Blake Cube Storage - Long Shelf Unit
13/11/2020
V1
two-person job
A few important pointers before you start:
• Please read the instructions right through before you start, and check
that all the components have been included in the pack; we nd
separating all the hardware into piles makes it easier to be sure that
everything is present and correct.
• Make sure you have the right tools.Allen keys are provided if required,
but screw drivers and other tools are not. You’ll nd details of the tools
you need at the beginning of the instructions.
• Do not throw away any packing materials until assembly is complete,
just in case you accidentally discard smaller parts or hardware.
Thank you for shopping with GLTC, we hope you enjoy
having this product in your home.
We know assembling furniture, toys or accessories is not everyone’s
favourite way to spend their time, so we’ve tried to make assembling
this item as quick and painless as possible.
Hopefully our efforts will have been worthwhile and you’ll sail
through the whole process. But if it all feels a bit too much
like hard work, then we do have an assembly company we
can recommend: the Flatpack Construction Company offers a
nationwide service and can be contacted on 0843 289 4951 or
www.atpackconstruction.co.uk.
Assembly Difculty
easy - medium - hard

2
Safety Warnings:
• PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
• Adult assembly required.
• CHOKING HAZARD - Unassembled product contains small parts
which may present a choking hazard to children under 3 years old.
• Children should be kept away from the product during assembly to
avoid any possible risk of injury.
• Assemble and use on a at and level surface.
• This product is heavy, so we recommend that you build it where you
are planning to use it.
• DO NOT use power tools in the assembly of this product as there is a
risk of over-tightening and consequently splitting of the wood.
• Cam dowels are used in the assembly of this unit.There is a natural
stopping point when turning, do not over-tighten.
• To avoid possible injury from tipping, DO NOT allow children to climb
on this product.
• Serious or fatal crushing injuries can occur from furniture tipping over.
Ensure you secure this furniture product to the wall before you use it
using the kit provided. If you have not received an anti-tip kit with your
product please contact Customer Services.
• Always use the wall straps provided.
• Check all xtures and ttings regularly and tighten as necessary.
Customer Service:
• If you nd that any components are missing or damaged, please do
not begin assembly and do not use the item. Please contact GLTC
Customer Services on 0344 848 6000 immediately.
• We do stock spare hardware packs at our warehouse, so we should be
able to send you a replacement pack immediately if required.
Product Care:
• Wipe clean using a soft damp cloth followed by a dry cloth.
• Do NOT use cleaning products which contain ammonia, solvents or
abrasive material.
• Do NOT expose the item to extremes of heat and humidity.
Could we do better?
If there is anything you think could be improved in these instructions or in
the assembly of this product we’d be grateful if you could let us know; we’ll
pass any helpful hints and tips on to other customers via our website and
update the instructions.
All you need to do is drop us a line at [e-mail]
Thank you

3
A B
C D
E F
G H
I
K L
J
1x Shelf Panel 1x Central Vertical Panel
2x Vertical Divider Panels
1x Side Panel
1x Upper Back Panel
2x Side Skirting Bars
1x Lower Back Panel
2x Long Skirting Bars 5x Feet
#1 #2
#3 #4
#5 #6
#7
#9
#8
#10
14x Cam Dowels 14x Cam Locks
28x Wooden Dowels (20mm) 10x Barrel Nuts
10x Cross-head Bolt (47mm)
18x Back Panel Screws
5x Hex Bolts (42mm)
5x Wooden Dowels (25mm) 1x Anti-tip Kit
14x Wood Screws (25mm)
1x Allen key
You will need
(not supplied)
Philips Head Screwdriver
1x Side Panel
1x Base Panel
1x Top Panel
Component Check List Hardware Check List

4
STEP 2:
Slot in vertical divider panel B, making sure the smaller drill holes on the end
of the panel are positioned at the base end (the side near the protruding
hardware) and the larger drill holes are at the top.
Note: The holes are visible on the other side of the panel.
Hardware for Step 1:
4x #1 Cam Dowels
STEP 1:
Working on a protective surface like a carpet or
rug, you will be building this unit with the back
facing up.
Take the shelf panel A and position it as shown,
with the small pilot holes along the edge facing
upwards and the drill holes on the shelf itself
facing down towards the base of the unit. Insert
4x cam dowels (#1) as shown.
*Please note: These drill holes on the
edge of panel A are to be facing up.
#1
#1
#1
#1
A
A
B
BASE
BASE
TOP
TOP

5
STEP 4:
Prepare both side panels (D & E) by inserting 2x cam dowels (#1) into the holes
shown on BOTH panels.
STEP 3:
Insert 4x 20mm wooden dowels (#3) into the holes next to the 2 sets of metal
hardware on panel A.
Position 2x smaller divider panels C over the xed hardware and the wooden
dowels as shown, again ensuring that the smaller holes are at the base of the
unit.
Push the panels into place and insert 4x cam locks (#2) into the large drill
holes of the divider panels C and turn clockwise to secure.
Hardware for Step 3:
4x #2 Cam Locks
4x #3 Wooden Dowels
(20mm)
#2
#2
#2
#2
#3
#3
#3
#3
B
A
C
C
Hardware for Step 4:
4x #1 Cam Dowels
BASE
BASE
BASE
TOP
TOP
TOP
D
E
#1
#1
#1
#1
Using Cam Locks:
When inserting into the
panel, ensure that each cam
lock’s arrow is pointing
towards the drill hole on
the side edge of the panel
& the dowel that it will be
receiving.
When the panels are in the
connected position, using a
screwdriver, turn the cam
lock in a clockwise direction
to lock and secure.

