iThe sun sensor can also be commissioned with the eNet server as an alternative to the
commissioning described here. When commissioning with the eNet server, the sun sensor
should be attached in a light place in order to prevent it from switching off due to low
voltage during programming over a longer period of time.
The sun sensor is commissioned in two steps. In the first step, the required actuators are
connected with the Sun protection or Twilight scenes (see Connection scenes to radio
actuators). In the second step, switching or dimming positions or blind positions are assigned in
the actuators (see Saving scene values in the actuator).
Connecting scenes with radio actuators
oSwitch all the actuators to be connected with the scene to programming mode (see
actuator instructions).
oPress the Prog button for approx. 4 seconds.
The sun sensor is in programming mode for approx. 1 minute. The Status LED flashes.
oBriefly press the scene button Sun protection 3 (5) or Twilight 2 (4).
The scene is connected to the actuators. The Status LEDs of the transmitter and actuators
light up for a few seconds. The sun sensor and actuators exit the programming mode
automatically.
iUp to 10 actuators can be connected to a radio transmitter in a single step.
iWhen the status LED switches to triple flashing for about 5 seconds, the operation was not
successful and must be repeated.
Saving scene values in the actuator
When actuators have been connected to the scenes, switching or dimming values or, in the
case of blinds/shutters, positions, must be allocated to each actuator.
The presetting for blinds/shutters is the bottom end position.
Actuators are connected to the scene.
iWith shutter actuators, the actual shutter movement time must be saved (see shutter
actuator instructions), otherwise scenes will not be opened.
oSet the lighting or blind/shutter positions.
oPress the 2 button (4) or the 3 button (5) for longer than 4 seconds.
The set values are saved to the actuators.
Disconnecting connections to radio actuators
oCarry out the same steps as when connecting (see Connecting scenes to radio actuators).
The connection to the radio actuators is disconnected. The LED on the sensor lights up for
a few seconds and the LED of the actuator flashes quickly for approx. 5 seconds.
The sun sensor and actuators exit the programming mode automatically.
iWhen the status LED switches to triple flashing for about 5 seconds, the operation was not
successful and must be repeated.
Resetting scene to the default setting
All the connections of the scene to actuators are disconnected.
iThe connections in the actuators are preserved and must be deleted separately.
oPress the Prog (3) button for at least 20 seconds.
The status LED flashes after 4 seconds. After 20 seconds the status LED flashes faster.
oBriefly press the 2 or 3 button within 10 seconds.
The Status LED flashes briefly. The scene is reset to default setting.
Resetting the device to the factory setting
All the connections to actuators are disconnected.
iThe connections in the actuators are preserved and must be deleted separately.
oPress the Prog (3) button for at least 20 seconds.
The status LED flashes after 4 seconds. After 20 seconds the status LED flashes faster.
