A1
B1
B3
B
MG DN A A1 B B1 B2 B3
10 12 - 20 192.0 63.0 59.5 134.5 115.0 82.0
20 15 - 25 195.0 66.0 59.5 134.5 115.0 82.0
25 32 204.0 75.0 59.5 134.5 115.0 82.0
40 40, 50 228.0 91.0 80.0 167.0 147.5 94.5
Dimensions in mm
MG = diaphragm size
* CT = A + H1 (see body dimensions)
www.gemu-group.com16 / 47GEMÜ R629 eSyLite
8 Dimensions

8.2 Actuator dimensions with distance piece
B3
B1
B2
A
CT*
A1
B
MG A A1 B B1 B2 B3
50 265.0 129.0 80.0 167.0 147.5 94.5
Dimensions in mm
MG = diaphragm size
* CT = A + H1 (see body dimensions)
MG 50 with metal distance piece
GEMÜ R629 eSyLitewww.gemu-group.com 17 / 47
8 Dimensions

8.3 Actuator dimensions with GEMÜ 1215 position indicator
A
AZ1
BZ2
AZ2
BZ1
MG A AZ1 AZ2 BZ1 BZ2
10 237.0 72.0 61.0 30.0 40.0
20 240.0 72.0 61.0 30.0 40.0
25 249.0 72.0 61.0 30.0 40.0
40 273.0 72.0 61.0 30.0 40.0
50 310.0 72.0 61.0 30.0 40.0
Dimensions in mm
MG = diaphragm size
MG 50 with metal distance piece
www.gemu-group.com18 / 47GEMÜ R629 eSyLite
8 Dimensions

8.4 Actuator dimensions with GEMÜ 1235 position indicator
A
AZ1
BZ2
BZ1
AZ2
MG A AZ1 AZ1 øBZ1 BZ2
10 257.0 92.0 45.0 60.0 40.5
20 260.0 92.0 45.0 60.0 40.5
25 269.0 92.0 45.0 60.0 40.5
40 293.0 92.0 45.0 60.0 40.5
50 330.0 92.0 45.0 60.0 40.5
Dimensions in mm
MG = diaphragm size
MG 50 with metal distance piece
GEMÜ R629 eSyLitewww.gemu-group.com 19 / 47
8 Dimensions

8.5 Body dimensions
8.5.1 Spigot DIN/inch (code 0, 30)
L
c
Ød
H1
H
Connection type spigot DIN (code 0) 1), body material PVC-U (code 1), PP (code 5), PVDF (code 20), inliner/outliner (code 71,
75) 2)
MG DN NPS c ød H H1 L
Material Material
1 5, 20 71, 75 1 5, 20 71, 75
20 15 1/2" 16.0 - 18.0 20.0 36.0 - 36.0 10.0 124.0
20 3/4" 19.0 - 19.0 25.0 38.0 - 38.0 12.0 144.0
25 1" 22.0 - 22.0 32.0 39.0 - 39.0 13.0 154.0
25 32 1¼" 32.0 - 32.0 40.0 41.0 - 41.0 15.0 174.0
40 40 1½" 35.0 - 26.0 50.0 63.2 - 63.2 23.2 194.0
50 2" 38.0 - 33.0 63.0 63.2 - 63.2 23.2 224.0
50 65 2½" 46.0 46.0 - 75.0 78.8 78.8 - 38.8 284.0
Connection type spigot - inch (code 30) 1), body material PVC-U (code 1), ABS (code 4) 2)
MG DN NPS c ød H H1 L
20 15 1/2" 24.0 21.4 36.0 10.0 141.0
20 3/4" 27.0 26.7 38.0 12.0 144.0
25 1" 30.0 33.6 39.0 13.0 154.0
25 32 1¼" 33.0 42.2 41.0 15.0 174.0
40 40 1½" 35.0 48.3 63.2 23.2 194.0
50 2" 40.0 60.3 63.2 23.2 224.0
50 65 2½" 46.0 73.0 78.8 38.8 284.0
Dimensions in mm
MG = diaphragm size
1) Connection type
Code 0: Spigot DIN
Code 30: Spigot – inch, for welding or solvent cementing, depending on the body material
2) Valve body material
Code 1: PVC-U, grey
Code 4: ABS
Code 5: PP, reinforced
Code 20: PVDF
Code 71: Inliner PP-H, grey, outliner PP, reinforced
Code 75: Inliner PVDF/outliner PP, reinforced
www.gemu-group.com20 / 47GEMÜ R629 eSyLite
8 Dimensions