6
STEP 5:
Insert 2x 20mm wooden dowels (#3) into the
holes next to the metal hardware on side panel D.
Orientate side panel D with the smaller drill
holes positioned at the base of the panel and the
grooved edge facing upwards.
Align the hardware with the holes on the edge of
panel A and connect to the unit as shown. When
in place, insert 2x cam locks (#2) into the large
drill holes of the shelf panel and turn clockwise to
secure.
STEP 6:
Insert 2x 20mm wooden dowels (#3) into the
holes next to the metal hardware on side panel E.
Orientate side panel E with the smaller drill
holes positioned at the base of the panel and the
grooved edge facing upwards.
Align the hardware with the holes on the
remaining edge of panel A and connect to the unit
as shown. When in place, insert 2x cam locks (#2)
into the large drill holes of the shelf panel and
turn clockwise to secure.
#4
#8
#2
Hardware for Step 5: Hardware for Step 6:
2x #3 Wooden Dowels
(20mm)
2x #3 Wooden Dowels
(20mm)
2x #2 Cam Locks 2x #2 Cam Locks
BASE
BASE
TOP TOP
D A
#2
#2
#3
#3
E
#3
#3 #2
A

7
STEP 7:
Prepare top panel G by inserting 6x cam dowels
(#1) into the outer holes as shown.
STEP 8:
Insert 6x 20mm wooden dowels (#3) into the
holes next to the metal hardware on top panel G
and bring the panel to the unit.
Align the hardware with the corresponding holes
on panels B, D & E and push together to connect.
When in place, insert 6x cam locks (#2) into
the large drill holes on panels B, D & E and turn
clockwise to secure.
Hardware for Step 7: Hardware for Step 8:
6x #1 Cam Dowels
6x #2 Cam Locks
6x #3 Wooden Dowels
(20mm)
#3
#2
#2
#2
#2
#2
#2
#3
#3
#3
#3
#3
G
B
D
E
#1
#1
#1
G
#1
#1
#1
TOP TOP
BASE
BASE

8
STEP 9:
Take base panel F and position with the multi-drilled side
face up as shown.
Attach the 2x side skirting bars (J) to panel F using 4x
25mm wood screws (#8) in the position shown. The
recessed holes on the bars should be facing up.
When in place, attach the central foot (L) to panel F. Turn
panel F on its side to do this and position the foot using
1x 25mm wooden dowel (#9), then insert 1x hex bolt
(#5) into the foot from the other side of panel F. Tighten
fully.
Hardware for Step 9: Hardware for Step 11:
1x #5 Hex Bolts (42mm) 10x #3 Wooden Dowels
(20mm)
1x #9 Wooden Dowels
(25mm) 10x #7 Cross-head Bolt
(47mm)
4x #8 Wood Screws
(25mm) 10x #4 Barrel Nuts
L
F
J
J
#9
#8
#8
#8
#8
#8
#8
#8 #8
#8
#5
BASE
TOP
#8
#8
#8
#8
#3
#3
#3
#3
#8 K
K
F
STEP 10:
Return base panel F to be at on the oor and
attach the long skirting bars (K) to the base panel.
Position the bars along the edges of the base using
2x 20mm wooden dowels (#3) for EACH bar, then
x in place using 5x 25mm wood screws (#8) for
EACH bar. Tighten fully.
Note:The recessed holes on the bars should be
facing up.
Hardware for Step 10:
10x #8 Wood Screws
(25mm)
4x #3 Wooden Dowels
(20mm)
TOP
BASE
STEP 11:
Attach base panel F to the unit.
Start by inserting 10x 20mm wooden dowels (#3) into
the two inner holes of the open edges of panels B,
2xC, D & E.
Now insert 10x barrel nuts (#4) into the holes on
the sides of panels B, 2xC, D & E. Ensure the holes in
the nut are pointing towards the edge where the base
panel is joining.
With the grooved edge of the base panel facing up,
align base panel F with the wooden dowels on the built
unit and push into place.
Now insert 10x cross-head bolts (#7) into the holes as
shown. Fully tighten to secure the base.
D
E
C
B
C
F
#7
#7
#7
#7
#7
#7
#7
#7
#3
#3
#3
#3
#3
#4
#4
#4
#4
#4
#7
#7
2x
2x
2x
2x
2x
2x
2x
2x
2x
2x
*Please Note: The rest of
the feet will be attached later.

9
TOP
TOP
BASE
BASE
D
L
L
L
L
E
#5 #9 #6
#9
#9
#9
#5
STEP 12:
Finish attaching the feet (L) to the base unit.
Each foot uses 1x 25mm wooden dowel (#9) to
position it and is then xed in place with 1x hex
bolt (#5).
Complete step with all 4 remaining feet.
STEP 13:
Align and attach the back panels H & I using 18x
back panel screws (#6).
Please note that the 2x pilot holes indicated at the
top of the side of the unit are to attach anti-tip
straps included separately with this item. Please
see next step.
Hardware for Step 12: Hardware for Step 13:
4x #5 Hex Bolts (42mm) 18x #6 Back Panel Screws
4x #9 Wooden Dowels (25mm)
H
F
I
#6 #6
#6
#6
#6
#6 #6
#6
#6
#6
#6
#6
#6
#6
#6
#6

10
Copyright© 2021 G.L.T.C. Ltd.All rights reserved.
Great Little Trading Company and GLTC are registered trade marks of G.L.T.C. Limited.
#10
#10
#10
STEP 14:
Finally, open the anti tip kit included with your
unit and attach 2 of the brackets to the unit using
the screws in the kit in the position shown.
Your unit is now ready to be attached to the wall
using hardware suitable for the wall type in your
home (not provided). Please see kit instructions
for details.
Hardware for Step 14:
1x #10 Anti-tip Kit
